Summary of Contents for Extech Instruments SL130
- Page 1 User Manual Sound Level Alert Model SL130 GlobalTestSupply www. .com Find Quality Products Online at: sales@GlobalTestSupply.com...
- Page 2 ANSI and IEC Type 2 Sound Level Meter standards. The SL130 offers a High/Low Alarm Limit feature where four two-color high intensity LEDs and a large OVER indicator provide alarm alerts when limits are exceeded. The SL130’s physical Alarm Output circuit can be used to drive the optional Alarm Module Kit to power a larger, remote indicating device such as a “QUIET”...
- Page 3 Alert switch – Red position High-Low Alarm switch Remote Alarm output connector AC adaptor connector Rear Panel Tilt stand Battery compartment AC Adaptor connector Remote Alarm output connector Windscreen SL130-EU-EN v3.6 08/13 GlobalTestSupply www. .com Find Quality Products Online at: sales@GlobalTestSupply.com...
- Page 4 Select FAST to capture noise peaks and noises that occur very quickly. Select the SLOW response to monitor a sound source that has a consistent noise level or to average quickly changing levels. Select SLOW response for most applications. SL130-EU-EN v3.6 08/13 GlobalTestSupply www.
- Page 5 40 second flashing red indication when level transitions from Low ALARM low to high. 40 second flashing red indication when level transitions from Red (3) low to high. SL130-EU-EN v3.6 08/13 GlobalTestSupply www. .com Find Quality Products Online at: sales@GlobalTestSupply.com...
- Page 6 For desk mounting, extend the rear legs and lock in place with the hinged locks. The tripod mounting nut is located on the bottom of the unit. SL130-EU-EN v3.6 08/13 GlobalTestSupply www.
- Page 7 The relay module can be used to power external warning signs, “QUIET” signs or other indicating devices when the sound level is higher than the programmed limit. Refer to the manual supplied with the module for connection information. Rear AC Adaptor and Alarm outputs. SL130-EU-EN v3.6 08/13 GlobalTestSupply www. .com Find Quality Products Online at: sales@GlobalTestSupply.com...
-
Page 8: Battery Replacement
(LED’s are not functional when battery powered) Operating temperature 0 to 50 C (32 to 122 Operating humidity Less than 80% RH Dimensions / Weight 22x18x3.2cm / 285g (8.75x7.1x1.25" / 0.63 lbs). SL130-EU-EN v3.6 08/13 GlobalTestSupply www. .com Find Quality Products Online at: sales@GlobalTestSupply.com...
