. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1

Instrument Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2

Initial Drive Information . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-4

Vehicle Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-16

Performance and Maintenance . . . . . . . . . . . . . . . . . . 1-21

Front Seats . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-2

Safety Belts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-9

Child Restraints . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-26

Airbag System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-44

Restraint System Check . . . . . . . . . . . . . . . . . . . . . . . . . 2-60

Keys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-3

Doors and Locks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-10

Windows . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-16

Theft-Deterrent Systems . . . . . . . . . . . . . . . . . . . . . . . . 3-19

. . . . . . . . . . . . . . . . . . . . . . 2-1

. . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1

Starting and Operating Your Vehicle . . . . . . . . . . . . . 3-21

Mirrors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-39

Universal Home Remote System . . . . . . . . . . . . . . . . 3-42

Storage Areas . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-50

Roof Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-54

Convertible Top . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-59

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-1

Instrument Panel Overview . . . . . . . . . . . . . . . . . . . . . . . 4-3

Climate Controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-22

Warning Lights, Gauges, and Indicators . . . . . . . . . 4-29

Driver Information Center (DIC) . . . . . . . . . . . . . . . . . 4-47

Audio System(s) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-80

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-1

Your Driving, the Road, and the Vehicle . . . . . . . . . . 5-2

Towing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-33

Table of Contents

Advertisement

Chapters

Table of Contents

Need help?

Need help?

Do you have a question about the 2010 Corvette Convertible and is the answer not in the manual?

