- Page 1 ARC-1209/1509 12.1"/15" Intel® Atom™ SoC Processor E3845 /Intel® Celeron® J1900 Fanless Rugged Touch Panel PC with IET Expansion Quick Reference Guide Ed – 22 June 2018 Copyright Notice Copyright 2018 ALL RIGHTS RESERVED. Part No. E2017A290A5R...
- Page 2 For the most frequently asked questions, you can easily find answers in your product documentation. These answers are normally a lot more detailed than the ones we can give over the phone. So please consult the user’s manual first. 2 ARC-1209/1509 Quick Reference Guide...
-
Page 3: Table Of Contents
1.5.3 ARC-1509 (A Model) ......................13 1.5.4 ARC-1509 (B Model) ......................14 Hardware Configuration ..................15 2.1 ARC-1209/1509 connector mapping ............... 16 2.1.1 Serial port 1 connector (COM1) ..................... 16 2.1.2 Serial port 2 connector (COM2) ..................... 16 2.2 Installing Hard Disk & Memory ................17 2.3 Installing ARC-BYT DB ................... - Page 4 2.15 ARC-BYT DB-K Connectors settings ..............48 2.15.1 Serial Port 1 connector (I_COM1) ..................48 2.15.2 Serial Port 2 connector (I_COM2) ..................48 3.BIOS Setup ........................49 3.1 Introduction ......................50 3.2 Starting Setup ......................50 4 ARC-1209/1509 Quick Reference Guide...
- Page 5 Quick Reference Guide 3.3 Using Setup ......................51 3.4 Getting Help ......................52 3.5 In Case of Problems ....................52 3.6 BIOS setup ......................53 3.6.1 Advanced Menu ........................53 3.6.1.1 IT8528 Super IO Configuration ......................53 ARC-1209/1509 Quick Reference Guide...
-
Page 6: Getting Started
Place all electronic components in a static-dissipative surface or static-shielded bag when they are not in the chassis. 1.2 Packing List 1 x ARC-1209/1509 Panel PC 1 x Power Adapter ... -
Page 7: System Specifications
1 x RS-232/422/485 (Factory Optional) Com Port 1 x RS-232 Other 3 x Knockouts for Antenna Mounting Display Intel® Valleyview SoC integrated Graphics Chipset Supports optional dual display Resolution HDMI: Max. resolution 1920x1200 @ 60Hz (by IET module) ARC-1209/1509 Quick Reference Guide... - Page 8 ARC-1209 (A Model) With SSD/mSATA : 5Grms, IEC 60068-2-64, Random, 5 ~ 500Hz, 1hr/axis Vibration Test ARC-1209 (B Model)/ ARC-1509 (A/B Model) With SSD/mSATA : 3Grms, IEC 60068-2-64, Random, 5 ~ 500Hz, 1hr/axis Operating with SSD/CFast/mSATA : MIL-STD-810G, Method 516.6,...
- Page 9 OBDII - CAN Bus Kit for ARC Series (Small Vehicle) ACC-ARC-OBDII-2R OBDII - CAN Bus Kit for ARC Series (Large Vehicle) ACC-ARC-OBDII-3R OBDII - CAN Bus Kit for ARC Series (Special Large Vehicle) Note: Specifications are subject to change without notice. ARC-1209/1509 Quick Reference Guide...
