PROGRAMMING INSTRUCTIONS
RTS Motor Programming Instructions

CONTROLLER OVERVIEW

Single-channel Handheld Remote/
Wall Switch
UP
STOP/
I N T E R M E D I -
DOWN
ATE POSITION
FRONT

ADJUSTING THE LIMITS

SETTING AN INTERMEDIATE POSITION (PREFERRED POSITION)

Technical Support: call 800-544-4749 x3 or email technical.support@swfcontract.com
Handheld Remote
Program
Button
BACK
TO CHANGE THE LOWER LIMIT
1. Send the shade to its current lower limit.
2. Press both Up and Down at the same time until the
3. Press My or Stop until the shade jogs.
TO CHANGE THE UPPER LIMIT
1. Send the shade to its current upper limit.
2. Press both Up and Down at the same time until the
3. Press My or Stop until the shade jogs.
SETTING
1. Press the Up and Down to operate shade. At the desired
2. Once the desired intermediate position is reached,
USING
1. Send the shade to the intermediate position by pressing
Wall Switch
Use
paper clip,
required
to program
button
Program
O P
S T
Button
FRONT
shade jogs. Adjust to a new lower limit position.
shade jogs. Adjust to a new upper limit position.
intermediate (preferred) position press My or Stop to
stop the shade.
press and hold My or Stop until the shade jogs.
My or Stop from ANY shade position.
Note: Shade needs to be stationary prior to activating
intermediate position function.
Multichannel Handheld Remote/
Wall Switch
Lights
indicate
Channel
selected
Selector
channel
FRONT
S19002.37_RTS Solar Motors Programming Guide
1