Questions and answers

Summary of Contents for Chevrolet 2010 Corvette Convertible

Page 1 ..........1-1 Instrument Panel .
Page 2 ....6-1 Service ......... . . 6-3 Fuel .
Page 3 For vehicles first sold in Canada, substitute the name General Motors of Canada Limited for Chevrolet Motor Division wherever it appears in this manual. Keep this manual the vehicle for quick reference.
Page 4 Warning messages found on vehicle labels and in this manual describe hazards and what to do to avoid or reduce them. indicates a hazard with a high level of risk which will result in serious injury or death. indicates a hazard that could result in injury or death.
Page 5 Here are some additional symbols that may be found on the vehicle and what they mean. For more information on the symbol, refer to the index. Airbag Readiness Light Air Conditioning Antilock Brake System (ABS) Audio Steering Wheel Controls or OnStar Brake System Warning Light Charging System Cruise Control...
Page 7: Table Of Contents
Instrument Panel ........1-2 Initial Drive Information ......1-4 Remote Keyless Entry (RKE) System .
Page 8: Instrument Panel
Instrument Panel...
Page 9 A. Outlet Adjustment on page 4 27. B. Head-Up Display (HUD) on page 4 16 (If Equipped). C. Turn Signal/Multifunction Lever on page 4 4. Cruise Control on page 4 7. Fog Lamps on page 4 13. Exterior Lamps on page 4 11. D.
Page 10: Remote Keyless Entry (Rke) System
Initial Drive Information This section provides a brief overview about some of the important features that may or may not be on your specific vehicle. For more detailed information, refer to each of the features which can be found later in this owner manual. Remote Keyless Entry (RKE) System The keyless access transmitter is used to lock and unlock the doors from up to 30 m (100 feet) away from...
Page 11: Inside The Vehicle
Door Locks From the outside, press the keyless access transmitter. When you have the transmitter with you, you may also unlock and open the door by squeezing the door handle sensor (A). From the inside, use the power door lock switch (B), located at the top of the door panel, near both windows.
Page 12: Trunk Release
Trunk Release Opening and Closing the Hatch/Trunk There are three ways to open the hatch/trunk: Touch the button located above the license plate. The Keyless Access transmitter must be within three feet of the button. Press the button located to the left of the steering wheel.
Page 13: Manual Seats
Seat Adjustment Manual Seats 1. Lift the bar to 2. Slide the seat to the Try to move the seat to be sure it is locked in place. See Manual Seats on page 2 2. Power Seats unlock the seat. desired position and release the bar.
Page 14: Reclining Seatbacks
Power Lumbar and Side Bolsters On vehicles with power lumbar and side bolsters: Move (A) forward or rearward to adjust lumbar support. Move (B) up or down to adjust the side bolsters. See Power Lumbar and Side Bolsters on page 2 3. Reclining Seatbacks To recline the seatback: 1.
Page 15: Heated Seats
Heated Seats On vehicles with heated seats, the buttons are located on the center console. The ignition must be on for this feature to work. : Press to turn the seat on at the high setting. Press again to turn it to the low setting : Press to turn the system off.
Page 16: Sensing System For Passenger Airbag
Sensing System for Passenger Airbag The passenger sensing system will turn off the right front passenger frontal airbag and seat mounted side impact airbag under certain conditions. The driver airbags are not affected by this. The passenger airbag status indicator will be visible in the rearview mirror when the vehicle is started.
Page 17: Exterior Mirrors
Mirror Adjustment Exterior Mirrors Controls for the outside power mirrors are located on the driver door. 1. Move the top control to the left or right to select either the driver or passenger mirror. 2. Use the arrows located on the four-way control pad to move the mirror in the desired direction.
Page 18: Steering Wheel Adjustment
Steering Wheel Adjustment The lever is located on the left side of the steering column. To adjust the steering wheel: 1. Pull the lever toward you. 2. Move the steering wheel up or down into a comfortable position. 3. Release the lever to lock the steering wheel in place.
Page 19: Interior Light Control
Interior Lighting Courtesy Lamps When any door or the hatch/trunk lid is opened, the interior lamps will go on, unless it is bright outside. The courtesy lamps can also be turned on and off by pressing the instrument panel brightness knob. Reading Lamps The inside rearview mirror includes two reading lamps.
Page 20: Turn And Lane-Change Signal
: Manual operation of the parking lamps and other exterior lamps. : Manual operation of the headlamps and other exterior lamps. Turn and Lane-Change Signal The turn signal lever has two upward and downward positions to signal a lane change or a turn. For a lane change, raise or lower the lever.
Page 21: Automatic Transmission
Climate Controls With this system, the heating, cooling, and ventilation can be controlled. A. Driver Temperature F. Air Conditioning Control G. Fan Control B. Display H. Air Delivery Mode C. Passenger Control Temperature Control I. Defrost D. AUTO J. Rear Window E.
Page 22: One To Four Shift Light (Manual Transmission)
The Manual Paddle Shift system can be deactivated by moving the shifter from S (Sport Mode) back to D (Drive), or by holding the up shift button for more than one second. The Manual Paddle Shift system will not allow either an up-shift or a down-shift, if the vehicle speed is too fast or too slow, nor will it allow a start from 4 (Fourth) or higher gear...
Page 23: Setting Preset Stations
: Turn to select radio stations. SEEK : Press to seek stations. SCAN : Press and hold to scan stations. : Press to change the information that shows on the display while listening to the radio. For more information about these and other radio features, see Audio System(s) on page 4 80 and Radio(s) on page 4 81.
Page 24: Portable Audio Devices
Portable Audio Devices This vehicle may have an auxiliary input jack, located on the audio faceplate. External devices such as iPod MP3 players, etc. can be connected to the auxiliary input jack using a 3.5 mm (1/8 in) input jack cable. See Using the Auxiliary Input Jack under Radio(s) on page 4 81.
Page 25: Navigation System
Navigation System The vehicle's navigation system provides detailed maps of most major freeways and roads throughout the United States and Canada. After a destination has been set, the system provides turn-by-turn instructions for reaching the destination. In addition, the system can help locate a variety of points of interest (POI), such as banks, airports, restaurants, and more.
Page 26: Vehicle Personalization
TRIP : Press to display your total and trip distance driven, the elapsed time function, your average speed, and the engine oil life. OPTION : Press to choose personal options that are available on your vehicle, depending on the options your vehicle is equipped with, such as door locks, easy entry seats, and language.
Page 27: Power Outlets
Power Outlets The accessory power outlet can be used to connect electrical equipment, such as a cellular phone. The accessory power outlet is located inside the center console storage compartment, on the forward left side. To use the outlet, remove the tethered cap. See Accessory Power Outlet(s) on page 4 20.
Page 28: Towing
The vehicle may have Competitive Driving Mode (except ZR1), Performance Traction Management (ZR1), and Launch Control systems designed to allow increased performance while accelerating and cornering. See Competitive Driving Mode on page 5 9. Towing The vehicle was neither designed nor intended to be towed with any of its wheels on the ground.
Page 29: Brake Noise
Z06, Z16, and ZR1 Features Checking Engine Oil ZO6, Z16 (Grand Sport), and ZR1 models have a high performance dry sump lubrication system. This system operates differently than a standard engine lubrication system. See Engine Oil on page 6 19. You should check the oil level only after the engine has been thoroughly warmed up and then shut off for at least five minutes.
Page 30: Resetting The Oil Life System
Engine Oil Life System The engine oil life system calculates engine oil life based on vehicle use and displays a DIC message when it is necessary to change the engine oil and filter. The oil life system should be reset to 100% only following an oil change.
Page 31: Online Owner Center
U.S.: 1-800-CHEV-USA (1-800-243-8872) TTY Users: 1-888-889-2438 Canada: 1-800-268-6800 As the owner of a new Chevrolet, you are automatically enrolled in the Roadside Assistance program. This program provides technically trained advisors who are available 24 hours a day, 365 days a year, minor repair information or towing arrangements.
Page 32: How Onstar Service Works
How OnStar Service Works : This blue button connects you to a specially trained OnStar advisor to verify your account information and to answer questions. : Push this red emergency button to get priority help from specially trained OnStar emergency advisors. : Push this button for hands free, voice activated calling and to give voice commands for turn by turn navigation.
Page 33: Onstar Steering Wheel Controls
Location information about the vehicle is only available if the GPS satellite signals are unobstructed and available. The vehicle must have a working electrical system, including adequate battery power, for the OnStar equipment to operate. There are other problems OnStar cannot control that may prevent OnStar from providing OnStar service at any particular time or place.
Page 34 NOTES 1-28...
Page 35: Front Seats
......... 2-2 Manual Seats .
Page 36 You can lose control of the vehicle if you try to adjust a manual driver's seat while the vehicle is moving. The sudden movement could startle and confuse you, or make you push a pedal when you do not want to. Adjust the driver's seat only when the vehicle is not moving.
Page 37 On vehicles with power seats: Move the control forward or rearward to adjust the seat location. Move the front or rear of the control up or down to adjust the seat cushion height. Your seat position can be stored and recalled if you have the memory option.
Page 38 On vehicles with heated seats, the buttons are located on the center console. The ignition must be on for this feature to work. Press to turn the seat on at the high setting. Press again to turn it to the low setting Press to turn the system off.
Page 39 To recall a memory position: On vehicles with an automatic transmission, press and release the desired button. If the vehicle is in P (Park), a single beep sounds and the memory position is recalled after a brief delay. If the vehicle is not in P (Park), three beeps sound and the memory position is not recalled.
Page 40 You can lose control of the vehicle if you try to adjust a manual driver's seat while the vehicle is moving. The sudden movement could startle and confuse you, or make you push a pedal when you do not want to. Adjust the driver's seat only when the vehicle is not moving.
Page 41 Sitting in a reclined position when your vehicle is in motion can be dangerous. Even if you buckle up, your safety belts cannot do their job when you are reclined like this. The shoulder belt cannot do its job. In a crash, you could go into it, receiving neck or other injuries.
Page 42 To fold a seatback forward, lift the latch located on top of the backside of the seat. The seatback locks when folded down. To return the seatback upright, lift up on the latch and push the seatback rearward. The seatback must be locked in place.
Page 43 This section of the manual describes how to use safety belts properly. It also describes some things not to do with safety belts. Do not let anyone ride where a safety belt cannot be worn properly. In a crash, if you or your passenger(s) are not wearing safety belts, the injuries can be much worse.
Page 44 In most states and in all Canadian provinces, the law requires wearing safety belts. Here is why: You never know if you will be in a crash. If you do have a crash, you do not know if it will be a serious one. A few crashes are mild, and some crashes can be so serious that even buckled up, a person would not survive.
Page 45 Put someone on it. Get it up to speed. Then stop the vehicle. The rider does not stop. 2-11...
Page 46 The person keeps going until stopped by something. or the instrument panel... In a real vehicle, it could be the windshield... 2-12...
Page 47 or the safety belts! With safety belts, you slow down as the vehicle does. You get more time to stop. You stop over more distance, and your strongest bones take the forces. That is why safety belts make such good sense. You could be whether you are wearing a safety belt or not.
Page 48: Safety Belts
You may be an excellent driver, but if you are in a crash even one that is not your fault your passenger(s) can be hurt. Being a good driver does not protect you from things beyond your control, such as bad drivers. Most accidents occur within 25 miles (40 km) of home.
Page 49 Sit up straight and always keep your feet on the floor in front of you. The lap part of the belt should be worn low and snug on the hips, just touching the thighs. In a crash, this applies force to the strong pelvic bones and you would be less likely to slide under the lap belt.
Page 50 The shoulder belt is too loose. It will not give as much protection this way. 2-16 You can be seriously hurt if your shoulder belt is too loose. In a crash, you would move forward too much, which could increase injury. The shoulder belt should fit snugly against your body.
Page 51 The lap belt is too loose. It will not give nearly as much protection this way. You can be seriously hurt if your lap belt is too loose. In a crash, you could slide under the lap belt and apply force on your abdomen. This could cause serious or even fatal injuries.
Page 52 You can be seriously injured if your belt is buckled in the wrong place like this. In a crash, the belt would go up over your abdomen. The belt forces would be there, not on the pelvic bones. This could cause serious internal injuries. Always buckle your belt into the buckle nearest you.
Page 53 You can be seriously injured if your belt goes over an armrest like this. The belt would be much too high. In a crash, you can slide under the belt. The belt force would then be applied on the abdomen, not on the pelvic bones, and that could cause serious or fatal injuries.
Page 54 The shoulder belt is worn under the arm. It should be worn over the shoulder at all times. 2-20 You can be seriously injured if you wear the shoulder belt under your arm. In a crash, your body would move too far forward, which would increase the chance of head and neck injury.
Page 55 You can be seriously injured by not wearing the lap-shoulder belt properly. In a crash, you would not be restrained by the shoulder belt. Your body could move too far forward increasing the chance of head and neck injury. You might also slide under the lap belt.
Page 56 You can be seriously injured by a twisted belt. In a crash, you would not have the full width of the belt to spread impact forces. If a belt is twisted, make it straight so it can work properly, or ask your dealer/retailer to fix it.
Page 57 All seating positions in the vehicle have a lap-shoulder belt. The following instructions explain how to wear a lap-shoulder belt properly. 1. Adjust the seat, if the seat is adjustable, so you can sit up straight. To see how, see Seats in the Index.
Page 58 4. To make the lap part tight, pull up on the shoulder belt. It may be necessary to pull stitching on the safety belt through the latch plate to fully tighten the lap belt on smaller occupants. 2-24 To unlatch the belt, push the button on the buckle. The belt should return to its stowed position.
Page 59 This vehicle has safety belt pretensioners for the front outboard occupants. Although the safety belt pretensioners cannot be seen, they are part of the safety belt assembly. They can help tighten the safety belts during the early stages of a moderate to severe frontal and near frontal crash if the threshold conditions for pretensioner activation are met.
Page 60 If the vehicle's safety belt will fasten around you, you should use it. But if a safety belt is not long enough, your dealer/ retailer will order you an extender. When you go in to order it, take the heaviest coat you will wear, so the extender will be long enough for you.
Page 61 The manufacturer's instructions that come with the booster seat, state the weight and height limitations for that booster. Use a booster seat with a lap-shoulder belt until the child passes the below fit test: Sit all the way back on the seat. Do the knees bend at the seat edge? If yes, continue.
Page 62 Never do this. Never allow two children to wear the same safety belt. The safety belt can not properly spread the impact forces. In a crash, the two children can be crushed together and seriously injured. A safety belt must be used by only one person at a time. 2-28 Never do this.
Page 63 Everyone in a vehicle needs protection! This includes infants and all other children. Neither the distance traveled nor the age and size of the traveler changes the need, for everyone, to use safety restraints. In fact, the law in every state in the United States and in every Canadian province says children up to some age must be restrained while in a vehicle.
Page 64 Never do this. Never hold an infant or a child while riding in a vehicle. Due to crash forces, an infant or a child will become so heavy it is not possible to hold it during a crash. For example, in a crash at only 40 km/h (25 mph), a 5.5 kg (12 lb) infant will suddenly become a 110 kg (240 lb) force on a person's arms.
Page 65: Child Restraints
Never do this. Children who are up against, or very close to, any airbag when it inflates can be seriously injured or killed. Never put a rear-facing child restraint in the right front seat. Secure a rear-facing child restraint in a rear seat. It is also better to secure a forward-facing child restraint in a rear seat.
Page 66 Add-on child restraints, which are purchased by the vehicle's owner, are available in four basic types. Selection of a particular restraint should take into consideration not only the child's weight, height, and age but also whether or not the restraint will be compatible with the motor vehicle in which it will be used.
