- Page 1 Manual for Warwick and RockBass Alien Acoustic Bass ENGLISH...
- Page 3 The Alien Acoustic bass offers musicians worldwide a high quality, reasonably priced instrument. At Warwick, our customers are FIRST. We strive to give our consumers the best possible product and best possible customer service and it is you, our satisfied cus- tomers, who continue to give us our worldwide success.
-
Page 4: Table Of Contents
Models, Specifications RockBass Alien Standard Acoustic Bass RockBass Alien Deluxe Acoustic Bass Warwick Alien Acoustic Bass Warwick Alien Acoustic Bass 6-string Warwick Alien Deluxe Acoustic Bass 6-string Warwick Deluxe Thinline Acoustic Bass 6) Tips for Body, Neck and Fingerboard Care... -
Page 5: Tuners - Stringing / Tuning Procedure
1) Tuners - Stringing / tuning procedure Tuners: All Alien acoustic basses come standard with high quality precision tuners (18:1 ratio). Warwick tuners feature a sealed, self-lubricating gear that warrants high tuning stability and needs no maintenance. The tuners are installed slanted facing... - Page 6 Stringing / Tuning Procedure: Place the string’s ball end on the bridge RockBass Alien basses come with slotted string holder. Hold the ball end down with bridge pins. Before you pull out a bridge one hand and with the other feed the string pin, make sure that there is no tension on to the tuner.
-
Page 7: Truss Rod Cover / Truss Rod Adjustment
2) Truss Rod Cover / Truss Rod Adjustment Truss Rod Cover: The truss rod cover of an Alien acoustic bass gives you - when needed - quick access to the truss rod. You’ll need a flat screwdriver to unlock the integrated latch mechanism. -
Page 8: Nut / Bridge
4) Strings Standard String Gauges for Warwick and RockBass Alien Acoustic Basses. Alien Acoustic Bass 4-Saiter Warwick Black Label - Acoustic Bass Strings / Medium Scale: .045" .065" .085" .105" (36200 MS 4) -
Page 9: Piezo - Pickups / Electronics For All Models
Warwick Black Label - Acoustic Bass Strings / Long Scale: .045" .065" .085" .105" .135" (36301 LOS 5) 6-Saiter Warwick Black Label - Acoustic Bass Strings / Long Scale: .025" .045" .065" .085" .105" .135" (36302 LOS 6) RockBass Alien Standard und Deluxe Akustik Bass 4-Saiter Warwick Red Strings - Acoustic Bass Strings / Medium Scale: .045"... -
Page 10: Rockbass Alien Deluxe Acoustic Bass
RockBass Alien Deluxe Acoustic Bass Pickups: Fishman Sonicore Piezo Elektronik: Fishman Presys+™ Low battery indicator Tuner: The preamp also has a built in chromatic tuner. The display shows the note actually played. The red light on the left side of the display shows when the note is flat, the green light in the middle shows when the note is in tune, the red light on the right side shows when the note is sharp. -
Page 11: Warwick Alien Acoustic Bass
Alien Acoustic Bass / Alien Acoustic 6-string Bass / Rockbass Alien Deluxe 6-string Bass Pickups: Fishman Acoustic Matrix Elektronik: Fishman Prefix Plus-T Notch Filter: This is a fixed-level, variable-frequency filter for eliminating feedback or unwanted res- onance. The affected frequency is variable from 40 to 500 Hz. The Notch Filter is effectively turned off in the full counterclockwise position. -
Page 12: Warwick Deluxe Thinline Acoustic Bass
To clean and protect the fingerboard use products specially made for this purpose and that are available at selected stores or specialist shops. Please refer to the manufacturer’s product information to achieve the desired result. You can order our cleaning products on our webshop: www.shop.warwick.de. -
Page 13: Access To The Battery Compartment
The piezo pickup systems are powered by a 9V battery. To change the battery you can open the electronics compartments as shown below: Warwick Alien and RockBass Alien Deluxe: The battery and electronics compartment can be easily opened with your fingernail. Push the battery in until it locks in place. -
Page 14: Security Locks
8) Security Locks All Warwick and RockBass Alien acoustic basses ship with Warwick Security Locks, which need to be installed. The Warwick Alien and the RockBass Alien Deluxe are equipped with a strapholder that also contains the output jack. This cannot be replaced. The strap lock can only be installed at the neck joint, where the wood is thick enough to hold the screw (see illustration). -
Page 15: User Kit
9) User-Kit You also receive the Warwick user-kit with your Alien Acoustic bass. It contains useful supplies like: - Trussrod Tool - Polish Cloth - 1,5 mm Allen key - 2,5 mm Allen key - Warranty Card 10) Warranty / Customer Service Warwick’s warranty for all musical instruments is limited to 2 years, but this condition may vary from... - Page 16 Do not trash. Dispose of accordingly. Weee-Nr.: DE93670540...
