GOLDEN ECLIPSE
Owner's Operation and Installation Manual
(Also Design Certified As Vented Decorative Appliances)
WARNING: If the information in this manual
is not followed exactly, a fire or explosion
may result causing property damage,
personal injury, or loss of life.
— Do not store or use gasoline or other
flammable vapors and liquids in the
i v
i c
i n
y t
f o
h t
s i
r o
— WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch; do
not use any phone in your building.
• Immediately call your gas supplier
from a neighbor's phone. Follow the
gas supplier's instructions.
• If you cannot reach your gas supplier,
call the fire department.
— Installation and service must be
performed by a qualified installer,
service agency, or the gas supplier.
This is an unvented gas-fired heater. It uses
air (oxygen) from the room in which it is
installed. Provisions for adequate combus-
tion and ventilation air must be provided.
Refer to page 4, Air for Combustion and
Ventilation.
VENT FREE GAS LOG SET
GERRR18NG, GERRR18LP
GERRR24NG, GERRR24LP
Remote Control Included
a
ny other appliance.
INSTALLER: Leave this manual with the
appliance.
CONSUMER: Retain this manual for future
reference.
Thisappliancehasbeentestedandapproved
under ANSI Z21.11.2–2011 Unvented Gas-
Fired Room Heaters.
WARNING: This appliance is for installation
only in a solid fuel burning masonry or UL127
factory-built fireplace or listed ventless fire-
box enclosure. It has been design certified for
these installations. EXCEPTION: DO NOT in-
stall this appliance in a factory-built fireplace
that includes instruction stating it has not
been tested or should not be used with un-
vented gas logs.
This appliance may be installed in an
aftermarket,* permanently located, manu-
factured (mobile) home, where not prohib-
ited by local codes.
This appliance is only for use with the type of
gas indicated on the rating plate. This app-
liance is not convertible for use with other
gases.
* Aftermarket: Completion of sale, not for purpose of resale, from
the manufacturer
ANSI Z21.11.2 - 2013
Unvented Heaters
ANSI Z21.60 - 2012
Vented Decorative Appliances
Advertisement
Table of Contents
Related Manuals for SHM GERRR18NG
Summary of Contents for SHM GERRR18NG
- Page 1 GOLDEN ECLIPSE VENT FREE GAS LOG SET Owner’s Operation and Installation Manual (Also Design Certified As Vented Decorative Appliances) GERRR18NG, GERRR18LP GERRR24NG, GERRR24LP ANSI Z21.11.2 - 2013 Unvented Heaters ANSI Z21.60 - 2012 Remote Control Included Vented Decorative Appliances INSTALLER: Leave this manual with the WARNING: If the information in this manual appliance.
-
Page 2: Table Of Contents
TABLE OF CONTENTS DANGER: Carbon monoxide poisoning may lead to death! Safety Information ............2 Carbon Monoxide Poisoning: Early signs of carbon Local Codes ..............3 monoxide poisoning resemble the flu, with headaches, diz- Unpacking ..............4 ziness, and/or nausea. If you have these signs, heater may not be working properly. -
Page 3: Safety Information
SAFETY INFORMATION fireplace if not enough fresh air is available. See Air CONTINUED for Combustion and Ventilation, pages 4 through 6. If appliance keeps shutting off, see Troubleshooting, pages 17 through 20. Keep the appliance area clear and free from 11. -
Page 4: Unpacking
4. Check heater for any shipping damage. If h eater is is provided by the method described in damaged, call SHM International at (800) 229-5647 the National Fuel Gas Code, ANSI Z223.1/ for replacement parts before returning to dealer. - Page 5 Ventilation Air From Outdoors Unusually Tight Construction Provide extra fresh air by using ventilation grills or ducts. The air that leaks around doors and windows may provide enough fresh air for combustion and ventilation. However, in You must provide two permanent openings: one within 12"...
- Page 6 AIR FOR COMBUSTION WARNING: If the area in which the AND VENTILATION heater may be operated does not meet the required volume for indoor combustion CONTINUED air, combustion and ventilation air shall be 3. Add the Btu/Hr of all fuel burning appliances in the provided by one of the methods described space.
