Page 1 The first syllable, Ki , in the word “Kia” means “to arise from to the world” or “to come up out of to the world.” The second syllable, a , means “Asia.” So, the word Kia , means “to arise from”...
Page 2 The dedicated to your complete satisfaction. information and specifications provided in this manual were accurate at the time of printing. Kia Because subsequent owners require this important reserves the right to discontinue or change information as well, this publication should remain specifications or design at any time without notice with the vehicle if it is sold.
Page 3: Table Of Contents
TABLE OF CONTENTS INTRODUCTION YOUR VEHICLE AT A GLANCE KNOWING YOUR VEHICLE DRIVING YOUR VEHICLE DRIVING TIPS IN CASE OF AN EMERGENCY MAINTENANCE SPECIFICATIONS CONSUMER ASSISTANCE (U.S. only) INDEX...
Page 4 INTRODUCTION How to Use This Manual ......1-2 Vehicle Break-In Process ..... . . 1-4...
Page 5: Introduction
WARNING and CAUTION sections are easily with your Kia vehicle. You should carefully read and recognized by their special markings listed on follow ALL procedures and recommendations this page. provided in these WARNING’s, CAUTION’s and Illustrations complement the words in this manual NOTICE’s.
Page 6 VEHICLE BREAK-IN PROCESS WARNING No special break-in period is needed. By following A WARNING indicates a situation in which a few simple precautions for the first 600 miles severe bodily injury or death is likely if the (1 000 km) you may add to the performance, warning is ignored.
Page 7 YOUR VEHICLE AT A GLANCE Interior and Exterior Overview ....2-2 Instrument Panel Overview ..... 2-3...
Page 8: Your Vehicle At A Glance
Your Vehicle At A Glance INTERIOR AND EXTERIOR OVERVIEW Outside Steering Rear hatch Airbags Seat rearview mirror wheel Power mirror control Taillights Power window Rear door Door switches CBGQ0200...
Page 9 INSTRUMENT PANEL OVERVIEW Airbag Instrument cluster Auto cruise Audio (optional) Wiper/Washer Hazard warning Airbag Storage Light control/ Turn signals Steering wheel Instrument panel Glove box illumination Rear dome light control switch Climate control Parking brake Ashtray and release lever cigarette lighter Power outlet Fual filler lid Shift lever...
Page 10 KNOWING YOUR VEHICLE Keys ........3-3 Door Locks .
Page 11 Cup Holder ....... . . 3-96 Sunglass Holder ......3-98 Storage Compartment .
Page 12: Keys
CBGQ0331 CAUTION The key code number is stamped on the plate Use only Kia original parts for the ignition key attached to your key set. Should you lose your keys, this number will enable an authorized Kia in your vehicle. If an aftermarket key is used, dealer to duplicate your keys easily.
Page 13: Knowing Your Vehicle
Knowing Your Vehicle DOOR LOCKS FRONT REAR UNLOCK LOCK C1V21040 C1V21042 Two turn unlock system Automatic Door Locks To unlock the other doors and rear hatch, turn the Operating Door Locks - With the Key key to the rear of the vehicle twice within three •...
Page 14 NOTICE Always remove the ignition key, engage the parking brake, close all windows and lock all doors when leaving your vehicle unattended. CGQ03108 Operating Door Locks - Without the Key Pushing the door lock knob and then closing the door enables the door to lock without a key.
Page 15 Knowing Your Vehicle • LOCK ( If you depress the corresponding button on the transmitter, all four doors and rear hatch will lock and the hazard lamp will flash once. • UNLOCK ( If you depress the corresponding button on the transmitter, the driver’s door will unlock, the hazard lamp will flash twice and the dome light will come on for 30 seconds if the switch is...
Page 16 WARNING Leaving your vehicle unlocked can invite theft or possible harm to you or others from some- one hiding in your vehicle while you are gone. Always remove the ignition key, engage the parking brake, close all windows and lock all doors when leaving your vehicle unattended.
Page 17 - the transmitter is close to a radio transmit- ter such as a radio station or an airport which can interfere with normal operation of the transmitter. • If you have a problem with the keyless entry system, contact an authorized Kia dealer as soon as possible.
Page 18 Unlock Lock LOCK UNLOCK C1MS1040 CBGQ1020 Operating Door Locks From Central door locks Inside the Vehicle • Pressing the front portion of the door lock switch will automatically lock all the doors and rear • To lock a door, push the door lock button to the hatch.
Page 19 Knowing Your Vehicle WARNING - Unattended Children enclosed vehicle become extremely hot, causing death or severe Lock Unlock injury to unattended children or animals who cannot escape the vehicle. Further- more, children might operate features of the vehicle that could injure them, or they could encounter other harm, possibly from someone gaining entry to the vehicle.
Page 20 Rear NOTICE Lock Unlock • When the door is locked, the red mark on the switch is not visible. • The rear sliding doors are designed to only open from the inside when holding the handle with the palm facing out (toward the door).
Page 21 Knowing Your Vehicle • To lock a rear door so that it cannot be opened FREE from the inside, push the child safety lock located on the forward edge of the door to the “LOCK” position before closing the door. •...
Page 22: Windows
WINDOWS Power Windows The ignition switch must be in the ON position for power windows to operate. Each door has a power window switch that controls that door’s window. However, the driver has a power window switch which can block the operation of the passenger windows.
Page 23 Knowing Your Vehicle Driver’s power window switch Driver’s window automatic-down window switch The driver’s power window switch provides two (2) separate window-down functions. The driver’s window has an “Automatic-Down” feature. To activate the express-down feature, • Depressing the driver’s power window switch momentarily depress the front of the switch to the completely lowers the driver’s window automati- second detent position.
Page 24 WARNING - Power Windows • Keep the driver’s door power window lock switch in the ON (depressed) posi- tion, except when someone is operating a passenger door window. Serious injury can result (especially to children) from unintentional window operation. • Always double check to make sure all arms, hands, and other obstructions are Power window lock switch safely out of the way before closing a...
Page 25 Knowing Your Vehicle NOTICE The driver’s door power window “LOCK” switch must be in the OFF position (not depressed) to operate the passenger door windows. CBGQ0316 Passenger Doors Power Window Controls To open a window, press down on the front portion of the power window switch.
Page 26 QUARTER WINDOWS Type A Type B DOOR DOOR TILT SLIDE MODE HOUR MODE HOUR C1V2B033 C1GQ1028/C1GQ1026 Manual Flip - Open Power Open (if equipped) To open the quarter windows, pull the rear portion Front of the latch out. Swing the latch forward and out, The power rear quarter vent windows operate with then lock it into the open position by pushing rear- the ignition in the ON position.
Page 27 Knowing Your Vehicle C1GQ1024 Rear To open, pull up on the forward part of the switch. To close it, push down on the forward part of the switch. When the power window lock switch on the driver’s door is ON, the rear power open switch does not control the vent windows.
Page 28: Front Seat
FRONT SEAT WARNING - Driver’s Seat • Adjusting the driver’s seat with the vehicle in motion could cause loss of control and a serious accident. • Do not allow anything to interfere with the normal position of the seatback. Storing items against a seatback or in any other way interfering with proper locking of a seatback could result in serious or fatal...
Page 29 Knowing Your Vehicle CAUTION Loose objects in the driver’s foot area could interfere with the operation of the foot pedals, possibly causing an accident. Loose objects might interfere with the seat slide mechanism. Do not place anything under the front seats. CAS2B042 Adjusting the Front Seatback Recliner To change the seatback angle, lean forward slightly...
Page 30 WARNING - Front Seat Riding in a vehicle with a front seatback reclined could lead to serious or fatal injury in an accident. If a front seat is reclined, the occupant’s hips may slide under the lap portion of the safety belt applying great force to the unprotected abdomen.
Page 31 Knowing Your Vehicle To change the height (rear portion) of the seat cushion, rotate the knob located on the outside of the seat cushion. • To lower the seat cushion, rotate the knob toward the rear of the vehicle. • To raise the seat cushion, rotate the knob toward the front of the vehicle.
Page 32 Front Seat Adjustment - Power (if equipped) (Continued) • In order to avoid unnecessary airbag The front seat can be adjusted by using the control injuries including the possibility of knob on the outside of the seat. Before driving, severe injury or death, always sit as far adjust the seat to the proper position so as to easily back as possible from the steering wheel control the steering wheel, pedals and switches on...
Page 33 Knowing Your Vehicle NOTICE Prior to operating the vehicle, ensure the seat is locked securely by trying to move the seat forward or backward without using the control knob. If the seat moves, it is not locked prop- erly. C1V2B034 Moving the front seat forward and backward Push the control knob forward or backward to move the seat to the desired position.
Page 34 C1V2B035 C1V2B036 Adjusting the front seatback recliner Adjusting the height of front seat cushion Rotate the upper portion of the control knob Front height of front seat cushion forward or backward to recline the seatback to the Move the front portion of the control knob up to desired position.
Page 35 Knowing Your Vehicle C1V2B038 C1V2B037 Height of front seat cushion Rear height of front seat cushion To raise or lower the seat cushion totally, pull up Move the rear portion of the control knob up to and push down on the center of the corresponding raise or down to lower the rear part of the seat switch.
Page 36 WARNING To minimize the risk of possible severe personal injury in the event of a collision, both the driver's and passenger's seat- backs should be in a normal seating posi- tion while the car is in motion. The protec- tion provided by the vehicle’s restraint system may be reduced significantly when the seatbacks are reclined.
Page 37 Knowing Your Vehicle NOTICE • The seat warmer will not operate if ambient temperature is above 43±3°C (109±5°F). • If the seat warmer doesn't work when ambi- ent temperature is below 33±3°C (91±5°F), have the system checked by an authorized dealer.
Page 38 If your vehicle is equipped with the headrest swing feature, the front headrests may be adjusted forward to four positions by pulling if forward. To adjust the headrest backwards, pull it forward and release it. WARNING - Headrests • To reduce the risk of head and neck injuries, don’t operate the vehicle with Release lever the headrest removed or improperly...
Page 39 Knowing Your Vehicle C1V2B011 C1V2B010 Armrest (if equipped) Type B (non-adjustable armrest) Your second row seats have armrests located on Type A (adjustable armrest) the side seatbacks. Your front seats have the armrest located on the To use the armrests, swing them down to the side of seatback.
Page 40 CGQ03004 Side Table (if equipped) The side table is located on the inner portion of the passenger’s seat. To use the table, pull the table all the way up until it locks into place. Verify the table is locked by trying to push it down.
Page 41: Rear Seat
Knowing Your Vehicle REAR SEAT (Continued) WARNING - Rear Seatback • No passenger should ride in the cargo • The rear seatback must be securely area or sit or lie on folded seatbacks latched. If not, passengers and objects while the vehicle is moving. All passen- could be thrown forward resulting in gers must be in seats and restrained serious injury or death in the event of a...
Page 42 CGQ03001 CGQ03002 Rear Seat - Second Row (separate seat) Adjusting the rear seatback recliner To change the rear seatback angle, lean forward Moving the rear seat forward and backward slightly and raise the lever located on the side of To move the rear seat forward or backward, pull the the seat.
Page 43 Knowing Your Vehicle CBGQ0300 CGQ03003 Rear Seat - Second Row (bench seat) Folding the rear seatback (if equipped) To use the rear seatback as a table, press down Moving the rear bench seat forward and back- the folding lever located on the rear corner of seat ward cushion and fold the rear seatback all the way To move the rear bench seat forward or backward,...
Page 44 CGQ03110 CGQ03113 Adjusting the rear bench seatback recliner Folding the rear bench seatback To change the rear bench seatback angle, lean To fold the rear bench seatback, press down on the forward slightly and raise the lever located on the lever located on the rear corner of seat cushion side of the seat.
Page 45 Knowing Your Vehicle Rear Seat - Third Row Adjusting the rear seatback recliner CGQ03005 CGQ03006 To change the rear seatback angle, lean forward Moving the third row seat forward and back- slightly and raise the lever located on the side of the ward seat.
