- Page 1 ARC-1232/1532 12.1"/15" 6th Gen Intel® ULT Core™ Processor i7/i5/i3 Fanless Rugged Touch Panel PC with IET Expansion Quick Reference Guide Ed – 28 January 2019 Copyright Notice Copyright 2019 ALL RIGHTS RESERVED. Part No. E2017A220A6R...
- Page 2 For the most frequently asked questions, you can easily find answers in your product documentation. These answers are normally a lot more detailed than the ones we can give over the phone. So please consult the user’s manual first. 2 ARC-1232/1532 Quick Reference Guide...
-
Page 3: Table Of Contents
1.5.3 ARC-1532 (A Model) ......................14 1.5.4 ARC-1532 (B Model) ......................15 Hardware Configuration ..................16 2.1 ARC-1232/1532 connector mapping ............... 17 2.1.1 Serial port 1 connector (COM1) ..................... 17 2.1.2 Serial port 2 connector (COM2) ..................... 17 2.2 Installing Hard Disk & Memory ................18 2.3 Installing ARC-BYT DB ................... - Page 4 2.13 ARC-BYT DB-K Connectors settings ..............43 2.13.1 Serial Port 1 connector (I_COM1) ..................43 2.13.2 Serial Port 2 connector (I_COM2) ..................43 3.BIOS Setup ........................44 3.1 Introduction ......................45 3.2 Starting Setup ......................45 4 ARC-1232/1532 Quick Reference Guide...
- Page 5 3.6.3.2.1.1 PCI Express Root Port5 (i210/211) ..................67 3.6.3.2.1.2 PCI Express Root Port8 (B2B mPCIe) ..................68 3.6.3.2.1.3 PCI Express Root Port12 (mPCIe) ..................69 3.6.3.2.2 USB Configuration ........................... 70 3.6.3.2.3 HD Audio Configuration ........................70 ARC-1232/1532 Quick Reference Guide...
- Page 6 Boot ............................73 3.6.6 Save and exit ........................74 3.6.6.1 Save Changes and Reset ........................ 75 3.6.6.2 Discard Changes and Reset ......................75 3.6.6.3 Restore Defaults ..........................75 3.6.6.4 Launch EFI Shell from filesystem device ..................75 6 ARC-1232/1532 Quick Reference Guide...
-
Page 7: Getting Started
Place all electronic components in a static-dissipative surface or static-shielded bag when they are not in the chassis. 1.2 Packing List 1 x ARC-1232/1532 Panel PC 1 x Power Adapter ... -
Page 8: System Specifications
4 x USB 3.0 SATA 1 x SATA III 1 x RS-232/422/485 (Factory Optional) Com Port 1 x RS-232 Other 3 x Knockouts for Antenna Mounting Display Intel® Skylake SoC integrated Graphics Chipset Supports optional dual display 8 ARC-1232/1532 Quick Reference Guide... - Page 9 Wall / Stand / VESA 75mm x 75mm, 100mm x 100mm Operating with SSD/CFast/mSATA : MIL-STD-810G, Method 516.6, Shock Test Procedure I, functional shock=20G Certifications Certifications Information FCC Class B Software Support OS Information Win7, Win 8.1,Win 10, Linux ARC-1232/1532 Quick Reference Guide...
- Page 10 OBDII - CAN Bus Kit for ARC Series (Small Vehicle) ACC-ARC-OBDII-2R OBDII - CAN Bus Kit for ARC Series (Large Vehicle) ACC-ARC-OBDII-3R OBDII - CAN Bus Kit for ARC Series (Special Large Vehicle) Note: Specifications are subject to change without notice. 10 ARC-1232/1532 Quick Reference Guide...