-
Page 10: System Overview
DC Power-in connector Option: Phoenix Connector(MOQ apply) COM1/2 Serial port 1/2 connector DB-9 male connector 3 x USB 2.0 connector 1 x USB 3.0 connector LAN1/2 RJ-45 Ethernet 1/2 HDD/Power LED indicator Power Switch Power on button 10 ARC-1209/1509 Quick Reference Guide... -
Page 11: System Dimensions
Quick Reference Guide 1.5 System Dimensions 1.5.1 ARC-1209 (A Model) (Unit: mm) ARC-1209/1509 Quick Reference Guide 11... -
Page 12: Arc-1209 (B Model)
ARC-1209/1509 1.5.2 ARC-1209 (B Model) (Unit: mm) 12 ARC-1209/1509 Quick Reference Guide... -
Page 13: Arc-1509 (A Model)
Quick Reference Guide 1.5.3 ARC-1509 (A Model) (Unit: mm) ARC-1209/1509 Quick Reference Guide 13... -
Page 14: Arc-1509 (B Model)
ARC-1209/1509 1.5.4 ARC-1509 (B Model) (Unit: mm) 14 ARC-1209/1509 Quick Reference Guide... -
Page 15: Hardware Configuration
Quick Reference Guide 2. Hardware Configuration For advanced information, please refer to: 1- ARC-BYT, ARC-BYT DB-A/B/C/D/E/F/G/H/K included in this manual. ARC-1209/1509 Quick Reference Guide 15... -
Page 16: Arc-1209/1509 Connector Mapping
NRIA# RS-485 Signal PIN PIN Signal DATA- RS-422 DATA+ Signal PIN PIN Signal TxD- TxD+ RxD+ RxD- 2.1.2 Serial port 2 connector (COM2) Signal PIN PIN Signal NDCDB# NDSRB# NRXDB NRTSB# NTXDB NCTSB# NDTRB# NRIB# 16 ARC-1209/1509 Quick Reference Guide... -
Page 17: Installing Hard Disk & Memory
Memory Installation: Remove 3 screws to release the chassis cover, and remove it. Step 2.1 Insert the SODIMM into the memory socket. Step 2.2 Re-assemble your system back through previous steps to complete the installation. ARC-1209/1509 Quick Reference Guide 17... - Page 18 ARC-1209/1509 Step 3. HDD Installation: Insert the HDD into the Drive Bay and fasten 2 screws. 18 ARC-1209/1509 Quick Reference Guide...
-
Page 19: Installing Arc-Byt Db
Quick Reference Guide 2.3 Installing ARC-BYT DB Step 1. Unfasten 2 screws of the HDD bracket and take it off. Step 2. Remove 4 screws to release the chassis cover, and remove it. ARC-1209/1509 Quick Reference Guide 19... - Page 20 ARC-1209/1509 Step 2.1 Insert the ARC-BYT DB into the socket and fasten 3 screws. Step 2.2 Re-assemble your system back through previous steps to complete the installation 20 ARC-1209/1509 Quick Reference Guide...
-
Page 21: Arc-Byt Overviews
Quick Reference Guide 2.4 ARC-BYT Overviews ARC-1209/1509 Quick Reference Guide 21... -
Page 22: Arc-Byt Jumper And Connector List
JEC1 EC Debug connector 3 x 1 header, pitch 2.00 mm JSATA1 Serial ATA connector 2 x 1 wafer, pitch 2.00mm JSATA2P1 SATA Power connector JVGA1 VGA connector 8 x 2 wafer, pitch 2.00 mm 22 ARC-1209/1509 Quick Reference Guide... -
Page 23: Arc-Byt Jumpers & Connectors Settings