Page 46 Folding the rear seatback. Double-folding the rear seat Reclining strap Catch release Rear sliding strap lever CGQ03008 CGQ0300A You can increase the cargo area by folding the rear To fold the rear seat forward for cargo area. seatback forward and sliding it forward. To fold the 1.
Page 47 Knowing Your Vehicle To unfold the rear seat for passenger use: 1. Remove the folding loop hook from the headrest pole. 2. Insert the folding loop into the pocket. 3. Lift the rear portion of the seat cushion then push down firmly to lock the catches into the rear anchors until an audible “click”...
Page 48 CGQ03009 CGQ03010 Removal of The Rear Seats (2nd Row & 2. Pull up the catch release strap located under the rear of the seat cushion to release the rear 3rd Row) catches from the anchors. To remove a rear seat : 1.
Page 49 Knowing Your Vehicle CGQ03011 CGQ03114 To install a rear seat : 3. Lift the rear portion of the seat cushion and remove the seat from the four anchors on the 1. Put the front anchor strikers along the front floor. anchors on the floor to slide the seat forward.
Page 50 4. Make sure the catches are locked in position by moving the seat forward and backward or lifting the rear portion of the seat. If the seat moves, it is not locked properly. CGQ03115 3. Lift the rear portion of the seat cushion then push down firmly to lock the catches into the rear anchors until an audible “click”...
Page 51: Safety Belts
Knowing Your Vehicle SAFETY BELTS Driver’s side airbag Passenger’s side airbag SBS403100 CBGQ0334 Pre-tensioner Seat Belt When the vehicle stops suddenly, or if the occu- pant tries to lean forward too quickly, the seat belt Your vehicle is equipped with driver’s and front retractor will lock into position.
Page 52 “ON” or “ACC”, or if it remains illu- minated for more than 6 seconds, or if it illu- minates while the vehicle is being driven, please have an authorized Kia dealer inspect the system as soon as possible. 3-43...
Page 53 Knowing Your Vehicle Safety Belt Restraint System WARNING - Pre-tensioner Repair or Replacement WARNING - Safety Belts • Pre-tensioners are designed to operate To minimize the risk of serious or fatal once. After activation, pre-tensioner injury in an accident, the driver and all safety belts must be replaced.
Page 54 We strongly recommend that the driver and all This allows the occupants some freedom of move- passengers be properly restrained at all times by ment and increased comfort while using the safety using the safety belts provided with the vehicle. belts.
Page 55 Knowing Your Vehicle The rear safety belts use a special auto-lock Safety belts provide the best restraint when: feature designed to allow a child restraint to be • The seatback is upright used in these positions without an added locking •...
Page 56 A twisted or jammed safety belt cannot restrain you properly. If you cannot untwist or unjam the safety belt, have a qualified Kia technician repair it immedi- ately. never drive or ride with a twisted or jammed safety belt. 3-47...
Page 57 Knowing Your Vehicle WARNING - Belt Use (Continued) Safety belts must be used correctly to work • Never use a single safety belt for more properly in an accident. Each seating posi- than one person. tion in your vehicle has a specific safety belt •...
Page 58 WARNING - Safety Belt Care • A damaged belt may not give you the protection you need in an accident. • Inspect the safety belts periodically for excessive wear or damage. Pull out each belt fully and look for fraying, cuts, burns or other damage.
Page 59 Knowing Your Vehicle Type B As a reminder to the driver and passenger, safety belt warning light will blink for approximately 6 seconds each time you turn the ignition switch ON regardless of belt fastening. If the driver's safety belt is unfastened after the ignition switch is ON, the safety belt warning light will blink for approximately 6 seconds.
Page 60 Take up slack Too high Keep as low on hip bone as possible CBGQ0337 CBGQ0336 4. Position the lap portion of the belt across your 3. Insert the tongue plate into the open end of the lap as LOW ON THE HIPS as possible to reduce buckle until an audible “click”...
Page 61 Knowing Your Vehicle CGQ03101 CBGQ0338 5. Adjust the shoulder anchor position to your size. To unfasten the lap/shoulder belt: To raise the anchor position, push the anchor up. Press the release button on the buckle and allow To lower the anchor position, press the button the belt to slowly retract.
Page 62 (Continued) WARNING - Safety Belts • Never use a single belt to restrain more • The seatbacks should always remain in than one person at a time. a comfortable, upright position while the Failure to follow these warnings will vehicle is in motion. The safety belt increase the chance and severity of injury system will provide the most protection in an accident.
Page 63 Knowing Your Vehicle Lengthen CBGQ0339 CBGQ0340 Lap Belt Only (Rear Center Seat) 2. Insert the tongue plate into the open end of the buckle until an audible “click’’ is heard, indicating To fasten the rear lap belt: the latch is locked. Make sure the belt is not 1.
Page 64 Too high Adjust to a snug fit Keep as low on the hip bone as possible CBGQ0341 CBGQ0342 3. Grasp the free portion of the belt webbing and 4. Make sure that the belt is placed as LOW ON pull until the belt is snug over the hips and lower THE HIPS as possible.
Page 65 Knowing Your Vehicle Proper Use and Care of the Safety Belt System To ensure that the safety belts provide the maxi- mum protection, please follow these instructions: • Use the belts at all times - even on short trips. • If the safety belt is twisted, straighten it prior to use.
Page 66 Restraint of Pregnant Women Restraint of Infants and Small Children Pregnant women should wear lap/shoulder belt To increase their safety, infants and young children assemblies whenever possible according to should always be restrained by a restraint system specific recommendations by their doctors. The lap approved for their age and size.
Page 67: Child Restraints
Follow The child restraint system should be chosen to fit all instructions in this section of your Kia both the size of the child and the size of the vehi- manual and the instructions that came on cle seat.
Page 68 WARNING - Hot Metal Parts (Continued) Since a safety belt or child restraint system • Never allow a child to stand or kneel on the can become very hot in a closed vehicle seat of a moving vehicle. Insist the child during warm sunny weather, be sure to sit down in an approved restraint system.
Page 69 Knowing Your Vehicle Restraint of Large Children Placement of a Child Restraint System As children grow, they may need to use new child We recommend that, whenever possible, you put restraints, including larger child seats or booster the child restraint in the center position of the rear seats, which are appropriate for their increased seat and secure it to the vehicle with the lap belt.
Page 70 Installing a Child Restraint System in the WARNING - Restraint Instruc- Front Passenger Seat and Rear Seats tions For safety reasons, we recommend that the child Failure to observe this manuals instruc- restraint system be used in the center rear seat. If tions regarding child restraint systems and the center rear seat is unavailable, a rear-facing the instructions provided with the child...
Page 71 Knowing Your Vehicle CBGQ0343 CGQ03120 Installing a Child Restraint System in the Rear Center Seat WARNING - Child Restraint To install a child restraint system in the rear center Placement seat, do the following: Never use a rear-facing child restraint in 1.
Page 72 CBGQ0344 CBGQ0345 Installing a Child Restraint System in the Placing a Passenger Safety Belt Into The Front Seat and Rear Outboard Seats Auto Lock Mode 1. Place the child restraint system in the seat and The use of the auto lock mode will ensure that the route the lap/shoulder belt around or through the normal movement of the child in the vehicle does restraint, following the restraint manufacturer’s...
Page 73 Knowing Your Vehicle "Click" CBGQ0346 CBGQ0347 3. Pull the shoulder portion of the safety belt all the 4. Slowly allow the belt to retract. Pull up on the way out. When the shoulder portion of the safety shoulder webbing. A “clicking” or “ratcheting” belt is fully extended, it will shift the retractor to sound will be heard as the belt retracts.
Page 74 WARNING - Auto Lock Mode The lap/shoulder belt automatically returns to the “emergency lock mode” whenever the belt is allowed to retract fully. Therefore, the preceding six steps must be followed each time a child restraint is installed. If the safety belt is not placed in the “auto lock”...
Page 75 Knowing Your Vehicle Child restraint anchor position For small children and babies, the use of a child seat or infant seat is strongly recommended. This child seat or infant seat should be of appropriate size for the child and should be installed in accor- dance with the manufacturer’s instructions.
Page 76 Installing a Child Restraint seat ; WARNING - Child Restraint 1. Position the child restraint seat on the rear passenger seat cushion. Check that the child restraint system is secure by pushing and pulling it in differ- 2. Route the child restraint seat tether strap over ent directions.
Page 77 Knowing Your Vehicle GQD300A/GQD301A CGQ03014/CGQ03102 Child seat lower anchors ISOFIX anchors have been provided in your vehi- cle. The ISOFIX anchors are located in the left and Some child seat manufacturers make child right outboard 2nd row seating positions. Their restraint seats that are labeled as ISOFIX or locations are shown in the illustration.
Page 78 Once you have installed the ISOFIX child restraint, WARNING - Child Restraint assure that the seat is properly attached to the ISOFIX and tether anchors. Also, test the child Placement restraint seat before you place the child in it. Tilt the •...
Page 79 Knowing Your Vehicle AIR BAG - SUPPLEMENTAL RESTRAINT SYSTEM What Your Air Bag System Does Not Do The air bag system is designed to supplement or What Your Air Bag System Does add to the protection offered by the safety belt Your vehicle is equipped with a dual Supplemental system.
Page 80 The Importance of Using Safety Belts WARNING - Air Bags & Safety There are four very important reasons to use Belts safety belts even with an air bag supplemental • Even in vehicles with air bags, you and restraint system. They: your passengers must always wear the •...
Page 81 • Emergency power backup in case the electrical ous personal injury or death. Have the system in your car is disconnected in a crash. vehicle towed to an authorized Kia dealer for inspection and necessary repairs. 3-72...
Page 82 How the Driver’s Air Bag (SRS) Works Driver’s airbag Passenger’s airbag The driver’s air bags are stored in the center of the steering wheel. The passenger’s air bag is stored in the dashboard above the glove box. In certain frontal collisions, your air bags will instantly inflate to help protect you from serious physical injury or death.
Page 83 Knowing Your Vehicle The air bags will completely inflate and deflate Steering wheel air bag in less than 1/10 of a second. The speed of infla- tion and deflation protects the driver’s ability to operate the vehicle. This is important in crashes where a vehicle continues to move after an impact and the driver still has some control of the vehicle’s steering,...
Page 84 Noise and Smoke WARNING - Air Bag Injuries When the air bags inflate, they make a loud noise • You must always sit as far back from the and they leave smoke and powder in the air inside steering wheel air bag as possible, while of the vehicle.
Page 85 Knowing Your Vehicle It is essential that the front passenger always wear their safety belt, even when the vehicle is moving in a parking lot or up a driveway into a garage. The reason for this is that in most frontal impacts, the occupants are thrown forward.
Page 86 WARNING - Front Passengers • Never place a rear-facing child restraint in the front seat. A rear-facing child restraint would be positioned too close to the air bag. If the air bag deploys, it would impact the rear-facing child restraint, causing serious or fatal injury. •...
Page 87: Air Bags
• Manufacturers are required by govern- ment regulations to provide a contact point concerning modifications to the vehicle for persons with disabilities, which modifications may affect the vehi- cle’s air bag system. That contact is Kia’s toll-free Customer Assistance hotline at 1-800-333-4KIA. 3-78...
Page 88 Note that these government warnings focus on the risk to children, Kia also wants you to be aware of the risks which adults are exposed to. Those have been described in previous pages.
Page 89: Rear Hatch
Knowing Your Vehicle REAR HATCH UNLOCK LOCK Handle C1V2B012 CGQA5054 Opening the Rear Hatch 3. Pull the rear hatch back and up to open. To open the rear hatch from the outside: Make certain that you close the rear hatch door before driving your vehicle.
Page 90: Hood
HOOD WARNING - Rear Hatch • Check to be sure the rear hatch is completely closed before driving. If the rear hatch is open, exhaust gases can enter the vehicle. • Occupants should never ride in the rear cargo area where no restraints are avail- able.
