- Page 1 Megatherm wood-pellet burner MPB serie's Wood pellet burners MPB 60 & MPB 80 Installation & User Manual This manual is for the Installer. Read, understand, and follow these instructions for safe installation and operation.
-
Page 2: Table Of Contents
Burner's safety systems ............. Errors ..................Electrical diagram ..............Warranty .................. MPB Wood Pellet Burner Installation Manual - January 2018 - Version 4 Megatherm rreserves the right to change part or parts of this manual at any time without prior notice... -
Page 3: Warnings, Cautions, And Notes
Megatherm wood-pellet burner MPB serie's Warnings, Cautions, and Notes Read the safety instructions carefully before Installation, operation, service, and other installation. Always follow the safety work must be carried out by qualified instructions during installation and during personnel in accordance with local codes and maintenance regulations. -
Page 4: The Principle Of Working
Mega MPB s The principle of working The burner's operation is based on providing fuel via controlling the feeder appropriately and also the air fan which steers the burning process. After reaching a particular temperature of the heating water, the burner goes into the mode of maintaining the temperature or switches the burner completely off. -
Page 5: Boiler
Megatherm wood-pellet burner MPB serie's Boiler It is important to check that the combustion chamber in the boiler is big enough to ensure that the flame does not come in contact with the water-cooled walls. Verify that the boiler’s capacity range complies with the burner. There must be enough space for the ash to accumulate. -
Page 6: Unpacking And Installing The Burner
Megatherm wood-pellet burner MPB serie's Unpacking and installing MPB pellet burner 6.1 Unpacking It is included in the box: Burner MPB 60 or MPB 80 ✔ Electronic controller ✔ Elbow metal pipe ✔ Plastic flexible pipe Φ60 ✔ Gasket (white insluation flange) ✔... -
Page 7: Description Of The Controller
Megatherm wood-pellet burner MPB serie's Description of the controller Description: Diodes signalising the status of outputs and the working mode of the driver, LCD screen used for communication between the device and the user, Buttons steering the driver's work. DESCRIPTION OF BUTTONS: Πλήκτρο... - Page 8 Megatherm wood-pellet burner MPB serie's TECHNICAL CHARACTERISTICS OF THE CONTROLLER Sensors: KTY-210 Measurement range: 0 – 120 °C Measurement resolution: 0.1 °C Time of measurements: Data's reading: LCD screen 2x20 signs Steering outputs: Igniter: ~230V 2A (0.8A) • Feeder: ~230V 2A (0.8A) •...
-
Page 9: Operation Functions
Megatherm wood-pellet burner MPB serie's Operation functions After switching the burner on, it is appeared on the LCD screen the program's logo • defining the type of the driver and the version of the current software PELLETS DRIVER ** REG-03/G v4.0 **... - Page 10 Megatherm wood-pellet burner MPB serie's In the table beneath a short description of particular functions of the burner, activated depending on the working mode of the driver, is shown. FUNCTION'S DESCRIPTION OF FUNCTIONS NAME STOP Burner stopped. Filling the feeder.
-
Page 11: Parameter's
Megatherm wood-pellet burner MPB serie's Parameter's To move round the menu and to set particular parameters there are four buttons placed on the driver's panel: “MODE/ ”, “MENU/OK”, “+”, “-”. The parameters chosen by the user are divided into four groups: (A) “CH FURNACE SETTINGS”, (B) “WUW BUFFER SETTINGS”, (C) “BURNER SETTINGS”, (D) “DRIVER SETTINGS”. - Page 12 Megatherm wood-pellet burner MPB serie's SELF CLEANING TIME 0-60 BURNER FLAME 0-100 ------- MEASUREMENT ** Burner has 3 modes: continuous mode, single mode and analogue mode. Single mode: The burner reaches the desired “HEATING WATER TEMPERATURE “ and burns off. Then, it starts its operation again when the temperature of the boiler goes down to the temperature “HEATING WATER TEMPERATURE - CH FURNACE HYSTERESIS”.
