Honeywell Fire-Lite Alarms LCD-80F Manual

Remote fire annunciator
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
PN:51338:B
ECN 06-297
Remote Fire Annunciator
LCD-80F
Document 51338
B
08/24/05
Rev:

Advertisement

Table of Contents
loading

Related Manuals for Honeywell Fire-Lite Alarms LCD-80F

Summary of Contents for Honeywell Fire-Lite Alarms LCD-80F

  • Page 1 PN:51338:B ECN 06-297 Remote Fire Annunciator LCD-80F Document 51338 08/24/05 Rev:...
  • Page 2 While a fire alarm system may lower insurance Fire Alarm System Limitations rates, it is not a substitute for fire insurance! An automatic fire alarm system–typically made up of Heat detectors do not sense particles of combustion smoke detectors, heat detectors, manual pull stations, and alarm only when heat on their sensors increases at audible warning devices, and a fire alarm control panel a predetermined rate or reaches a predetermined level.
  • Page 3 Adherence to the following will aid in problem-free Installation Precautions installation with long-term reliability: WARNING - Several different sources of power can be Like all solid state electronic devices, this system connected to the fire alarm control panel. Disconnect may operate erratically or can be damaged when sub- all sources of power before servicing.
  • Page 4 Notes This product has been certified to comply with the requirements in the Standard for Control Units and Accessories for Fire Alarm Systems, UL 864, 9th Edition. Operation of this product with products not tested for UL 864, 9th Edition has not been evaluated. Such operation requires the approval of the local Authority Having Jurisdiction (AHJ).

  • Page 5: Table Of Contents

    Table of Contents Table of Contents Section 1: LCD-80F Annunciator .............6 1.1 Features of LCD-80F ..............7 1.2 Components & Wiring ..............8 1.3 SW1 DIP Switch Settings ...............11 1.4 Typical Configuration ..............14 Section 2: Operation ...................15 2.1 Display Patterns ................15 2.2 Switch Functions ................16 2.2.1 Key-switch ................16 2.2.2 Acknowledge/Step ...............16 2.2.3 Silence ..................17...

  • Page 6: Section 1: Lcd-80F Annunciator

    LCD-80F Annunciator LCD-80F Annunciator Section 1: FIRE ALARM ANNUNCIATOR AC Power Alarm Trouble Supervisory Alm. Silenced Drill Ack/Step Silence Reset Hold 2 sec. The LCD-80F Annunciator is a compact, 80-character, backlit LCD fire annunciator designed for use with compatible FACPs (Fire Alarm Control Panel).

  • Page 7: Features Of Lcd-80F

    LCD-80F Annunciator Features of LCD-80F Features of LCD-80F • 80-character LCD display (20 characters x 4 lines) is backlit under normal and alarm conditions • System Status LEDs for AC Power (green), Alarm (red), Trouble (yellow), Supervisory (yellow) and Alarm Silenced (yellow) •...

  • Page 8: Components & Wiring

    LCD-80F Annunciator Components & Wiring Components & Wiring Figure 1-1: Components OFF = Key-switch Enabled Note: See “DIP Switch Settings ON = Piezo Enable Example” on page 13. OFF = Receive only Panel Configuration Top view Future use SW 1 Piezo Sounder The LCD-80F sounder, if enabled, will be Membrane Connector...
  • Page 9 LCD-80F Annunciator Components & Wiring Figure 1-2: Wiring to Terminals Side view 1 2 3 4 5 6 7 8 Terminal Block replacement P/N 02109 Terminal Block 4 3 2 1 7 6 5 4 3 2 1 replacement P/N 02108 Earth Ground Option -24 VDC OUT -24 VDC IN...
  • Page 10 LCD-80F Annunciator Components & Wiring Figure 1-3: FACP EIA-485 Wiring to LCD-80F LCD-80F - - + + + EIA-485 Out to Next Device - EIA-485 Out to Next Device (or back to FACP) EIA-485 MS-9200UD LCD-80F - - + + + EIA-485 Out to Next Device - EIA-485 Out to Next Device (or back to FACP)

