- Page 1 Sport Windshield instruction manual 1-866-291-5244...
- Page 2 Parts List Sport Windshield (1) Floor Supports (2) Bolts M10x40 Metric M6x25 Metric M6 Washer M6 Nyloc Nut *Parts not shown in proportion.
- Page 3 Installation 1. Remove Roof Remove bolts connecting rear top supports to seat supports. Remove plastic inserts in corners of dash. Remove bolts connecting top supports to front. 2. Install Windshield Insert Sport Windshield into support slots. Bolt to front using M10 x 40 bolts. Re-insert plastic insert.
- Page 4 Installation 3. Install Angle Supports on both sides of cart. Bolt end with triangle plate to windshield support Remove bolt on upper running board and using M6 x 25 Bolt, at washer, and nut. bolt on end with metal L.