Quick Reference Guide 2.6 ARC-BYT Jumpers & Connectors settings 2.6.1 Clear CMOS (JCMOS1) Protect* Clear CMOS *Default 2.6.2 Serial port 1/2 pin9 signal select (JRI1/JRI2) Ring* +12V JRI1 JRI2 * Default ARC-1209/1509 Quick Reference Guide 23... -
Page 24: Lcd Backlight Brightness Adjustment (Jvr1)
ARC-1209/1509 2.6.3 LCD backlight brightness adjustment (JVR1) PWM Mode* DC Mode * Default 2.6.4 AT/ATX Input power select (JAT1) ATX* * Default 24 ARC-1209/1509 Quick Reference Guide... -
Page 25: Serial Port 1 In Rs-422/485 Mode (Jp1)
Signal +12V BKLEN VBRIGHT Note: For inverters with adjustable Backlight function, it is possible to control the LCD brightness through the VR signal controlled by JVR. Please see the JVR section for detailed circuitry information. ARC-1209/1509 Quick Reference Guide 25... -
Page 26: On-Board Header For Usb2.0 (H_Jusb3)
ARC-1209/1509 2.6.7 On-board header for USB2.0 (H_JUSB3) Signal USBVCC4 USB_DN_R_5 USB_DP_R_5 2.6.8 SATA Power connector (JSATA2P1) Signal 26 ARC-1209/1509 Quick Reference Guide... -
Page 27: Lvds Connector (Jlvds1)
LVDS_CLK2_P LVDS_CLK1_P LVDS_DATA7_N 29 30 LVDS_DATA6_N LVDS_DATA7_P 27 28 LVDS_DATA6_P LVDS_DATA5_N 23 24 LVDS_DATA4_N LVDS_DATA5_P 21 22 LVDS_DATA4_P LVDS_DATA3_N 17 18 LVDS_DATA2_N LVDS_DATA3_P 15 16 LVDS_DATA2_P LVDS_DATA1_N 11 12 LVDS_DATA0_N LVDS_DATA1_P 10 LVDS_DATA0_P +3.3V +3.3V ARC-1209/1509 Quick Reference Guide 27... -
Page 28: Battery Connector (Bt1)
ARC-1209/1509 2.6.10 Battery connector (BT1) Signal +3.3VSB 2.6.11 AMPLIFIER_R (JSPR1) Signal SPK_R+ SPK_R- 28 ARC-1209/1509 Quick Reference Guide... - Page 29 Quick Reference Guide 2.6.12 AMPLIFIER_L (JSPL1) Signal SPK_L+ SPK_L- 2.6.13 LPC connector (JLPC1) Signal PIN PIN Signal LPC_SERIRQ LPC_PORT80_CLK LPC_AD3 LPC_FRAME# LPC_AD2 LPC_PORT80_RST# LPC_AD1 +3.3V LPC_AD0 ARC-1209/1509 Quick Reference Guide 29...
- Page 30 ARC-1209/1509 2.6.14 SPI connector (JSPI1) Signal PIN PIN Signal +VSPI_BIOS SPI_ROM_CS# SPI_ROM_CLK SPI_ROM_MISO_R SPI_ROM_MOSI SPI_HOLD# 2.6.15 EC_Program (JEC1) Signal EC_SMCLK_DEBUG EC_SMDAT_DEBUG 30 ARC-1209/1509 Quick Reference Guide...
- Page 31 PWR-LED- PWR-LED+ HDD-LED- HDD-LED+ LAN1-LED- LAN1-LED+ LAN2-LED- LAN2-LED+ 2.6.17 LCD backlight brightness adjustment (JBLK_CTRL1) Signal Note BLK_VR_MOD VR must select 10K/1% Low pulse button for BLK_BRI_UP backlight brighter Low pulse button for BLK_BRI_DN backlight dim ARC-1209/1509 Quick Reference Guide 31...
- Page 32 DDI0_HDMI_CLK_N 30 Signal PIN PIN Signal DDI0_HDMI_CLK_P 31 PCIE_CLKN_3 PCIE_CLKP_3 +12VSB MIC_RIN +12VSB MIC_LIN MIC1_JD LPC_SERIRQ 46 +5VSB LINEOUT1_JD LINE1_JD LPC_FRAME# 47 +5VSB LINEOUT_R LINE1_RIN LPC_COM_CLK1 48 +5VSB LINEOUT_L LNE1_LIN LPC_AD0 49 +5VSB LPC_AD1 50 +5VSB 32 ARC-1209/1509 Quick Reference Guide...
