- Page 1 Contents/Precautions L-03E ‘12.X Before Using this Terminal ISSUE DATE: NAME: Setting Up PHONE NUMBER: MAIL ADDRESS: Connecting to the Internet INSTRUCTION MANUAL Settings Overseas Use Appendix/Troubleshooting...
- Page 3 0.39 0.39 0.39...
- Page 4 Before Using this Terminal LED indicator Names of Parts and Functions Lights in red: charging this terminal Lights in green: charging this terminal is completed Lights in blue: charging mobile device Display Jog dial Works in different way according to the pressing direction and time. Power switch Hold down the switch for over 2 seconds to turn on or off the terminal. Press lightly to change the on/off-screen. External terminal Connect the supplied AC adaptor L04 or USB cable. Before Using this Terminal...
- Page 5 Display Overview The signs (icons) that appear on the display indicate these states (press the power button to display the icons): Xi antenna: Network communication antenna is built in. Back cover: Removing the back cover, the miniUIM slot guide is under the battery pack. Levels of radio wave reception Sub-antenna: Strong Weak Sub-antenna is for improving the communication quality by using plural antennas. This antenna is : Out of service area or where radio built in. waves do not reach Wi-Fi antenna: Types of networks available during connection...
- Page 6 ■ Indicators Top menu of L-03E Connection Manager u The display shows the charging state of click “ネットワーク設定 (NETWORK)” u “ プロ battery pack, wireless LAN states, name of ファイル (Profile)”, confirm that the settings the connecting network, etc. are correct. (Examples are shown below.) Public wireless LAN receiving level States of network connection : Connecting : Not connected Software update available USB tethering or charging Charging Activating WPS Battery is Number of connecting terminals to wireless...
- Page 7 Inserting the miniUIM Using miniUIM When inserting the miniUIM, hold this terminal A miniUIM is an IC card that stores personal with both hands. information such as your phone number. • Turn the power off and remove the battery Without the miniUIM installed in this terminal, pack before attaching the miniUIM ( → P27 you cannot use data communication.
- Page 8 Removing the miniUIM Note • Do not lose the removed miniUIM. When removing the miniUIM, hold this terminal • Check both sides of the miniUIM. with both hands. • Turn the power off and remove the battery pack before removing the miniUIM ( → P27 “Attaching and Detaching the Battery Pack”). Slide the miniUIM in the direction of arrow • Be careful not to touch or scratch the miniUIM IC. to remove. • Inserting a miniUIM in the reverse direction may cause malfunction. • Inserting or removing the miniUIM with an excessive force may cause malfunction to the miniUIM.
- Page 9 ■ Unblocking PIN Code Security Codes The unblocking PIN code is the number in 8 digits used to unblock the PIN1 code. Details are written in the A miniUIM has PIN1 (Personal Identification application of the contract (a duplicate copy) during the Number) code. subscription. You cannot change the unblocking PIN code. The default setting for the PIN1 code is If you improperly enter the unblocking PIN code for 10 [0000]. The PIN1 code is a 4 to 8-digit times in a row, the miniUIM locks automatically. security code to be entered every time this terminal is turned on for user verification to Caution prevent any unauthorized use by others.
- Page 10 Attaching and Detaching Logging-in to L-03E Connection Manager PIN1 code Verification screen appears the Battery Pack Use the Battery Pack L17 for this terminal. Enter PIN1 Code Note Incorrect entry 3 times in a row • Always turn off this terminal before removing the battery pack. If the battery pack is removed while the power is on, this terminal may not work correctly. Enter Unblocking PIN Code Incorrect entry 10 times in a row Available to set a Contact a docomo new PIN1 code Shop Before Using this Terminal...
- Page 11 not remove the back cover as described Attaching the Battery Pack below. When attaching the battery pack, hold this Do not remove the back cover by terminal with both hands. inserting a fingernail into a part Insert a fingernail into the groove at the other than the groove. bottom of this terminal, and pull up in the direction of arrow while pressing in the direction of arrow to remove the back...
- Page 12 With the “ ” side of the battery pack up, Detaching the Battery Pack align the metal contacts of both the When attaching the battery pack, hold this battery pack and this terminal, attach the terminal with both hands. battery pack in the direction a, and then Insert a fingernail into the groove at the push it down in the direction b.