Page 91 Knowing Your Vehicle SBGQ1018 C1GQ1017 2. Go to the front of the vehicle, slightly raise the 3. Raise the hood. It will raise completely by itself hood, push the secondary latch to the right and after it has been raised halfway. lift the hood.
Page 92: Fuel Filler Lid
FUEL FILLER LID Closing the Hood: • Check the area under the hood to make certain all filler caps are in place and that all loose items have been removed. • Lower the hood then push down to properly lock in place.
Page 93 Knowing Your Vehicle WARNING - Refueling • If pressurized fuel sprays out, it can CLOSE OPEN cause serious injuries. Always remove the fuel cap carefully and slowly. If the cap is venting fuel or if you hear a hiss- ing sound, wait until the condition stops before completely removing the cap.
Page 94 WARNING (Continued) • Do not get back into a vehicle once you Automotive fuels are flammable/explosive have begun refueling. Do not touch, rub materials. When refueling, please note the or slide against any item or fabric (poly- following guidelines carefully. Failure to ester, satin, nylon, etc.) capable of follow these guidelines may result in producing static electricity.
Page 95 Knowing Your Vehicle (Continued) (Continued) • Do not use cellular phones around a gas • Do not light any fire around a gas station or while refueling any vehicle. station. DO NOT use matches or a lighter Electric current and/or electronic inter- and DO NOT SMOKE or leave a lit ciga- ference from cellular phones can poten- rette in your vehicle while at a gas...
Page 96 NOTICE • If the fuel filler cap requires replacement, use only a genuine Kia cap or the equivalent specified for your vehicle. An incorrect fuel filler cap can result in a serious malfunction of the fuel system or emission control system.
Page 97: Steering Wheel
Knowing Your Vehicle STEERING WHEEL CAUTION • To sound the horn, press the area indicated by the horn symbol on your steering wheel (see illustration). The horn will operate only when this area is pressed. • Do not strike the horn severely to operate it, or hit it with your fist.
Page 98 WARNING - Tilt Steering • Never adjust the position of the steering wheel while the vehicle is in motion, or you may lose control of the vehicle. • After adjusting, push the steering wheel up and down to be certain it is locked in position.
Page 99: Mirrors
Knowing Your Vehicle MIRRORS Outside Rearview Mirrors Be sure to adjust mirror angles before driving. WARNING - Convex Mirror The outside rearview mirrors are convex. Objects seen in the mirror are closer than they appear. When changing lanes, use your inside rearview mirror or direct obser- vation to determine the actual distance of following vehicles.
Page 100 NOTICE The mirrors stop moving when they reach the maximum adjusting angles, but the motor continues to operate while the switch is depressed. Do not depress the switch longer than necessary, the motor may be damaged. Outside Rearview Mirror Heater (if equipped) The outside rearview mirror heater is actuated in C1V2B013...
Page 101 Knowing Your Vehicle Electric type (if equipped) The electric rearview mirror automatically controls the glare from the headlights of the car behind you in nighttime or low light driving conditions. The Day/Night lever sensor mounted in the mirror senses the light level around the vehicle, and through a chemical reac- tion, automatically controls the headlight glare from vehicles behind you.
Page 102: Interior Lights
INTERIOR LIGHTS DOOR TILT SLIDE MODE HOUR Sensor Indicator HGQ3074 C1GQ1030 Dome Light - Front Press the button ( ) to turn the automatic- dimming function on. The mirror indicator light will The front dome light switch has three positions. illuminate.
Page 103 Knowing Your Vehicle NOTICE The dome lig ht(s) will automatically turn on and then go off after about 20 seconds when any of the following occur: If the upper part ( ) of the rear dome light main control switch is pressed in. •...
Page 104 C1V21010 CGQ03105 Rear Cargo Area Light The rear dome lights are switched ON or OFF by pressing the corresponding lense. The cargo area light is located on the inside of rear hatch. The switch has three positions: OFF - The light stays off even when a door is open. NOTICE •...
Page 105: Cup Holder
Knowing Your Vehicle CUP HOLDER arms CBGQ750A CBGQ1029 Door Courtesy Lamp Front Cup Holder The door courtesy lamp comes ON when the door Press the cup holder in, then release it to allow the is opened. To assist when you get in or out and also cup holder to slowly extend from the instrument to warn passing vehicles.
Page 106 2nd row bench seat (if equipped) NOTICE To use the front cup holder, pull the front face completely and the arms will swing open widely to the utmost. The arms can be adjusted to the size of a beverage cup or can.. You can select it from 5 arm positions.
Page 107: Sunglass Holder
Knowing Your Vehicle SUNGLASS HOLDER (IF EQUIPPED) WARNING - Hot Liquids • Do not place uncovered cups of hot liquid in the cup holder while the vehicle is in motion. If the hot liquid spills, you could be burned. Such a burn to the driver could cause a loss of control of the vehicle.
Page 108: Storage Compartment
STORAGE COMPARTMENT CBGQ1010/C1GQ1014 C1V21050 Front Seat Storage Bin (if equipped) Storage The storage bin is located under the front passen- To access a storage compartment, open by releas- ger’s seat and can be locked with a key. To open, ing the latch. pull the lever up and pull the storage bin out.
Page 109 Knowing Your Vehicle C1GQ1012 C1GQ1020 Rear Console Storage Glove Box To access the rear console storage compartment, The glove box door can be locked or unlocked with pull the latch, and lift the cover. a key. To open the glove box door, pull the latch out and let the glove box open.
Page 110: Plastic Grocery Bag Retainer
PLASTIC GROCERY BAG RETAINER (IF EQUIPPED) CAUTION To reduce the risk of injury in case of an acci- dent or sudden stop, always keep the glove box door closed while driving. NOTICE To avoid possible theft, do not leave valuables in the glove box.
Page 111: Clothes Hanger
Knowing Your Vehicle CLOTHES HANGER (IF EQUIPPED) COIN HOLDER C1V21052 CBGQ1024 The clothes hanger is designed with a hook. Press The coin holder is located to the left of the steering the hanger cover to extend the clothes hook. column. Do not use the coin holder as an ashtray.
Page 112: Electrical Power Outlet
ELECTRICAL POWER OUTLET (IF EQUIPPED) C1GQ1023/C1GQ1018 CBGQ1013 To plug in auxiliary electrical equipment, flip the NOTICE outlet cover open from the edge of the cover and • Use when the engine is running, and remove follow the proper installation instructions that are a plug from the power outlet after using the included with any electrical equipment you use.
Page 113: Seatback Holder
Knowing Your Vehicle SEATBACK HOLDER (IF EQUIPPED) (Continued) • Adjust the air-conditioner or heater to the lowest operation level when you have to use the power socket while using air-condi- tioner or heater. • If you have to use to the electrical acces- sories that draw higher power (vacuum cleaner, lights, cooler, etc.) only use the power outlet intermittently and with greater...
Page 114: Sunroof
SUNROOF (IF EQUIPPED) Sliding the sunroof Open The sunroof can be opened or closed when the ignition switch is in the “ON” position. To slide the DOOR sunroof, press “Open” on the SLIDE switch once. TILT SLIDE The sunroof will slide all the way open. To stop the sunroof sliding at any point, press “Open”...
Page 115 Knowing Your Vehicle DOOR TILT SLIDE Down MODE HOUR C1GQ1027 CGQ03016 Sunshade Tilting the sunroof The sunshade will be opened with the glass panel To tilt the sunroof, press “Up” on the TILT switch. To automatically when the glass panel is slid. You will close it, press “Down”...
Page 116 NOTICE • Do not depress the sunroof switch longer than necessary. It could cause the failure of the sunroof motor. • Periodically remove any dirt that may accu- mulate on the guide rail. • If you try to open the sunroof when the temperature is below freezing or when the sunroof is covered with snow or ice, the glass or the motor could be damaged.
Page 117: Antenna
Knowing Your Vehicle ANTENNA CAUTION • Be sure to remove the antenna before washing the car in an automatic car wash or it may be damaged. • When reinstalling your antenna, it is impor- tant that it is fully tightened to ensure proper reception.
Page 118: Roof Rack
ROOF RACK (IF EQUIPPED) NOTICE • The cross bars should be positioned before carrying a load on the roof rack. • In case the sunroof is equipped, do not posi- tion roof rack loads that could interfere with opening of the sunroof. •...
Page 119 Knowing Your Vehicle • Loading cargo or luggage above 45 kg (100 lb) on the roof rack may damage your vehicle. When you carry large objects, never let them hang over the rear or the sides of your vehicle. • To prevent damage or loss of cargo as you are driving, check frequently to make sure the luggage carrier and cargo are still securely fastened.
Page 120 DRIVING YOUR VEHICLE Ignition Switch ....... 4-3 Starting ........4-5 Automatic Transaxle .
Page 121 Hazard Warning Flasher ..... . 4-60 Interior Features ......4-61 Climate Control System .
Page 122: Ignition Switch
IGNITION SWITCH Ignition Switch and Anti-Theft Steering Column Lock Ignition Switch Positions LOCK The steering wheel locks to protect against theft. The ignition key can be removed only in the LOCK position. When turning the ignition switch to the LOCK position, push the key inward at the ACC position and turn the key toward the LOCK posi- tion.
Page 123: Driving Your Vehicle
Driving Your Vehicle WARNING - Ignition Key The warning lights can be checked before the • It is dangerous to turn the ignition switch engine is started. This is the normal running posi- to LOCK or ACC while the vehicle is tion after the engine is started.
Page 124 STARTING THE ENGINE 1. Make sure the parking brake is applied. NOTICE 2. Place the transaxle shift lever in P (Park). Depress the brake pedal fully. If the engine stalls while you are in motion, do not attempt to move the shift lever to the P You can also start the engine when the shift (Park) position.
Page 125 Driving Your Vehicle If the engine fails to start when the engine is cold: If the engine fails to start when the engine is warm: A no-start condition, characterized by failure to The engine is “cold” when the engine coolant restart a warmed engine despite repeated temperature drops below 32°F/0°C.
Page 126 Excessive engine noise may occur if the engine has not been operated for an extended period. The noise should stop after the engine has reached normal operating temperature. If the noise does not stop, have the vehicle inspected by an autho- rized Kia dealer.
Page 127 Driving Your Vehicle AUTOMATIC TRANSAXLE (IF EQUIPPED) Lock release button Prevents shift lever movement without first depressing the button. O/D System Shift lever Pressing the button de- Normal transaxle gear ranges activates the O/D mode. are provided on the right side of Pressing again re-acti- the indicator.
Page 128 To move the shift lever from the P (Park) position, the ignition switch must be in the ON position, the brake pedal must be depressed and the lock release button must be depressed. For smooth operation, depress the brake pedal when shifting from N (Neutral) to a forward or reverse gear.
Page 129 Also, the ignition key cannot be removed unless Authorized Kia Dealer as soon as possible. the shift lever is in the P (Park) position. If the igni- tion switch is in any other position, the key cannot be removed.
Page 130 When driving down a sloping road with the transaxle in O/D (5th), you can decrease the vehi- cle speed without using the brakes by pressing the O/D OFF button. When the ignition is switched OFF, O/D OFF mode is automatically cancelled. O/D OFF indicator This indicator light illuminates in the instrument panel when the O/D mode is cancelled.
Page 131 Driving Your Vehicle P (Park) • Before leaving the driver’s seat, always This position locks the transaxle and prevents the make sure the shift lever is in the P front wheels from rotating. Always come to a (PARK) position. Set the parking brake complete stop before shifting into this position.
Page 132 For extra power when passing another vehicle or R (Reverse) climbing grades, depress the accelerator fully, at Use this position to drive the vehicle backward. which time the transaxle will automatically downshift to the next lower gear. NOTICE 3 (Third Gear) Always come to a complete stop before shift- Use 3 (Third Gear) for more power climbing hills ing into or out of R (Reverse);...