-
Page 11: System Overview
Default: Lockable DC Jack DC-IN DC Power-in connector Option: Phoenix Connector(MOQ apply) COM1/2 Serial port 1/2 connector DB-9 male connector 4 x USB 3.0 connector LAN1/2 RJ-45 Ethernet 1/2 HDD/Power LED indicator Power Switch Power on button ARC-1232/1532 Quick Reference Guide 11... -
Page 12: System Dimensions
ARC-1232/1532 1.5 System Dimensions 1.5.1 ARC-1232 (A Model) (Unit: mm) 12 ARC-1232/1532 Quick Reference Guide... -
Page 13: Arc-1232 (B Model)
Quick Reference Guide 1.5.2 ARC-1232 (B Model) (Unit: mm) ARC-1232/1532 Quick Reference Guide 13... -
Page 14: Arc-1532 (A Model)
ARC-1232/1532 1.5.3 ARC-1532 (A Model) (Unit: mm) 14 ARC-1232/1532 Quick Reference Guide... -
Page 15: Arc-1532 (B Model)
Quick Reference Guide 1.5.4 ARC-1532 (B Model) (Unit: mm) ARC-1232/1532 Quick Reference Guide 15... -
Page 16: Hardware Configuration
ARC-1232/1532 2. Hardware Configuration For advanced information, please refer to: 1- ARC-SKLU, ARC-BYT DB-A/B/C/D/G/H/K included in this manual. 16 ARC-1232/1532 Quick Reference Guide... -
Page 17: Arc-1232/1532 Connector Mapping
PIN PIN Signal TxD- Please set BIOS & JCOM1_SEL1 TxD+ RxD+ RxD- Please set BIOS & JCOM1_SEL1 2.1.2 Serial port 2 connector (COM2) Signal PIN PIN Signal NDCDB# NDSRB# NRXDB NRTSB# NTXDB NCTSB# NDTRB# NRIB# ARC-1232/1532 Quick Reference Guide 17... -
Page 18: Installing Hard Disk & Memory
Memory Installation: Remove 3 screws to release the chassis cover, and remove it. Step 2.1 Insert the SODIMM into the memory socket. Step 2.2 Re-assemble your system back through previous steps to complete the installation. 18 ARC-1232/1532 Quick Reference Guide... - Page 19 Quick Reference Guide Step 3. HDD Installation: Insert the HDD into the Drive Bay and fasten 2 screws. ARC-1232/1532 Quick Reference Guide 19...
-
Page 20: Installing Arc-Byt Db
ARC-1232/1532 2.3 Installing ARC-BYT DB Step 1. Unfasten 2 screws of the HDD bracket and take it off. Step 2. Remove 4 screws to release the chassis cover, and remove it. 20 ARC-1232/1532 Quick Reference Guide... - Page 21 Quick Reference Guide Step 2.1 Insert the ARC-BYT DB into the socket and fasten 3 screws. Step 2.2 Re-assemble your system back through previous steps to complete the installation ARC-1232/1532 Quick Reference Guide 21...
-
Page 22: Arc-Sklu Overviews
ARC-1232/1532 2.4 ARC-SKLU Overviews 22 ARC-1232/1532 Quick Reference Guide... -
Page 23: Arc-Sklu Jumper And Connector List
JPWR1 JSPI1 SPI connector 4 x 2 header, pitch 2.00mm EC Debug connector 2 x 1 header, pitch 2.00 mm JEC1 SATA1 Serial ATA connector 2 x 1 wafer, pitch 2.00mm SATAPW1 SATA Power connector ARC-1232/1532 Quick Reference Guide 23... -
Page 24: Arc-Sklu Jumpers & Connectors Settings
ARC-1232/1532 2.6 ARC-SKLU Jumpers & Connectors settings 2.6.1 Clear CMOS (JCOMS1) Protect* Clear CMOS *Default 2.6.2 Serial port 1/2 pin9 signal select (JRI1/JRI2) Ring* +12V JRI2 JRI1 * Default 24 ARC-1232/1532 Quick Reference Guide... -