  • Page 11: Sw1 Dip Switch Settings

    LCD-80F Annunciator SW1 DIP Switch Settings SW1 DIP Switch Settings Refer to “DIP Switch Settings Example” on page 13, for an explanation of DIP switch positions. SW1 switch settings follow: 1 -ON = Key-switch disabled, OFF = Key-switch enabled. Switch 1 set to the OFF position enables key-switch operation. The key-switch may now be used to enable the LCD-80F membrane switches, allowing remote switch functions, or lockout the switches, preventing remote switch functions...
  • Page 12 LCD-80F Annunciator SW1 DIP Switch Settings 4 through 6 = Configuration for use with a particular FACP. Switches 4, 5 and 6 are used to select the FACP (Fire Alarm Control Panel) which is being connected to the LCD-80F. Refer to the following table for the appropriate switch settings.
  • Page 13 LCD-80F Annunciator SW1 DIP Switch Settings Figure 1-4: DIP Switch Settings Example switch 1 shown in switches 2 through 8 ON position shown in Off position Note: SW1 DIP switch settings as illustrated in Figure 1-3 are as follows: 1. DIP switch 1: ON = Key-switch disabled (membrane function switches are always enabled with key-switch having no affect on their function).

  • Page 14: Typical Configuration

    LCD-80F Annunciator Typical Configuration Typical Configuration The LCD-80F Annunciator mimics the FACP display, has full point- display capacity and requires no programming. Note that the FACP may require programming to allow communication with the LCD-80F. Refer to the appropriate FACP manual for programming information. The LCD-80F offers multiple annunciator locations with the capability of remote Acknowledge, Signal Silence, Drill and Reset functions.

  • Page 15: Section 2: Operation

    Operation Display Patterns Operation Section 2: Display Patterns The LCD-80F Annunciator directly displays (mimics) the information on the FACP display with the following exceptions: • Upon Power-up, the LCD-80F may display the following message until a valid message is received from the FACP INITIALIZING...

  • Page 16: Switch Functions

    Operation Switch Functions Switch Functions 2.2.1 Key-switch Key-switch (shown in Off position) The key-switch is used to enable and disable the operation of the function switches if switch 1 on DIP switch SW1 has been placed in the OFF position. ATOR To enable the Acknowledge, Silence, Drill and Reset function...

  • Page 17: Silence

    Operation Switch Functions When more than one event exists, the first press of the Acknowledge switch silences system piezo sounders. The second press of the switch stops the scrolling and holds the event on the display for one minute. Subsequent pressing of the switch 'steps' through each active event.

  • Page 18: Led Indicators

    Operation LED Indicators LED Indicators 2.3.1 AC Power This is a green LED which illuminates if AC power is applied to the host FACP. The green LED will turn off if AC power to the host FACP is lost. 2.3.2 Alarm This is a red LED that turns on steady when one or more fire alarms occur.

  • Page 19: Section 3: Mounting

    Mounting Annunciator Preparation Mounting Section 3: Annunciator Preparation The LCD-80F Annunciator can be surface mounted in a three-gang electrical box such as the P/N SBB-3 (2.75" depth) or semi-flush mounted in a three-gang electrical box, P/N 10103 or equivalent, with a minimum depth of 2 3/16".
  • Page 20 Mounting Annunciator Preparation Figure 3-2: Hardware and Backboxes FIRE ALARM ANNUNCIATOR AC Power Alarm Trouble Supervisory Alm. Silenced Drill Ack/Step Silence Reset Hold 2 sec. LCD-80F flange LCD-80F Trim Ring (replacement P/N 23165) 3-Gang Electrical Box P/N 10103 (semi-flush mount) 3-Gang Electrical Box P/N SBB-3 (surface mount) Three Ganged Electrical Boxes...

  • Page 21: Semi-Flush Mount Backbox

    Mounting Semi-flush Mount Backbox Semi-flush Mount Backbox Mounting in SBB-3 Three Gang Electrical Box Remove the plug-in terminal blocks from the LCD-80F circuit board. Connect the EIA-485 and power wiring into the terminal block positions illustrated in Figure 1-2 on page 9, Figure 4-1 on page 24 and Figure 4- 2 on page 25.
  • Page 22 Mounting Semi-flush Mount Backbox Mounting in Three Electrical Boxes Ganged Together Remove the plug-in terminal blocks from the LCD-80F circuit board. Connect the EIA-485 and power wiring into the terminal block positions illustrated in Figure 1-2 on page 9, Figure 4-1 on page 24 and Figure 4- 2 on page 25.

  • Page 23: Surface Mount Backbox

    Mounting Surface Mount Backbox Surface Mount Backbox Remove the plug-in terminal blocks from the LCD-80F circuit board. Connect the EIA-485 and power wiring into the terminal block positions illustrated in Figure 1-2 on page 9, Figure 4-1 on page 24 and Figure 4- 2 on page 25.