Page 133 Driving Your Vehicle NOTICE Do not exceed the recommended maximum speeds in 3 (Third Gear) or L (Low). Operat- ing the vehicle at speeds above the maximum recommended, for these gears may cause excessive heat to develop which could result in damage to or failure of the automatic transaxle.
Page 134 CBGQ1015 CBGQ1017 2. Insert the ignition key into the access hole and 3. Depress the lock release button and move the press down on the key. shift lever. 4. Have your vehicle inspected by an authorized Kia dealership immediately. 4-15...
Page 135: Brake System
Driving Your Vehicle BRAKE SYSTEM In the Event of Brake Failure Power Brakes If the service brakes should fail to operate while the Your vehicle has power-assisted brakes that adjust vehicle is in motion, you can make an emergency automatically through normal usage. stop with the parking brake.
Page 136 Disc Brake Wear Indicators WARNING - Brakes Your vehicle has front disc brakes. • Do not drive with your foot resting on the When your front brake pads are worn and it’s time brake pedal. This will create abnormally for new pads, you will hear a high-pitched warning high brake temperatures, excessive brake sound from your front brakes.
Page 137 Driving Your Vehicle Rear Drum Brakes NOTICE Your rear drum brakes do not have wear indicators. To avoid costly brake repairs, do not continue Therefore, have the rear brake linings inspected if to drive with worn brake pads. Always replace you hear a rear brake rubbing noise.
Page 138 CBGQ1026 CBGQ1027 Parking Brake To release the parking brake, pull the handle forward you while applying the service brake. To set the parking brake, depress the parking brake pedal fully and firmly downward while apply- ing the service brake. 4-19...
Page 139 Driving Your Vehicle WARNING To prevent unintentional movement when stopped and leaving the vehicle, do not use the gearshift lever in place of the park- ing brake. Set the parking brake AND make sure the gearshift lever is securely posi- tioned in P (Park).
Page 140 If the brake warning light remains on after the park- Parking on Curbed Streets ing brake is released, there may be a malfunction • When parking your vehicle on an uphill grade, in the brake system. Immediate attention is neces- park as close to the curb as possible and turn sary.
Page 141 Driving Your Vehicle Anti-Lock Brake System (ABS) • Driving too fast on poor road surfaces. (If equipped) The ABS is designed to improve maxi- mum braking effectiveness on typical WARNING - ABS Brakes highways and roads in good condition. On poor road surfaces in poor condition, Your ABS is not a substitute for good the ABS may actually reduce braking driving judgement.
Page 142 The ABS system continuously senses the speed of the wheels. If the wheels are going to lock, the ABS system repeatedly modulates the hydraulic brake pressure to the wheels. When you apply your brakes under conditions which may lock the wheels, you may hear a “tik-tik’’...
Page 143 If the light stays on, you may have a Otherwise, you may have a problem with problem with your ABS system. Contact an the ABS. Contact an authorized Kia dealer authorized Kia dealer or another competent or another competent service center as soon service center as soon as possible.
Page 144 NOTICE When you jump start your vehicle because of a discharged battery, the engine may not run as smoothly and the ABS warning light may blink at the same time. This happens because of the low battery voltage. It does not mean your ABS is malfunctioning.
Page 145: Power Steering
Kia dealer or another competent When this happens, increase the engine RPM service center. to 1500 rpm then release or let the engine idle for two or three minutes to warm up the fluid.
Page 146 NOTICE • Never hold the steering wheel against a stop (extreme right or left turn) for more than five seconds with the engine running. Hold- ing the steering wheel for more than five seconds in either position may cause damage to the power steering pump. •...
Page 147: Cruise Control
Driving Your Vehicle CRUISE CONTROL (IF EQUIPPED) The cruise control system allows you to program the vehicle to maintain a constant speed without resting your foot on the accelerator pedal. With cruise control, you can set and automatically maintain any speed of more than about 24 mph (40 km/h).
Page 148 WARNING If the CRUISE MAIN switch is left on, the cruise control can be switched on acciden- tally. Keep the CRUISE MAIN switch off when cruise control is not in use. AIR BAG CGQ04102 3. Depress the SET/COAST switch, located on the steering wheel, and release it at the speed you want.
Page 149 Driving Your Vehicle To Cancel Cruise Control, do one of the To turn cruise control off, do one of the follow- following: ing: • Depress the brake pedal. • Push the CRUISE switch to the OFF position. • Shift into N (Neutral). •...
Page 150 To Temporarily Accelerate with the Cruise Control On If you want to speed up temporarily when the cruise control is on, depress the accelerator pedal. Increased speed will not interfere with cruise control operation or change the set speed. To return to the set speed, take your foot off the accelerator.
Page 151 Driving Your Vehicle AIR BAG CGQ04102 CGQ04103 To Decrease the Cruising Speed: To Resume Cruising Speed at More Than 24 mph (40 km/h): Follow either of these procedures: If something besides the CRUISE MAIN switch • Depress the COAST/SET switch and hold it.Your was used to cancel cruising speed and the system vehicle will gradually slow down.
Page 152: Instrument Cluster
INSTRUMENT CLUSTER 1. Tachometer 2. Turn signal indicators 3. Speedometer 4. Engine temperature gauge 5. Warning and indicator lights 6. Tripmeter / Odometer 7. Trip meter reset button 8. A/T range indicator 9. Fuel gauge 5GQ0411 4-33...
Page 153: Gauges
Driving Your Vehicle GAUGES Speedometer The speedometer indicates the forward speed of the vehicle. Odometer/Tripmeter You can choose the odometer, tripmeter A and trip- meter B by pressing the mode selection button. Odometer The odometer indicates the total distance the vehi- cle has been driven.
Page 154 CGQ04113 CBGQ0411 Fuel Gauge Tachometer The fuel gauge indicates the approximate amount The tachometer indicates the approximate number of fuel remaining in the fuel tank. of engine revolutions per minute (rpm). Fuel tank capacity - 19.5 gal. (75 liters). Use the tachometer to select the correct shift points and to prevent lugging the engine and/or The fuel gauge is supplemented by a low fuel over-revving the engine.
Page 155 Driving Your Vehicle The tachometer pointer may move slightly when the ignition switch is in ACC or ON position with the engine OFF. This movement is normal and will not affect the accuracy of the tachometer once the engine is running. NOTICE Do not operate the engine within the tachome- ter’s RED ZONE.
Page 156: Warnings And Indicators
The light will go off if the ABS system is operating that does not illuminate should be checked by an normally. Authorized Kia Dealer or another competent Also, this light illuminates if the key is turned to ON service center.
Page 157 If the warning light remains on after adding oil or if oil is not available, call an Authorized Kia Dealer or 3. If the belt is adjusted properly, a problem exists other competent repair shop.
Page 158 N operate properly. Have it towed to any Authorized (Neutral), D (Drive), 3 (Third), and L (Low) symbols Kia Dealer for a brake system inspection and are illuminated by green lights. necessary repairs.
Page 159 Refuel as soon as possible. is dangerous. If the brake warning light remains on, have the brakes checked and Front and Rear Window repaired immediately by an Authorized Kia Defroster Indicator Dealer. This light comes on when the defroster switch is...
Page 160 Generally, your vehicle will continue to be drivable Door Ajar Warning and will not need towing, but have the system checked by an Authorized Kia Dealer or other competent repair shop as soon as possible. This warning light comes on when a door is not closed securely with the ignition in any position.
Page 161 Authorized ignition key is turned ON or if it is unfastened after Kia Dealer or another competent service center for the key is ON, the safety belt warning chime will immediate service.
Page 162: Back Warning System
BACK WARNING SYSTEM (IF EQUIPPED) This system will activate when the back-up light comes on and the ignition switch is in the "ON" position. The warning signal has three distinct alerts. The 1st alert beeps intermittently, the 2nd beeps a little faster and 3rd beeps continuously. If you hear an audible warning sound when shifting gears to "R"...
Page 163 • Do not push, or scratch the surface of the this occurs, have your vehicle checked by sensor. This may cause damage to the cover- your authorized Kia dealer as soon as ing. possible. • The sensor system might not recognize...
Page 164: Trip Computer
TRIP COMPUTER (IF EQUIPPED) The trip computer is a driver controlled microcom- puter that provides the driver with important driving information such as a clock, possible driving distance, average speed, drive time and ambient MODE HOUR temperature. Mode Pushing the MODE button allows you to select the trip meter functions.
Page 165 Driving Your Vehicle NOTICE If the battery has been removed and reinstalled or if the vehicle is not level, the possible MODE HOUR driving distance function may not operate correctly. The possible driving distance may be some different from actual driving distance MILES according to your driving conditions.
Page 166 MODE HOUR MODE HOUR TIME MILES FGQ412 CBGQ0416A Average speed Drive time This mode indicates the average speed from igni- This mode indicates the total time from ignition key tion key “ON” to ignition key “OFF”. To reset the “ON” to ignition key “OFF”. To reset the drive time, average speed, push “MODE”...
Page 167 Driving Your Vehicle MODE HOUR CBGQ0418 Ambient temperature This mode indicates the ambient temperature around the vehicle. 4-48...
Page 168: Lighting
LIGHTING Battery Saver Function • The purpose of this feature is to prevent the battery from being discharged. The system auto- matically turns off the small light when the driver removes the ignition key and opens the driver- AUTO AUTO side door.
Page 169 Driving Your Vehicle Parklight position. When the light switch is in the parklight position, the tail, parking, license and instrument panel lights are ON. AUTO AUTO Headlight position. When the light switch is in the headlight position, the head, tail, parking, license and instrument panel lights are ON.
Page 170 External illumination sensor AUTO CCGQ0416 CCGQ0411 High-Beam Operation NOTICE To turn on the high-beam headlights, push the To ensure better control of the auto light lever away from you. Pull it back for low beams. system, never place items on the sensor The high-beam indicator will light when the head- located on the dash.
Page 171 Driving Your Vehicle AUTO AUTO CCGQ0412 CCGQ0413 Flashing Headlights Turn Signals To flash the headlights, pull the lever toward you. It The ignition switch must be on for the turn signals will return to the normal position when released. to function. To turn on the turn signals, move the The headlight switch does not need to be on to use lever up or down.
Page 172 Lane Change Signals To signal a lane change, move the turn signal lever slightly and hold it in position. The lever will return to the OFF (center) position when released. If an indicator stays on and does not flash or if it flashes abnormally, one of the turn signal bulbs may be burned out and will require replacement.
Page 173: Wipers And Washer
Driving Your Vehicle WIPERS AND WASHERS CCGQ04001 CCGQ04002 Auto Control (if equipped) Windshield Wipers When the windshield wiper switch is placed in the The ignition switch must be ON. “AUTO” position, the rain sensor located on the To turn the wipers on, move the lever down. upper end of windshield glass senses the amount INT - Intermittent wiper operation of rainfall and controls for the appropriate length of...
Page 174 TIME REAR Rain sensor CCGQ04003 CCGQ04007 Variable Intermittent Wipers Set the lever to the INT/AUTO position and choose WARNING - Rain Sensor the desired wiper interval by turning the ring. When the ignition switch is on and the windshield wiper switch is placed in the “AUTO”...
Page 175 Driving Your Vehicle NOTICE • To prevent possible damage to the wipers or windshield, do not operate the wipers when the windshield is dry. • To prevent damage to the wiper blades, do not use gasoline, kerosene, paint thinner, or TIME REAR other solvents on or near them.
Page 176 If the washer does not work, check the washer fluid level. If the fluid level is not sufficient, you will need to add an appropriate non-abrasive windshield washer fluid to the washer reservoir. The reservoir filler neck is located in the front of the engine compartment on the passenger side.
Page 177 Driving Your Vehicle - Spraying washer fluid and wiping INT - Intermittent wiper operation ON - Normal wiper operation - Spraying washer fluid and wiping TIME REAR CCGQ04006 Rear Window Wiper and Washer Switch The rear window wiper and washer switch is located at the end of the wiper and washer switch lever.