- Page 13 Megatherm wood-pellet burner MPB serie's (IGNITION) PELLETS DOSE 50 - 500 (IGNITION) FEEDER kg/h 5.0 – 45.0 14.0 PERFORMANCE PELLETS FEEDING seconds 10 - 60 PERIOD OVERFLOW AIR multiplier 0.2 - 2 (WORK) OVERFLOW AIR multiplier 0.2 - 2 (MAINTAIN) FLAME DETECTOR 5 –...
-
Page 14: Manufacturer's Menu
Megatherm wood-pellet burner MPB serie's Manufacturer's menu Activation of Manufacturer's menu In order to activate the manufacturer's settings menu, go to the settings menu of the driver "DRIVER SETTINGS" and sub-menu "ENABLE SERVICE MODE" and with the help of buttons "MENU/OK" and "+" or "-" choose the code 112. Then, press "MODE/ "... - Page 15 Megatherm wood-pellet burner MPB serie's FAN POWER (IGNITION) In this parameter the producer sets the power of the fan during the pellet's ignition. The fan's power is set in the bracket of 5 to 50%. If chimney's draught is over -15Pa, then the parameter stays at 10% If chimney's draught is from 0 to -15Pa, then the parameter must change to 15-20%.
- Page 16 Megatherm wood-pellet burner MPB serie's OVERFLOW PELLETS AIR (MAINTAIN) In this parameter the manufacturer sets the overflow of the air needed to burn the specified amount of the pellet during “Maintain” mode. This parameter should be increased if during the working cycle too low capacity of the fan would be noticed. The overflow of the air is set in the bracket from 0.2 to 4.
- Page 17 Megatherm wood-pellet burner MPB serie's application. E12. IGNITION STABILIZATION When ignition has occurred, the air-fan works for the time, which has been set by this parameter. This operation drives the ignition gases out of the boiler faster. Manufacturer Advise: 30-60sec E13.
-
Page 18: Room Therostat
Megatherm wood-pellet burner MPB serie's 2. When thermostat is OFF, the burner burns off This is mostly suggested for low consumption houses (less than 3.000kg/year) or for connecting with timer. If external control Yes(Manufacturer's settings): 1. When thermostat is ON, the burner works at the maximum power it is set. -
Page 19: First Use
Megatherm wood-pellet burner MPB serie's First use – adjusting the burner's fire Ensure that the installation has been done according to this manual Ensure that the plastic pipe is not connected to burner's feeding pipe Fill the feeder up with wood-pellet, by following the direction of paragraph 16 (Feeder's Filling Procedure). -
Page 20: Stop Of The Burner
Megatherm wood-pellet burner MPB serie's “ignition”. By pressing the button “MODE/ “ changes the operation from “Ignition” to “Automatic”. 4. In “Automatic mode”, starts the operation of the burner. CH temperature WUW temperature CH:39.5 C WUW:23.6 C IGNITION... Burner function 5. -
Page 21: Restart The Burner After An Error
Megatherm wood-pellet burner MPB serie's “ignition”. By pressing the button “MODE/ “ changes the operation from “Ignition” to “Automatic”. ** The frequency of cleaning burner's chamber is depended on wood pellet's quality. If premium pellet is used, It is suggested the burner's chamber to be cleace a week. -
Page 22: Self Cleaning
Megatherm wood-pellet burner MPB serie's 18. Self cleaning system Self cleaning can be activated only when the burner is equipped with an electro- valve and it is connected with an air-compressor. Minimum requirements for air-compressor: 10Lt at 7bar, or 6Lt at 8 bar The installation of self cleaning is very easy. -
Page 23: Errors
wood-pell MPB s 20. Errors Indication Description Solution / 1. The driver starts up relevant emergency CH: !!!!!! WUW: !!!!!!! procedures for every sensor in order to prevent STOP the boiler from working beyond the safe range Malfunction of the water for the installation of the central heating temperature sensors 2. -
Page 24: Electrical Diagram
Megatherm wood-pellet burner MPB serie's 21. Electrical diagram... -
Page 25: Warranty
MPB s 22. Warranty 2-years in metal parts 2-years in electric parts (feeder's motor & air-fan) 2-year in electronic controller No waarranty is given for the heating element (igniter) Megatherm Pellet heating systems Vasilika, Thessaloniki 57006, Greece tel. +30 2396023437 www.megatherm.gr...
