Battery Replacement

AC power is the normal power source for this meter. If 8 AA batteries are used, they are located in
the rear battery compartment. When the battery icon appears on the meter's LCD, it is time to
replace the batteries.
1. Turn power off.
2. Open the rear battery cover
3. Insert the batteries into battery holder, observing the correct polarity.
4. Put the battery cover back in place.
You, as the end user, are legally bound (Battery ordinance) to return all used batteries
and accumulators; disposal in the household garbage is prohibited!
You can hand over your used batteries / accumulators at collection points in your
community or wherever batteries / accumulators are sold!
Disposal: Follow the valid legal stipulations in respect of the disposal of the device at the
end of its lifecycle

Specifications

Applicable standards
Display
Frequency bandwidth
Accuracy / Resolution
Microphone
Measurement ranges
Frequency weighting
Response time
Max Hold
Alarm output
Limit range
Under range indication
Over range indication
Power
Battery life
Operating temperature
Operating humidity
Dimensions / Weight
All rights reserved including the right of reproduction in whole or in part in any form
www.ponpe.com
Meets IEC 60651-1979 and ANSI S1.4 1983 Type 2 SLM
standards
11.7 x 7.94cm (4.6" x 3.125") multifunction LCD
31.5 Hz to 8 KHz
± 1.5dB (under reference conditions) / 0.1dB
0.5" Electret Condensor Microphone (remote mic option)
30 to 80dB, 60 to 110dB, 80 to 130dB
'A' and 'C'
Fast (125ms) / Slow (1s)
Maximum reading is displayed with time stamp
3.5mm Mono Phone Plug, 3.4mA @ 5 Vdc, typical
30 to 130dB
"- - -"
"OL"
AC adaptor (9V@500ma) or 8 AA batteries
240hrs continuous (approx); 30 days @ 8hrs/day
(LED's are not functional when battery powered)
o
0 to 50 C (32 to 122
Less than 80% RH
22x18x3.2cm / 285g (8.75x7.1x1.25" / 0.63 lbs).
Copyright © 2013 FLIR Systems, Inc.
ISO‐9001 Certified
www.extech.com
o
F)
8
SL130-EU-EN v3.6 08/13