Page 178: Defroster
DEFROSTER (IF EQUIPPED) NOTICE • To prevent damage to the conductors bonded to the inside surface of the bottom of the front windshield and the rear window, never use sharp instruments or window cleaners containing abrasives to clean the window. •...
Page 179: Hazard Warning Flasher
Driving Your Vehicle HAZARD WARNING FLASHER If your vehicle is equipped with the outside rearview mirror defroster, you can also clear frost from the mirrors by depressing this rear window defroster switch. To activate the defroster, depress the defroster switch located on the center console switch panel. Front windshield and rear window defroster indica- tors illuminate when the defrosters are on.
Page 180: Interior Features
NOTICE • Do not hold the lighter in after it is already heated because it will overheat. • Only a genuine Kia lighter or equivalent should be used in the cigarette lighter socket. The use of plug-in accessories (shavers, hand-held vacuums, and coffee pots, for example) may damage the socket or cause electrical failure.
Page 181 Driving Your Vehicle WARNING -Ashtray Use • Do not use the vehicle’s ashtrays as waste receptacles. • Putting lit cigarettes or matches in an ashtray with other combustible materi- als may cause a fire. C1GQ1011 Ashtrays Front Ashtray To use the ashtray, press the front face and release it to allow the cigarette lighter and ashtray cover to flip up.
Page 182 C1GQ1013 C1GQ1015 Rear Ashtray Sunvisors To use the ashtray, open the cover. To use a sunvisor, pull it downward. To remove the ashtray, pull it up and out. To use a sunvisor for a side window, pull it downward, unsnap it from the bracket and swing it to the side. You can extend the side of the sunvisor to provide additional shade.
Page 183: Climate Control System
Driving Your Vehicle CLIMATE CONTROL SYSTEM (IF EQUIPPED) REAR FRONT 1. Fan speed control knob 4. Rear fan speed control knob 2. Mode selection knob 5. Air conditioning button (if equipped) 3. Temperature control knob 6. Air flow control button 4GQN401 4-64...
Page 184 FRONT CBGQ0409 CBGQ0410 Temperature Control Knob Fan Speed Control Knob The temperature control knob allows you to control Four (4) adjustable fan speeds are provided which the temperature of the air flowing from the ventila- increase as the number increases. The ignition tion system.
Page 185 Driving Your Vehicle 4GQN402 Mode Selection Knob The mode selection knob controls the direction of the air flow through the ventilation system. The air from outlet port D flows at any mode. Close the ventilation outlets using the knob to block the air CGQA2162 flow if you do not want the air.
Page 186 Face position Floor position Air flow is directed toward the upper body Most of the air flow is directed to the floor, and face. Additionally, each outlet can be with a small amount of the air being controlled to direct the air discharged directed to the windshield and side from the outlet.
Page 187 Driving Your Vehicle Floor - defrost position MAX/ A/C position (if equipped) Most of the air flow is directed to the floor When you select the MAX A/C mode and the windshield with a small amount while the fan speed is on, it will be set the directed to the side window defrosters.
Page 188 This position can be used temporarily for maximum heating or cooling (if equipped with an air condi- tioning) and to help prevent undesirable outside air flow into the vehicle. CAUTION Continued climate control system operation in the recirculated air position may allow humid- ity to increase inside the vehicle which may fog the glass and obscure visibility.
Page 189 Driving Your Vehicle Outside (fresh) air position PUSH If you press the air intake control button again, the air position will be changed to outside (fresh) air and air will enter the ventilation system from outside the vehicle. Use this position for normal ventilation and heating.
Page 190 Heating System Operation 1. Set the mode selection knob to the position. Ventilation 2. Set the air intake control button to the outside 1. Set the mode selection knob to the position. (fresh) air position. 2. Set the air intake control button to the outside 3.
Page 191 • If warmer air is desired at floor level for bi-level Air conditioning (if equipped) operation, set the mode selection knob to the All Kia Air Conditioning Systems are filled with position and adjust the temperature control environmentally friendly R134a refrigerant which is knob to maintain maximum comfort.
Page 192 • The air conditioning system includes a function Air Conditioning System Operation Tips that will automatically turns the air conditioning • If the vehicle has been parked in direct sunlight compressor off if engine coolant temperature during hot weather, open the windows for a short approaches an over heating level.
Page 193 Driving Your Vehicle RR HTR CGQ03902/BGQD601A 4GQN403/C1V21012A Rear Climate Control System Cooling To turn the rear cooling system ON, depress the air You can control the rear climate control system for rear passenger compartment in front seat. conditioning button and turn the rear fan speed control knob clockwise to the desired position.
Page 194 CGQ03902A C1V21012 The rear fan speed control knob located on the roof Rear fan speed control konb at the rear seat has three (3) adjustable fan speeds Three (3) adjustable fan speeds are provided which increase with the size bar beside the knob. which increase as the number increases.
Page 195: Windshield Defrosting And Defogging
Driving Your Vehicle WINDSHIELD DEFROSTING AND CAUTION DEFOGGING Do not use defrost position during cooling operation in extremely humid weather. The difference between the temperature of the outside air and that of the windshield could cause the outer surface of the windshield to fog up, causing loss of visibility.
Page 196 • For maximum defrosting, set the temperature control knob to the extreme right/hot position and the fan speed control knob to the highest speed. • If warm air to the floor is desired while defrosting or defogging, set the mode selection knob to the floor- defrost position.
Page 197 Driving Your Vehicle 1. Turn the ignition switch to the “ON” position. 2. Turn the fan speed control knob to the “0” posi- tion. FRONT 3. Turn the mode selection knob to the defrost position 4. Push the air intake control button at least 5 times within 3 seconds.
Page 198 1. Turn the ignition switch to the “ON” position. 2. Turn the fan speed control knob to the “0” posi- tion. FRONT 3. Turn the mode selection knob to the defrost position 4. Push the air intake control button at least 5 times within 3 seconds.
Page 199 DRIVING TIPS Fuel Requirements ......5-2 Emission Control System ..... . 5-3 Tips on Driving Your Vehicle .
Page 200: Driving Tips
Never add any fuel system cleaning agents to result from the use of: the fuel tank other than what Kia has specified or the equivalent. (Consult an authorized Kia 1. Gasohol containing more than 10% ethanol.
Page 201: Emission Control System
Engine exhaust gases contain carbon This vehicle should not be modified. Modification of monoxide (CO). Though colorless and your Kia could affect its performance, safety or odorless, it is dangerous and could be durability and may even violate governmental lethal if inhaled. Follow the instructions safety and emissions regulations.
Page 202 Driving Tips • Do not operate the engine in confined or closed Operating Precautions for Catalytic areas (such as garages) any more than what is Converters necessary to move the vehicle in or out of the area. WARNING - Fire •...
Page 203: Tips On Driving Your Vehicle
TIPS ON DRIVING YOUR VEHICLE • Do not operate the engine at high idle speed for Before Entering Vehicle: extended periods (5 minutes or more). • Be sure that all windows, outside mirror(s), and • Do not modify or tamper with any part of the outside lights are clean.
Page 204 Driving Tips Before Starting WARNING - Driving Under the • Close and lock all doors. Influence of • Position the seat so that all controls are easily Alcohol or Drugs reached. Drinking and driving is dangerous. Drunk • Adjust the inside and outside rearview mirrors. driving is the number one contributor to •...
Page 205: Suggestions For Economical Operation
SUGGESTIONS FOR ECONOMICAL OPERATION • Do not use the air conditioner unnecessarily. • Slow down when driving on rough roads. Your vehicle’s fuel economy depends mainly on your style of driving, where you drive and when you • For longer tire life and better fuel economy, drive.
Page 206: Special Driving Conditions
Therefore, • Avoid sudden movements in braking or steering. have an authorized Kia dealer perform scheduled • When braking in the four-wheel drive mode (if inspections and maintenance. equipped), pump the brake pedal with a light up- and-down motion until the vehicle is stopped.
Page 207 • If stalled in snow, mud, or sand, use second Rocking the Vehicle gear. Accelerate slowly to avoid spinning the If it is necessary to rock the vehicle to free it from drive wheels. snow, sand, or mud, first turn the steering wheel •...
Page 208 Driving Tips Driving at Night NOTICE Because night driving presents many more Prolonged rocking may cause engine over- hazards than driving in the daylight, here are some heating, transaxle damage or failure, and tire important tips to remember: damage. • Slow down and keep more distance between you and other vehicles, as it may be more difficult to see at night, especially in areas where there may not be any street lights.
Page 209 Driving in the Rain Winter Driving Rain and wet roads can make driving dangerous, • We recommend that you carry emergency especially if you’re not prepared for the slick equipment, including tire chains, a window pavement. Here are a few things to consider when scraper, windshield de-icer, a bag of sand or driving in the rain: salt, flares, a small shovel and jumper cables.
Page 210 Driving Tips Snow Tires If you mount snow tires on your Kia, make sure they are radial tires of the same size and load range as the original tires. Mount snow tires on all four wheels to balance your vehicle’s handling in all weather conditions.
Page 211 Chain Installation CAUTION When installing chains, follow the manufacturer's • Make sure the snow chains are the correct instructions and mount them as tightly as you can. size and type for your tires. Incorrect snow Drive slowly with chains installed. If you hear the chains can cause damage to the vehicle chains contacting the body or chassis, stop and body and suspension and may not be...
Page 212 Driving Tips Driving in Flooded Areas WARNING - Tire Chains Avoid driving through flooded areas unless you are • The use of chains may adversely affect sure the water is no higher than the bottom of the vehicle handling. wheel hub. Drive through any water slowly. Allow •...
Page 213: Trailer Towing
TRAILER TOWING NOTICE WARNING - Towing a Trailer Pulling a trailer improperly can damage your If you don’t use the correct equipment and vehicle and result in costly repairs not covered drive properly, you can lose control when by your warranty. To pull a trailer correctly, you pull a trailer.
Page 214 Driving Tips Load-pulling components such as the engine, • After your odometer indicates 500 miles or more, transaxle, wheel assemblies, and tires are forced you can tow a trailer. For the first 500 miles that to work harder against the load of the added you tow a trailer, don’t drive over 50 mph (80 weight.
Page 215 Weight of the Trailer Tongue WARNING The tongue load of any trailer is an important • An improperly loaded trailer can cause weight to measure because it affects the total loss of control of your vehicle. gross vehicle weight (GVW) of your vehicle. This •...
Page 216 Driving Tips Hitches It’s important to have the correct hitch equipment. Crosswinds, large trucks going by, and rough roads are a few reasons why you’ll need the right hitch. Here are some rules to follow: • Will you have to make any holes in the body of your vehicle when you install a trailer hitch? If you do, then be sure to seal the holes later when you remove the hitch.
Page 217 Safety Chains Trailer Brakes You should always attach chains between your If your trailer weighs more than 1,250 pounds (570 vehicle and your trailer. Cross the safety chains kg) loaded, then it needs its own brakes – and they under the tongue of the trailer so that the tongue must be adequate.
Page 218 Driving Tips Driving with a Trailer Following Distance Towing a trailer requires a certain amount of Stay at least twice as far behind the vehicle ahead experience. Before setting out for the open road, as you would when driving your vehicle without a you must get to know your trailer.
Page 219 When you’re turning with a trailer, make wider turns Use only an approved trailer wiring harness. Your than normal. Do this so your trailer won’t strike soft authorized Kia dealer can assist you in installing shoulders, curbs, road signs, trees, or other the wiring harness.
Page 220 Driving Tips Driving on Grades Parking on Hills Reduce speed and shift to a lower gear before you Generally, you should not park your vehicle, with a start down a long or steep downgrade. If you don’t trailer attached, on a hill. People can be seriously shift down, you might have to use your brakes so or fatally injured, and both your vehicle and the much that they would get hot and no longer...
Page 221 However, if you ever have to park your trailer on a When You Are Ready to Leave After hill, here’s how to do it: Parking on a Hill 1. Apply your brakes, but don’t shift into gear. 1. With the transaxle in P (Park), apply your brakes 2.