Page 67 A young child's hip bones are still so small that the vehicle's regular safety belt may not remain low on the hip bones, as it should. Instead, it may settle up around the child's abdomen. In a crash, the belt would apply force on a body area that is unprotected by any bony structure.
Page 68 A booster seat (C-D) is a child restraint designed to improve the fit of the vehicle's safety belt system. A booster seat can also help a child to see out the window. 2-34 A child can be seriously injured or killed in a crash if the child restraint is not properly secured in the vehicle.
Page 69 When securing an add-on child restraint, refer to the instructions that come with the restraint which may be on the restraint itself or in a booklet, or both, and to this manual. The child restraint instructions are important, so if they are not available, obtain a replacement copy from the manufacturer.
Page 70 Your vehicle does not have lower anchors or top tether anchors to secure a child restraint with the LATCH system. If a national or local law requires that your top tether be anchored, do not use a child restraint in this vehicle because a top tether cannot be properly anchored.
Page 71 A top tether (A, C) anchors the top of the child restraint to the vehicle. A top tether anchor is built into the vehicle. The top tether attachment (B) on the child restraint connects to the top tether anchor in the vehicle in order to reduce the forward movement and rotation of the child restraint during driving or in a crash.
Page 72 Seating positions with top tether anchors. To assist you in locating the top tether anchors, the top tether anchor symbol is located on the trim cover. 2-38 (Top Tether Anchor): The top tether anchor is located behind the passenger seat.
Page 73 If a LATCH-type child restraint is not attached to anchors, the child restraint will not be able to protect the child correctly. In a crash, the child could be seriously injured or killed. Install a LATCH-type child restraint properly using the anchors, or use the vehicle's safety belts to secure the restraint, following the instructions that came with the child restraint and the instructions...
Page 74 If the position you are using has a fixed headrest or head restraint and you are using a dual tether, route the tether around the headrest or head restraint. 3. Push and pull the child restraint in different directions to be sure it is secure. This vehicle has airbags.
Page 75 Rear-facing child restraints should not be installed in the vehicle, even if the airbag(s) are off. If the child restraint has the LATCH system, see Lower Anchors and Tethers for Children (LATCH) (Coupe and Convertible Models Only) on page 2 35 or Lower Anchors and Tethers for Children (LATCH) (Z06 and ZR1 Models Only) on page 2 36 for how and where to install the child restraint using LATCH.
Page 76 4. Push the latch plate into the buckle until it clicks. 5. Pull the rest of the shoulder belt all the way out of the retractor to set the lock. Position the release button on the buckle so that the safety belt could be quickly unbuckled if necessary.
Page 77 6. To tighten the belt, push down on the child restraint, pull the shoulder portion of the belt to tighten the lap portion of the belt and feed the shoulder belt back into the retractor. When installing a forward-facing child restraint, you may find it helpful to use your knee to push down on the child restraint as you tighten the belt.
Page 78 The vehicle has the following airbags: A frontal airbag for the driver. A frontal airbag for the right front passenger. A seat-mounted side impact airbag for the driver. A seat-mounted side impact airbag for the right front passenger. All of the airbags in the vehicle will have the word AIRBAG embossed in the trim or on an attached label near the deployment opening.
Page 79 Airbags inflate with great force, faster than the blink of an eye. Anyone who is up against, or very close to, any airbag when it inflates can be seriously injured or killed. Do not sit unnecessarily close to the airbag, as you would be if you were sitting on the edge of your seat or leaning forward.
Page 80 The driver frontal airbag is in the middle of the steering wheel. 2-46 The right front passenger frontal airbag is in the instrument panel on the passenger's side.
Page 81 The seat-mounted side impact airbags for the driver and right front passenger are in the side of the seatbacks closest to the door. If something is between an occupant and an airbag, the airbag might not inflate properly or it might force the object into that person causing severe injury or even death.
Page 82 Frontal airbags are designed to inflate in moderate to severe frontal or near-frontal crashes to help reduce the potential for severe injuries mainly to the driver's or right front passenger's head and chest. However, they are only designed to inflate if the impact exceeds a predetermined deployment threshold.
Page 83: Airbag System
Thresholds can also vary with specific vehicle design. Frontal airbags are not intended to inflate during vehicle rollovers, rear impacts, or in many side impacts. In addition, your vehicle has dual-stage frontal airbags. Dual-stage airbags adjust the restraint according to crash severity.
Page 84 In a deployment event, the sensing system sends an electrical signal triggering a release of gas from the inflator. Gas from the inflator fills the airbag causing the bag to break out of the cover and deploy. The inflator, the airbag, and related hardware are all part of the airbag module.
Page 85 After the frontal and seat-mounted side impact airbags inflate, they quickly deflate, so quickly that some people may not even realize the airbags inflated. Some components of the airbag module may be hot for several minutes. For location of the airbag modules, see What Makes an Airbag Inflate? on page 2 50.
Page 86: Vehicle Data Recording And Privacy
airbags inflate. You can lock the doors, turn the interior lamps off, and turn the hazard warning flashers off by using the controls for those features. A crash severe enough to inflate the airbags may have also damaged important functions in the vehicle, such as the fuel system, brake and steering systems, etc.
Page 87 The vehicle has a passenger sensing system for the right front passenger position. The passenger airbag status indicator will be visible in the rearview mirror when the vehicle is started. The words ON and OFF, or the symbol for on and off, will be visible during the system check.
Page 88 A label on the sun visor says, Never put a rear-facing child seat in the front. This is because the risk to the rear-facing child is so great, if the airbag deploys. A child in a rear-facing child restraint can be seriously injured or killed if the right front passenger airbag inflates.
Page 89 When the passenger sensing system has turned off the right front passenger frontal airbag and seat-mounted side impact airbag, the off indicator will light and stay lit to remind you that the airbag(s) are off. See Passenger Airbag Status Indicator on page 4 34. The passenger sensing system is designed to turn on (may inflate) the right front passenger frontal airbag and seat-mounted side impact airbag anytime the system...
Page 90 If a child restraint has been installed and the on indicator is lit: 1. Turn the vehicle off. 2. Remove the child restraint from the vehicle. 3. Remove any additional items from the seat such as blankets, cushions, seat covers, seat heaters, or seat massagers.
Page 91 If this happens, use the following steps to allow the system to detect that person and enable the right front passenger frontal airbag and seat-mounted side impact airbag: 1. Turn the vehicle off. 2. Remove any additional material from the seat, such as blankets, cushions, seat covers, seat heaters, or seat massagers.
Page 92 A thick layer of additional material, such as a blanket or cushion, or aftermarket equipment such as seat covers, seat heaters, and seat massagers can affect how well the passenger sensing system operates. We recommend that you not use seat covers or other aftermarket equipment except when approved by GM for your specific vehicle.
Page 93 Yes. If you add things that change your vehicle's frame, bumper system, height, front end or side sheet metal, they may keep the airbag system from working properly. Changing or moving any parts of the front seats, safety belts, the airbag sensing and diagnostic module, steering wheel, instrument panel, the inside review mirror, front sensors, or airbag wiring can affect the operation of the airbag system.
Page 94 Now and then, check that the safety belt reminder light, safety belts, buckles, latch plates, retractors, and anchorages are all working properly. Look for any other loose or damaged safety belt system parts that might keep a safety belt system from doing its job.
Page 95 A crash can damage the restraint systems in your vehicle. A damaged restraint system may not properly protect the person using it, resulting in serious injury or even death in a crash. To help make sure your restraint systems are working properly after a crash, have them inspected and any necessary replacements made as soon as possible.
Page 96 2-62...
Page 97 ..........3-3 Keyless Access System .
Page 98 Universal Home Remote System Operation ..3-43 ........3-50 Glove Box .
Page 99: Keys
Leaving children in a vehicle with the keyless access transmitter is dangerous for many reasons, children or others could be badly injured or even killed. They could operate the power windows or other controls or even make the vehicle move. The windows will function with the keyless access transmitter in the vehicle and they could be seriously injured or killed if caught in the path of a closing window.
Page 100 The key, located inside the keyless access transmitter, can be used to lock and unlock the glove box and to open the hatch/trunk lid if power to the vehicle is lost. See more information. This vehicle has a keyless access system with pushbutton start.
Page 101 for information regarding Part 15 of the Federal Communications Commission (FCC) Rules and RSS-210/211 of Industry Canada. Changes or modifications to this system by other than an authorized service facility could void authorization to use this equipment. If there is a decrease in the RKE operating range, try this: Check the distance.
Page 102 Press the hatch/trunk release button located on the rear of the hatch/trunk lid above the license plate to open the trunk if the keyless access transmitter is within range. for additional information. There are other conditions that can affect the performance of the transmitter.
Page 103 Only keyless access transmitters programmed to this vehicle will work. If a transmitter is lost or stolen, a replacement can be purchased and programmed through your dealer/retailer. The vehicle can be reprogrammed so that lost or stolen transmitters no longer work. Each vehicle can have up to four transmitters programmed to it.
Page 104 This procedure requires three ten minutes cycles to complete the programming process. United States owners are permitted to program a new transmitter to their vehicle when a recognized transmitter is not available. The Canadian immobilizer standard requires that Canadian owners see their dealer/retailer for programming new transmitters when two recognized transmitters are not available.
Page 105 8. The DIC reads WAIT 10 MINUTES and counts down to zero. 9. The DIC displays OFF-ACCESSORY TO LEARN again. 10. Press Acc. on the ignition switch. 11. Steps 8, 9 and 10 will be repeated two more times. 12. A beep sounds and the DIC reads READY FOR FOB #1.
Page 106 1. Separate the transmitter with a flat, thin object inserted into the slot on the side or back of the transmitter. 2. Remove the old battery. Do not use a metal object. 3. Insert the new battery, positive side facing down. Replace with a CR2032 or equivalent battery.
Page 107 There are several ways to lock and unlock your vehicle. From the outside, press the lock or unlock button on the keyless access transmitter. When you have the transmitter with you, you may also unlock and open the door by squeezing the door handle sensor (A).
Page 108 2. From outside the vehicle, use the key in the cylinder above the license plate to open the hatch. Then, use the door release tab (A), located on the carpet inside the hatch on the driver's side of the vehicle. Pull the tab to unlock and unlatch the driver's door.
Page 109 The vehicle is programmed so that, when the doors are closed, the ignition is on and the shift lever is moved out of P (Park)for automatic transmissions, or when vehicle speed becomes faster than 8 mph (13 km/h) for manual transmissions, both doors will lock. Use the power door unlock switch to unlock the door when the vehicle is not in P (Park).
Page 110 Exhaust gases can enter the vehicle if it is driven with the liftgate, trunk/hatch open, or with any objects that pass through the seal between the body and the trunk/hatch or liftgate. Engine exhaust contains Carbon Monoxide (CO) which cannot be seen or smelled. It can cause unconsciousness and even death.
Page 111 There are several ways to release the hatch/trunk lid. If your vehicle has an automatic transmission, the shift lever must be in P (Park). For manual transmission vehicles, the parking brake must be set when the ignition is started for the hatch/trunk release to operate. The parking brake does not need to be set when the ignition is off for the hatch/trunk release to operate.
Page 112 There is a glow-in-the-dark emergency trunk release handle located on the rear wall of the trunk below the latch. This handle will glow following exposure to light. Pull the release handle down to open the trunk from the inside. 3-16 Leaving children, helpless adults, or pets in a vehicle with the windows closed is dangerous.
Page 113 The power window switches are located on each door. Pull up or press down on the front of the switch to raise or lower the window. Retained Accessory Power (RAP) allows you to use the power windows when the ignition is off. For more information, see 3-17...
Page 114 Press the front of the switch to the second position to activate the express-down feature. If you want to stop the window as it is lowering, press the switch again. This feature automatically lowers the window a small amount when the door is opened. When the door is closed, the window will raise to its full up position.
Page 115: Theft-Deterrent Systems
Vehicle theft is big business, especially in some cities. This vehicle has theft-deterrent features, however, they do not make it impossible to steal. This vehicle has a theft-deterrent alarm system. The security light flashes if a door is open and locked with the power door lock switch.
Page 116 To test the system: 1. Make sure the trunk lid/hatch is latched. 2. Lower the window on the driver door. 3. Manually arm the system. 4. Close the doors and wait 30 seconds. 5. Reach through the open window and manually pull the release lever on the floor.
Page 117 If the vehicle does not start and the keyless access transmitter appears to be undamaged, try another keyless access transmitter. Or, place the transmitter in the transmitter pocket. See NO FOBS DETECTED under additional information. Check the fuse. See . If the engine still does not start with the other transmitter, the vehicle needs service.
Page 118 For the first 500 miles/805 km: Avoid full throttle starts and abrupt stops. Do not exceed 4,000 engine rpm. Avoid driving at any one constant speed, fast or slow, including the use of cruise control. Avoid downshifting to brake or slow the vehicle when the engine speed will exceed 4000 RPM.
Page 119 The vehicle has an electronic keyless ignition with a pushbutton start. In order to shift out of P (Park), the vehicle must be running or in Acc. mode and the regular brake pedal must be applied. Press this button while your foot is on the brake for an automatic transmission, or while pressing in the clutch for a manual transmission, to start the engine.
Page 120 These vehicle accessories can be used for up to 10 minutes after the engine is turned off: Audio System Power Windows These features continue to work up to 10 minutes after the engine is turned off or until either door is opened. If a door is opened, the power windows and audio system will shut off.
Page 121 3. Do not race the engine immediately after starting it. Operate the engine and transmission gently until the oil warms up and lubricates all moving parts. 4. If the engine does not start and no DIC message is displayed, wait 15 seconds before trying again to let the cranking motor cool down.
Page 122 If the vehicle has an automatic transmission, move the shift lever to P (Park) and press and hold the Acc. (Off/Accessory) button, located on the instrument panel, until the engine shuts off. If the shift lever is not in P (Park), the engine shuts off and the vehicle goes into the Accessory Mode.
Page 123 It is dangerous to get out of the vehicle if the shift lever is not fully in P (Park) with the parking brake firmly set. The vehicle can roll. Do not leave the vehicle when the engine is running unless you have to. If you have left the engine running, the vehicle can move suddenly.
Page 124 In this position, the engine does not connect with the wheels. To restart the engine when the vehicle is already moving, use N (Neutral) only. If the vehicle needs towing, see Shifting into a drive gear while the engine is running at high speed is dangerous.
Page 125 While in S (Sport Mode), the paddles located on the steering wheel can be used to manually up-shift or down-shift the transmission. The Manual Paddle Shift system is activated from S (Sport Mode) by pushing the paddle, above the steering wheel spokes, to up-shift to the next gear, or pulling on the paddle, behind the steering wheel spokes, to down-shift to the next gear.
Page 126 When using the Manual Paddle Shift feature while in S (Sport Mode), the current gear will be displayed in the Driver Information (DIC), or the Head-Up Display (HUD), if the vehicle has either of these features. If the vehicle has a Navigation system, see Head-Up Display (HUD) in the Index of the navigation manual.
Page 127 Up-shifts to 4 (Fourth) gear require approximately 35 km/h (22 mph). Up-shifts to 5 (Fifth) gear require approximately 45 km/h (28 mph). Up-shifts to 6 (Sixth) gear require approximately 65 km/h (41 mph). To prevent damage to the powertrain, Manual Paddle downshifts to a lower gear cannot be done above certain speeds.