-
Page 7: Installation
CHECK GAS TYPE INSTALLATION Use the correct gas type (natural or propane/LP) for your appliance. If your gas supply is not correct or if you do not WARNING: Before installing in a solid- fuel-burning fireplace, the chimney flue know your gas type, do not install appliance. and firebox must be cleaned of soot, creo- sote, ashes, and loose paint by a qualified INSTALLATION ITEMS NEEDED... - Page 8 INSTALLATION CONNECTING TO GAS SUPPLY CONTINUED WARNING: This appliance requires a 5/8” UNF (Unified National Fine Thread) INSTALLATION CLEARANCES and 1/2" NPT (National Pipe Thread) inlet connection and the gas connection tube WARNING: Maintain the minimum clear- ances. provided. Mantel Clearances for Installation WARNING: A qualified service person must connect log set to gas supply.
- Page 9 CAUTION: Use pipe joint sealant that is CAUTION: Use only new, black iron or resistant to liquid petroleum (LP) gas. steel pipe. Internally-tinned copper tubing may be used in certain areas. Check your local codes. Use pipe of 1/2" diameter or We recommend that you install a sediment trap in supply greater to allow proper gas volume to ap- line as shown in Figure 5.
- Page 10 INSTALLATION CONTINUED OPTIONAL REMOTE CONTROL SET INSTALLATION AND OPERATION Test Pressures Equal To or Less Than 1/2 PSIG (3.5 kPa) Remote control set included with log set. - + - + 1. Close equipment shutoff valve (see Figure 6). 2. Pressurize supply piping system by either opening propane/LP supply tank valve for propane/LP gas or Install four (4) "AA"...
- Page 11 Proper Log Placement for Discovery Elm 18” Models GERRR18 MODELS Log #2 Log #1 Log #3 Log #4 Log #5 Log #6 Log #7 If you have any questions, please call (800) 229-5647...
- Page 12 Proper Log Placement for Golden Eclipse 24” Models GERRR24 MODELS Log #1 Log #2 Log #4 Log #3 Log #5 Log #6 Log #7 If you have any questions, please call (800) 229-5647...
- Page 13 OPERATING HEATER LIGHTING INSTRUCTIONS REMOTE - READY MODELS WARNING: FOR YOUR SAFETY • If fireplace has glass doors, never READ BEFORE LIGHTING operate this heater with glass doors closed. If you operate heater with WARNING: If you do not follow these instructions exactly, a fire or doors closed, heat buildup inside explosion may result causing prop-...
- Page 14 OPERATING HEATER continued CAUTION: Do not try to adjust 4. Press in and turn control knob clockwise heating levels by using the equip- the OFF position (see Figure 7 ). ment shutoff valve. 5. Wait five (5) minutes to clear out any gas. Then smell for gas, including near the floor.
- Page 15 HAND HELD REMOTE MANUAL LIGHTING CONTROL OPERATION PROCEDURE NOTICE: You must light the pilot be- 1. Follow steps 1 through 5 under Lighting In- fore using the hand-held remote structions, page 14. control unit. See Lighting Instruct- 2. Press in and hold control knob and light pilot ions on page 14.
-
Page 16: Inspecting Burners
INSPECTING BURNERS Continued Check pilot flame pattern and burner patterns • turn Gas Log Set off (see Turning OFF the Ap- often. pliance page 15) PILOT FLAME PATTERN Figure 13 shows a correct pilot flame pattern. • see Cleaning and Maintenance, this page Figure 14 shows an incorrect pilot flame pattern. - Page 17 ( See Fig 18 ). ( See Fig 18 ). Figure 18 - Pilot Inlet Air Hole...
- Page 20 Model Number: GERRR18(NG,LP), GERRR24(NG,LP) (Gas supply tube may be carefully bent into needed shape) SERVICE PARTS LIST ITEM DESCRIPTION QUANTITY GERRR18(NG,LP) GERRR24(NG,LP) Dual Burner RMH-120-01120 RMH-120-01430 Air Shutter NG RMH-120-00260 RMH-120-00260 Air Shutter LP RMH-120-00252 RMH-120-00252 FRAME, GRATE BURNER ASSM. WIP-120-90530A WIP-120-90534A Gas Valve, mV NG...
-
Page 21: Specifications
• model and serial numbers of your heater • how heater was malfunctioning You may have further questions about installation, opera- tion or troubleshooting. If so, contact SHM International’s • type of gas used (propane/LP or natural gas) Technical Service Department at (800) 229-5647. -
Page 22: Warranty Information
SHM International Corp. warrants the components of this appliance to be free from defects in material and workmanship for one (1) year from the date of purchase. SHM International Corp. at its option, will repair or replace this product or any component of the product found to be defective during the warranty period. Re- placement will be made with a new manufactured product or component.