Page 222 Driving Tips Maintenance When Trailer Towing NOTICE Your vehicle will need service more often when you Due to higher load during trailer usage, regularly pull a trailer. Important items to pay overheating might occur in hot days or during particular attention to include engine oil, automatic uphill driving.
Page 223: Overloading
Overloading LABEL INFORMATION There several important labels WARNING - Weight Rating identification numbers located on your vehicle. The label locations are identified in the illustrations on The gross axle weight rating (GAWR) and the following three pages. the gross vehicle weight rating (GVWR) for your vehicle are on the manufacturer’s label attached to the driver’s door.
Page 224 Driving Tips CBGQ0551 CBGQ05101 Vehicle Identification Number (VIN) Vehicle Certification label (MVSS label) This is the legal identifier for your vehicle. It The VIN also appears on the vehicle’s certification appears on a plate attached to the left side of the label and VIN label on the pillar.
Page 225 3500 CGQ0610A CBGQ05102 Frame Vehicle Identification Number Vehicle Emission Control Information/Vacuum Hose Routing Diagram 5-27...
Page 226 Driving Tips CBGQ05100 1GHA611 Engine Number Tire Information Label 5-28...
Page 227: Homelink® Wireless Control System
HOMELINK® WIRELESS CONTROL SYSTEM (IF EQUIPPED) • Retain the original transmitter for future programming procedures (i.e., new vehicle CAUTION purchase). It is also suggested that upon • When programming HomeLink® the sale of the vehicle, the programmed Wireless Control System, you may be HomeLink buttons be erased for security operating a garage door or gate operator.
Page 228 Driving Tips Programming 1. Press and hold the two outside buttons releasing only when the indicator light begins to flash after approximately 20 seconds. (This procedure NOTICE erases the factory-set default codes. Do Not Some vehicles may require the ignition switch perform this step to program additional hand- to be turned to the second (or “accessory”) held transmitters.)
Page 229 3. The HomeLink indicator light will flash, first NOTICE slowly and then rapidly. When the indicator light For non rolling code garage door openers, flashes rapidly, both buttons may be released. follow steps 2 - 3. (The rapid flashing light indicates successful For rolling code garage door openers, follow programming of the new frequency signal.) steps 2 - 6.
Page 230 Driving Tips Rolling Code Programming 6. Return to the vehicle and firmly press and release the programmed HomeLink button up to To train a garage door opener (or other rolling code three times. The rolling code equipped device equipped devices) with the rolling code feature, should now recognize the HomeLink signal and follow these instructions after completing the activate when the HomeLink button is pressed.
Page 231 Operating HomeLink Erasing Programmed HomeLink Buttons To operate, simply press the programmed To erase the three programmed buttons (individual HomeLink button. Activation will now occur for the buttons cannot be erased): trained product (garage door, security system, • Press and hold the two outside buttons until the entry door lock, estate gate, or home or office indicator light beings to flash - after 20 seconds.
Page 232 Driving Tips Reprogramming a Single HomeLink Gate Operator Programming & Canadian Button Programming To program a device to HomeLink using a During programming, your hand-held transmitter HomeLink button previously trained, follow these may automatically stop transmitting. Continue to steps: press and hold the HomeLink button (note steps 2 through 4 in the “Programming”...
Page 233 Accessories WARNING If you would like additional information on the The transmitter has been tested and HomeLink Wireless Control System, HomeLink complies with FCC and DOC/MDC rules. compatible products, or to purchase other Changes or modifications not expressly accessories such as the HomeLink® Lighting approved by the party responsible for Package, please contact HomeLink at 1-800-355- compliance could void the user’s authority...
Page 234 IN CASE OF AN EMERGENCY Road Warning ....... 6-2 Overheating ....... . . 6-3 Emergency Starting .
Page 235: In Case Of An Emergency
In Case Of An Emergency ROAD WARNING Depress the flasher switch to activate at any time. The flasher switch is located in the center console switch panel. All turn signal lights will flash simultaneously. • The hazard warning flasher operates whether your vehicle is running or not.
Page 236: Overheating
Neutral (manual transaxle) or Park been corrected. Call an authorized Kia dealer for (automatic transaxle) and apply the parking assistance. If you do not find a leak or other brake.
Page 237: Emergency Starting
This could cause serious injury. or towing service jump start your vehicle. If the engine frequently overheats, have the cooling NOTICE system checked and repaired by Authorized Kia Use only a 12-volt jumper system. You can Dealer. damage a 12-volt starting motor, ignition...
Page 238 WARNING - Battery WARNING - Battery Never attempt to check the electrolyte level • Keep all flames or sparks away from the of the battery as this may cause the battery battery. The battery produces hydrogen to rupture or explode causing serious gas which may explode if exposed to injury.
Page 239 In Case Of An Emergency Connecting jumper cables Connect cables in numerical order and disconnect in reverse order. Discharged battery 3500 Booster battery Jumper Cables CGQ06001...
Page 240 Kia dealer. the booster battery. Proceed to connect one end of the other jumper cable to the negative...
Page 241 In Case Of An Emergency Push-Starting Your manual transaxle-equipped vehicle should not be push-started because it might damage the emission control system. Vehicles equipped with automatic transaxles cannot be push-started. Follow the directions for jump-starting in this manual. CAUTION Never tow a vehicle to start it because the sudden surge forward when the engine starts could cause a collision with the tow vehicle.
Page 242: Electrical Circuit Protection
Blown rating. Main fuse If the same fuse blows again, avoid using the system involved and immediately consult an authorized Kia dealer. Two kinds of fuses are used: standard for lower amperage rating and main for higher amperage Normal Blown ratings.
Page 243 In Case Of An Emergency Fuse Replacement WARNING - Fuse Replacement • Never replace a fuse with anything but another fuse of the same rating. • A higher capacity fuse could cause damage and possibly a fire. • Never install a wire instead of the proper fuse –...
Page 244 If a fuse is blown, it must be replaced. If it fits loosely, consult an authorized Kia dealer. 1. Turn the ignition switch and all other switches off. 2. Remove the fuse block cover by unhooking the tab on one end and tilting the cover back toward the other end.
Page 245 In Case Of An Emergency Fuse Box 3500 3500 CGQ06101 CGQ06003 If the 120A “MAIN” fuse is blown, it must be removed as follows: NOTICE 1. Disconnect the negative battery cable. After checking the fuse box in the engine 2. Remove the bolts in the photo above. compartment, securely install the fuse box cover.
Page 246 Description FUSE RATING PROTECTED OMPONENT Fuse Panel Description 1. W/SHD 15 A Defroster 2. S/ROOF 20 A Sunroof Driver-side kick panel 3. SRART 10 A Starting system, PCM, ACC 4. HAZARD 15 A Turn & Hazard flasher unit 5. P/SCK(FRT) 20 A Front Power Socket W/SHD...
Page 247 In Case Of An Emergency Engine compartment HORN 20 A Horm ABS2 30 A P/TRN 10 A PCM, Main relay MAIN 120A INJECTOR 15 A AUDIO 15 A Audio HORN (INJECTOR) (ABS2) (P/TRN) HEAD (HI) 15 A Head Light AUDIO HEAD(HI) ILLUMI (DN))
Page 248 1. Turn off the engine. 2. Turn off the headlights and tail lights. 3. Open the main fuse box cover in engine compartment and pull up the “AUDIO FUSE 15A”. This will change the memory fuse mode to prevent battery discharge. CAUTION •...
Page 249: Towing
It is acceptable to tow the vehicle with the rear If emergency towing is necessary, we recommend wheels on the ground (without dollies) and the front having it done by an authorized Kia dealer or a wheels off the ground. commercial tow-truck service. Proper lifting and...
Page 250 When towing your vehicle in an emergency without wheel dollies : 1. Set the ignition switch in the ACC position. 2. Place the transaxle shift lever in N (Neutral). 3. Release the parking brake. NOTICE Failure to place the transaxle shift lever in N (Neutral) may cause internal damage to the transaxle.
Page 251 CAUTION If towing is necessary, we recommend you to have it done by an Authorized Kia dealer or a Do not use the hooks under the rear of the commercial tow truck service. vehicle for towing purposes. These hooks are designed ONLY for transport tie-down.
Page 252 Towing in this manner may be done only on hard- NOTICE surfaced roads for a short distance and at low • Attach a towing strap to the tow hook. speeds. Also, the wheels, axles, power train, • Using a portion of the vehicle other than the steering and brakes must all be in good condition.
Page 253 • If the towing vehicle can hardly move, do not forcibly continue the towing. Contact an Authorized Kia dealer or a commercial tow CBGQB603A truck service for assistance. • Use a towing strap less than 16 feet (5 m) long.
Page 254 When your vehicle is being towed by NOTICE another vehicle other than a tow truck (In To prevent internal damage to the transaxle, case of an emergency) never tow your vehicle from the rear • Turn the ignition switch to ACC so the steering (backwards) with all four tires in contact with wheel isn’t locked.
Page 255 In Case Of An Emergency Tips for towing a stuck vehicle The following methods are effective when your vehicle is stuck in mud, sand or similar substances that prevent the vehicle from being driven out under its own power. • Remove the soil and sand, etc. from the front and the back of the tires.
Page 256: If You Have A Flat Tire
IF YOU HAVE A FLAT TIRE SPARE TIRE Remove Install C1V2B060 CGQ06200 Removing the Spare Tire Storing the Jack and Tools Your spare tire is stored underneath your vehicle, The jack handle and wheel lug nut wrench are directly below the cargo area. stored in the tool bag located in the rear washer compartment with the jack.
Page 257 In Case Of An Emergency CBGQ0610 C1V2B062 4. Loosen the wing nut located on the spare tire 3. Use the wheel lug nut wrench to loosen the bolt carrier assembly and then disconnect the latch enough to lower the spare tire carrier assembly, connecting the spare tire carrier to the spare tire enough to access to the wing-nut securing the lock assembly.
Page 258 Changing Tires Jacking instructions The jack is provided for emergency tire changing only. Follow jacking instructions to reduce the possibility of personal injury. WARNING - Changing Tires • Never attempt vehicle repairs in the traffic lanes of a public road or highway. C1V2B063 •...
Page 259 In Case Of An Emergency (Continued) • Be sure to use the correct front and rear jacking positions on the vehicle; never use the bumpers or any other part of the vehicle for jack support. • The vehicle can easily roll off the jack causing serious injury or death.
Page 260 4. Remove the wheel lug nut wrench, jack, jack handle, and spare tire from the vehicle. 5. Block both the front and rear of the wheel that is diagonally opposite the jack position. WARNING - Changing Tires To prevent vehicle movements while changing a tire, always set the parking brake fully, and always block the wheel diagonally opposite the wheel being...
Page 261 In Case Of An Emergency Type A Type B WARNING - Jack Location To reduce the possibility of injury, be sure to use only the jack provided with the vehicle and in the correct jack position; never use any other part of the vehicle for jack support.
Page 262 C1S21080 C1V2B065 8. Insert the jack handle into the jack and turn it 10. Mount the spare tire into position and install the clockwise, raising the vehicle until the tire just wheel lug nuts with the beveled edge inward. clears the ground. This measurement is approximately 1.2 in (30mm).
Page 263 In Case Of An Emergency C1S21081 CBGQ0615 11. Turn the jack handle counterclockwise and 12. Once the wheel lug nuts have been tightened, lower the vehicle until it touches the ground. lower the vehicle fully to the ground and continue to tighten the lug nuts until they are fully secured.
Page 264 If in doubt, Check the inflation pressures as soon as consult an Authorized Kia Dealer. possible after installing the spare tire. Adjust it to the specified pressure, if necessary. Refer to Section 8, Specifications.
Page 265 MAINTENANCE Maintenance Services ......7-3 Owner Maintenance ......7-11 Engine Compartment .
Page 266 Wiper Blades ....... 7-36 Battery ........7-39 Tires and Wheels .