Page 25: Lcd Backlight Brightness Adjustment (Jbklsel1)
Quick Reference Guide 2.6.3 LCD backlight brightness adjustment (JBKLSEL1) PWM Mode* DC Mode * Default 2.6.4 AT/ATX Input power select (JAT1) ATX* * Default ARC-1232/1532 Quick Reference Guide 25... -
Page 26: Serial Port 1 In Rs-232/422/485 Mode (Jcom1_Sel1)
NDTRA# 485_422TX1+ COM1-2 NRXDA 422RX1+ COM1-3 NTXDA 485_422TX1- COM1-1 NDCDA# Note: This connector is available after modify the mode of COM1 in BIOS setting. * Default 2.6.6 LCD Inverter connector (JBKL1) Signal LVDS_BKLT_CTL LVDS_BKLT_EN +12V 26 ARC-1232/1532 Quick Reference Guide... -
Page 27: On-Board Header For Usb2.0 (Jusb1)
Quick Reference Guide 2.6.7 On-board header for USB2.0 (JUSB1) Signal +5VSB USB_z_PN10 USB_z_PP10 2.6.8 On-board header for USB2.0 (JUSB2) Signal PIN PIN Signal +5VSB +5VSB USB_z_PN6 USB_z_PN5 USB_z_PP6 USB_z_PP5 ARC-1232/1532 Quick Reference Guide 27... -
Page 28: Battery Connector (Jbat1)
ARC-1232/1532 2.6.9 Battery connector (JBAT1) Signal +RTCBAT 2.6.10 LCD backlight brightness adjustment (JBLK_CTRL1) Signal Note BLK_VR_MOD VR must select 10K/1% Low pulse button for BLK_BRI_UP backlight brighter Low pulse button for BLK_BRI_DN backlight dim 28 ARC-1232/1532 Quick Reference Guide... -
Page 29: Lvds Connector (Jlvds1)
LVDS_DATA1_P LVDS_DATA0_N 12 11 LVDS_DATA1_N LVDS_DATA2_P 16 15 LVDS_DATA3_P LVDS_DATA2_N 18 17 LVDS_DATA3_N LVDS_DATA4_P 22 21 LVDS_DATA5_P LVDS_DATA4_N 24 23 LVDS_DATA5_N LVDS_DATA6_P 28 27 LVDS_DATA7_P LVDS_DATA6_N 30 29 LVDS_DATA7_N LVDS_CLK1_P LVDS_CLK2_P LVDS_CLK1_N LVDS_CLK2_N +12V +12V ARC-1232/1532 Quick Reference Guide 29... -
Page 30: Amplifier_R (Jspr1)
ARC-1232/1532 2.6.12 AMPLIFIER_R (JSPR1) Signal SPK_R- SPK_R+ 2.6.13 AMPLIFIER_L (JSPL1) Signal SPK_L- SPK_L+ 30 ARC-1232/1532 Quick Reference Guide... -
Page 31: Spi Connector (Jspi1)
Quick Reference Guide 2.6.14 SPI connector (JSPI1) Signal PIN PIN Signal +3.3VSB SPI0_CS0# SPI_CLK SPI_SO SPI_SI HOLD# 2.6.15 EC Debug connector (JEC1) Signal EC_SMCLK_DEBUG EC_SMDAT_DEBUG ARC-1232/1532 Quick Reference Guide 31... -
Page 32: B2B Connector (Jb2B1)
PCIE_RXP8 HDMI1_CLKN Signal PIN PIN Signal HDMI1_CLKP CLK_B2BPCIE_N2 CLK_B2BPCIE_P2 +12V MIC_RIN +12V MIC_LIN MIC1_JD LPC_SERIRQ 46 +5VSB LINEOUT1_JD LINE1_JD LPC_LFRAME# 47 +5VSB LINEOUT_R LINE1_RIN CLK3_LPC_B2B 48 +5VSB LINEOUT_L LNE1_LIN LPC_AD0 49 +5VSB LPC_AD1 50 +5VSB 32 ARC-1232/1532 Quick Reference Guide... -
Page 33: Touch Panel Connector (Jtp1)
Quick Reference Guide 2.6.17 Touch panel connector (JTP1) Signal SENSE 2.6.18 General purpose I/O connector (JGPIO1) Signal PIN PIN Signal +3.3V SMB_DATA SMB_CLK DIO_GP23 DIO_GP13 DIO_GP22 DIO_GP12 DIO_GP21 DIO_GP11 DIO_GP20 DIO_GP10 ARC-1232/1532 Quick Reference Guide 33... -
Page 34: Sata Power Connector (Satapw1)
ARC-1232/1532 2.6.19 SATA Power connector (SATAPW1) Signal 2.6.20 Power connector (PWR1) *Option: Phoenix Connector Signal +DCIN 34 ARC-1232/1532 Quick Reference Guide... -
