7.4 LIST OF ERROR CODES FROM CONTROL SOFTWARE
ERRO NO./DISPLAY
1. Heater
2. Sensor
3. Overheating
4. COM Port
11. Connection
12. Cup chute
13. Sample cup retrieval
21.Cryo-trap Temperature
CAUSE
Heater not powered
Abnormal input from sensor
Overheated.
USB cable contact failure
Connection failure to
Auto-Shot Sampler
Cup chute not attached to the
Auto-Shot Sampler.
Sample cups not properly
retrieved.
MJT sensor not properly
cooled.
7-6
SOLUTION/CHECK POINTS
Check to see if the cable from the pyrolyzer is
properly connected to the POWER connector
located on the rear of controller.
[Furnace or Interface]
Make sure the cable from the pyrolyzer is
properly connected to the SENSOR connector
located on the rear of the controller.
[Cryo-Trap]
Ensure that the temperature sensor connector
is short-circuited when MicroJet Cryo-Trap is
not used.
Make sure the cable from the pyrolyzer is
properly connected to the SENSOR connector
located on rear of the controller.
If this does not resolve the problem, it may be
heater failure (Furnace or Interface). Or it may
be a cooling fan failure (Sample cup stand by
position). Contact your nearest sales office.
Re-seat the USB cable at the PC
(1) Ensure that the cable from Auto-Shot
Sampler is properly connected to RS-232C
connector on the rear of the controller.
(2) Make sure the Auto-Shot Sampler is
powered on.
Properly attach cup chute to Auto-Shot
Sampler.
(1) Make sure supply pressure of gas reservoir
is 300 kPa – 500 kPa.
(2) Ensure that the valve control cable from the
gas reservoir is properly connected to the rear
of the Auto-Shot Sampler.
(3) Make sure sample cups are not deformed.
(1) While the thermal exchange coil is at room
temperature, make sure the pressure is 250 –
300 kPa when Cooling is turned ON.
(2) Make sure there is ample amount of liquid
nitrogen.