Page 267: Maintenance Services
An authorized Kia dealer has factory-trained in accordance with the scheduled maintenance technicians and genuine Kia parts to service your service charts shown on the following pages. You vehicle properly. For expert advice and quality need this information to establish your compliance service, see an authorized Kia dealer.
Page 268: Maintenance
Schedule 1 – Normal Maintenance. quality standards and receives technical support • Repeated short distance driving. from Kia in order to provide you with a high level of • Driving in dusty conditions or sandy areas. service satisfaction.
Page 269 SCHEDULE 1 - NORMAL MAINTENANCE MAINTENANCE Number of Months or kilometers (Miles), whichever comes first INTERVALS Months 15 22.5 30 37.5 45 52.5 60 67.5 75 82.5 90 97.5 105 112.5 120 Miles x 1,000 15 22.5 30 37.5 45 52.5 60 67.5 75 82.5 90 97.5 105 112.5 120 MAINTENANCE (12) (24) (36) (48) (60) (72) (84) (96) (108) (120) (132) (144) (156) (168) (180) (192) ITEM...
Page 270 California Fuel tank air filter I : Inspect and if necessary, adjust, correct, clean or replace. (2) This maintenance is recommended by Kia. However, it is not necessary for emission warranty coverage or manufacturer recall R : Replace or change.
Page 271 SCHEDULE 1 - NORMAL MAINTENANCE (CONTINUED) MAINTENANCE Number of Months or kilometers (Miles), whichever comes first INTERVALS Months 15 22.5 30 37.5 45 52.5 60 67.5 75 82.5 90 97.5 105 112.5 120 Miles x 1,000 15 22.5 30 37.5 45 52.5 60 67.5 75 82.5 90 97.5 105 112.5 120 MAINTENANCE (12) (24) (36) (48) (60) (72) (84) (96) (108) (120) (132) (144) (156) (168) (180) (192) ITEM...
Page 272 Maintenance SCHEDULE 2 - SEVERE MAINTENANCE MAINTENANCE Number of Months or kilometers (Miles), whichever comes first INTERVALS Months 95 100 105 110 Miles x 1,000 95 100 105 110 MAINTENANCE (km x 1,000) (8) (16) (24) (32) (40) (48) (56) (64) (72) (80) (88) (96) (104) (112) (120) (128) (136) (144) (152) (160) (168) (176) ITEM Drive belts Replace every 3,000 miles or 3 months...
Page 273 California Fuel tank air filter I : Inspect and if necessary, adjust, correct, clean or replace. (2) This maintenance is recommended by Kia. However, it is not necessary for emission warranty coverage or manufacturer recall R : Replace or change.
Page 274 Maintenance SCHEDULE 2 - SEVERE MAINTENANCE (CONTINUED) MAINTENANCE Number of Months or kilometers (Miles), whichever comes first INTERVALS Months 95 100 105 110 Miles x 1,000 95 100 105 110 MAINTENANCE (km x 1,000) (8) (16) (24) (32) (40) (48) (56) (64) (72) (80) (88) (96) (104) (112) (120) (128) (136) (144) (152) (160) (168) (176) ITEM Brake lines and connections Drum brakes...
Page 275: Owner Maintenance
Bring any problem to the attention of an authorized WARNING Kia dealer or qualified service technician as soon Be careful when checking your engine as possible. coolant level. The engine compartment will be hot and you could be burned.
Page 276 • Coolant level in reservoir (cold engine) in this manual. Every 6 months (for example, every spring and When servicing your vehicle use only genuine Kia fall), check: replacement parts or equivalent. Genuine Kia parts can be obtained from your authorized Kia •...
Page 277 This section gives instructions only for warranty period may affect warranty coverage. items that are easy to perform. For details, read the separate Kia Warranty and Consumer Information Manual provided with the vehicle. If you’re unsure about any WARNING - Maintenance Work...
Page 278 Maintenance WARNING - Loose Clothing or WARNING - Engine Cooling Jewelry Fans Working under the hood with the engine Because your engine cooling fans are running is dangerous. It becomes even electronically controlled, they will run if the more dangerous when you wear jewelry or ignition switch is ON, even if the engine is loose clothing.
Page 279: Engine Compartment
ENGINE COMPARTMENT 1. Power steering fluid reservoir 2. Brake fluid reservoir 3. Air cleaner 4. Fuse box 5. Engine coolant reservoir 6. Windshield washer fluid reservoir 7. Engine oil filler cap 8. Engine oil dipstick 9. Auto transaxle oil dipstick 3500 3500 10.
Page 280: Engine Oil And Oil Filter
Maintenance ENGINE OIL AND OIL FILTER Checking the Engine Oil Level 1. Be sure the vehicle is on level ground. 2. Start the engine and allow it to reach normal operating temperature. Full 3. Turn the engine off and wait a few minutes for the oil to return to the oil pan.
Page 281 1. Run the engine for a few minutes to warm it up, Changing the Engine Oil and Filter then turn it off. Remove the oil filler cap. Change engine oil and filter according to the 2. Remove the drain plug from the oil pan and drain Scheduled Maintenance at the beginning of this the engine oil into a suitable container.
Page 282 Maintenance 3. Remove the engine oil filter with an oil filter 7. Install a new washer on the drain plug. wrench. 8. Replace the drain plug after the oil has thoroughly drained. Torque the plug to 22lb•ft (30N•m) NOTICE 9. Refill the engine with new oil to the F mark on Do not allow the oil filter gasket to remain on the dipstick.
Page 283: Engine Cooling System
These filters are not interchangeable. To avoid potential engine damage, use only the specified filter. Consult an authorized Kia dealer. • Follow these instructions carefully. An improper oil filter installation can cause oil leakage and engine damage.
Page 284 Maintenance Checking the Coolant Level (Continued) • Even if the engine is not operating, do WARNING - Removing not remove the radiator cap or the drain plug while the engine and radiator are Radiator Cap hot. Hot coolant and steam may still •...
Page 285 If the coolant level is low, add enough coolant to bring the level to FULL, but do not overfill. If frequent additions are required, see an authorized Kia dealer or another competent repair center for a FULL cooling system inspection.
Page 286 Maintenance For mixture percentage, refer to the following table Changing Coolant Change coolant according to the Scheduled Mixture percentage (volume) Maintenance. Ambient temperature Coolant • Use only soft (de-mineralized) water in the Water solution coolant mixture. 5°F (-15°C) • The engine in your vehicle has aluminum engine -13°F (-25°C) parts and must be protected by an ethylene- glycol-based coolant to prevent corrosion and...
Page 287 4. Drain the system completely and retighten the drain plug. Add the necessary amount of ethylene-glycol-based coolant and water to provide the required protection against freezing and corrosion. In extremely cold climates, add ethylene-glycol based coolant in accordance with the instructions of the manufacturer. 5.
Page 288: Brakes
If the fluid level becomes low frequently, have the brake system checked by an authorized Kia dealer or another competent repair center. Use only the specified brake fluid. (Refer to “Recommended Lubricants’’...
Page 289 CAUTION WARNING Do not allow brake fluid to contact the When changing and adding brake fluid, vehicle's body paint, as paint damage will handle it carefully. Do not let it come in result. Brake fluid, which has been exposed to contact with your eyes.
Page 290: Parking Brake
Before adding power steering fluid, thoroughly less than specified, have the parking brake clean the area around the reservoir cap to prevent adjusted by an authorized Kia dealer or another power steering fluid contamination. competent repair center. If the level is low, add fluid to the MAX level.
Page 291 In the event the power steering system requires frequent addition of fluid, the vehicle should be inspected by an authorized Kia dealer or another competent repair center. Use only the specified power steering fluid. (Refer to “Recommended Lubricants’’ in this section.)
Page 292 Maintenance AUTOMATIC TRANSAXLE The volume of the transaxle fluid changes with Checking the Automatic Transaxle Fluid temperature. Although it is best to check the level Level after having driven the vehicle for at least 30 minutes, the level can be checked after warming Automatic transaxle fluid dipstick the fluid using the procedure below.
Page 293 4. With the engine still idling, pull out the dipstick, appear light brown. Therefore, have an wipe it clean and reinsert it fully. Authorized Kia dealer change the automatic 5. Pull out the dipstick again and check the fluid transaxle fluid according to the Scheduled level.
Page 294 Maintenance 2. Remove the drain plug located at the bottom Changing the Automatic Transaxle Fluid center front of the transaxle pan. 1. Raise and suitably support the vehicle. 3. After the oil has drained, completely install a new washer on the plug, reinstall the drain plug, WARNING - Lifting Your and tighten to 22 lb•ft (30 N•m).
Page 295 NOTICE Do NOT overfill the automatic transaxle reservoir. Doing so can cause a seal “blow out,” loss of fluid, and damage to the transaxle. If you overfill the reservoir, you must drain the excess prior to driving the vehicle. transaxle will hold 2.7 qts. (2.5L) when completely empty.
Page 296: Lubricants And Fluids
Maintenance LUBRICANTS AND FLUIDS CGQ06005 C1V2B072 Checking the Front Washer Fluid Level Checking the Rear Washer Fluid Level The reservoir is translucent so that you can check The rear washer fluid reservoir filler tube is located the level with a quick visual inspection. along the right side of the cargo area, just below the pillar at the very rear of your vehicle.
Page 297 Body Lubrication WARNING All moving points of the body, such as door hinges, • Do not use radiator coolant or antifreeze hood hinges, and locks, should be lubricated each in the washer fluid reservoir. time the engine oil is changed. Use a non-freezing •...
Page 298: Air Cleaner
Maintenance AIR CLEANER 3500 3500 Air cleaner element CGQ07107 CGQ06007 Element Replacement 3. Wipe the inside of the air cleaner housing with a damp cloth. A viscous paper air cleaner filter is used. It must be replaced when necessary, and should not be 4.
Page 299 Replace the element according to the Scheduled Maintenance Section. If the vehicle is operated in extremely dusty or sandy areas, replace the element more often than the usual recommended intervals. (Refer to Schedule 2 - Severe Maintenance in the section.) CAUTION •...
Page 300: Wiper Blades
Maintenance WIPER BLADES Windshield Wiper Blade Replacement Windshield Wiper Blade Maintenance When the wipers no longer clean adequately, the blades may be worn or cracked, and require NOTICE replacement. Commercial hot waxes applied by automatic car washes have been known to make the NOTICE windshield difficult to clean.
Page 301 Metal support Push Tabs Plastic locking clip CBGQ0702 CBGQ0701 1. Raise the wiper arm and turn the wiper blade 2. Firmly grasp the end of the rubber blade and pull assembly to expose the plastic locking clip. until the tabs are free of the metal support. Compress the clip and slide the blade assembly downward;...
Page 302 Maintenance Retainer Retainer CBGQ0703 CBGQ0704 3. Remove the metal retainers from the rubber 4. Carefully insert a new rubber blade and install blade and install them in the new rubber blade. the blade assembly. Install the blade with the tabs facing towards the bottom of the wiper arm.
Page 303: Battery
BATTERY (Continued) WARNING - Battery Dangers If any electrolyte gets into your Always read following eyes, flush your eyes with clean instructions carefully when handling water for at least 15 minutes and get a battery. immediate medical attention. If Keep lighted cigarettes and all other possible, continue to apply water flames or sparks away from the with a sponge or cloth until medical...
Page 304 Maintenance (Continued) • When lifting a plastic-cased battery, excessive pressure on the case may cause battery acid to leak, resulting in personal injury. Lift with a battery carrier or with your hands on opposite corners. • Never attempt to charge the battery when the battery cables are connected.
Page 305 Battery Recharging WARNING - Recharging Your vehicle has a maintenance-free, calcium- Battery based battery. When recharging the battery, observe the • If the battery becomes discharged in a short following precautions: time (because, for example, the headlights or interior lights were left on while the vehicle was •...
Page 306: Tires And Wheels
Maintenance TIRES AND WHEELS Tire Care (Continued) For proper maintenance, safety, and maximum fuel • Disconnect the battery charger in the economy, must always maintain following order. recommended tire inflation pressures and stay 1. Turn off the battery charger main within the load limits and weight distribution switch.