Page 128 This is the shift pattern for the six-speed manual transmission. Here is how to operate the transmission: Press the clutch pedal and shift into 1 (First). Then slowly let up on the clutch pedal as you press the accelerator pedal. You can shift into 1 (First) when you are going less than 40 mph (64 km/h).
Page 129 If you skip a gear when you downshift, you could lose control of the vehicle. You could injure yourself or others. Do not shift down more than one gear at a time when you downshift. This chart shows when to shift to the next higher gear for the best fuel economy.
Page 130 Do not downshift into the gear shown below at a speed greater than shown in the table: 1 (First) 2 (Second) 3 (Third) 4 (Fourth) The six-speed transmission has a spring that centers the shift lever near 3 (Third) and 4 (Fourth). This spring helps you know which gear you are in when you are shifting.
Page 131 It can be dangerous to get out of the vehicle if the shift lever is not fully in P (Park) with the parking brake firmly set. The vehicle can roll. If you have left the engine running, the vehicle can move suddenly.
Page 132 If you are parking on a hill and you do not shift the transmission into P (Park) properly, the weight of the vehicle may put too much force on the parking pawl in the transmission. You may find it difficult to pull the shift lever out of P (Park).
Page 133 Things that can burn could touch hot exhaust parts under the vehicle and ignite. Do not park over papers, leaves, dry grass, or other things that can burn. Engine exhaust contains Carbon Monoxide (CO) which cannot be seen or smelled. Exposure to CO can cause unconsciousness and even death.
Page 134 It is better not to park with the engine running. But if you ever have to, here are some things to know. Idling a vehicle in an enclosed area with poor ventilation is dangerous. Engine exhaust may enter the vehicle. Engine exhaust contains Carbon Monoxide (CO) which cannot be seen or smelled.
Page 135: Mirrors
The vehicle may have an automatic dimming inside rearview mirror with a compass display and/or map ® lamps, and OnStar . The mirror automatically changes to reduce glare from headlamps behind you. A time delay feature prevents rapid changing from the day to night positions while driving under lights and through traffic.
Page 136 Press once to turn the compass display on or off. If after several seconds the display does not show a compass heading, there may be a strong magnetic field interfering with the compass. Interference can be caused by a magnetic antenna mount, note pad holder or similar object.
Page 137 Controls for the outside power mirrors are located on the driver door. To adjust the mirrors: 1. Move the top selector control to the left or right to select either the driver or passenger mirror. 2. Use the arrows located on the four-way control pad to move the mirror in the desired direction.
Page 138 A convex mirror can make things, like other vehicles, look farther away than they really are. If you cut too sharply into the right lane, you could hit a vehicle on the right. Check the inside mirror or glance over your shoulder before changing lanes.
Page 139: Universal Home Remote System
On vehicles with this feature there are three round Light Emitting Diode (LED) indicator lights above the Universal Home Remote buttons, follow the instructions below. This system provides a way to replace up to three remote control transmitters used to activate devices such as garage door openers, security systems, and home automation devices.
Page 140 To program up to three devices: 1. Press START or put the vehicle in accessory mode. See additional information. Programming can only occur when the vehicle is running or in accessory mode. 2. From inside the vehicle, press the two outside buttons at the same time for one to two seconds, and immediately release them.
Page 141 4. Immediately return to the vehicle. Press and hold the Universal Home Remote button that will be used to control the garage door until the garage door moves. The indicator light, above the selected button, should slowly blink. This button may need to be held for up to 20 seconds.
Page 142 2. To verify that the garage door opener is a Fixed Code unit, remove the battery cover on the hand held transmitter supplied by the manufacturer of the garage door opener motor. If there are a row of dip switches similar to the graphic above, the garage door opener is a Fixed Code unit.
Page 143 The panel of switches might not appear exactly as they do in the examples above, but they should be similar. The switch positions on the hand-held transmitter could be labeled, as follows: A switch in the up position could be labeled as Up, +, or On.
Page 144 5. The indicator lights blink slowly. Enter each switch setting from Step 3 into the vehicle's Universal Home Remote. You have two and one-half minutes to complete Step 5. Now press one button on the Universal Home Remote for each switch setting as follows: If you wrote Left, press the left button in the vehicle.
Page 145 Press and hold the appropriate button for at least half of a second. The indicator light comes on while the signal is being transmitted. Operation can occur: If the vehicle is in accessory mode. If the vehicle is in running. If the vehicle is in Retained Accessory Mode (RAP).
Page 146: Storage Areas
Open the glove box by lifting up on the lever. Use the key to lock and unlock the lighted glove box. Two cupholders are located on the center console next to the shift lever. Slide the handle from the left to the right side to access the lid.
Page 147 Two rear storage compartments are located in the floor of the rear hatch/trunk area. To access a storage compartment, pull up to open the cover. The covers cannot be removed. For Z06, ZR1 and Grand Sport models, the right rear compartment stores the battery and cannot be used for storage.
Page 148 Pull the divider up and snap it onto the snaps on both sides of the trunk. Use the convenience net, located in the rear, to store small loads as far forward as possible. The net should not be used to store heavy loads. 3-52 For vehicles with this feature, the security shade can provide hidden storage in the rear area of the vehicle.
Page 149 4. Push the loop to the top of the striker (base plate). 3. Grasp the loop at the rear center of the shade and wrap it around the striker assembly. 3-53...
Page 150 On vehicles with a removable roof panel, follow the procedures when removing or installing it. Do not try to remove a roof panel while the vehicle is moving. Trying to remove the roof panel while the vehicle is moving could cause an accident. The panel could fall into the vehicle and cause you to lose control, or it could fly off and strike another vehicle.
Page 151 6. To unlock the release latches on the front of the The driver's side handle moves toward the driver's roof panel, grasp each handle and pull it outward. door. The passenger's side handle moves toward the passenger's door. 3-55...
Page 152 7. To unlock the rear of Pull down the latch lever. 3-56 8. Stand on one side of the vehicle, and if necessary, the roof panel's rear release latch, press the back of the release handle (B). Then press 9. When the roof panel is loosened from the vehicle, the button on the front of the release handle (A).
Page 153 1. Turn the roof panel so that the front edge of the panel is facing the storage area. 2. Insert the roof panel so that the outside front edges line up between the receiver covers. Push forward on the roof panel until it stops. 3.
Page 154 An improperly attached roof panel may fall into or fly off the vehicle. You or others could be injured. After installing the roof panel, always check that it is firmly attached by pushing up on the underside of the panel. Check now and then to be sure the roof panel is firmly in place.
Page 155 6. Turn the front release handles inward so that they latch to the closed position. 7. Push up on the handle of the rear roof release handle to latch its hook in the closed position. 8. Push and pull the roof panel up and down and side-to-side to ensure the roof panel is securely installed.
Page 156 The parts of the manual convertible top that are used when lowering and raising it are: A. Front Edge of the Convertible Top B. Rear Edge of the Convertible Top C. Tonneau Cover 3-60...
Page 157 1. Park on a level surface. Shift an automatic transmission into P (Park) and set the parking brake. Shift a manual transmission into N (Neutral) and set the parking brake. 2. Make sure the ignition is off. 3. Make sure the trunk is closed. 4.
Page 158 6. Tilt the driver's seatback forward and press the tonneau cover release button located on the underside of the tonneau cover (C) behind the driver's seat. Then raise the tonneau cover (C). 3-62 If the tonneau cover does not release and three chimes are heard, check to make sure the trunk lid is closed.
Page 159 7. Pull the cable to release the tonneau cover. 8. Push forward on the front edge (A) of the convertible top to allow the rear edge (B) of the convertible top to be moved to its full-down position. 3-63...
Page 160 9. Then move the top rearward to its fully-stored position. 10. After the top is stored, apply one even push on the center of the front edge (A) of the convertible top to assure that the top is fully retracted. 11.
Page 161 6. Pull the convertible top up by firmly gripping the front edge (A) near the center and applying a brisk upward and forward motion to get the top in the full-up position. 7. Lift the rear edge (B) of the convertible top to its full-up position by first raising the front edge (A).
Page 162 For care and cleaning of the convertible top see under Service and Appearance Care . High pressure car washes may cause water to enter the vehicle. To operate the power convertible top use the following steps. 11. Pull the top front latch handle down and turn it counterclockwise to lock the convertible top.
Page 163 1. Park on a level surface. Start the engine. Shift an automatic transmission into P (Park) and set the parking brake. Shift a manual transmission into N (Neutral), and set the parking brake. 2. Make sure the trunk is closed and the rear trunk partition in the rear storage area is in the fastened upright position, and that no objects are forward of the divider.
Page 164 4. Push and hold the The windows will automatically lower and the convertible top will lower into the rear of the vehicle. A chime will sound when the convertible top has lowered completely. If the radio is on the sound may be muted for a brief time due to a new audio system equalization being loaded.
Page 165 If the radio is on the sound may be muted for a brief time due to a new audio system equalization being loaded. If the vehicle has lost power, the convertible top can still be raised by releasing pressure on the hydraulic pump, located under the passenger's side of the tonneau cover, by using the following steps.
Page 166 1. Open the tonneau cover by pulling the emergency 2. Locate the pressure release bolt on the front side release cable. of the hydraulic pump. The tonneau cover emergency release cable is located behind the passenger's seat head restraint, on the underside forward edge of the tonneau cover.
Page 167 3. Use the wrench, located in the console, and turn the pressure release bolt counterclockwise one revolution, to relieve pressure to the hydraulic pump. This will allow you to manually raise the convertible top. 4. Then follow the steps under raising the manual convertible top.
Page 168 3-72...
Page 169 Section 4 Instrument Panel Overview ......4-3 Hazard Warning Flashers ..... . . 4-3 Horn .
Page 170 Fog Lamp Light ....... . 4-45 Lights On Reminder ......4-45 Highbeam On Light .
Page 171: Instrument Panel Overview
Instrument Panel Overview Hazard Warning Flashers The hazard warning flashers warns others that you have a problem. The button is located near the center of the instrument panel. : Press to make the front and rear turn signal lamps flash on and off. Press again to turn the flashers off. The hazard warning flashers work no matter what mode the ignition is in, even if the ignition is turned off.
Page 172: Turn Signal/Multifunction Lever
Telescopic Steering Column For vehicles with this feature, the telescopic steering column switch is located on the right side of the steering column. To adjust the telescopic steering column: 1. Push the switch forward to move the wheel away from you. 2.
Page 173: Turn And Lane-Change Signals (Auto Signal)
Turn and Lane-Change Signals (Auto Signal) An arrow on the instrument panel cluster flashes in the direction of the turn or lane change. Move the the lever all the way up or down to signal a turn. Raise or lower the lever until the arrow starts to flash to signal a lane change.
Page 174: Windshield Wipers
Windshield Wipers The windshield wiper lever is located on the right side of the steering column. Move the lever to the following positions: (High Speed) : Fast wipes. (Low Speed) : Slow wipes. (Delay) : Use to set a delay between wipes. (Delay Adjustment) : Use for a delayed wiping cycle.
Page 175 WARNING: In freezing weather, do not use your washer until the windshield is warmed. Otherwise the washer fluid can form ice on the windshield, blocking your vision. If the fluid in the windshield washer fluid reservoir is low, the message CHECK WASHER FLUID will appear on the Driver Information Center (DIC) display.
Page 176: Setting Cruise Control
The vehicle has cruise control. (Off): Turns the system off. (On): Turns the system on. (Resume/Accelerate): Use to make the vehicle accelerate or resume a previously set speed. (Set): Press this button at the end of the lever to set the speed. Setting Cruise Control WARNING: If you leave your cruise control on when you are...
Page 177: Increasing Speed While Using Cruise Control
Resuming a Set Speed If the cruise control is set at a desired speed and then the brakes are applied, the cruise control is disengaged. But it does not need to be reset. Once the vehicle is going about 40 km/h (25 mph) or more, you can move the cruise control switch briefly from to The vehicles goes back up to your chosen speed and...
Page 178: Using Cruise Control On Hills
Using Cruise Control on Hills How well the cruise control works on hills depends upon the vehicle's speed, load, and the steepness of the hills. When going up steep hills, you might want to step on the accelerator pedal to maintain the vehicle's speed. When going downhill, you might have to brake or shift to a lower gear to keep the vehicle's speed down.
Page 179: Exterior Lamps
Exterior Lamps The exterior lamp control is located to the left of the steering wheel on the multifunction lever. (Exterior Lamp Control) : Turn the band with this symbol on it to operate the exterior lamps. The exterior lamp band has four positions: (Off) : Turns off all lamps.
Page 180: Wiper Activated Headlamps
Wiper Activated Headlamps This feature activates the headlamps and parking lamps after the windshield wipers have been in use for approximately 15 seconds and deactivates and returns to ambient lighting conditions 15 seconds after the wipers are turned off. If the exterior lamp control has been turned off or is in the parking lamp position while the wiper control is active in any position, the HEADLAMPS SUGGESTED message appears on the Driver Information Center...
Page 181: Fog Lamps
When it is bright enough outside, the regular lamps go off, and the front turn signal lamps will take over. If the vehicle is started in a dark garage, the automatic headlamp system comes on immediately. Once the vehicle leaves the garage, it takes approximately one minute for the automatic headlamp system to change to DRL if it is light outside.
Page 182: Twilight Sentinel
® Twilight Sentinel ® Twilight Sentinel can turn the lamps on and off for you. A light sensor on top of the instrument panel makes the ® Twilight Sentinel work, so be sure it is not covered. ® With Twilight Sentinel , the following will happen: When it is dark enough outside, the front turn signal lamps (DRL) will go off, and the headlamps...
Page 183: Exterior Lighting Battery Saver
Exterior Lighting Battery Saver If the manual parking lamps or headlamps have been left on, the exterior lamps will turn off as soon as the ignition is turned off or Retained Accessory Power (RAP) is active. This protects against draining the battery in case you have accidentally left the headlamps or parking lamps on.
Page 184: Battery Run-Down Protection
Battery Run-Down Protection This vehicle has a feature to help prevent the battery from being drained in case any of the following lamps are left on; the underhood lamp, if your vehicle has this feature, vanity mirror lamps, cargo lamps, reading lamps, console or glove box lamps.
Page 185 Transmission Fluid Temperature Gauge, (Automatic Transmission Vehicles Only) Engine Oil Temperature Gauge Engine Oil Pressure Gauge G-Force Gauge Boost Gauge (If Equipped) Audio Functions, Street Mode Only Navigation, Only with Navigation Radio, Turn-by-Turn Guidance There are three HUD modes that can be viewed in the HUD display.
Page 186 Within each mode, the display, can be further customized by pressing the PAGE button. Pressing this button in each mode will turn off and on the following: Street Mode No tachometer, circular tachometer, and linear tachometer. Track Modes 1 and 2 No minor gauge, coolant temperature, transmission oil temperature, engine oil temperature, engine oil pressure, and boost...
Page 187 The HUD controls are located to the left of the steering wheel. To adjust the HUD so it can be seen properly, do the following: 1. Start the engine and press the HUD dimmer control all the way up by pressing the (+) button. The brightness of the HUD image is determined by the light conditions in the direction the vehicle is facing and where you have the HUD dimmer...
Page 188: Accessory Power Outlet(S)
To change the language and unit selections, see OPTION under Clean the inside of the windshield as needed to remove any dirt or film that reduces the sharpness or clarity of the HUD image. To clean the HUD, spray household glass cleaner on a soft, clean cloth.
Page 189: Ashtray(S) And Cigarette Lighter
Adding any electrical equipment to the vehicle can damage it or keep other components from working as they should. The repairs would not be covered by the vehicle warranty. Do not use equipment exceeding maximum amperage rating of 20 amperes. Check with your dealer/retailer before adding electrical equipment.
Page 190: Climate Controls
