  • Page 1 User manual (EN) Full HD H265 Media  Auto Auto Android DLNA 1080p codec Player FastScan DiSEqC TimeShift iOS app friendly Flash Display SPDIF NEW CORE NEW DDRIII MEMORY  NEW FLASH MEMORY COMMON SMARTCARD UNIVERSAL 100 MBit OPTICAL 1GHz 256MB 16MB DISPLAY INTERFACE READER SERIAL PORT ETHERNET OUTPUT HD Digital Satellite Receiver...

  • Page 3: Table Of Contents

    Content ..............Safety Precaution 1. Reference ········································································· 4 1.1 General Features ·························································· 4 1.2 Accessories ································································ 5 2. Product Overview ································································ 6 2.1 Front Panel ································································ 6 2.2 Rear Panel ································································· 7 2.2 Remote Control Unit (RCU) ············································ 8 3. Installation ······································································ 10 3.1 Powering On ····························································...
  • Page 4 6. X-tras ············································································ 26 6.1 Calendar ································································· 26 6.2 Games ···································································· 26 6.3 Network Apps ·························································· 26 7. Multimedia ····································································· 28 7.1 USB ······································································ 28 7.2 Setting ··································································· 29 7.3 Play Files ································································ 30 8. Basic Operation ································································ 34 8.1 Audio ···································································· 34 8.2 Satellite List ·····························································...

  • Page 5: Safety Precaution

    !Safety Precaution This STB has been designed and manufactured to satisfy the international safety standards. Please read the following safety precautions carefully before operating this receiver. 4 Main Supply: Before operating, please check the units operating voltage is 90~250V AC 50/60Hz.

  • Page 6: Reference

    and licensed service personnel to repair the receiver, or contact your dealer. 1. Reference 1.1 General Features DVB-S/DVB-S2 Satellite Compliant (MPEG-II/ MPEG-IV/ H.264) SCPC & MCPC receivable from Ku and C band satellites Universal, Single, Single S & C Band Wideband LNB Sensitive Tuner with Loop-Through DiSEqC1.0/1.1/1.2/1.3 (USALS) Unicable Supported...

  • Page 7: Accessories

    1.2 Accessories l Users manual l Remote Control Unit l Batteries Figure 1.Accessories...

  • Page 8: Product Overview

    2. Product Overview 2.1 Front Panel Figure 2. Front Panel 1. Power LED Power indicator. 2. Signal LED Signal indicator.（delete） 2. Display It displays channel information. In standby mode it displays local time. 3. Power button Switch between operation and standby modes. 4.

  • Page 9: Rear Panel

    2.2 Rear Panel Figure 3. Rear Panel 1. LOOP OUT Connect another receiver. 2. LNB IN Connect the satellite antenna cable. 3. USB2.0 One USB 2.0 Host Port. 4. SPDIF Digital Audio output (Optical). 5. LAN Connect to the internet using an Ethernet cable. 6.

  • Page 10: Remote Control Unit (Rcu)

    2.2 Remote Control Unit (RCU) You can control this receiver by this remote controller with full function. 1. STANDBY: Switch between operation and standby modes. 2. F1: Accessorial function. 3. SHIFT Enable/Disable timeshift. 4. MUTE: Mute audio. 5. I I : Pause/Time shift. 6.
  • Page 11 23. MEDIA : Access to the USB menu. 24. SAT: Show the scanned satellite list. 25. SUB: Display the subtitle language list. 26. TV/RAD: Switch between TV and RADIO. 27. FIND: Quickly find channels which you want. 28. V-FORMAT: Set the screen mode. 29.

  • Page 12: Installation

    3. Installation You should install the receiver when powering on your product for the first time after purchase. Tip: The default password is 0000 . If you have forgotten your password, please contact your local product distributor. 3.1 Powering On 1.
  • Page 13 7. DiSEqC 1.1: Press the ◄/► button to select the required DiSEqC1.1 input. 8. Motor: Press the ◄/► button to select DiSEqC1.2 or USALS. Scan Mode ◄/► : Press the button to select scan mode. 10. Start search: Press the ◄/► button to select Satellite & Multi-Sat & Blind scan &...
  • Page 14 move one satellite from one position to another. ØDelete You can delete the user satellite. Select the satellite that you want to delete from the satellite list. Then press the YELLOW button. You will be asked to confirm whether delete the satellite or not. If you select YES, all the channels and transponders in the selected satellite will be deleted.
  • Page 15 Transponder will disappear. ØEdit Press yellow button to edit. Here you can set the Transponder frequency, polarization, symbol rate and FEC. ØDelete All Press the button. You can delete all the channels and Transponder in the selected satellite will be deleted. 3.1.3 Search Channels from Satellite A: Satellite Search 1.
  • Page 16 button to confirm. D: TP Search 1. Highlight the Satellite and press the OK button to enter satellite list. And then select one satellite you want to search. 2. Complete the antenna setting of this satellite. 3. Highlight the Transponder and press the OK button to enter TP list. And then select one transponder you want search.