- Page 13 Put your fingertip at the concave part of Charging this terminal, press in the direction a, lift it in the direction b, and then remove it in the ■ Battery pack life direction c. • The battery pack is a consumable item. The usable time decreases every time the battery pack is recharged. • When the usable time after each recharging part shortens by approximately half compared to a new battery pack, it is recommended that the...
- Page 14 ■ Approximate battery pack usage & charging time • Plug or unplug the connector slowly and securely avoiding excessive force. The usage time may vary depending on the operating • If you start charging the fully drained battery pack, environment and the battery pack deterioration. this terminal may not be turned on for a while. Continuous Approx. • If you make communication while charging, communication XX hours the inside of this terminal may become hot time and charging may stop. In this case, end the 3G（HSDPA/ Approx. functions in use and wait until this terminal HSUPA, XX hours becomes cool down, and then try charging again. W-CDMA） • Depending on the usage condition, charging Continuous Approx. may stop before the battery level becomes stand-by time XX hours 100%. In this case, remove the battery pack 3G（HSDPA/ Approx.
- Page 15 Insert the USB connector of the microUSB • Depending on network conditions in the country you stay, usage time may become Connection Cable to the AC Adapter, and shorter than the described values. insert the microUSB connector straight to • The estimated charging time is the duration the external connector of this terminal with of time to charge a fully drained battery pack with this terminal turned off. the inscribed B side up. The charging time becomes longer with this Insert the power plug of AC Adapter to an terminal turned on.
- Page 16 Turning Power Off Turning Power On/Off When this terminal is turned on, hold down Turning Power On the power button for over 2 seconds. When this terminal is turned off, hold down the power button for over 2 seconds. When turning power on, network search for Xi area and FOMA area etc. starts. When this terminal is connected to the network, the network name appears on the display.
- Page 17 Wireless LAN Available Communications You can connect up to 10 PCs or game consoles compatible with wireless LAN (IEEE Basic Usage 802.11 b/g/n) simultaneously. • This terminal supports WPS function. When your You can perform data communication at a wireless LAN terminal supports WPS function, speed of up to 75Mbps* for receiving data and you can set up the wireless LAN connection up to 25Mbps* for sending data by connecting easily ( →...
- Page 18 Communication speed is theoretical Note values when sending and receiving data • Note that high communication fees are which does not show the actual ones. The charged when performing communications actual communication speed depends on with large amount of data such as browsing communication environment and network websites with many graphics or downloading congestion. data. • Depending on bandwidth, communication speed for • Data communication may take more time or receiving is theoretically 100/100/75/37.5Mbps become difficult to connect depending on (with bandwidth of [20/15/10/5MHz]), and for the network congestion. For customers who sending is 50/37.5/25/12.5Mbps (with bandwidth use a large amount of data communication of [20/15/10/5MHz]). (Approximate 1GByte data or more is • For the FOMA HIGH-SPEED areas outside Xi used within the last three days including area, the maximum speed for receiving data is the current day), it may have difficulties in 14Mbps and for sending is 5.7Mbps. sending and receiving data on time. Also, • Sending and receiving data become 384kbps data communication may get disconnected in FOMA area out of Xi area and FOMA HIGH- when a large amount of data communication SPEED area. occurs at a time or within a certain period of • The communication speed varies depending on time, when being connected for a long time the access point and radio wave status.
- Page 19 Internet connection is unavailable when “Not Usage Notes connected” icon appears on the display of this terminal. ■ Internet service provider (ISP) fees Top menu of L-03E Connection Manager Fees to an ISP may be required to connect u Click “ ネットワーク設定 (NETWORK)” u to the Internet. These fees are added to “ プロファイル (Profile)”, confirm that the the Xi service fees and are paid to your ISP settings are correct. directly. For details on connection fees, ■ Requirements for communication contact your ISP. The following conditions must be met You can subscribe to such as “mopera U”, to perform communications using this one of DOCOMO's Internet connection terminal. However, a connection may not be services. established if traffic is heavy at the base Charge for subscribing “mopera U” is station or if radio waves are weak. required. • This terminal must be in Xi network, FOMA For service and connection settings of network or DOCOMO's roaming service area.
- Page 20 Attaching and Detaching Connection Cable to the USB port of the this Terminal to/from a PC • For the first time connection after Attach this terminal to a PC to charge this purchasing, the L-03E driver setup screen terminal with microUSB Connection Cable. appears by zero-install function only for Windows version. Follow the onscreen Attaching to a PC instructions to install the driver.* The driver is necessary only when updating software. After installation, the shortcut of...