Climate Controls Dual Automatic Climate Control System With this system the heating, cooling, and ventilation can be controlled. A. Driver Temperature F. Air Conditioning Controls G. Fan Control B. Display H. Air Delivery Mode C. Passenger Temperature Control D. AUTO J.
Page 191: Manual Operation
The system operates to reach the set temperature as quickly as possible. The AUTO control system works best with the windows up and the removable roof installed or the convertible top up. 1. Press the AUTO button. 2. Adjust the temperature to a comfortable setting between 16°C (60°F) and 32°C (90°F).
Page 192 (Air Delivery Mode Control) : Press this button to manually lock in the current air delivery setting and to stop the automatic mode control. Pressing AUTO from the digital display and the mode graphics will be shown. To change the setting, press The AUTO button must be pressed to return to the automatic mode selection.
Page 193 You may notice a slight change in engine performance when the air-conditioning compressor shuts off and turns on again. This is normal. The system is designed to make adjustments to help with fuel economy while still maintaining the selected temperature. On hot days, open the windows to let hot inside air escape;...
Page 194: Rear Window Defogger
Sensors The solar sensor on the vehicle monitors the solar heat and uses the information to maintain the selected temperature when operating in AUTO mode by automatically adjusting the temperature, fan speed and air delivery system. The system may also supply cooler air to the side of the vehicle facing the sun.
Page 195: Outlet Adjustment
The rear window defogger turns off about 10 minutes after the button is pressed when traveling less than 48 km/h (30 mph). If turned on again, the defogger only runs for about five minutes before turning off. The defogger can also be turned off by turning off the engine.
Page 196: Passenger Compartment Air Filter
Passenger Compartment Air Filter The passenger compartment air filter removes certain particles from the air including pollen and dust particles. Reductions in airflow, which may occur more often in dusty areas, indicate that the filter may need to be replaced. See for information on how often to replace the filter.
Page 197: Warning Lights, Gauges, And Indicators
3. Remove the filter and install the new air filter. 4. Replace the filter cover. 5. Attach the retainer clips. Warning Lights, Gauges, and Indicators Warning lights and gauges can signal that something is wrong before it becomes serious enough to cause an expensive repair or replacement.
Page 198: Instrument Panel Cluster
Instrument Panel Cluster United States Manual Transmission shown, Canada, Automatic Transmission and Z06 Model similar 4-30...
Page 199 ZR1 United States shown Canada similar 4-31...
Page 200: Safety Belt Reminder Light
Speedometer and Odometer The speedometer shows the speed in either kilometers per hour (km/h) or miles per hour (mph). For more information see Personal Options under To read the odometer with the ignition off, turn on the parking lamps. If the vehicle needs a new odometer installed, the mileage total of the new odometer will be set to the original kilometers (miles) of the old odometer.
Page 201: Airbag Readiness Light
Airbag Readiness Light The system checks the airbag's electrical system for possible malfunctions. If the light stays on it indicates there is an electrical problem. The system check includes the airbag sensor, the pretensioners, the airbag modules, the wiring and the crash sensing and diagnostic module.
Page 202: Passenger Airbag Status Indicator
Passenger Airbag Status Indicator The vehicle has the passenger sensing system. See safety information. The rearview mirror has a passenger airbag status indicator. United States Canada 4-34 When the vehicle is started, the passenger airbag status indicator will light ON and OFF, or the symbol for on and off, for several seconds as a system check.
Page 203: Voltmeter Gauge
If, after several seconds, both status indicator lights remain on, or if there are no lights at all, there may be a problem with the lights or the passenger sensing system. See your dealer/retailer for service. WARNING: If the airbag readiness light ever comes on and stays on, it means that something may be wrong with the airbag system.
Page 204: One-To-Four Shift Light
One-to-Four Shift Light (Manual Transmission) When this light comes on, the vehicle can only be shifted from 1 (First) to 4 (Fourth) instead of 1 (First) to 2 (Second). The shift must be completed into 4 (Fourth) to turn off this feature.
Page 205: Antilock Brake System (Abs) Warning Light
This light comes on briefly while starting the engine. If it does not come on, have it fixed so it is ready to warn if there is a problem. WARNING: The brake system might not be working properly if the brake system warning light is on. Driving with the brake system warning light on can lead to a crash.
Page 206: Traction Control System (Tcs) Warning Light
Traction Control System (TCS) Warning Light The Traction Control System (TCS) Warning light comes on briefly when the engine is started. If the light does not, have the vehicle serviced by your dealer/retailer. If the system is working normally the light then goes off.
Page 207: Active Handling System Light
Active Handling System Light The Active Handling System light comes on briefly as the engine is started. If the light does not, have the vehicle serviced by your dealer/ retailer. If the system is working normally the light goes off. If the light stays on or comes on while driving, a chime sounds and a SERVICE ACTIVE HANDLING SYSTEM message appears on the DIC and the vehicle need...
Page 208: Engine Coolant Temperature Gauge
Engine Coolant Temperature Gauge United States This gauge shows the engine coolant temperature. If the gauge pointer moves into the shaded area, the engine is too hot. This means that the engine coolant has overheated. If the vehicle has been operating under normal driving conditions, pull off the road, stop the vehicle and turn off the engine as soon as possible.
Page 209: Malfunction Indicator Lamp
When the Light Flashes First and Then is On Steady This indicates that there may be a problem with the Tire Pressure Monitor System. The light flashes for about a minute and stays on steady for the remainder of the ignition cycle.
Page 210 This light comes on during a malfunction in one of two ways: Light Flashing : A misfire condition has been detected. A misfire increases vehicle emissions and could damage the emission control system on the vehicle. Diagnosis and service might be required. The following can prevent more serious damage to the vehicle: Reduce vehicle speed.
Page 211: Emissions Inspection And Maintenance Programs
If none of the above have made the light turn off, your dealer/retailer can check the vehicle. The dealer/retailer has the proper test equipment and diagnostic tools to fix any mechanical or electrical problems that might have developed. Emissions Inspection and Maintenance Programs Some state/provincial and local governments have or might begin programs to inspect the emission...
Page 212: Maintenance Schedule
Engine Oil Pressure Gauge United States United States Z06 and Canada ZR1 Models 4-44 WARNING: Do not keep driving if the oil pressure is low. The engine can become so hot that it catches fire. Someone could be burned. Check the oil as soon as possible and have the vehicle serviced.
Page 213: Security Light
The engine oil pressure can also be displayed using the GAGES button on the Driver Information Center (DIC). Security Light For information regarding this light and the vehicle's security system, see Fog Lamp Light The fog lamp light comes on when the fog lamps are in use.
Page 214: Fuel Gauge
Fuel Gauge The fuel gauge shows how much fuel the vehicle has left while the engine is on. An arrow on the fuel gauge indicates the side of the vehicle the fuel door is on. When the needle approaches the low fuel symbol, a chime sounds and LOW FUEL appears on the Driver Information Center (DIC) display.
Page 215: Boost Gauge (Zr1 Only)
The DIC buttons are located on the instrument panel, to the right of the cluster. The DIC comes on when the ignition is turned on. After displaying CORVETTE BY CHEVROLET, the DIC shows the information that was last displayed before the engine was turned off.
Page 216 (Fuel): Press this button to display fuel information such as fuel economy and range. (Gauges): Press this button to display gauge information like oil pressure and temperature, coolant temperature, automatic transmission fluid temperature, if equipped, battery voltage, and front/rear tire pressures.
Page 217 Press the fuel button to display average fuel economy, such as: AVERAGE FUEL ECONOMY 11.7 L/100 km or AVERAGE FUEL ECONOMY 20.1 MPG Instantaneous Fuel Economy : Instantaneous fuel economy reflects only the fuel economy that the vehicle has right now and will change frequently as driving conditions change.
Page 218 If the oil temperature is low, the display will show OIL TEMPERATURE LOW. If the oil temperature is high, the display will show OIL TEMPERATURE HIGH. Coolant Temperature : This display shows the engine coolant temperature. Press the gauges button again to display the coolant temperature, such as: COOLANT TEMPERATURE 51°C or COOLANT TEMPERATURE 123°F...
Page 219: Trip Button
TRIP Button The TRIP button displays the odometer, trip distance, elapsed time, average speed, and oil life remaining information. Odometer : The odometer shows how far your vehicle has been driven in either kilometers or miles. Press the TRIP button to display odometer readings, such as: ODOMETER 20008 km or ODOMETER 12345 MI You can also display the odometer by turning on the...
Page 220: Reset Button
Press and hold the RESET button to reset to 0.0 km/h (mph). Engine Oil Life : Press the TRIP button until the engine oil life is displayed, such as OIL LIFE REMAINING 89%. This is an estimate of the engine oil's remaining useful life.
Page 221: Battery Saver Active
ABS (Antilock Brake System) ACTIVE This message displays when the Antilock Brake System (ABS) is adjusting brake pressure to help avoid a braking skid. Slippery road conditions may exist if this message is displayed, so adjust your driving accordingly. The message stays on for a few seconds after the system stops adjusting brake pressure.
Page 222: Buckle Passenger
BUCKLE PASSENGER This message reminds you to buckle the passenger's safety belt. This message displays and a sound will be heard when the ignition is on, the driver's safety belt is buckled, the passenger's safety belt is unbuckled with the passenger airbag enabled, and the vehicle is in motion.
Page 223: Competitive Driving Mode
CHECK COOLANT LEVEL This message displays when the engine coolant level is low. Have the cooling system serviced by your dealer/ retailer as soon as possible. See CHECK GAS CAP This message displays if the fuel cap has not been fully tightened.
Page 224: Engine Overheated Stop Engine
COOLANT OVER TEMPERATURE This message displays and a sound will be heard if the engine coolant exceeds 124°C (255°F). If you have been operating the vehicle under normal driving conditions, pull off the road, stop the vehicle, and turn off the engine as soon as possible. You can monitor the coolant temperature with the gauges button on the DIC or the engine coolant temperature gauge on the instrument panel cluster.
Page 225: Ice Possible
Multiple chimes sound when this message is displayed. This message remains displayed and active until the issue is resolved. HEADLAMPS SUGGESTED This message displays if it is dark enough outside and the headlamps and the Twilight Sentinel off. This message informs the driver that turning on the exterior lamps is recommended.
Page 226: Low Oil Pressure
LOW OIL PRESSURE This message displays if low oil pressure levels occur. If this message appears while the engine is running, stop the engine and do not operate it until the cause of low oil pressure is corrected. Severe damage to the engine can result.
Page 227 MAXIMUM SPEED 129 km/h (80 MPH) This message displays when a malfunction is present in the Selective Ride Control system. The vehicle speed will be limited to a value determined by the vehicle when the shock absorber system has failed and the shocks are in their full soft mode.
Page 228 NO FOB - OFF OR RUN? This message displays when the keyless access transmitter is not detected inside the vehicle while you are trying to turn the ignition off. The vehicle may be near a strong radio antenna signal causing the keyless access system to be jammed.
Page 229 This system is available only on ZR1 models. See Performance Traction Management and Launch Control under for more information about the use of this mode. PERF TRAC 3 SPORT ACTIVE HANDLING ON This message displays and a sound will be heard when this Performance Traction Management mode is selected.
Page 230: Automatic Transmission Only
PERF TRAC 5 RACE ACTIVE HANDLING OFF This message displays and a sound will be heard when this Performance Traction Management mode is selected. The instrument panel cluster light will also be on when this mode is selected. Launch Control is available when this mode selected.
Page 231 SERVICE ACTIVE HANDLING SYSTEM This message displays if there is a problem with the Active Handling System and the vehicle needs service. The active handling system light on the instrument panel cluster also turns on and a sound will be heard. See your dealer/retailer.
Page 232: Service Electrical System
SERVICE CHARGING SYSTEM If this message displays while you are driving, there may be a problem with the electrical charging system. It could mean that there is a loose or broken drive belt or that there is another electrical problem. Have the vehicle checked right away by your dealer/retailer.
Page 233: Service Transmission
SERVICE TRACTION SYSTEM If this message displays when you are driving, there is a problem with the Traction Control System (TCS) and the vehicle is in need of service. See your dealer/retailer. When this message is displayed, the system will not limit wheel spin.
Page 234 The vehicle will remain in ACCESSORY, without the 20 minute time-out period, until the shift lever is moved to P (Park) or until the driver presses the pushbutton to restart the vehicle. See for more information. SHIFT TO PARK OR SET PARK BRAKE FOR TOP If the vehicle has an automatic transmission, this message displays and a sound will be heard if you...
Page 235 This message is followed by the MAXIMUM SPEED 90 km/h (55 MPH) message, and then by the REDUCED HANDLING message. The Active Handling System will intervene more quickly when a flat tire has been detected. Adjust your driving accordingly. You can receive more than one tire pressure message at a time.
Page 236 TRACTION SYSTEM AND ACTIVE HANDLING This message displays, the instrument panel cluster light turns on, and a sound will be heard when the Traction Control System (TCS) and Active Handling System are turned off by pressing the Active Handling System button on the console for five seconds. The Antilock Brake System (ABS) remains on with the TCS and Active Handling System off.
Page 237: Turn Signal On
TRANSMISSION HOT IDLE ENGINE This message displays and four chimes sound if the transmission fluid temperature rises above 132°C (270°F) or rises rapidly. The transmission may shift gears or apply the torque converter clutch to reduce the fluid temperature. Driving aggressively or driving on long hills can cause the transmission fluid temperature to be higher than normal.
Page 238: Other Messages
Other Messages Here are more messages that you can receive on your Driver Information Center (DIC). To acknowledge a message and read another message that may have come on at the same time, press the RESET button. ACCESSORY MODE ON BATTERY VOLTAGE HIGH BATTERY VOLTAGE LOW CHECK WASHER FLUID...
Page 239: Dic Vehicle Personalization
DIC Vehicle Personalization Many features on your vehicle can be personalized. This means that the operation of these features can be set to operate differently depending on who is driving the vehicle. See Personal Options later in this section for the features that you can personalize. The personalization settings for other features are automatically updated and saved as the driver adjusts them.
Page 240: Personal Options
Entering the Personal Options Menu To enter the personal options menu, use the following steps: 1. If you have an automatic transmission vehicle, turn the vehicle on with the shift lever in P (Park). If you have a manual transmission vehicle, turn the vehicle on with the parking brake set.
Page 241 Press the OPTION button until AUTO MEMORY RECALL appears on the display, then press the RESET button to scroll through the following modes: NO (default) If you choose YES, the driver's seat, the outside rearview mirrors and the telescopic steering column, if your vehicle has this feature, positions are recalled when you turn the ignition on.
Page 242 Approach Lights : This option briefly turns on the parking lamps, the high-beam headlamps and the back-up lamps during low light periods when the keyless access transmitter is used to unlock the vehicle. Press the OPTION button until APPROACH LIGHTS appears on the display, then press the RESET button to scroll through the following modes: ON (default)
Page 243 If you choose 90 S, the twilight delay time will be set to 90 seconds. When the mode you want is selected, press the OPTION button to set your choice and advance to the next personal option. Flash at Unlock : This option activates the front and rear turn signals for two short flashes when the unlock or hatch/trunk button on the keyless access transmitter is pressed.
Page 244 FOB Reminder : This option sounds the horn three times when the driver's door is closed and there is a keyless access transmitter inside the interior of the vehicle. This will only occur when the vehicle is off. Press the OPTION button until FOB REMINDER appears on the display, then press the RESET button to scroll through the following modes: NO (default)
Page 245 If you choose HORN, the doors will automatically lock and the horn will sound a short time after you remove a keyless access transmitter from the interior of the vehicle and close both doors. If you are parking in a quiet area and do not want the horn to sound when the doors lock, press the lock button on the keyless access transmitter immediately after removing it from the interior and closing the doors.
