1. Parts Overview
The Unit
1 On/Off Button
Insert the plug into the electrical outlet. Press the
on/off switch on the top of the vacuum cleaner, to
switch the vacuum cleaner on and press the button
again to turn the vacuum cleaner off.
2 Dirt Container
Locked into the unit.
3 Dirt bin separator
4 Dirt Container Carry Handle
Use the carry handle located on the front of the dirt
bin to carry the dirt dontainer.
5 Dirt Container Release Button
Press the button on the top of the dirt container carry
handle to release the bin from the unit.
What is your vax's model number?
V
What is your vax's serial number?
(on the base of
your cleaner)
Note this down in case you need it in future
www.vax.co.uk
All manuals and user guides at all-guides.com
Vax careline
8
10
9
31/10/08 13:47 Page 1
0870 606 1248
instruction manual
13
1
11
12
6 Hose inlet
7 Tool storage cover
Crevice tool & 2-in-1 tool storage.
8 Carry handle
Located on the top of the unit, used to move the
vacuum cleaner from room to room.
9 Auto-Cord rewind
To rewind the power cord, press the cord rewind
button, located on the top of the vacuum cleaner
10 Floor tool parking slot (hidden)
For convenience there is a parking slot located at the
rear of the vacuum cleaner where the Floor Tool can
be parked for carrying and storage.
11 Plug (hidden)
12 Exhaust filter cover (hidden)
Located at the rear of the unit.
13 Dirt bin quick release button
Hold the dirt container over a bin and press the
release button.
14 Pre-motor filter
Located on the side of the dirt bin.