- Page 21 Battery level is displayed, and charging Detaching from a PC starts. When charging completes, the battery level Remove microUSB Connection Cable. icon displays full charge. Depending on the OS settings, “ 自動再生 (Auto start)” screen may appear. When the screen appears, select “ フォルダーを開いて ファイルを表示 (Open the folder and display files)”. * Do not cancel the driver installation halfway or remove this terminal. Without the driver, Software update ( → P86) cannot be performed. Before Using this Terminal...
- Page 22 Setting Up Item Requirement Setting Up Windows XP: 256MB or more Windows Vista: 512MB or more Before using this terminal, make settings to Required Windows 7: 1GB or more (32bit), connect your wireless LAN terminal to this Memory * 2GB or more (64bit) terminal's wireless LAN. Mac OS X 10.6.8: 1GB or more You can also change the wireless LAN and Mac OS X 10.7.3: 2GB or more other settings according to your environment.
- Page 23 Flow of Setup Connecting to a Wireless LAN Terminal Setup is made in the following procedure. Setting procedures vary depending on the Connect your wireless LAN terminal to this wireless LAN you use. The procedures for the terminal's wireless LAN ( → P40) following terminals are described here.
- Page 24 Connecting to Windows PC • This terminal can connect up to 10 wireless LAN terminals simultaneously. The setting procedure when security mode • For Windows PC and Mac, you need to login of this terminal is set to “WPA2-PSK/AES” is with the user account which has administrative described here. right beforehand. ■ SSID and Security key (WPA2 shared key) For Windows 7/ Windows Vista printed area Check SSID and Security key (WPA2 Hold down the power button of this...
- Page 25 Click “ ネットワークに接続 (Connect to a In “ セキュリティキーまたはパスフレーズ network)”. (Security key or pass phrase)”, enter Security key (WPA2 shared key) ( → P41) set to this terminal, and click “OK”. Click “ 接続 (Connect)” for Windows Vista. Click the item which shows SSID (Default: “L03E_XXXXXXXX”, →...
- Page 26 Click the item which shows SSID For Windows XP (Default: “L03E_XXXXXXXX”, → P41) set to this terminal, and click Hold down the power button of this “ 接続 (Connect)”. terminal for over 2 seconds. This terminal turns on, and the wireless LAN function turns on. Turn on the wireless LAN function of a Click スタート...
- Page 27 Connecting to Mac Note • When the message “ すべての優先するネット The setting procedure for Mac OS X 10.7 ワークを利用できません (All preferred networks when security mode of this terminal is set to cannot be used)” appears, click “ キャンセル “WPA2-PSK/AES” is described here. (Cancel)”, and click “ 新しいネットワークに接続 することを確認 (Confirm to connect to a new Hold down the power button of this network)” to cancel the selection.
- Page 28 In “ パスワード (Password)”, enter Connecting to iPad Security key (WPA2 shared key) The setting procedure for iPad when security ( → P41) set to this terminal, select mode of this terminal is set to “WPA2-PSK/ “ このネットワークを記憶 (Remember this AES”...
- Page 29 Connecting to iPod touch Connecting to Nintendo DS The setting procedure for iPod touch when The setting procedure for Nintendo DSi security mode of this terminal is set to when security mode of this terminal is set to “WPA2-PSK/AES” is described here. “WPA2-PSK/AES”...
- Page 30 Enter Security key (WPA2 shared key) Connecting to PSP ( → P41) set to this terminal, and The setting procedure for PSP-3000 when touch “OK”. security mode of this terminal is set to “WEP” Touch “OK”. is described here. The setting is saved. Note Touch “...
- Page 31 Select “ 検索する (Search)” and press Connecting to WPS Compatible “ ” of direction buttons. Wireless LAN Terminal Select the item which shows SSID Note (Default: “L03E_XXXXXXXX”, → P41) set to this terminal, and • Setting procedures vary depending on the wireless LAN terminal. Refer to the instruction press “ ○ ” button. manual of your wireless LAN terminal.
- Page 32 ■ Setting Wireless LAN function turns on. You can change the settings of wireless Start the web browser on PC which LAN and the basic settings of LAN. is connected with the wireless LAN, and login to the setting page (L-03E ■ Setting Network Connection Manager). You can change the settings of access Set the wireless LAN function of the point and miniUIM.