Page 246 When the mode you want is selected, press the OPTION button to set your choice and advance to the next personal option. Language : This option allows you to select the language the DIC, the Head-Up Display (HUD), if your vehicle has this feature, and the radio uses to display messages.
Page 247 4. Press the OPTION button and a cursor will display where you can insert a letter. 5. Press the OPTION button again until the letter you want is displayed. To scroll through the letters faster and without a beeping noise, keep the OPTIONS button depressed.
Page 248: Audio System(S)
Audio System(s) Determine which radio the vehicle has and read the following pages to become familiar with its features. WARNING: Taking your eyes off the road for extended periods could cause a crash resulting in injury or death to you or others. Do not give extended attention to entertainment tasks while driving.
Page 249: Playing The Radio
Radio(s) Single CD Radio shown, Six-Disc CD Radio similar The vehicle has one of these radios as its audio system. An indicator light on the upper left side of the radio flashes when the ignition is off, to indicate the theft deterrent feature is set.
Page 250: Audio Settings
Audio Settings Press and hold when no tone or speaker control is displayed to adjust all tone and speaker controls to the middle position. AUDIO SETTINGS CENTERED displays. Adjusting the Tone (Bass/Treble) (Bass/Treble): To adjust the Bass or Treble: Press and release until BASS or TREBLE displays.
Page 251 AUTO (Automatic Volume): Automatic volume automatically adjusts the audio system to make up for road and wind noise, by increasing the volume as vehicle speed increases. ® For vehicles without the Bose sound system: 1. Set the volume at the desired level. 2.
Page 252: Using The Radio
Using the Radio Radio Data System (RDS) RDS features are available for use only on FM stations that broadcast RDS information. The station name or call letters display while the radio is tuned to an RDS station. This system relies upon receiving specific information from these stations and works only when the information is available.
Page 253 To scan preset stations: Press and hold for four seconds until PRESET SCAN displays. The radio goes to the next preset station, plays for a few seconds, then goes to the next preset station. Press again or one of the pushbuttons to stop scanning presets.
Page 254: Radio Messages
SCAN : To scan the stations within a category: 1. Press CAT. The last selected category displays. 2. Turn the knob to select a category. 3. Press and hold until a beep sounds and SCAN CATEGORY displays. The radio begins scanning the stations in the category.
Page 255: Using The Cd Player
TRAF (Traffic) : TA (traffic) displays when the station broadcasts traffic announcements, the announcement will be played. Press TRAF and the radio seeks to a station that broadcasts traffic announcements. When a station is found, the radio stops seeking and TA displays. NO TRAFFIC INFO displays if a station that broadcasts traffic announcements can not be found.
Page 256: Playing A Cd
To insert multiple CDs: 1. Press and hold for two seconds. Two beeps sound and LOAD ALL DISCS displays. 2. Load a CD and insert the CD partway into the slot, label side up when INSERT CD # displays. The player pulls the CD in. 3.
Page 257 Six-Disc CD Radio: Press to eject the CD that is currently playing. To eject multiple CDs: 1. Press and hold for two seconds. A beep sounds and EJECT ALL displays. 2. The ejected CD can be removed when REMOVE DISC displays. To stop ejecting the CDs, press the The CD is automatically pulled back into the player if the CD is not removed after 25 seconds.
Page 258 (Song List): The Song List feature can save 20 track selections. To save tracks: 1. If S-LIST is displayed, press 2. Select the desired CD by pressing the numbered pushbutton and then use select the track to be saved. 3. Press and hold until a beep sounds and ADDED SONG displays.
Page 259: Using The Auxiliary Input Jack
Care of CDs and the CD Player Care of CDs Store CD(s) in their original cases or other protective cases and away from direct sunlight and dust. The CD player scans the bottom of the disc. If the bottom of a CD is damaged it may not play properly or at all.
Page 260: Using An Mp3
Connect a 3.5 mm (1/8 in.) cable to the radio s front auxiliary input jack to use a portable audio player. The radio displays AUX INPUT DEVICE when a device is connected and begins playing audio from that device. Top Knob (Power/Volume) : Turn to increase or decrease the volume of the portable player.
Page 261: File Naming
Supported Bit Rates The following bit rates are supported: 32 kbps, 40 kbps, 56 kbps, 64 kbps, 80 kbps, 96 kbps, 112 kbps, 128 kbps, 160 kbps, 192 kbps, 224 kbps, 256 kbps, and 320 kbps or a variable bit rate. File Naming ID3v1 and ID3v2 tags are supported.
Page 262 (Next Folder): Press to go to the first track in the next folder. Press and hold to fast forward the current track. RDM (Random) : Press to hear the tracks in random, rather than sequential order, on one CD, one folder, or all of the loaded CDs.
Page 263: Xm Radio Messages
XM Radio Messages XL (Explicit Language Channels) : These channels, or any others, can be blocked by calling 1-800-852-XMXM (9696). Updating : The encryption code in the receiver is being updated, and no action is required. This process should take no longer than 30 seconds. No Signal : The system is functioning correctly, but the vehicle is in a location that is blocking the XM signal.
Page 264: Voice Recognition
Navigation/Radio System For vehicles with a navigation radio system, see the separate Navigation System manual. ® Bluetooth Vehicles with a Bluetooth system can use a Bluetooth capable cell phone with a Hands Free Profile to make and receive phone calls. The system can be used while the key is in ON/RUN or ACC/ACCESSORY position.
Page 265: Pairing A Phone
Pairing A Bluetooth enabled cell phone must be paired to the in vehicle Bluetooth system first and then connected to the vehicle before it can be used. See the cell phone manufacturers user guide for Bluetooth functions before pairing the cell phone. If a Bluetooth phone is not connected, calls will be made using OnStar Free Calling, if available.
Page 266: Storing Name Tags
Listing All Paired and Connected Phones 1. Press and hold for two seconds. The system responds with Ready followed by a tone. 2. Say Bluetooth . The system responds with Bluetooth ready followed by a tone. 3. Say List . The system lists all the paired Bluetooth devices.
Page 267 Using the Store Command The store command allows a phone number to be stored without entering the digits individually. 1. Press and hold for two seconds. The system responds with Ready followed by a tone. 2. Say Store . The system responds with Store, number please followed by a tone.
Page 268: Deleting Name Tags
3. Say the first digit to be stored. The system will repeat back the digit it heard followed by a tone. Continue entering digits until the number to be stored is complete. If an unwanted number is recognized by the system, say Clear at any time to clear the last number.
Page 269: Making A Call
3. Say the name tag to be deleted. The system responds with Would you like to delete, <name tag>? Please say yes or no . If the name tag is correct, say Yes to delete the name tag. The system responds with OK, deleting <name tag>, returning to the main menu.
Page 270 Using the Digit Dial Command 1. Press and hold for two seconds. The system responds with Ready followed by a tone. 2. Say Digit Dial . The system responds with Digit dial using <phone name>, please say the first digit to dial followed by a tone.
Page 271: Call Waiting
Using the Re dial Command 1. Press and hold for two seconds. The system responds with Ready followed by a tone. 2. After the tone, say Re dial . The system responds with Re dial using <phone name> and dials the last number called from the connected Bluetooth phone.
Page 272: Bluetooth System
Ending a Call Press to end a call. Muting a Call During a call, all sounds from inside the vehicle can be muted so that the person on the other end of the call cannot hear them. To Mute a call 1.
Page 273: Voice Pass-Thru
Voice Pass-Thru Voice Pass Thru allows access to the voice recognition commands on the cell phone. See the cell phone manufacturers user guide to see if the cell phone supports this feature. This feature can be used to verbally access contacts stored in the cell phone. 1.
Page 274: Other Information
Sending a Stored Name Tag During a Call 1. Press . The system responds with Ready followed by a tone. 2. Say Send name tag. The system responds with Say a name tag to send tones followed by a tone. 3.
Page 275: Audio Steering Wheel Controls
Audio Steering Wheel Controls For vehicles with steering wheel controls, some audio controls can be adjusted at the steering wheel. (Mute/Push to Talk): Press to silence the vehicle speakers only. Press again to turn the sound on. For vehicles with Bluetooth or OnStar and hold for longer than two seconds to interact with those systems.
Page 276: Radio Reception
To select tracks on a CD: Press to go to the next or to the previous track when a CD is playing. Press and hold for more than two seconds to scan the current CD. The CD goes to the next track, plays the first 10 seconds, then goes to the next track.
Page 277: Cellular Phone Usage
Satellite Radio Service XM Satellite Radio Service gives digital radio reception from coast-to-coast in the 48 contiguous United States, and in Canada. Just as with FM, tall buildings or hills can interfere with satellite radio signals, causing the sound to fade in and out. In addition, traveling or standing under heavy foliage, bridges, garages, or tunnels may cause loss of the XM signal for a period of time.
Page 278 NOTES 4-110...
Page 279 Defensive Driving ....... 5-2 Drunk Driving ........5-2 Control of a Vehicle .
Page 280 Defensive driving means always expect the unexpected. The first step in driving defensively is to wear your safety belt Assume that other road users (pedestrians, bicyclists, and other drivers) are going to be careless and make mistakes. Anticipate what they might do and be ready.
Page 281 For persons under 21, it is against the law in every U.S. state to drink alcohol. There are good medical, psychological, and developmental reasons for these laws. The obvious way to eliminate the leading highway safety problem is for people never to drink alcohol and then drive.
Page 282 Braking action involves perception time and reaction time. Deciding to push the brake pedal is perception time. Actually doing it is reaction time. Average reaction time is about three fourths of a second. But that is only an average. It might be less with one driver and as long as two or three seconds or more with another.
Page 283 This vehicle has the Antilock Brake System (ABS), an advanced electronic braking system that helps prevent a braking skid. When the engine is started and the vehicle begins to drive away, ABS checks itself. A momentary motor or clicking noise might be heard while this test is going on, and it might even be noticed that the brake pedal moves a little.
Page 284 ABS allows the driver to steer and brake at the same time. In many emergencies, steering can help more than even the very best braking. This vehicle has a brake assist feature that responds to emergency braking by generating additional pressure and engaging the ABS.
Page 285 The SERVICE TRACTION SYSTEM message and the TCS warning light will come on if there is a problem with TCS. When this light and the SERVICE TRACTION SYSTEM message are on, the system will not limit wheel spin. Adjust your driving accordingly. TCS automatically comes on whenever the vehicle is started.
Page 286 The Active Handling System is a computer controlled system that helps the driver maintain directional control of the vehicle in difficult driving conditions. This is accomplished by selectively applying any one of the vehicle's brakes. The ACTIVE HANDLING message will come on when the system is operating.
Page 287 If the Tire Pressure Monitor (TPM) system detects a flat tire and the Driver Information Center (DIC) displays TIRE FLAT, or if the TPM system is malfunctioning and the DIC displays SERVICE TIRE MONITOR, the Active Handling System will be affected as follows: The Active Handling System cannot be turned off by the driver.
Page 288 This light is on when the vehicle is in the Competitive Driving Mode. This optional handling mode can be selected by pressing the ACTIVE HANDLING button on the console quickly two times. COMPETITIVE DRIVING MODE displays in the Driver Information Center (DIC). more information.
Page 289 To experience the performance benefit of this system, after entering a curve and at the point where the driver would normally start to increase acceleration, the accelerator pedal can be fully pressed. The Performance Traction Management system will modify the level of engine power for a smooth and consistent corner exit.
Page 290 For use by drivers who are familiar with the track Dry conditions only Requires more driving skill than mode 2 Active Handling is on and more engine power is available than in mode 2 For use by drivers who are familiar with the track Dry conditions only Requires more driving skill than modes 2 or 3 Active Handling is off and available engine power...
Page 291 A Launch Control feature is available, within Competitive Driving Mode (except ZR1) or Performance Traction Management (ZR1), on vehicles with a manual transmission to allow the driver to achieve high levels of vehicle acceleration in a straight line. Launch Control is a form of traction control that manages tire spin while launching the vehicle.
Page 292 Vehicles with a limited-slip rear axle can give more traction on snow, mud, ice, sand or gravel. It works like a standard axle most of the time, but when traction is low, this feature allows the drive wheel with the most traction to move the vehicle.
Page 293 Three Driver Information Center (DIC) messages (SERVICE RIDE CONTROL, SHOCKS INOPERATIVE and MAXIMUM SPEED 80 MPH (129 KM/H) display when a malfunction occurs with the Selective Ride Control system . Refer to for more information. This knob is located on the center console.
Page 294 If power steering assist is lost because the engine stops or the system is not functioning, the vehicle can be steered but it will take more effort. This system continuously adjusts the effort felt when steering at all vehicle speeds. It provides ease when parking, yet a firm, solid feel at highway speeds.
Page 295 An emergency like this requires close attention and a quick decision. If holding the steering wheel at the recommended 9 and 3 o'clock positions, it can be turned a full 180 degrees very quickly without removing either hand. But you have to act fast, steer quickly, and just as quickly straighten the wheel once you have avoided the object.
Page 296 Passing another vehicle on a two-lane road can be dangerous. To reduce the risk of danger while passing: Look down the road, to the sides, and to crossroads for situations that might affect a successful pass. If in doubt, wait. Watch for traffic signs, pavement markings, and lines that could indicate a turn or an intersection.
Page 297 If the vehicle starts to slide, ease your foot off the accelerator pedal and quickly steer the way you want the vehicle to go. If you start steering quickly enough, the vehicle may straighten out. Always be ready for a second skid if it occurs.
Page 298 After conversion to the high performance brake fluid, follow the brake fluid service recommendations outlined by the fluid manufacturer. Do not use silicone or DOT 5 brake fluids. If the vehicle is a Z06, ZR1, or Grand Sport model, it has greaseable outer ends on both of the rear toe links.
Page 299 Run this procedure in a safe manner and in compliance with all local and state ordinances/laws regarding motor vehicle operation. Run this procedure only on dry pavement. 1. From a stop, accelerate as rapidly as possible without activating traction control to a speed of 97 kph (60 mph).
Page 300 Night driving is more dangerous than day driving because some drivers are likely to be impaired alcohol or drugs, with night vision problems, or by fatigue. Night driving tips include: Drive defensively. Do not drink and drive. Reduce headlamp glare by adjusting the inside rearview mirror.
Page 301 Hydroplaning is dangerous. Water can build up under your vehicle's tires so they actually ride on the water. This can happen if the road is wet enough and you are going fast enough. When your vehicle is hydroplaning, it has little or no contact with the road. There is no hard and fast rule about hydroplaning.
Page 302 Always be alert and pay attention to your surroundings while driving. If you become tired or sleepy, find a safe place to park your vehicle and rest. Other driving tips include: Keep the vehicle well ventilated. Keep interior temperature cool. Keep your eyes moving scan the road ahead and to the sides.
Page 303 Coasting downhill in N (Neutral) or with the ignition off is dangerous. The brakes will have to do all the work of slowing down and they could get so hot that they would not work well. You would then have poor braking or even none going down a hill.
Page 304 improves vehicle stability during hard stops on a slippery roads, but apply the brakes sooner than when on dry pavement. Allow greater following distance on any slippery road and watch for slippery spots. Icy patches can occur on otherwise clear roads in shaded areas. The surface of a curve or an overpass can remain icy when the surrounding roads are clear.
Page 305 For more information about carbon monoxide, see Snow can trap exhaust gases under your vehicle. This can cause deadly CO (carbon monoxide) gas to get inside. CO could overcome you and kill you. You cannot see it or smell it, so you might not know it is in your vehicle.
Page 306 Turn the steering wheel left and right to clear the area around the front wheels. Turn the traction control system off. Shift back and forth between R (Reverse) and a forward gear, spinning the wheels as little as possible. For a manual transmission, shift slowly between either 1 (First) or 2 (Second) and R (Reverse), allowing the wheels to stop before shifting into gear.
Page 307 A vehicle specific Tire and Loading Information label is attached to the center pillar (B-pillar) of your vehicle. With the driver's door open, you will find the label attached below the door latch. This label shows the number of occupant seating positions (A), and the maximum vehicle capacity weight (B) in kilograms and pounds.