-
Page 33: Power Connector (Pwr1)
Quick Reference Guide 2.6.19 Touch panel connector (JTP1) Signal PROBE 2.6.20 Power connector (PWR1) *Option: Phoenix Connector Signal +DCIN ARC-1209/1509 Quick Reference Guide 33... -
Page 34: Arc-Byt Db-A/B/C/D/E/F/G/H/K Overviews
ARC-1209/1509 2.7 ARC-BYT DB-A/B/C/D/E/F/G/H/K Overviews 2.7.1 ARC-BYT DB-A 2.7.2 ARC-BYT DB-B 2.7.3 ARC-BYT DB-C 34 ARC-1209/1509 Quick Reference Guide... -
Page 35: Arc-Byt Db-D
Quick Reference Guide 2.7.4 ARC-BYT DB-D 2.7.5 ARC-BYT DB-E 2.7.6 ARC-BYT DB-F ARC-1209/1509 Quick Reference Guide 35... -
Page 36: Arc-Byt Db-G
ARC-1209/1509 2.7.7 ARC-BYT DB-G 2.7.8 ARC-BYT DB-H 2.7.9 ARC-BYT DB-K 36 ARC-1209/1509 Quick Reference Guide... -
Page 37: Arc-Byt Db-A/B/C/D/E/F/G/H/K Connector List
Serial Port 1/2 connector DB-9 male connector D_JB2B1 B2B connector 2.8.5 ARC-BYT DB-E Jumpers Label Function Note E_JCAN20 CAN2.0 Switch 3 x 1 header, pitch 2.00mm For user update FW 3 x 1 header, pitch 2.00mm E_JIAP1 ARC-1209/1509 Quick Reference Guide 37... -
Page 38: Arc-Byt Db-F
H_USB_PWR_SEL1 USB Power selector 3 x 1 header, pitch 2.00mm Connectors Label Function Note H_JUSB1 USB3.0 connector H_COM1/2 Serial Port 1/2 connector DB-9 male connector H_JB2B1 B2B connector 2.8.9 ARC-BYT DB-K Connectors Label Function Note 38 ARC-1209/1509 Quick Reference Guide... - Page 39 Quick Reference Guide I_JLAN1 RJ-45 Ethernet I_COM1/2 Serial Port 1/2 connector DB-9 male connector B2B connector I_JB2B1 ARC-1209/1509 Quick Reference Guide 39...
-
Page 40: Arc-Byt Db-D Connectors Settings
Serial Port 1 connector (D_COM1) Signal PIN PIN Signal NDCD#_3_D NDSR#_3_D NRXD_3_D NRTS#_3_D NTXD_3_D NCTS#_3_D NDTR#_3_D NRI#_3_D 2.9.2 Serial Port 2 connector (D_COM2) Signal PIN PIN Signal NDCD#_2_D NDSR#_2_D NRXD_2_D NRTS#_2_D NTXD_2_D NCTS#_2_D NDTR#_2_D NRI#_2_D 40 ARC-1209/1509 Quick Reference Guide... -
Page 41: Arc-Byt Db-E Jumpers & Connectors Settings
Quick Reference Guide 2.10 ARC-BYT DB-E Jumpers & Connectors settings 2.10.1 CAN2.0 Switch (E_JCAN20) CAN2.0A (11-bit)* CAN2.0B (29-bit) *Default 2.10.2 For user update FW (E_JBOOT0) Default* For user update FW *Default ARC-1209/1509 Quick Reference Guide 41... -
Page 42: For User Update Fw (E_Jiap1)
ARC-1209/1509 2.10.3 For user update FW (E_JIAP1) Default* For user update FW *Default 2.10.4 For user update FW (E_CN1) Signal +3.3V SWDIO SWCLK CAN_BUS_RESET# 42 ARC-1209/1509 Quick Reference Guide... - Page 43 Quick Reference Guide 2.10.5 General purpose I/O connector (E_GPIO1) Signal +3.3V 2.10.6 CAN Bus connector (E_CAN1) Signal CANH CANL ARC-1209/1509 Quick Reference Guide 43...