- Page 33 Connecting to the Internet Internet Connection Connecting to the Internet To connect to the Internet with this terminal, You can use the Internet by turning on this the subscription to the Internet service terminal to connect automatically to the provider (mopera U, etc.) compatible with the access point set to the Profile.
- Page 34 This terminal turns on, and the wireless LAN function turns on. You can make various settings by starting Turn on a PC and the wireless LAN Web browser on a PC connected via wireless function. LAN and displaying the setting page (L-03E Connection Manager). This terminal is connected to the PC via wireless LAN. • When connecting for the first time, wireless Note LAN setup is required. For setting up, refer • You can change this terminal's setting...
- Page 35 Enter “Admin” in [Username] field, enter When “PIN1 code verification” screen the log-in password (default: “1234”) in appears, enter PIN1 code in [PIN1 [Password] field, and then click [Login]. code] field, and then click [Apply]. • In [Language] field, you can select a For details on PIN1 code, see “Security Codes” language on the setting page. ( → P26). When PIN1 code is set, “PIN1 code verification”...
- Page 36 Click [OK] when a message of PIN1 unlock The Setting Page Screen appears. “Status” screen appears. If there is latest version, a message from web page is displayed on “Status” screen. For updating procedure, see “Updating Software” ( → P88). Top menu Click a menu item to switch the setting page. You can select the following items. • STATUS ( → P54) Note • WLAN ( → P55) • For your security, it is recommended to • NETWORK ( → P62) change the default setting of log-in password. • SECURITY ( → P67) • SYSTEM ( → P68) For details, see “Changing Login Password The submenu appears for some items, and you (Modify password)” ( →...
- Page 37 Network : The connecting band is displayed. Click to edit the setting. selection* Network name* : The connecting network name is displayed. Click to refresh the information on the “Status” FOMA/Xi signal : The current level of radio wave screen. strength* reception is displayed. Wi-Fi status : The status of the wireless LAN Confirming Connection/Setting function is displayed. Conditions of this Terminal Connected : The number of currently clients connected terminals via wireless LAN is displayed. Click [STATUS] in the top menu. Wi-Fi auto off : The setting status of the Wi-Fi “Status” screen appears.
- Page 38 Country (Default: JAPAN) Setting Wireless LAN Select a country name where this terminal is used. (When JAPAN or KOREA is selected, you can select up to 13 channels. When CANADA or Note UNITED STATES is selected, you can select • When using wireless LAN overseas, check the up to 11 channels.) available frequency band, laws, regulations or Channel (Default: Auto) other conditions of the country beforehand. Select a channel of wireless LAN. IEEE802.11 Mode: (Default: 11b/g/n) Setting Basic Functions of Select an operation mode of wireless LAN. • 11b only Wireless LAN • 11b/g • 11g only In the top menu, click [WLAN]. • 11n only In the submenu, click [Basic Setting].
- Page 39 ■ When Enable is set Setting Wi-Fi auto off Function Wi-Fi off time (min) (Default: 10) When “Enable” is set to Wi-Fi auto off, select In the top menu, click [WLAN]. the time (minutes) to set automatically to off. • 10 In the submenu, click [Wi-Fi auto off]. • 30 • 60 On the setting screen, set the required Click [Apply] to save the setting.
- Page 40 ■ When Open is set Setting Security Mode of Limitation of clients (Default: 1) Wireless LAN The number of terminals which can be connected is displayed (it cannot be changed.). ■ When WEP is set In the top menu, click [WLAN]. WEP key1-4 (Default: XXXXX) In the submenu, click [Security]. Enter WEP key. You can enter 5, 10, 13 or 26 letters with On the setting screen, set the required one-byte alphanumeric.
- Page 41 WPS shared key (Default: XXXXXXXX) Limitation of clients (Default: 10) Enter Security key of WPA. The number of terminals which can be You can enter 8-64 letters with one-byte connected is displayed. alphanumeric. Click [Apply] to save the setting. For 64-letter key, use hexadecimal numbers (0-9, A-F). Setting WPS Function Limitation of clients (Default: 10) The number of terminals which can be Note connected is displayed. ■ When WPA2-PSK is set • WPS Function cannot be used when “WEP” Encryption type (Default: AES) is set for “Security” ( →...
