Genesis Multiple G9F18 AU000 Quick Start Manual

Electronic Installation Instructions
If this is a printed copy of the installation instructions, ensure you have the latest revision by
scanning the QR code or by entering the website address listed below before beginning
installation. Use the latest revision date as noted by "Rev. Date" above.
Application Notes
This product is intended for use on carpeted surfaces only, view application chart on Page 3.
Instructional Symbols / Definitions
Denotes warnings that may lead to
serious physical injury or vehicle damage
Denotes cautions to be taken to avoid
physical injury or electronic component
damage
Denotes cautions to be taken to avoid
vehicle and component damage
Basic Required Tools
None
Part Weight (Gross)
0.40
lbs
0.18
kg
Notes to the Installer:
1) Read the entire Installation Instructions prior to beginning the installation of this accessory.
If applicable, scan the barcode label located on the accessory part or packaging prior to installing, to register the part. If this accessory is installed as a
2)
replacement, register the removal of the old part before registering the new part. Old and new parts will have different barcode data, and the old
registration cannot be reused.
3) Make sure the vehicle is completely clean and dry in the area(s) the part is to be installed.
4) Ensure the vehicle is properly protected in the area(s) that the accessory is to be installed.
5) NEVER place tools on painted surfaces, seating surfaces, dash pad, console or floor carpet/mats.
6) Always wear appropriate personal protective equipment, including gloves, safety glasses, etc, when required.
Kit Overview
No. Qty Description
1 4 Cargo Blocks
2 1 Quick Reference Guide
ISHY025
Genuine Accessories
Vehicle Model: Multiple
Model Year Multiple
Part No. G9F18 AU000
Language English
Rev. Date 4/7/2022
www.genesisaccessories.com/installation_sheets/g9f18_au000.pdf
N
O
T
E
FMVSS 110 Compliance Information
All dealers must determine if the Net weight they have added in the form of all options or accessories, when added to the weight of all Port/Dealer Installed
options or accessories, exceeds the lesser of 1.5% of GVWR or 100 lbs. If the additional weight does exceed the lesser of the indicated thresholds, a "Load
Carrying Capacity Reduced" label must be installed. A black, fine-point, indelible marker must be used to write by hand onto the label, the reduced carrying
capacity in kilograms or pounds, which is the total weight of all added options and accessories.
Load Label Part Number: NP070 - 09003
1
Accessory:
Denotes quality processes to be checked
prior to moving to the next step
Denotes specific tools that are necessary
to complete a step
Denotes important information to be
reviewed during the step
2
Revision Date
04/07/2022
Cargo Blocks
Difficulty: ( A )
Difficulty stated above reflects the minimum level of
Note:
expertise required to install the accessory:
(A) Customer
(B) Dealer Technician
(C) Master Technician or Specialist
Denotes personal protective equipment (PPEs) that
may be required for a step. Examples of safety
equipment icons noted below:
Glasses
Mask Hearing Protection
Gloves
Page 1 of 3