Page 307 WARNING Severe underinflation (10 psi or more) can lead to severe heat build-up, especially on hot days and when driving at high speed. This can potentially cause tread separation and other tire irregularities to appear that can result in the loss of vehicle control leading to severe injury or death.
Page 308 If a tire frequently to 6 psi (28 to 41 kPa). Do not release air needs refilling, have it checked by an from warm tires to adjust the pressure. authorized Kia dealer or a competent tire The tires will be underinflated. shop. (Continued) •...
Page 309 Tire Rotation With a full-size spare tire To equalize tread wear, it is recommended that the tires be rotated every 7,500 miles (12,000 km) or sooner if irregular wear develops. During rotation, check the tires for correct balance. When rotating tires, check for uneven wear and Without a spare tire damage.
Page 310 Maintenance Wheel Alignment and Tire Balance The wheels on your vehicle were aligned and Tread wear indicator balanced carefully at the factory to give you the longest tire life and best overall performance. In most cases, you will not need to have your wheels aligned again.
Page 311 Use only tire and wheel combinations recommended on the Tire Label or by an authorized Kia dealer. Be sure the tire size matches the wheel size. (Continued) 7-47...
Page 312 Maintenance Wheel Replacement Tire Size Designation When replacing the metal wheels for any reason, A tire’s sidewall is marked with a tire size make sure the new wheels are equivalent to the designation. You will need this information when original factory units in diameter, rim width and selecting replacement tires for your car.
Page 313 Wheel Size Designation Tread wear xxx Traction x Wheels are also marked with important information Temperature x that you need if you ever have to replace one. The following explains what the letters and numbers in the wheel size designation mean. Example wheel size designation: 6.0JJ x 15 6.0 –...
Page 314 Sustained high passenger vehicle tires. The tires available as temperature can cause the material of the tire to standard or optional equipment on Kia vehicles degenerate and reduce tire life, and excessive may vary with respect to grade.
Page 315 DOT : XXXX XXXX OOOO WARNING - Tire Temperature The front part of the DOT means a plant code number, tire size and tread pattern and the last four The temperature grade for the tire on your numbers indicate week and year manufactured. vehicle is established for a tire that is properly inflated and not overloaded.
Page 316: Bulb Replacement
Maintenance BULB REPLACEMENT Headlight Replacement WARNING - Working on the Lights WARNING - Halogen Bulbs Prior to working on the light, firmly apply • Halogen bulbs contain pressurized gas the parking brake and ensure that the that will produce flying pieces of glass if ignition switch is turned to the “LOCK”...
Page 317 Headlight main electrical connector Turn signal/Position light Head light (Low) Head light (High) 4GQN701 4GQN702 1. Open the hood. 3. Disconnect the headlight main electrical connector. 2. Remove the light assembly from the body of the vehicle loosening the bolts. 7-53...
Page 318 Maintenance CLOSE OPEN OPEN CLOSE CGQ07109 CBGQ0709 4. Remove the headlight bulb cover by turning it 5. Disconnect the headlight bulb socket-connector. counterclockwise. 6. Unsnap the headlight bulb retaining wire by depressing the end of it and pushing it upward. 7-54...
Page 319 9. Connect the headlight bulb socket-connector. 10. Install the headlight bulb cover by turning it clockwise. 11. Connect the headlight main connector. 12. Reinstall the light assembly to the body of the vehicle. CGQ07112 7. Remove the bulb from the headlight assembly. 8.
Page 320 Maintenance CGQ07116 4GQN703 Front Turn Signal Light Bulb Replacement 4. Remove the socket from the assembly by turning the socket counter clockwise until the tabs on 1. Open the hood. the socket align with the slots on the assembly. 2. Remove the light assembly from the body of the 5.
Page 321 6. Install a new bulb by inserting it into the socket and rotating it until it locks into place. 7. Install the socket in the assembly by aligning the tabs on the socket with the slots in the assembly. Push the socket into the assembly and turn the socket clockwise.
Page 322 Maintenance Remove Install CS407018 CS407019 2. Rotate the socket one-quarter turn counter 1. Remove the front fog light assembly from the clockwise and remove the front fog light bulb- front bumper after removing the four (4) bolts. socket from the assembly. 3.
Page 323 Front Rear CAUTION Prior to working on the Dome Light, ensure that the “OFF” button is depressed to avoid burning your fingers or receiving an electric shock. Door 2. Push up on the metal spring clip until the bulb drops down to remove it. 3.
Page 324 Maintenance CBGQ0710 CAS2B072 Vanity Mirror Light Rear Cargo Area Light Bulb Replacement 1. Using a flat-blade screwdriver, gently pry the Your rear cargo area light is located on the rear lens from the sunvisor. hatch. 2. Remove the bulb by pulling it straight out. 1.
Page 325 CAS2B073 CGQ07103 Center High-Mounted Stoplight Bulb 2. Push the bulb in, then rotate it one-quarter turn Replacement counterclockwise and remove it from the socket. 3. Insert a new bulb in the socket, then push the 1. Using a flat-blade screwdriver gently pry the bulb in and rotate it one-quarter turn clockwise to cover from the housing.
Page 326 Maintenance CAS2B070 CGQ07104 2. Rotate the socket one-quarter turn counter- 4. Install a new bulb in the socket. clockwise and remove it from the housing. 5. Insert the socket in the housing and secure it by 3. Push the bulb in, rotate it one-quarter turn rotating it one quarter turn clockwise.
Page 327 Stop/Tail light Turn signal light Back up light Stop/Tail light CGQ07105 CBGQ1050 License Plate Light Bulb Replacement Rear Combination Light Bulb Replacement 1. Using a cross-tip screwdriver, remove the two 1. Open the rear hatch. lens retaining screws. 2. Using a cross-tip screwdriver, remove the two (2) 2.
Page 328 Maintenance CBGQ0711 CBGQ0717 3. Slide the rear combination light out to disconnect 4. Remove the bulb from the three (3) slots on the the rear combination light assembly from the light assembly. body of the vehicle. 7-64...
Page 329 CGQ07115 5. Install a new bulb and reinsert into the light. 6. Reinstall the light assembly to the body of the vehicle. 7. Install the two (2) screws. 7-65...
Page 330: Lubricant Specifications
Maintenance LUBRICANT SPECIFICATIONS Recommended Lubricants To help achieve proper engine and powertrain performance and durability, use only lubricants of the proper quality. The correct lubricants also help promote engine efficiency that results in improved fuel economy. Engine oils labeled Energy Conserving Oil are now available. Along with other additional benefits, they contribute to fuel economy by reducing the amount of fuel necessary to overcome engine friction.
Page 331 Engine oil viscosity (thickness) has an effect on Recommended SAE Viscosity Number fuel economy and cold weather operating (starting and oil flow). Lower viscosity engine oils can NOTICE provide better fuel economy and cold weather Always be sure to clean the area around any performance, however, higher viscosity engine oils filler plug, drain plug, or dipstick before are required for satisfactory lubrication in hot...
Page 332: Exterior Care
Maintenance EXTERIOR CARE Even prompt washing with plain water may not Exterior General Caution completely remove all these deposits. A mild soap, It is very important to follow the label directions safe for use on painted surfaces, may be used. when using any chemical cleaner or polish.
Page 333 Waxing WARNING - Water Washing in Wax the vehicle when water will no longer bead on Engine Compartment the paint. Water washing in the engine compartment Always wash and dry the vehicle before waxing. may cause failure of electrical circuits. Use good quality liquid or paste wax, and follow the Systems of your vehicle could fail when manufacturer’s instructions.
Page 334 Maintenance Finish Damage Repair Bright-Metal Maintenance Deep scratches or stone chips in the painted • To remove road tar and insects, use a tar surface must be repaired promptly. Exposed metal remover, not a scraper or other sharp object. will quickly rust and may develop into a major •...
Page 335 Underbody Maintenance Aluminum Wheel Maintenance Corrosive materials used for ice and snow removal The aluminum wheels are coated with a clear and dust control may collect on the underbody. If protective finish. these materials are not removed, accelerated • Do not use any abrasive cleaner, polishing rusting can occur on underbody parts such as the compound, solvent, or wire brushes on fuel lines, frame, floor pan and exhaust system,...
Page 336: Interior Care
Maintenance INTERIOR CARE Fabric Interior General Precautions Remove dust and loose dirt from fabric with a Prevent caustic solutions such as perfume and whisk broom or vacuum cleaner. Clean with a mild cosmetic oil from contacting the dashboard soap solution recommended for upholstery or because they may cause damage or discoloration.
Page 337 Cleaning the Lap/Shoulder Belt Webbing Clean the belt webbing with any mild soap solution recommended for cleaning upholstery or carpet. Follow the instructions provided with the soap. Do not bleach or re-dye the webbing because this may weaken it. Cleaning the Interior Window Glass If the interior glass surfaces of the vehicle become fogged (that is, covered with an oily, greasy or waxy film), they should be cleaned with glass...
Page 338 SPECIFICATIONS Specifications ....... 8-2...
Page 339: Specifications
SPECIFICATIONS Light bulbs The specifications given here are for general information only. Please check with an authorized Light Bulb Wattage Kia dealer for more precise and more up-to-date Exterior Lights information. Headlights (High/Low) 55 / 55 Dimensions Front turn signal / position lights...
Page 340 Diamond ATF SP-III, SK Starter 12V-1.2KW ATF SP-III or other brands meeting the SP-III Transaxle oil 1.0 mm ~ 1.1 mm specification approved by RC10PYP4, Kia Motors Corp. Spark Plug Specification PFR5N-11, Coolant NALL-K5 RC10PYPB4 SAE J1703, FMVSS116 Brake fluid...
Page 341 CONSUMER ASSISTANCE (U.S. only) Toll Free Assistance ......9-2 Emergency Roadside Assistance ....9-2 Trip Interruption .
Page 342: Consumer Assistance (U.s. Only)
Please note that you must provide your Vehicle receive this service. In the event that Kia does not have a dealer or an alternative service location Identification Number (VIN) to verify coverage at the time of your call.
Page 343: Trip Interruption
$100 per day Kia as a new and register it in another country, subject to a three day maximum limit per incident. problems arising from the use of fuel other than...
Page 344: Electrical Equipment
To avoid damage to your consult an Authorized Kia Dealer, in order to ensure that you do not void your warranty. vehicle, consult an Authorized Kia Dealer concerning the proper equipment and installation.
Page 345: Reporting Safety Defects
However, NHTSA cannot become questions regarding the operation of your vehicle, involved in individual problems between you, your safety issues and defects please contact your Kia's dealer, or Kia Motors America, Inc. toll-free Consumer Assistance hot line as below:...
Page 346: Purchasing Factory Authorized Manuals
(NOTE: For Credit Card Holder Orders Only) and servicing of your vehicle can be obtained from Monday-Friday 8:00 A.M. - 6:00 P.M. EST Kia by calling the toll-free phone number. For MINIMUM CREDIT CARD PURCHASE $10.00 manuals prior to the year shown below, call 1-866- 542-6268.
Page 347 INDEX Index ........10-2 10-1...
Page 348: Index
Index BS ........4-22 are, exterior .
Page 349 Fluid, power steering ......7-26 ay/night rearview mirror ..... 3-93 Fluid, washer.
Page 350 Index Indicators, warning and ..... . . 4-37 aintenance, owner ......7-11 Instrument cluster .
Page 351 Lumbar support ..... . . 3-22, 3-27 ear cargo area light ......3-96 Power adjustment .
Page 352 Index Window defroster ......4-59 emperature control ......4-65 Windshield washers .

Kia Sedona 2005 Owner's Manual

Table of Contents

Knowing Your Vehicle

Driving Your Vehicle

Driving Tips

In Case of an Emergency

Maintenance

Quick Links

Chapters

Related Manuals for Kia Sedona 2005

Summary of Contents for Kia Sedona 2005

Table of Contents