- Page 42 ■ When Enable is set Setting MAC Address Filter WPS type (Default: Push button) Select a type of WPS function. In the top menu, click [WLAN]. • Enable only: When connect with WPS type In the submenu, click [MAC address filter]. after pressing the WPS button of this On the setting screen, set the required terminal (WPS function is not activated if you press [Apply] button.) items.
- Page 43 IP address (Default: 192.168.2.1) Setting DHCP Function Set private IP address of this terminal. Subnet mask (Default: 255.255.255.0) In the top menu, click [WLAN]. Set subnet mask of LAN. DHCP server (Default: Enable) In the submenu, click [DHCP]. Select whether to use DHCP function. • Enable: DHCP function is used On the setting screen, set the required • Disable: DHCP function is not used items.
- Page 44 Confirming Connected Clients Setting UPnP Function To use the application using the UPnP In the top menu, click [WLAN]. function, set to “Enable” the UPnP function. In the submenu, click [Connected In the top menu, click [WLAN]. clients]. In the submenu, click [UPnP]. The connected terminal's information On the setting screen, set the required appears.
- Page 45 Mode (Default: Auto) Setting Network Select whether to specify the access point. • Auto: The access point to connect is automatically selected. Selecting an Access Point • Manual: Select when you specify the access point. Click [Apply] to search the available You can specify the access point network. access point and register it to [Operators]. ■ When Manual is set • This function is unavailable in Japan. Operators (Default: none) In the top menu, click [NETWORK]. Select an access point to connect.
- Page 46 ■ To edit an existing access point Registering the Access Point In [Current profile], select an access point Settings to edit. Follow Procedure 4. Follow Procedure 6. Register, edit or delete the access point settings. You can register up to 10 access ■...
- Page 47 On the setting screen, set the required Authentication (Default: CHAP) Select the authentication method of the items. access point. • None • PAP • CHAP To register a new access point, click [Save]. Click [Apply] to save the setting. Protecting the Terminal with PIN1 lock status the Security Code The current setting condition is displayed.
- Page 48 In the top menu, click [NETWORK]. Unlocking PIN Lock In the submenu, click [Modify PIN1 If you improperly enter the PIN1 code for code]. 3 times in a row, further entry is locked automatically. In this case, enter “Unblocking On the setting screen, set the required PIN Code”...
- Page 49 The usage is automatically reset in the Displaying Network data usage following cases. • 0 o'clock on the first day of every month The amount of data communication is displayed. • When the miniUIM is replaced Data communication in overseas is not be • When SIM lock is unlocked added to this amount. Also, the amount of data Maximum data size (Default: Disable) communication in the international roaming Select from KB, MB and GB, and enter the area is not displayed.
- Page 50 ■ When Enable is set Setting Security Functions You can set IP filter. IP address When registering IP filter, enter source or Using Firewall Function destination IP address. Direction (Default: Source) Unauthorized access via the Internet can be Specify the direction of communication to blocked by using the Firewall function. Also, interrupt. you can set IP filter. • Source: Interrupt the access from the specified IP address.
- Page 51 Discarding WAN Ping Managing the System You can discard the Ping request to access from WAN to prevent answering and block the Changing Log-in Password IP information leakage from this terminal and LAN terminals. You can change the log-in password of the In the top menu, click [SECURITY].
- Page 52 In the setting screen, make the Current password Enter the current password. following procedures. New password Enter the new password. Confirm password Enter the same password as [New password] for confirmation. Click [Apply]. The message “Password is changed successfully” appears. Click [OK]. Backup to file Click [Backup], specify the file name (Default: Saving/Restoring the Setting webcm_config.cfg) and save the current Data setting. * Depending on the browser, the file name All setting data can be saved to a PC on cannot be specified.
- Page 53 Resetting the Settings Confirming the Version Information You can reset all settings of the setting In the top menu, click [SYSTEM]. page to default. However, the amount of data communication which is displayed on the In the submenu, click [Version]. display cannot be reset.
- Page 54 ■ When ON is set Displaying the Inquiries The confirmation message for software update appears each time you log in. To make the In the top menu, click [SYSTEM]. message not to appear, set to “OFF”. ■ When OFF is set In the submenu, click [Help]. Click [Check now] to check if you have any The information of the inquiry website, phone update files, and a message appears when a number and the URL of Instruction Manual new file exists. (PDF) appears. For update procedure, see “Updating Software” ( → P86). When you have changed software update setting, click [Apply].