  • Page 17: Fast Scan

    Select DiSEqC 1.2 or USALS using the ◄/► button. DiSEqC 1.2: General motor antenna using DiSEqC 1.2. USALS: Motor antenna using USALS. ØMove Auto[W/E] Press ◄/► button, the dish will be motorized to East/West continuously, it will stop until it find the best signal. ØMove west-east Press ◄/►...

  • Page 18: Factory Default

    the 12515 transponders. 3.4 Factory Default You can restore the product to the factory default and you can also setup it according to the wizard. Warning: Please note that once you perform Factory Default all , all data settings will be deleted. 1.

  • Page 19: Channel Manager

    4. Channel Manager : You can press the Sat button to choose different satellite according to the help information, press OK to confirm, then all the channels of this sat will be display. 4.1 Edit Channel Menu->EDIT CHANNEL->TV Channels / Radio Channels Edit Channels enables you to move, delete, rename, lock/unlock, swap the channels in the channel list conveniently.

  • Page 20: Edit Favorite

    1) Highlight the Delete function using ◄/► button or press GREEN button directly. 2) Press the ▲/▼ to highlight the channel you want to delete, press the OK button to sign the channel. 3) Press the EXIT button, here, select Yes will delete the chosen channels. 3.

  • Page 21: Sort Channels

    If you select a favorite list, press the CH+/CH- button can only change the channels in this favorite list and press the OK button can only display the channels in this favorite list. 4.3 Sort Channels You can sort the channels list. Menu->...

  • Page 22: Settings

    5. Settings 5.1 System Settings Menu->SETTINGS->Syste m Settings : You can set all the settings here by pressing ◄ /► button. 1. Menu Language: Set the menu language. 2. Audio1: Set the preferred audio language. 3. Audio2: Set the sub-prime audio language. 4.AD server：You can set on or off.

  • Page 23: Osd Setup

    14. Standby Time: You can set the Standby Time on or off.（delete） 15. PLSN Super Scan：you can set yes or on. 16.Front Panel Light: Set the brightness of the LED. 17. Front Panel Display: Set the LED display channel or clock. 18.

  • Page 24: Times

    previous password. You can also lock the changes you have made using Installation Lock , Edit Channel Lock and System Lock . And you can change Age Rating. 5.4 Times Menu-> SETTINGS ->Times 5.4.1 Time Settings Menu-> SETTINGS ->Times->Time Settings Time Settings will set the time mode, time zone and summer time.
  • Page 25 the timer after setup. Channel Select the Channel from Channel List. Date Input start date of the timer. Start/Stop Set Start and Stop time of the timer. Repeat <1X> only one time. <Day> Repeat every day. <Weekly> Repeat the channel weekly. <1-5>...

  • Page 26: Ca Menu

    5.5 CA Menu You must insert the smart card with gold chip down into CA slot. Menu-> SETTINGS ->CA Menu You can view the information about CA card.（delete） 5.5 CI Menu If you want to watch Pay-TV, then you need a CI module with aappropriate subscription card.

  • Page 27: Usb Update

    RED: Get IP address automatically. GREEN: Test the network if connect correctly. 5.6.2 Connecting to the 3G 1. Plug in the 3G dongle to the USB port. 2. Enter Menu->SETTINGS->3G. 3.selete the access point or set the auto detect on, then you can connect the network.

  • Page 28: X-Tras

    software & hardware version, and serial number and so on. When you need service from the dealer you need to submit this information in order go get the correct and fast after sales service. 6. X-tras 6.1 Calendar Menu->X-tras-> calendar Calendar can get the date information.
  • Page 29 4. According to the prompted information select the file you want to download and press the OK button to download it to USB device. 5. Press the RED button to enter the FTP_DOWNLOAD folder in USB. 6.3.3 Weather Forecast Menu->X-tras ->Network Apps->Weather Here you can input the city name to browse the weather of this city in future 5 days.

  • Page 30: Multimedia

    7. Multimedia Menu->Multimedia or press the MEDIA button directly Multimedia can play many kinds of media files, you can record program playback it and you can do various operations when using USB HDD or USB disk. Note: It supports FAT, FAT32 and NTFS format USB disk or USB HDD. 7.1 USB 1.

  • Page 31: Setting

    Press the OK button to create a new folder in current folder. ØSort 1) Press the RED button and Highlight the Sort. 2) Select the sort type. (First Name/Date/Size) 3) Press the OK button to sort by sort type which you selected. ØFormat Disk 1) Highlight a disk partition or enter a disk partition.

