CS-TU18WKY-5 series
CS-TU24WKY-5 series
Name and Address of Manufacturer:
Panasonic India Pvt. Ltd.
Plot no.1, Village - Bid Dadri,
Tehsil & District - Jhajjar - 124103,
Haryana, India.
Name and Address of Importer:
Panasonic Marketing Middle East & Africa FZE Jebel Ali,
Dubai, UNITED ARAB EMIRATES
© Panasonic India Pvt. Ltd. 2019.
Unauthorized copying and distribution is a violation
of law.
CU-TU18WKY-5 series
CU-TU24WKY-5 series
Operating Instructions
Air Conditioner
Thank you for purchasing Panasonic Air Conditioner.
Installation instructions attached.
Before operating the unit, please read these operating
instructions thoroughly and keep them for future
reference.
ACXF55-29970-AA