Page 308 The resulting figure equals the available amount of cargo and luggage load capacity. For example, if the XXX amount equals 1400 lbs and there will be five 150 lb passengers in your vehicle, the amount of available cargo and luggage load capacity is 650 lbs (1400 750 (5 x 150) = 650 lbs).
Page 309 Vehicle Capacity Weight for Example 2 = Subtract Occupant Weight @ 150 lbs (68 kg) x 2 = Available Cargo Weight = 400 lbs (181 kg) 300 lbs (136 kg) 100 lbs (45 kg) Vehicle Capacity Weight for 400 lbs (181 kg) Example 3 = Subtract Occupant Weight @ 200 lbs...
Page 310 Refer to your vehicle's Tire and Loading Information label for specific information about your vehicle's capacity weight and seating positions. The combined weight of the driver, passengers and cargo should never exceed your vehicle's capacity weight. A vehicle specific Certification label is attached to the rear edge of the driver's door.
Page 311 If you put things inside your vehicle suitcases, tools, packages or anything else they will go as fast as the vehicle goes. If you have to stop or turn quickly, or if there is a crash, they will keep going. Things you put inside your vehicle can strike and injure people in a sudden stop or turn, or in a crash.
Page 312 5-34...
Page 313 Section 6 Service ..........6-3 Accessories and Modifications .
Page 314 Section 6 Run-Flat Tires ....... . . 6-69 Inflation - Tire Pressure ......6-70 High-Speed Operation .
Page 315: Service
Service For service and parts needs, visit your dealer/retailer. You will receive genuine GM parts and GM-trained and supported service people. Genuine GM parts have one of these marks: Accessories and Modifications When non dealer/non retailer accessories are added to the vehicle, they can affect vehicle performance and safety, including such things as airbags, braking, stability, ride and handling, emissions systems, aerodynamics, durability, and electronic systems...
Page 316: California Proposition 65 Warning
Damage to vehicle components resulting from the installation or use of non GM certified parts, including control module modifications, is not covered under the terms of the vehicle warranty and may affect remaining warranty coverage for affected parts. GM Accessories are designed to complement and function with other systems on the vehicle.
Page 317: Doing Your Own Service Work
Doing Your Own Service Work WARNING: You can be injured and the vehicle could be damaged if you try to do service work on a vehicle without knowing enough about it. Be sure you have sufficient knowledge, experience, the proper replacement parts, and tools before attempting any vehicle maintenance task.
Page 318: Fuel
Fuel Use of the recommended fuel is an important part of the proper maintenance of this vehicle. To help keep the engine clean and maintain optimum vehicle performance, we recommend the use of gasoline advertised as TOP TIER Detergent Gasoline. Look for the TOP TIER label on the fuel pump to ensure gasoline meets enhanced detergency standards developed by auto companies.
Page 319: Gasoline Octane
Gasoline Octane If the vehicle has the 6.2L V8 engine (VIN Code W), use premium unleaded gasoline with a posted octane rating of 91 or higher. You can also use regular unleaded gasoline rated at 87 octane or higher, but the vehicle's acceleration could be slightly reduced, and a slight audible knocking noise, commonly referred to as spark knock, might be heard.
Page 320: Additives
Additives To provide cleaner air, all gasolines in the United States are now required to contain additives that help prevent engine and fuel system deposits from forming, allowing the emission control system to work properly. In most cases, nothing should have to be added to the fuel. However, some gasolines contain only the minimum amount of additive required to meet U.S.
Page 321: Fuels In Foreign Countries
Fuels in Foreign Countries If you plan on driving in another country outside the United States or Canada, the proper fuel might be hard to find. Never use leaded gasoline or any other fuel not recommended in the previous text on fuel. Costly repairs caused by use of improper fuel would not be covered by the vehicle warranty.
Page 322 The fuel door release button is located on the instrument panel to the left of the steering wheel. Push the button to release the fuel door. 6-10 There is also a manual fuel door release tab. It is located against the upper trim in the rear compartment on the driver side of the vehicle.
Page 323 WARNING: Fuel can spray out on you if you open the fuel cap too quickly. If you spill fuel and then something ignites it, you could be badly burned. This spray can happen if the tank is nearly full, and is more likely in hot weather.
Page 324: Filling A Portable Fuel Container
Filling a Portable Fuel Container WARNING: Never fill a portable fuel container while it is in the vehicle. Static electricity discharge from the container can ignite the fuel vapor. You can be badly burned and the vehicle damaged if this occurs.
Page 325: Hood Release
Hood Release To open the hood: 1. Pull the hood release lever with this symbol on it. It is located inside the vehicle below the instrument panel on the driver side. 2. Go to the side of the vehicle and pull up on the Before closing the hood, be sure all the filler caps are on properly.
Page 326: Engine Compartment Overview
Engine Compartment Overview If the vehicle has the 6.2 L LS3 V8 engine (without the dry sump engine oil tank) and you are facing the front of the vehicle, when the hood is opened: 6-14...
Page 327 A. Clutch Master Cylinder Reservoir (If Equipped). B. Windshield Washer Fluid Reservoir. See Adding Washer Fluid under C. Brake Fluid Reservoir. See Brake Fluid under D. Coolant Surge Tank and Pressure Cap. F. Power Steering Fluid Reservoir. See G. Engine Oil Fill Cap. See When to Add Engine Oil under H.
Page 328 If the vehicle has the 6.2 L LS9 Supercharged V8 engine and you are facing the front of the vehicle, when the hood is opened: 6-16...
Page 329 A. Intercooler. See C. Power Steering Fluid Reservoir and Cap. D. Coolant Surge Tank and Pressure Cap. E. Windshield Washer Fluid Reservoir. See Adding Washer Fluid under F. Clutch Master Cylinder Reservoir (If Equipped). G. Brake Fluid Reservoir. See Brake Fluid under H.
Page 330 If the vehicle has the 6.2 L LS3 V8 engine with the manual transmission (with the dry sump engine oil tank) or the 7.0 L LS7 V8 engine and you are facing the driver side of the vehicle, when the hood is opened: 6-18...
Page 331: Engine Oil
B. Power Steering Fluid Reservoir. See D. Remote Positive (+) Terminal (Out of View). E. Engine Oil Dipstick. See Checking Engine Oil under F. Dry Sump Engine Oil Tank. See Changing Engine Oil and Filter G. Engine Oil Fill Cap. See When to Add Engine Oil under H.
Page 332: When To Add Engine Oil
When to Add Engine Oil (Except ZO6, ZR1, and Grand Sport) If the oil is below the cross-hatched area at the tip of the dipstick, add at least one liter/quart of the recommended oil. This section explains what kind of oil to use. For engine oil crankcase capacity, for additional information on engine oil.
Page 333 Checking Engine Oil (ZO6, ZR1, and Grand Sport) A. Engine Oil Dipstick B. Engine Oil Fill Cap It is a good idea to check the engine oil level at each fuel fill. In order to get an accurate reading, the oil must be warm and the vehicle must be on level ground.
Page 334 cold engine dipstick readings. The engine oil level on the dipstick will also be inaccurate if checked while the engine is running. 1. To obtain an accurate engine oil level reading, warm up the engine to at least 80°C (175°F). Cold oil will not give a correct oil level reading.
Page 335: Changing Engine Oil And Filter
for the location of the external engine oil tank and fill cap. Add enough oil to put the level somewhere in the proper operating range. Push the dipstick all the way back into the oil tank when through. Changing Engine Oil and Filter (ZO6, ZR1, and Grand Sport) These vehicles have a racetrack ready dry sump engine lubrication system.
Page 336: What Kind Of Engine Oil To Use
2. Once the oil has been drained from the engine, remove the engine oil filter and allow the oil to drain. 3. Re install both drain plugs and tighten them to (18 lb ft). 4. Replace the oil filter and tighten it to 30 (22 lb ft).
Page 337: Engine Oil Additives / Engine Oil Flushes
Oils meeting these requirements should have the starburst symbol on the container. This symbol indicates that the oil has been certified by the American Petroleum Institute (API). This vehicle's engine was filled at the factory with a ® Mobil 1 synthetic oil meeting all requirements for this vehicle.
Page 338: How To Reset The Engine Oil Life System
Z06, ZR1, and Grand Sport models have a racetrack ready dry sump engine lubrication system. This high performance system operates differently than a standard engine lubrication system and requires a special procedure when changing the engine oil and filter. See When the system has calculated that oil life has been diminished, it indicates that an oil change is necessary.
Page 339: What To Do With Used Oil
What to Do with Used Oil Used engine oil contains certain elements that can be unhealthy for your skin and could even cause cancer. Do not let used oil stay on your skin for very long. Clean your skin and nails with soap and water, or a good hand cleaner.
Page 340 To inspect or replace the engine air cleaner/filter: 1. Open the hood. See 6.2 L V8 Engine LS3 shown, 6.2 L V8 Engine LS9 and 7.0 L V8 Engine LS7 similar A. Tube B. Clamp C. Duct 2. Remove the tube (A) from the air cleaner assembly.
Page 341 6.2 L V8 Engine LS3 6.2 L V8 Engine LS9 shown, 7.0 L V8 Engine LS7 similar 6. To access the air filter element, gently pull the air cleaner assembly upward until the fasteners are released from the retainer pins in the upper radiator support.
Page 342 6.2 L V8 Engine LS3 shown, 6.2 L V8 Engine LS9 and 7.0 L V8 Engine LS7 similar A. Screw B. Filter Cover C. Filter 7. To remove the filter from the LS3 and LS7 engines, remove the six screws (A) securing the filter cover (B) then pull away from to gain access to the air filter (C).
Page 343: Automatic Transmission Fluid
Automatic Transmission Fluid How to Check Automatic Transmission Fluid It is not necessary to check the transmission fluid level. A transmission fluid leak is the only reason for fluid loss. If a leak occurs, take the vehicle to your dealer/ retailer service department and have it repaired as soon as possible.
Page 344: When To Check And What To Use
When to Check and What to Use The hydraulic clutch fluid reservoir cap has this symbol on it. See reservoir location. Refer to the Maintenance Schedule for the proper fluid to use. See . The fluid requires changing every two years. See How to Check and Add Fluid Visually check the clutch fluid reservoir to make sure the fluid level is at the MIN (minimum) line on the side...
Page 345: Cooling System (Intercooler)
WARNING: An electric engine cooling fan under the hood can start up even when the engine is not running and can cause injury. Keep hands, clothing, and tools away from any underhood electric fan. WARNING: Heater and radiator hoses, and other engine parts, can be very hot.
Page 346: Engine Coolant
Checking Coolant 1. Verify that the engine and intercooler are no longer hot. 2. Place a cloth to absorb possible coolant loss under the driver's side bleeder valve (A). 6-34 3. Loosen, but do not completely unscrew the bleeder valve to check for coolant in the system. 4.
Page 347: Checking Coolant
What to Use WARNING: Adding only plain water to the cooling system can be dangerous. Plain water, or some other liquid such as alcohol, can boil before the proper coolant mixture will. The vehicle's coolant warning system is set for the proper coolant mixture. With plain water or the wrong mixture, the engine could get too hot but would not get the overheat warning.
Page 348: How To Add Coolant To The Coolant Surge Tank
The engine coolant surge tank is located toward the rear of the engine compartment on the driver side of the vehicle. for more information on location. When the engine is cold, the coolant level should be at the FULL COLD mark on the coolant surge tank. When the engine is hot, the level could be higher than the FULL COLD line.
Page 349 If coolant is needed, add the proper DEX-COOL coolant mixture directly to the surge tank, but be sure the cooling system is cool before this is done. 1. When the cooling system, including the coolant surge tank pressure cap and upper radiator hose, is no longer hot, remove the pressure cap.
Page 350: Engine Overheating
4. With the coolant surge tank pressure cap off, start the engine and let it run until you can feel the upper radiator hose getting hot. Any time during this procedure, watch out for the engine cooling fan. By this time, the coolant level inside the coolant surge tank may be lower.
Page 351: If Steam Is Coming From Your Engine
If you do decide to lift the hood , make sure the vehicle is parked on a level surface. Then check to see if the engine cooling fan is running. If the engine is overheating, the fan should be running. If it is not, do not continue to run the engine and have the vehicle serviced.
Page 352: If No Steam Is Coming From Your Engine
If No Steam Is Coming From Your Engine If an engine overheat warning is displayed but no steam can be seen or heard, the problem may not be too serious. Sometimes the engine can get a little too hot when the vehicle: Climbs a long hill on a hot day.
Page 353: Overheated Engine Protection Operating Mode
Overheated Engine Protection Operating Mode This emergency operating mode lets the vehicle be driven to a safe place, up to 50 miles (80 km), in an emergency situation. If an overheated engine condition exists and the messages COOLANT OVER TEMPERATURE and REDUCED ENGINE POWER are displayed, along with the check engine light, an overheat protection mode which alternates firing groups of cylinders helps prevent engine damage.
Page 354: How To Check Power Steering Fluid
How to Check Power Steering Fluid To check the power steering fluid: 1. Turn the ignition off and let the engine compartment cool down. 2. Wipe the cap and the top of the reservoir clean. 3. Unscrew the cap and wipe the dipstick with a clean rag.
Page 355: Adding Washer Fluid
Adding Washer Fluid Open the cap with the washer symbol on it. Add washer fluid until the tank is full. See reservoir location. When using concentrated washer fluid, follow the manufacturer's instructions for adding water. Do not mix water with ready-to-use washer fluid.
Page 356: Checking Brake Fluid
Do not top off the brake fluid. Adding fluid does not correct a leak. If fluid is added when the linings are worn, there will be too much fluid when new brake linings are installed. Add or remove brake fluid, as necessary, only when work is done on the brake hydraulic system.
Page 357 Using the wrong fluid can badly damage brake hydraulic system parts. For example, just a few drops of mineral-based oil, such as engine oil, in the brake hydraulic system can damage brake hydraulic system parts so badly that they will have to be replaced. Do not let someone put in the wrong kind of fluid.
Page 358 Brake Wear (ZR1 Only) The ZR1 model does not have built-in brake pad wear indicators and periodic visual inspection of the brake pads is required to determine when to replace the brake pads. Continuing to drive with worn-out brake pads could result in costly brake repair. Make sure that the brakes have been given sufficient time to cool and then set the park brake.
Page 359 Brake Rotor Wear ZR1 models have ceramic brake rotors. Rotors should be visually inspected whenever the brake pads are replaced. Rotors also need to be weighed before brake pads are replaced to confirm that the rotor mass is greater than the wear out mass printed on the rotor. The rotor can be reused if the weight of the rotor is above the mass limit.
Page 360: Brake Adjustment
A rotor protector should always be installed before any wheel removal. The protector can be installed by feeding it through the wheel spokes and slipping it over the outer edge of the rotor. Leave the protector in place, over the rotor edge, until the wheel is re installed. Rotor protectors are available through your dealer/retailer.
Page 361: Vehicle Storage
Battery Refer to the replacement number on the original battery label when a new battery is needed. For battery replacement, see your dealer/retailer or the service manual. To purchase a service manual, DANGER: Battery posts, terminals, and related accessories contain lead and lead compounds, chemicals known to the State of California to cause cancer and reproductive harm.
Page 362: Jump Starting
Jump Starting If your battery has run down, you may want to use another vehicle and some jumper cables to start your vehicle. Be sure to use the following steps to do it safely. WARNING: Batteries can hurt you. They can be dangerous because: They contain acid that can burn you.
Page 363 4. Open the hoods and locate the positive (+) and negative ( ) terminal locations on each vehicle. 6.2 L LS3 shown, 7.0 L LS7 and 6.2 L LS9 similar Your vehicle has a remote positive (+) terminal (A) and a remote negative ( ) terminal (B), as shown in the illustration, which should be used to jump start your vehicle.
Page 364 WARNING: Using an open flame near a battery can cause battery gas to explode. People have been hurt doing this, and some have been blinded. Use a flashlight if you need more light. Be sure the battery has enough water. You do not need to add water to the battery installed in your new vehicle.
Page 365 6. Connect the red positive (+) cable to the positive (+) terminal of the dead battery. Use a remote positive (+) terminal if the vehicle has one. 7. Do not let the other end touch metal. Connect it to the positive (+) terminal of the good battery. Use a remote positive (+) terminal if the vehicle has one.
Page 366 If the jumper cables are connected or removed in the wrong order, electrical shorting may occur and damage the vehicle. The repairs would not be covered by the vehicle warranty. Always connect and remove the jumper cables in the correct order, making sure that the cables do not touch each other or other metal.
Page 367: Headlamp Aiming
Rear Axle When to Check Lubricant It is not necessary to regularly check rear axle fluid unless you suspect there is a leak or you hear an unusual noise. A fluid loss could indicate a problem. Have it inspected and repaired. How to Check Lubricant To get an accurate reading, the vehicle should be on a level surface.
