Filtration System - KitchenAid KDPE334GPS User Instructions

Using the Bottle Wash feature (on some models)
Up to three sports bottles, baby bottles or other narrow items
may be washed in the upper rack with this feature.
To wash bottles:
1. Select BOTTLE WASH on the control panel.
2. Flip up any or all three of the nozzles just far enough to fit
inside your particular item.
3. Securely place items over the nozzles.
Your dishwasher has the latest technology in dishwasher filtration. This filtration system minimizes sound and optimizes water and
energy conservation while providing superior cleaning.
The filter system consists of two parts, an upper filter assembly and a lower filter.
IMPORTANT: To avoid damage to dishwasher, do not operate your dishwasher
without filters properly installed. Be sure lower filter is securely in place and upper
filter assembly is locked into place. If upper assembly turns freely, it is not locked
into place.
The filters may need to be cleaned when:
Visible objects or soils are on the upper filter assembly.
■
Dishes feel gritty to the touch.
■
It is very easy to remove and maintain the filters. The chart below shows the recommended cleaning frequency.
Number of Loads
Per Week
8–12
4–7
1–3
*Scrape excess food into the trash or food disposer prior to loading the dishwasher. We recommend this practice because it will
conserve the water and energy that you would have used to prepare your dishes. This will also save you time and effort.
Very Hard Water
If you have hard water (above 15 grains), clean your filter at least
once per month. Buildup of white residue on your dishwasher
indicates hard water. For tips on removing spots and stains, see
the "Troubleshooting" section.
12
RECOMMENDED TIME INTERVAL TO CLEAN YOUR FILTER
If you only scrape
before loading*
Every 2 months
Every 4 months
Twice per year
B
A. Water flows through these holes when the nozzle is flipped down.
B. Water flows through these holes when the nozzle is flipped up.
When you do not need to wash bottles, flip the nozzles down until
they stop.

Filtration System

If you scrape and rinse
before loading
Every 4 months
Once per year
Once per year
Filter Removal Instructions
1. Turn the upper filter assembly a quarter turn counterclockwise
and lift out.
2. Separate the upper filter assembly by gently pulling apart.
3. Clean the filters as shown.
A
Upper filter
assembly
If you wash before loading
Once per year
Once per year
Once per year
Locating tab
To remove upper filter assembly
Lower filter