  • Page 32: Play Files

    Set the Slide Show Interval from 2S-10S. ØPhoto View Mode Set the Photo View Mode state on Full Screen, 2x2 Thumbnail or 2x3 Thumbnail. 2. PVR Setting ØRecord Partition Select the Partition where save your record or other result of your operation. ØRecord Mode Set the Record Mode Channel or Transponder.(delete) ØRecord Type...
  • Page 33 2) Press the ▲/▼ to change the folder or file and press the OK button to open the folder or play the music file. OK: Play the selected file. ▲/▼: Change the highlighted item. ►: Play the file. ■ : Stop playing file. I◄◄: Play the previous file.
  • Page 34 3. Movie 1) Press the ◄/► to highlight the Movie. 2) Press the ▲/▼ to change the folder or file and press the OK button to open the folder or play the movie file. OK: View play list or play the highlighted file in the play list. ►: Play the file.
  • Page 35 I◄◄: Play the previous item. ►►I: Play the next item. INFO: Display playing progress. In this menu, press the INFO button again to display the EPG information. AUDIO: Set the audio language. SUB: If the file has subtitle, press the SUB button can change the subtitle. TXT：If the file has teletext, press the TXT button can display the teletext.

  • Page 36: Basic Operation

    8. Basic Operation 8.1 Audio You can select the language you prefer in Audio if the current program is available in multiple audio languages. Press the AUDIO button 2. Press ▲ / ▼ button and then press the OK button to select the audio language you prefer.

  • Page 37: Subtitle

    day of the selected channel. 3) Press OK button, then press ▲/▼▼ button to highlight the EPG event which you want, and the current EPG detail information will display on the bottom of screen. Highlight the EPG event which you want, press the Record button to enter Timer Setup menu.

  • Page 38: Program Information

    directly. Or by pressing Blue button in OK List/FAV List . 8.7 Program Information You can view the program information by pressing the INFO button while watching a program. 1. General Information : It is a FTA program. : It is a scramble p rogram. : The sound of current program is not Dolby.

  • Page 39: Channel List

    9. Channel List This chapter will help you manipulate the channel list. You can press the button to choose different satellite when you are operating on a channel list, press OK to confirm, then all the channels of this sat will be display.
  • Page 40 button can select the a program in current favorite list. 3) Press the RED button to sort the channels of the favorite list. 4) Press the GREEN button to manipulate the favorite list channels (move, delete, rename, lock/unlock, swap the channels of the favorite list). 5) Press the YELLOW button can help you find out channels quick by their first name.

  • Page 41: Usb Control

    10. USB Control 10.1 Recording and Timeshift 1. Start Recording 1) You can press the ● button to start recording while watching program. 2) If you have set the timer, and set the Time Record on, it will start recording automatically according to the start time of the timer.

  • Page 42: Pvr List

    10.2 PVR List You can enter the PVR list directly and then play the PVR file. In the PVR list you also can delete the PVR files. 1. Press ► button enter the PVR list when watching program. 2. Press the ▲/▼ to highlight the PVR file you want to play, press the OK button to play in small screen.

  • Page 43: Additional Information

    11. Additional Information 11.1 Trouble Shooting Before contacting your local service centre, please read the tips below carefully. If the problem persists after completing the following procedure, please contact your local product distributor or service centre for further instructions. 1. No message displayed on the front display. (The product will not switch on.) •...

  • Page 44: Technical Specification

    order. • [Satellite] Check the signal levels and adjust your antenna if the level is too low. The signal level may be affected by weather conditions. • [Terrestrial] Adjust the antenna direction to get a better picture. • [Terrestrial] Set the antenna power in menu to On, if you use the active antenna to improve the reception.(where applicable) 4.

  • Page 45: Glossary

    DiSEqC Control Version DiSEq C 1.0/1.1/1.2/1.3(USALS)Compatible, Tone burst A/B MPEG Transport Stream MPEG-2 ISO/IEC 13818Transport stream specification Profile Level MPEG1,MPEG-2 MP@ML,H.264, VC1, DV, DivX, and MPEG4 Input Rate 80 Mbps for MPEG Transport Stream and 25 Mbps for DV streams Aspect Ratio 4:3, 16:9 Video Resolution 576i, 576p, 480i, 480p, 720p50, 720p60, 1080i.1080p Audio Decoding MPEG-2 layer I and II (Music cam),MPEG4 AAC and MPEG4 AAC-HE (AAC+),Dolby...
  • Page 46 DiSEqC(Digital Satellite Equipment Control)system, it is a communication bus between satellite receivers and peripheral equipment using only the existing coaxial cable. ØDVB The Digital Video Broadcast group was created to establish a technical framework for the introduction of digital video broadcasting systems. ØLNB (low-noise block converter) or LNBF An electronic unit mounted on the satellite dish.
  • Page 47 ØTransponder An automatic device that receives, amplifies and retransmits a signal on a different frequency. ØSymbol rate Speed of the digital transmission. ØScrambled TV programmer Some TV programmer are transmitted in scrambled form.