-
Page 44: Arc-Byt Db-F Connectors Settings
CAN Bus connector 1 (F_CAN1) Signal PIN PIN Signal CAN_PWR CAN_8 CAN_IND CAN_9 BAT_GND CAN_WAKE CAN_11 UART_RXD_1_F CAN_12 UART_TXD_1_F CAN_13 CAN_14 2.11.2 CAN Bus connector 2 (F_CAN2) Signal PIN PIN Signal BAT_PWR CAN_12 CAN_8 CAN_13 CAN_9 CAN_14 BAT_GND CAN_11 44 ARC-1209/1509 Quick Reference Guide... -
Page 45: Arc-Byt Db-H Jumpers Settings
2.12 ARC-BYT DB-H Jumpers settings 2.12.1 USB Power selector (H_USB_PWR_SEL1) +5VSB* *Default 2.13 ARC-BYT DB-G Connectors settings 2.13.1 Serial Port 1 connector (G_COM1) Signal PIN PIN Signal NDCD#_3_G NDSR#_3_G NRXD_3_G NRTS#_3_G NTXD_3_G NCTS#_3_G NDTR#_3_G NRI#_3_G ARC-1209/1509 Quick Reference Guide 45... -
Page 46: Serial Port 2 Connector (G_Com2)
Serial Port 2 connector (G_COM2) Signal PIN PIN Signal NDCD#_2_G NDSR#_2_G NRXD_2_G NRTS#_2_G NTXD_2_G NCTS#_2_G NDTR#_2_G NRI#_2_G 2.13.3 Serial Port 3 connector (G_COM3) Signal PIN PIN Signal NDCD#_1_G NDSR#_1_G NRXD_1_G NRTS#_1_G NTXD_1_G NCTS#_1_G NDTR#_1_G NRI#_1_G 46 ARC-1209/1509 Quick Reference Guide... -
Page 47: Arc-Byt Db-H Connectors Settings
Serial Port 1 connector (H_COM1) Signal PIN PIN Signal NDCD#_1_H NDSR#_1_H NRXD_1_H NRTS#_1_H NTXD_1_H NCTS#_1_H NDTR#_1_H NRI#_1_H 2.14.2 Serial Port 2 connector (H_COM2) Signal PIN PIN Signal NDCD#_2_H NDSR#_2_H NRXD_2_H NRTS#_2_H NTXD_2_H NCTS#_2_H NDTR#_2_H NRI#_2_H ARC-1209/1509 Quick Reference Guide 47... -
Page 48: Arc-Byt Db-K Connectors Settings
Serial Port 1 connector (I_COM1) Signal PIN PIN Signal NDCD#_1_I NDSR#_1_I NRXD_1_I NRTS#_1_I NTXD_1_I NCTS#_1_I NDTR#_1_I NRI#_1_I 2.15.2 Serial Port 2 connector (I_COM2) Signal PIN PIN Signal NDCD#_2_I NDSR#_2_I NRXD_2_I NRTS#_2_I NTXD_2_I NCTS#_2_I NDTR#_2_I NRI#_2_I 48 ARC-1209/1509 Quick Reference Guide... -
Page 49: Bios Setup
Quick Reference Guide 3.BIOS Setup ARC-1209/1509 Quick Reference Guide 49... -
Page 50: Introduction
If you do not press the keys at the correct time and the system does not boot, an error message will be displayed and you will again be asked to. Press F1 to Continue, DEL to enter SETUP 50 ARC-1209/1509 Quick Reference Guide... -
Page 51: Using Setup
Note: Some of the navigation keys differ from one screen to another. To Display a Sub Menu Use the arrow keys to move the cursor to the sub menu you want. Then press <Enter>. A “” pointer marks all sub menus. ARC-1209/1509 Quick Reference Guide 51... -
Page 52: Getting Help
BIOS Vendor and your systems manufacturer to provide the absolute maximum performance and reliability. Even a seemingly small change to the chipset setup has the potential for causing you to use the override. 52 ARC-1209/1509 Quick Reference Guide... -
Page 53: Bios Setup
When new DB board is connected, item value should be adjusted manually. Item Option Description DB-A/C/E/J DB-B DB board A-K. DB-A/B/C/D/E/J w/o DB-F 1COM DB board UART DB-G w/t 3UART DB-D/H/K w/t DB-D/H/K 2COM 2UART DB-F w/t 1UART. DB-G 3COM M/B mode test[Default] ARC-1209/1509 Quick Reference Guide 53...
