- Page 1 Original Instruction Manual RPB8 8” Buffing Machine 71800 Version 3.1 May 2021 To register this product please visit www.recordpower.info It is important to register your product as soon as possible in order to receive efficient after sales support and be entitled to the full 5 year guarantee. Your statutory rights are not affected.
-
Page 2: Table Of Contents
Contents Explanation of Symbols General Health and Safety Guidance Additional Health and Safety Guidance for Buffing Machines Record Power Guarantee Specifications Contents of the Package Assembly Operation Maintenance 10 Dust Extraction 11 Troubleshooting 12 Electrical Connection and Wiring Diagram 13 Parts List and Diagram... -
Page 3: Explanation Of Symbols
1. Explanation of Symbols THE SYMBOLS AND THEIR MEANINGS SHOWN BELOW MAY BE USED THROUGHOUT THIS MANUAL. PLEASE ENSURE THAT YOU TAKE THE APPROPRIATE ACTION WHEREVER THE WARNINGS ARE USED. Mandatory Instructions Read and fully understand the instruction manual before attempting to use the machine. Indicates an instruction that requires particular attention Wear protective eyewear Use respiratory protective equipment... -
Page 4: General Health And Safety Guidance
2. General Health and Safety Guidance Ensure that you carefully read and fully understand the 6. The machine should be level and stable at all times instructions in this manual before assembly, installation and use • When using a leg stand or cabinet base that is designed to be fitted to of this product. - Page 5 2. General Health and Safety Guidance stop. enough to tip when not held down to the table top. • If the work area is to be left unattended, all machinery should be • Do not use another person as a substitute for a table extension, or as switched ‘OFF’...
- Page 6 2. General Health and Safety Guidance 32. Have your machine repaired by a qualified person intended function. • This machine complies with the relevant safety rules and standards • Check for alignment of moving parts, binding of moving parts, breakage appropriate to its type when used in accordance with these instructions of parts and any other conditions that may affect the operation of the and with all of the standard safety guards and equipment in place.
-
Page 7: Additional Health And Safety Guidance For Buffing Machines
3. Additional Health and Safety Guidance for Buffing Machines 1. Safe Operation • The buffing machine should always be level and stable. • Never attempt to lift the buffing machine while the wheels are in motion – the centrifugal force created can cause the machine to be unstable and could cause serious personal injury. -
Page 8: Record Power Guarantee
Guarantee guarantee must be reported to the Authorised Dealer from which it Record Power guarantees that for a period of 5 years from the date was purchased within 48 hours of receipt. of purchase the components of qualifying Products (see clauses 1.2.1 to 1.2.9) will be free from defects caused by faulty construction or... -
Page 9: Specifications
5. Specifications Wheel size: 200 mm Wheel bore: 15.9 mm Motor input P1: 300 W Motor output P2: 160 W Speed: 1490 rpm Voltage: 230-240 V Frequency: 50 Hz Full load current: 1.5 A Weight: 10 kg Shaft diameter: 15.9 mm 6. -
Page 10: Assembly
7. Assembly Fig 8.1 Before switching the machine ON ensure that the machine is fixed to the work bench. There are two holes located in the base of the machine to secure in place, do not over tighten any fixings as this could cause vibration. -
Page 11: Operation
8. Operation Fig 9.1 The buffing wheels are designed to achieve a high level of finish, together with the required buffing compound. Using your Buffing Machine. When buffing, items must be held below the centre line of the wheel, as this reduces the likelihood of loss of grip, Fig 9.1. -
Page 12: Maintenance
9. Maintenance Before starting a new buffing machine, it is recommended to check the general condition of each wheel and that the nuts are securely fastened. Check that the power cable is in good condition before use. Always keep the machine clean by clearing any excess ready for next use. Use only the correct sized buffing wheels for the machine, do not attempt to add any other type of wheel to this machine. -
Page 13: Troubleshooting
11. Troubleshooting Warning: For your own safety, always turn off and unplug the machine before carrying out any troubleshooting. Problem Cause Solution Machine will not start. 1. Power cord not connected. 1. Check that the cord is plugged into machine. 2. -
Page 14: Electrical Connection And Wiring Diagram
12. Electrical Connection and Wiring Diagram Machines supplied for use in the UK are fitted with a 3 pin plug conforming fitted with a fuse conforming to BS1362 appropriate to the rating of the to BS1363, fitted with a fuse conforming to BS1362 and appropriate to the machine. -
Page 15: Parts List And Diagram
13. Parts List and Diagram Buffing Machine Description Quantity Description Quantity L/H M16 nut Cable grommet Flange washer Switch Buffing wheel Screw M4 x 8 Spacer collar Switch cover Screw M5 x 200 Base End cap M8 nut Spring washer Capacitor bracket Bearing Capacitor... - Page 16 Andrew Greensted Managing Director Technical file held by Andrew Greensted, Record Power Ltd, Centenary House, 11 Midland Way, Barlborough Links, Chesterfield, Derbyshire, S43 4XA, United Kingdom Record Power B.V., Verlengde Poolseweg 16, 4818 CL BREDA, Netherlands, Tel: +31 76 52 44 766...
