MX67/MX68 Installation Guide
This document describes how to install and set up the MX67 and
MX68 security appliance. Additional reference documents are available
online at: www.meraki.com/library/products.
MX67/MX68 Overview
The Meraki MX67 and MX68 are enterprise security appliances
designed for distributed deployments that require remote administration.
It is ideal for network administrators who demand both ease of
deployment and a state-of-the-art feature set. A full overview of the
appliances' features can be found in the
Specifications.
Package Contents
In addition to the MX device, the following are provided:
MX67/MX68
Power Adapter (No Power Cable)
2x CAT5 Ethernet Cables
Wall Screws and Anchors
MX67C
Power Adapter (No Power Cable)
2x CAT5 Ethernet Cables
Wall Screws and Anchors
MX67 and MX68 Overview and
MX67W/MX68W
Power Adapter (No Power Cable)
2x CAT5 Ethernet Cables
Wall Screws and Anchors
2x WiFi Antennae
MX68CW
Power Adapter (No Power Cable)
2x CAT5 Ethernet Cables
Wall Screws and Anchors
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Cisco MERAKI MX67
Summary of Contents for Cisco MERAKI MX67
- Page 1 MX67/MX68 Installation Guide This document describes how to install and set up the MX67 and MX68 security appliance. Additional reference documents are available online at: www.meraki.com/library/products. MX67/MX68 Overview The Meraki MX67 and MX68 are enterprise security appliances designed for distributed deployments that require remote administration.
-
Page 2: Front Panels
Front Panels MX67/67C/67W MX68/68W/68CW Status Indicator The MX67/MX68 series devices uses an LED to inform the user of the device's status. LED patterns and their meanings are described below. LED Status Meaning Power is applied but the appliance is not connected to... -
Page 3: Back Panels
Flashing White Firmware upgrade in progress Fully operational/connected, uplink actively using wired Solid White Fully operational/connected, uplink actively using Solid Purple integrated cellular failover Back Panels MX67 MX67C... - Page 4 MX67W...
-
Page 5: Mx67/Mx67W/Mx67C Back Panel Functions
MX67/MX67W/MX67C Back Panel Functions Additional functions on the back panel are described below, from left to right. Active, supported SIM cards can be inserted into this SIM Card Slot (MX67C) slot to enable cellular capabilities. USB 3.0 for external 3G/4G wireless modems. Traffic USB port status is indicated by the USB LED. - Page 6 Press for 1 second to delete a downloaded configuration and reboot. Press and hold for more than 10 seconds to force a full factory reset. MX68 MX68W MX68CW...
-
Page 7: Mx68/Mx68W/Mx68Cw Back Panel Functions
MX68/MX68W/MX68CW Back Panel Functions Additional functions on the back panel are described below, from left to right. WAN / Internet ports These two ports provide connectivity to the WAN. These 8 ports provide connectivity to computers, printers, access points, or Ethernet switches. LAN ports A steady green LED indicates bidirectional connectivity, and flashing green indicates traffic. -
Page 8: Side Panels
Power input Designed for use only with the unit’s power supply. Insert a paper clip if a reset is required. Press for 1 second to delete a downloaded configuration Reset button and reboot. Press and hold for more than 10 seconds to force a full factory reset. - Page 9 MX68CW...
-
Page 10: Bottom Panel
USB 2.0 for 3G/4G wireless cards. Traffic status is USB port indicated by the USB LED. Bottom Panel Please note that the serial number is located on the product label at the bottom panel of MX67/MX68 devices... -
Page 11: Connecting To Wan
Mounting Hardware The supplied wall screws and anchors allow you to mount the appliance on a drywall surface, either vertically or horizontally. The distance between the holes you drill should be 5-1/8 inches (13 cm). • For mounting on drywall, use a ¼-in drill bit, then insert the plastic and screw assemblies. •... -
Page 12: Setting Up Cellular Failover
Setting up Cellular Failover The MX67C and MX68CW have an embedded LTE module for cellular failover connections. The following section will walk through first-time set-up of an MX with an internet connection as a primary connection and cellular as failover. Note that the IMEI cannot yet be found on the Meraki dashboard, only on the physical label of the device. -
Page 13: Additional Settings
MX68 devices come with two dedicated Internet ports, which are both configured on the Security Appliance > Appliance Status > Local Status under the Uplink Configuration. Setting up a Secondary WAN interface on the MX67 You can toggle the LAN2 port between LAN and Internet, through... -
Page 14: Configuring Physical Link Settings
Configuring Physical Link Settings To configure physical link settings on the Ethernet ports, click Local status > Ethernet configuration. You can enable half duplex, full duplex, and autonegotiation, as well as set 10- or 100-Mbps data rates.
