- Page 1 DESHUMIDIFIER MH-N User and installation manual MH-60-N MH-80-N HU10509 HU10511 English www.mundoclima.com...
-
Page 3: Safety Information
SAFETY INFORMATION Please read the operating instructions carefully before using your dehumidifier for the first time and keep them in a safe place. Never immerse the appliance in water or other liquids. Never operate the appliance if a cable or connector has been damaged, after appliance malfunction or if the appliance was dropped or otherwise damaged. - Page 4 OPERATING INSTRUCTIONS 1. Control panel 2. Air outlet 3. Handle 4. Front panel 5. Back panel 6. Water out hole 7. Water tank...
-
Page 5: Starting The Unit
CONTROL PLATE DESCRIPTION OPERATION INSTRUCTION Starting the unit 1. Firstly, turn the humidity control switch to the “OFF” position. 2. Plug in the dehumidifier. 3. Turn on the humidity control switch(to right side) and turn the same switch to the reading of the desired humidity(60% in general as shown on position”4”). -
Page 6: Drainage Instruction
CONTROL SWITCH APPROXIMATE POSITION NO. HUMIDITY SETTING 20﹪ 30﹪ 40﹪ 60﹪ 80﹪ °C 5. The operational temperature range for this unit is 5-32 6. If the dehumidifier does not start (the operational light does not illuminate) or the dehumidifier makes intermediate stop on unknown reasons, please check the plug and power supply for poor connection. -
Page 7: Continuous Drainage
USE OF WATER TANK: When the water full indicator illuminates, the tank is full, and the compressor and the fan will stop operation, please empty the water tank: 1. Remove the water tank as Fig 01. and empty it. 2. Insert gently the water tank into the unit reach to its original position. -
Page 8: Maintenance Instruction
Maintenance Instruction 1. The unit is not allow to be located on the floor of soft and uneven surface when the unit is in operation to avoid occurrence of vibration and noise. 2. Never insert any slim rod and hard object into the unit body to avoid occurrence of hazard or unit failure. -
Page 9: Specifications
SPECIFICATIONS MODEL MH-60-N MH-80-N SPECIFICATION POWER SOURCE 220-240V~50Hz RATED POWER 1150W 1350W INPUT(EN60335) RUNNING CURRENT 5.1A 6.2A 22,5Kg 23Kg NET WEIGHT MOISTURE REMOVAL 60 L/day 80 L/day ( 30℃ RH 80%) DIMENSION (W x D x H) 481 x 286 x 628mm 5℃-32 ℃... - Page 10 ASK FOR MORE INFORMATION Phone: (+34) 93 446 27 81 eMail: info@mundoclima.com TECHNICAL ASSISTANCE Phone: (+34) 93 652 53 57 www.mundoclima.com...