  • Page 24: Section 4: Electrical Connections

    Electrical Connections Power Connections Electrical Connections Section 4: Power Connections The LCD-80F Annunciator can be powered by the FACP (refer to the specific technical manual for the proper connection of the LCD-80F) or from a remote UL listed, filtered power supply such as the FCPS-24FS6/8.

  • Page 25: Eia-485 Connections

    Electrical Connections EIA-485 Connections EIA-485 Connections Figure 4-2: EIA-485 Connection 1 2 3 4 5 6 7 8 LCD-80F 4 3 2 1 7 6 5 4 3 2 1 Ferrite Core P/N FBD-1 is required (see note 5) - EIA-485 IN in from FACP + EIA-485 IN Out to next LCD-80F or return to...

  • Page 26: Section 5: Eia-485 Shield Termination

    EIA-485 Shield Termination EIA-485 Connections EIA-485 Shield Termination Section 5: The EIA-485 circuit must be wired using a twisted, shielded pair cable with a characteristic impedance of 120 ohms (+/- 20%). Do not run cable adjacent to or in the same conduit as 120 VAC service, noisy elec- trical circuits that are powering mechanical bells or horns, audio circuits above 25 V , motor control circuits or SCR power circuits.

  • Page 27: Shield Not In Conduit

    EIA-485 Shield Termination Shield Not in Conduit Shield Not in Conduit The EIA-485 line allows the FACP to communicate with the LCD-80F Annunciator. The shield for the EIA-485 line must be connected to earth ground at the FACP but must be left floating (no connection) at the annunciator if it is the first or only device on the EIA-485 line.

  • Page 28: Shield In Full Conduit

    EIA-485 Shield Termination Shield in Full Conduit Shield in Full Conduit The EIA-485 line allows the FACP to communicate with the LCD-80F Annunciator. The shield for the EIA-485 line must be connected to earth ground at the FACP (both exiting and entering the FACP) but must be left floating (no connection) at the annunciator if it is the first or only device on the EIA-485 line.
  • Page 29 Index Numerics 80-character 6, 7 AC loss 7 acknowledge switch 6, 16 Acknowledge/Step switch 7 see also acknowledge switch 16 alarm LED 6, 7, 18 alarm silence switch 7 alarm silenced LED 6, 7, 17, 18 annunciator 6 annunciator, maximum 14 application see also typical configuration 14 backboxes 7, 19...
  • Page 30 earth ground 19 EIA-485 6, 7, 11, 14, 21, 23, 25, 28 shield 26 EIA-485 wiring 25 electrical connections 24 enable/disable 7 see also key-switch 11 FACP compatibility 6 FACP selection 12 Fault 15 FCC Part 15 requirements 25 ferrite core 25 flange 21, 23 function switches 7, 11 see also switch functions 16...
  • Page 31 piezo sounder 7, 8, 11, 16 power for annunciator 6 power LED 6, 7, 18 power requirements 9, 14 power source 24 power-limited 9, 24 programming 7 receive only see also communication 11 receive/transmit see also communication 11 reset switch 6, 7, 16, 17 resound, piezo 7 SBB-3 backbox 19, 21 semi-flush mounting 21...
  • Page 32 three ganged electrical boxes 22 trim ring 19, 20, 21, 22, 23 trouble LED 6, 7, 18 typical configuration 14 wiring 8, 9 conduit 28 distance 25 EIA-485 25 ferrite core 25 no conduit 27 power 24 type 25 wiring requirements 14 Document 51338 Rev B 08/24/05 P/N 51338:B...
  • Page 33 Notes Document 51338 Rev. B 08/24/05 P/N 51338:B...
  • Page 34 Notes Document 51338 Rev. B 08/24/05 P/N 51338:B...
  • Page 35 Limited Warranty The manufacturer warrants products manufactured by it to be free from defects in materials and workmanship for eighteen (18) months from the date of manufacture, under normal use and service. Products are date stamped at time of manufacture. The sole and exclusive obligation of the manufacturer is to repair or replace, at its option, free of charge for parts and labor, any part which is defective in materials or workmanship under normal use and service.
  • Page 36 World Headquarters One Fire-Lite Place, Northford, CT 06472-1653 USA 203-484-7161 • Fax 203-484-7118 www.firelite.com ©2005 by Honeywell International Inc. All rights reserved. Unauthorized use of this document is strictly prohibited.
