Furniture of America CM2906CH-VN Assembly Instructions

For more information contact our team: service.ec@foagroup.com

ASSEMBLY RATING

The Assembly Rating is a 5-point system that

shows the degree of effort needed in

assembling a specific product (with 1 being

easy and 5 being difficult). For some

products, two persons are recommended.

EASY

Assembly Instructions

CM2906CH-VN

DIFFICULT

Tools Required For Assembly:

2 PERSONS RECOMMENDED

Page 1 of 5

Rev: 19-01-16

Table of Contents

Do you have a question about the CM2906CH-VN and is the answer not in the manual?

Page 1 Assembly Instructions For more information contact our team: service.ec@foagroup.com CM2906CH-VN ASSEMBLY RATING Tools Required For Assembly: The Assembly Rating is a 5-point system that shows the degree of effort needed in assembling a specific product (with 1 being easy and 5 being difficult). For some products, two persons are recommended.
Page 2 LOOSEN OVER TIME AND MAY CAUSE THE FURNITURE TO BE WOBBLY AND UNABLE TO SUPPORT ITS INTENDED WEIGHT CAPACITY. THIS MAY LEAD TO COLLAPSE AND MAY CAUSE SERIOUS INJURY. FAILURE TO FOLLOW THE GUIDELINES ABOVE MAY RESULT IN INJURY AND/OR PROPERTY DAMAGE. FURNITURE OF AMERICA.ALL RIGHTS RESERVED. Page 2 of 5...
Page 3 Before you begin, please read Page 2 of "Assembly and Care Advice". And remember, do not tighten until each step is completed or instructed. #A x 1pc #1 x 1pc Chair Front Leg #B x 2pcs Leg Ø50 x 6-1/2" #E x 2pcs Screw Ø6 x 15mm #C x 2pcs...
Page 4 1) Align front leg (#A) to the sofa (#1), 2) Align front leg supports (#C) to the front leg then secure by using bolts (#F,G). (#A), then secure by using bolts (#D,E). #A x 1pc #C x 2pcs #D x 2pcs #E x 2pcs #F x 2pcs #G x 6pcs...
Page 5 ASSEMBLY IS COMPLETED Page 5 of 5...