Page 368: Bulb Replacement
Bulb Replacement For the proper type of replacement bulbs, see For any bulb changing procedure not listed in this section, contact your dealer/retailer. High Intensity Discharge (HID) Lighting WARNING: The low beam high intensity discharge lighting system operates at a very high voltage. If you try to service any of the system components, you could be seriously injured.
Page 369 If the low-beam headlamp needs to be replaced, see your dealer/retailer. See for more information. To replace a high-beam or front parking/turn signal/ DRL bulb: 1. Turn the wheel to allow access to the wheel well. 2. Remove the three outer fasteners to move the access panel back.
Page 370: Taillamps, Turn Signal, And Stoplamps
Taillamps, Turn Signal, and Stoplamps To replace a stoplamp, taillamp/turn signal bulb: 1. Remove the screw from the top of the lamp assembly. 2. Tilt the lamp assembly toward you. 3. Turn the bulb socket one-quarter turn counterclockwise and pull it out. 6-58 4.
Page 371: Windshield Replacement
Windshield Replacement The windshield is part of the Head-Up Display (HUD) system. If you ever have to get the windshield replaced, get one that is designed for HUD or the HUD image may look out of focus. Windshield Wiper Blade Replacement Windshield wiper blades should be inspected for wear and cracking.
Page 372 A. Blade Assembly D. Blade Pivot B. Arm Assembly E. Hook Slot C. Locking Tab F. Arm Hook 6-60 3. Press down on the blade assembly pivot locking tab (C). Pull down on the blade assembly (A) to release it from the wiper arm hook (F). 4.
Page 373 To install the new wiper insert: 1. Slide the insert (D), notched end last, into the end with the two blade claws (A). Slide the insert all the way through the blade claws at the opposite end (B). The plastic caps (C) will be forced off as the insert is fully installed.
Page 374: Tires
Tires Your new vehicle comes with high-quality tires made by a leading tire manufacturer. If you ever have questions about your tire warranty and where to obtain service, see your vehicle Warranty booklet for details. For additional information refer to the tire manufacturer. WARNING: Poorly maintained and improperly used tires are dangerous.
Page 375: Winter Tires
Low Profile Performance Tire The original equipment tires on your vehicle are classified as low profile performance tires. These tires are designed for very responsive driving on wet or dry pavement. You may also notice more road noise with low profile tires and that they tend to wear faster.
Page 376: Tire Sidewall Labeling
Tire Sidewall Labeling Useful information about a tire is molded into its sidewall. The example below shows a typical passenger (p metric) tire sidewall. Passenger (P Metric) Tire Example (A) Tire Size The tire size is a combination of letters and numbers used to define a particular tire's width, height, aspect ratio, construction type, and service description.
Page 377: Tire Size
(F) Uniform Tire Quality Grading (UTQG) manufacturers are required to grade tires based on three performance factors: treadwear, traction and temperature resistance. For more information (G) Maximum Cold Inflation Load Limit Maximum load that can be carried and the maximum pressure needed to support that load. Tire Size The following illustration shows an example of a typical passenger (p metric) vehicle tire size.
Page 378: Tire Terminology And Definitions
Tire Terminology and Definitions Air Pressure The amount of air inside the tire pressing outward on each square inch of the tire. Air pressure is expressed in pounds per square inch (psi) or kilopascal (kPa). Accessory Weight This means the combined weight of optional accessories.
Page 379 Intended Outboard Sidewall asymmetrical tire, that must always face outward when mounted on a vehicle. Kilopascal (kPa) The metric unit for air pressure. Light Truck (LT Metric) Tire duty trucks and some multipurpose passenger vehicles. Load Index An assigned number ranging from 1 to 279 that corresponds to the load carrying capacity of a tire.
Page 380 Radial Ply Tire A pneumatic tire in which the ply cords that extend to the beads are laid at 90 degrees to the centerline of the tread. A metal support for a tire and upon which the tire beads are seated. Sidewall The portion of a tire between the tread and the bead.
Page 381: Run-Flat Tires
Run-Flat Tires This vehicle, when new, had run-flat tires. There is no spare tire, no tire changing equipment, and no place to store a tire in the vehicle. Run-flat tires perform so well without any air that a Tire Pressure Monitor System (TPMS) is used to alert you if a tire has lost pressure.
Page 382: Inflation - Tire Pressure
To locate the nearest GM or run-flat servicing facility, call Roadside Assistance. For phone numbers and Roadside Service details see WARNING: Run-flat tires are constructed differently than other tires and could explode during improper service. You or others could be injured or killed if you attempt to repair, replace, dismount, or mount a run-flat tire.
Page 383: How To Check
A vehicle specific Tire and Loading Information label is attached to your vehicle. This label shows your vehicle's original equipment tires and the correct inflation pressures for your tires when they are cold. The recommended cold tire inflation pressure, shown on the label, is the minimum amount of air pressure needed to support your vehicle's maximum load carrying capacity.
Page 384: High-Speed Operation
High-Speed Operation WARNING: Driving at high speeds, 160 km/h (100 mph) or higher, puts an additional strain on tires. Sustained high-speed driving causes excessive heat build up and can cause sudden tire failure. You could have a crash and you or others could be killed.
Page 385 As an added safety feature, your vehicle has been equipped with a tire pressure monitoring system (TPMS) that illuminates a low tire pressure telltale when one or more of your tires is significantly under inflated. Accordingly, when the low tire pressure telltale illuminates, you should stop and check your tires as soon as possible, and inflate them to the proper pressure.
Page 386: Tire Pressure Monitor Operation
Tire Pressure Monitor Operation This vehicle may have a Tire Pressure Monitor System (TPMS). The TPMS is designed to warn the driver when a low tire pressure condition exists. TPMS sensors are mounted onto each tire and wheel assembly on your vehicle.
Page 387: Tpms Malfunction Light And Message
TPMS Malfunction Light and Message The TPMS will not function properly if one or more of the TPMS sensors are missing or inoperable. When the system detects a malfunction, the low tire warning light flashes for about one minute and then stays on for the remainder of the ignition cycle.
Page 388: Tire Inspection And Rotation
Tire Inspection and Rotation We recommend that you regularly inspect your vehicle's tires for signs of wear or damage Also check for damaged wheels. See The tires on your vehicle are different sizes front to rear. Due to this, the tires should not be rotated. Each tire and wheel should be used only in the position it is in.
Page 389: Buying New Tires
You need a new tire if any of the following statements are true: You can see the indicators at three or more places around the tire. You can see cord or fabric showing through the tire's rubber. The tread or sidewall is cracked, cut or snagged deep enough to show cord or fabric.
Page 390 GM recommends replacing tires in sets of four. This is because uniform tread depth on all tires will help keep your vehicle performing most like it did when the tires were new. Replacing less than a full set of tires can affect the braking and handling performance of your vehicle.
Page 391: Different Size Tires And Wheels
Different Size Tires and Wheels If you add wheels or tires that are a different size than your original equipment wheels and tires, this may affect the way your vehicle performs, including its braking, ride and handling characteristics, stability, and resistance to rollover . Additionally, if your vehicle has electronic systems such as, antilock brakes, traction control, and electronic stability control, the performance of these systems can be affected.
Page 392 While the tires available on General Motors passenger cars and light trucks may vary with respect to these grades, they must also conform to federal safety requirements and additional General Motors Tire Performance Criteria (TPC) standards. All Passenger Car Tires Must Conform to Federal Safety Requirements In Addition To These Grades.
Page 393: Wheel Alignment And Tire Balance
Temperature A, B, C The temperature grades are A (the highest), B, and C, representing the tire's resistance to the generation of heat and its ability to dissipate heat when tested under controlled conditions on a specified indoor laboratory test wheel. Sustained high temperature can cause the material of the tire to degenerate and reduce tire life, and excessive temperature can lead to...
Page 394 If you need to replace any of your wheels, wheel bolts or wheel nuts, replace them only with new GM original equipment parts. This way, you will be sure to have the right wheel, wheel bolts, and wheel nuts for your vehicle.
Page 395 Tightening Wheel Lug Nuts WARNING: Never use oil or grease on studs or the threads of the wheel nuts. If you do, the wheel nuts might come loose and the wheel could fall off, causing a crash. WARNING: Incorrect wheel nuts or improperly tightened wheel nuts can cause the wheel to become loose and even come off.
Page 396: Tire Chains
Tire Chains WARNING: Do not use tire chains. There is not enough clearance. Tire chains used on a vehicle without the proper amount of clearance can cause damage to the brakes, suspension, or other vehicle parts. The area damaged by the tire chains could cause you to lose control of the vehicle and you or others may be injured in a crash.
Page 397 Make sure the jack you are using spans at least two crossmember ribs. Lift only in the areas shown in the following pictures. For additional information, see your dealer/retailer and the Chevrolet Corvette service manual. 6-85...
Page 398: Lifting From The Front
Lifting From the Front The front lifting points can be accessed from either side of your vehicle, behind the front tires. 6-86 1. Locate the front lifting points (A), according to the illustration shown. 2. Be sure to place a block or pad between the jack and the vehicle.
Page 399: Lifting From The Rear
Lifting From the Rear The rear lifting points can be accessed from the rear of the vehicle, on either the driver's or passenger's side. 3. Lift the vehicle with the jack, making sure the jack spans at least two of the crossmember ribs (B). 6-87...
Page 400 1. Locate the rear lifting points (A), according to the illustration shown. 2. Be sure to place a block or pad between the jack and the vehicle. 6-88 3. Lift the vehicle with the jack, making sure the jack spans at least two of the crossmember ribs (B). For more information, see...
Page 401: If A Tire Goes Flat
If a Tire Goes Flat It is unusual for a tire to blow out while you are driving, especially if you maintain the tires properly. If air goes out of a tire, it is much more likely to leak out slowly. for additional information.
Page 402: Appearance Care
Appearance Care Interior Cleaning The vehicle's interior will continue to look its best if it is cleaned often. Although not always visible, dust and dirt can accumulate on the upholstery. Dirt can damage carpet, fabric, leather, and plastic surfaces. Regular vacuuming is recommended to remove particles from the upholstery.
Page 403: Fabric/Carpet
Do not clean the vehicle using: A knife or any other sharp object to remove a soil from any interior surface. A stiff brush. It can cause damage to the vehicle's interior surfaces. Heavy pressure or aggressive rubbing with a cleaning cloth.
Page 404: Coated Moldings
To clean: 1. Saturate a lint-free, clean white cloth with water or club soda. 2. Wring the cloth to remove excess moisture. 3. Start on the outside edge of the soil and gently rub toward the center. Continue cleaning, using a clean area of the cloth each time it becomes soiled.
Page 405: Instrument Panel, Vinyl, And Other Plastic
Instrument Panel, Vinyl, and Other Plastic Surfaces A soft cloth dampened with water may be used to remove dust. If a more thorough cleaning is necessary, a clean soft cloth dampened with a mild soap solution can be used to gently remove dust and dirt. Never use spot lifters or removers on plastic surfaces.
Page 406: Washing Your Vehicle
Washing Your Vehicle The best way to preserve your vehicle's finish is to keep it clean by washing it often. Certain cleaners contain chemicals that can damage the emblems or nameplates on the vehicle. Check the cleaning product label. If it states that it should not be used on plastic parts, do not use it on the vehicle or damage may occur and it would not be covered by the warranty.
Page 407: Finish Care
Finish Care Occasional waxing or mild polishing of the vehicle by hand may be necessary to remove residue from the paint finish. Approved cleaning products can be obtained from your dealer/retailer. If the vehicle has a basecoat/clearcoat paint finish, the clearcoat gives more depth and gloss to the colored basecoat.
Page 408: Windshield And Wiper Blades
Windshield and Wiper Blades Clean the outside of the windshield with glass cleaner. Clean the rubber blades using a lint free cloth or paper towel soaked with windshield washer fluid or a mild detergent. Wash the windshield thoroughly when cleaning the blades. Bugs, road grime, sap, and a buildup of vehicle wash/wax treatments may cause wiper streaking.
Page 409: Convertible Top
Convertible Top The vehicle's convertible top should be cleaned often. However, high pressure car washes may cause water to enter your vehicle. When you hand wash the top, do it in partial shade. Use a mild soap, lukewarm water and a soft sponge. A chamois or cloth may leave lint on the top, and a brush can chafe the threads in the top fabric.
Page 410: Underbody Maintenance
cleaners with acid, or abrasive cleaning brushes on them because they could damage the surface. Do not use chrome polish on aluminum wheels. Using chrome polish on aluminum wheels could damage the wheels. The repairs would not be covered by the vehicle warranty. Use chrome polish on chrome wheels only.
Page 411: Fiberglass Springs (Composite Springs)
Fiberglass Springs (Composite Springs) If you use acidic or corrosive cleaning products, engine degreasers or aluminum cleaning agents on fiberglass springs, you may damage the springs. The repairs would not be covered by your warranty. Use only approved cleaners when cleaning your vehicle's fiberglass springs.
Page 412: Service Parts Identification Label
Service Parts Identification Label This label, on the inside of the glove box, has the following information: Vehicle Identification Number (VIN) Model designation Paint information Production options and special equipment Do not remove this label from the vehicle. Electrical System Add-On Electrical Equipment Do not add anything electrical to the vehicle unless you check with your dealer/retailer first.
Page 413: Fuses And Circuit Breakers
Fuses and Circuit Breakers The wiring circuits in the vehicle are protected from short circuits by a combination of J-Case fuses, mini-fuses and circuit breakers. This greatly reduces the chance of fires caused by electrical problems. Look at the silver-colored band inside the fuse. If the band is broken or melted, replace the fuse.
Page 414 Fuses BCK/UP LAMP Reverse Lamps BLANK Not Used BLANK Not Used 6-102 Usage BTSI SOL/STR WHL LCK CLSTR/HUD CRUISE SWITCH Fuses Usage Brake Transmission Shift Interlock, Steering Wheel Column Lock Cluster, Heads Up Display Cruise Control Switch...
Page 415 Fuses CTSY/LAMP Courtesy Lamp DR LCK Door Locks DRIV DR Driver Door Switch SWITCH Engine Control Module (ECM) Exhaust Module (Z06 & ZR1), EXH MDL Spare (Coupe and Convertible) GM LAN GM LAN Devices RUN/CRNK HTD SEAT/ Heated Seat, Wiper Relays WPR RLY HVAC/ Heating.
Page 416: Engine Compartment Fuse Block
Fuses REAR/FOG Rear Fog Lamps TONNEAU Tonneau Release RELSE TRUNK RELSE Trunk Release Fuses AUX PWR Auxiliary Power BLANK Not Used BLANK Not Used BLANK Not Used BLANK Not Used BLANK Not Used BLANK Not Used BLANK Not Used DRVR Driver Heated Seat HTD SEAT Cigarette Lighter...
Page 417 For ZR1 models, the Fuel System fuse is located at the battery. Fuse Transmission Control Module/ Transmission Horn, Alternator Sense Usage Fuse Usage Antilock Braking System (ABS)/Real Time Damping Wiper Stoplamps/Back-Up Lamps 6-105...
Page 418 Fuse Oxygen Sensor Battery Main 5 Parking Lamps Powertrain Relay Input/Electronic Throttle Control Manual Transmission Solenoids Antilock Braking System Odd Numbered Fuel Injectors Electronic Suspension Control (Option) Canister Purge Solenoid, Mass Air Flow Sensor Air Conditioner Compressor Even Numbered Fuel Injectors Windshield Washer Headlamp Washer Passenger Side Low-Beam Headlamp...
Page 419 Micro-Relays Usage Front Fog Lamp High-Beam Headlamp Headlamp Washer Fuel Pump (except ZR1) Mini-Relays Usage Rear Defog Windshield Wiper High/Low Windshield Wiper Run/Accessory Crank Powertrain Ignition 1 Windshield Wiper On/Off Low-Beam Headlamp Spare Fuses Usage Spare Spare Spare Spare Spare Spare Fuse Puller Diodes...
Page 420: Capacities And Specifications
Capacities and Specifications The following approximate capacities are given in English and metric conversions. Application Air Conditioning Refrigerant R134a Cooling System 6.2L LS3 V8 Engine 6.2L LS9 V8 Supercharged Engine 6.2L LS9 V8 Supercharged Engine Intercooler Cooling System 7.0L LS7 V8 Engine Engine Oil with Filter 6.2L LS3 V8 6.2L LS3 V8 with Z52 Dry Sump Oil System...
Page 421 Application Transmission Fluid Automatic Transmission (Pan Removal and Filter Replacement) Manual Transmission Base Manual Transmission Manual Transmission Manual Transmission Wheel Nut Torque All capacities are approximate. When adding, be sure to fill to the approximate level, as recommended in this manual. Recheck fluid level after filling Engine VIN Code...
Page 422: Engine Data
Engine Horsepower 6.2L LS3 V8 without 430 @ 5900 rpm option NPP 6.2L LS3 V8 with 436 @ 5900 rpm option NPP 6.2L LS9 V8 638 @ 6500 rpm Supercharged 7.0L LS7 V8 505 @ 6300 rpm 6-110 Engine Data Torque Displacement 424 lb ft @ 4600 rpm...