Page 35: Arc-Byt Db-A/B/C/D/G/H/K Overviews
Quick Reference Guide 2.7 ARC-BYT DB-A/B/C/D/G/H/K Overviews 2.7.1 ARC-BYT DB-A 2.7.2 ARC-BYT DB-B 2.7.3 ARC-BYT DB-C ARC-1232/1532 Quick Reference Guide 35... -
Page 36: Arc-Byt Db-D
ARC-1232/1532 2.7.4 ARC-BYT DB-D 2.7.5 ARC-BYT DB-G 2.7.6 ARC-BYT DB-H 36 ARC-1232/1532 Quick Reference Guide... -
Page 37: Arc-Byt Db-K
Line-in audio jack B_MIC_IN1 Mic-in audio jack B_JHDMI1 HDMI connector B2B connector B_JB2B1 2.8.3 ARC-BYT DB-C Connectors Label Function Note C_JPCIE1 Mini PCI Express connector C_JSIM1 SIM card slot (Push-push) C_JHDMI1 HDMI connector B2B connector C_JB2B1 ARC-1232/1532 Quick Reference Guide 37... -
Page 38: Arc-Byt Db-D
H_JUSB1 USB3.0 connector H_COM1/2 Serial Port 1/2 connector DB-9 male connector B2B connector H_JB2B1 2.8.7 ARC-BYT DB-K Connectors Label Function Note I_JLAN1 RJ-45 Ethernet I_COM1/2 Serial Port 1/2 connector DB-9 male connector I_JB2B1 B2B connector 38 ARC-1232/1532 Quick Reference Guide... -
Page 39: Arc-Byt Db-D Connectors Settings
Serial Port 1 connector (D_COM1) Signal PIN PIN Signal NDCD#_3_D NDSR#_3_D NRXD_3_D NRTS#_3_D NTXD_3_D NCTS#_3_D NDTR#_3_D NRI#_3_D 2.9.2 Serial Port 2 connector (D_COM2) Signal PIN PIN Signal NDCD#_2_D NDSR#_2_D NRXD_2_D NRTS#_2_D NTXD_2_D NCTS#_2_D NDTR#_2_D NRI#_2_D ARC-1232/1532 Quick Reference Guide 39... -
Page 40: Arc-Byt Db-G Connectors Settings
Serial Port 1 connector (G_COM1) Signal PIN PIN Signal NDCD#_3_G NDSR#_3_G NRXD_3_G NRTS#_3_G NTXD_3_G NCTS#_3_G NDTR#_3_G NRI#_3_G 2.10.2 Serial Port 2 connector (G_COM2) Signal PIN PIN Signal NDCD#_2_G NDSR#_2_G NRXD_2_G NRTS#_2_G NTXD_2_G NCTS#_2_G NDTR#_2_G NRI#_2_G 40 ARC-1232/1532 Quick Reference Guide... -
Page 41: Serial Port 3 Connector (G_Com3)
Quick Reference Guide 2.10.3 Serial Port 3 connector (G_COM3) Signal PIN PIN Signal NDCD#_1_G NDSR#_1_G NRXD_1_G NRTS#_1_G NTXD_1_G NCTS#_1_G NDTR#_1_G NRI#_1_G 2.11 ARC-BYT DB-H Jumpers settings 2.11.1 USB Power selector (H_USB_PWR_SEL1) +5VSB* *Default ARC-1232/1532 Quick Reference Guide 41... -
Page 42: Arc-Byt Db-H Connectors Settings
Serial Port 1 connector (H_COM1) Signal PIN PIN Signal NDCD#_1_H NDSR#_1_H NRXD_1_H NRTS#_1_H NTXD_1_H NCTS#_1_H NDTR#_1_H NRI#_1_H 2.12.2 Serial Port 2 connector (H_COM2) Signal PIN PIN Signal NDCD#_2_H NDSR#_2_H NRXD_2_H NRTS#_2_H NTXD_2_H NCTS#_2_H NDTR#_2_H NRI#_2_H 42 ARC-1232/1532 Quick Reference Guide... -
Page 43: Arc-Byt Db-K Connectors Settings
Serial Port 1 connector (I_COM1) Signal PIN PIN Signal NDCD#_1_I NDSR#_1_I NRXD_1_I NRTS#_1_I NTXD_1_I NCTS#_1_I NDTR#_1_I NRI#_1_I 2.13.2 Serial Port 2 connector (I_COM2) Signal PIN PIN Signal NDCD#_2_I NDSR#_2_I NRXD_2_I NRTS#_2_I NTXD_2_I NCTS#_2_I NDTR#_2_I NRI#_2_I ARC-1232/1532 Quick Reference Guide 43... -
Page 44: Bios Setup
ARC-1232/1532 3.BIOS Setup 44 ARC-1232/1532 Quick Reference Guide... -
Page 45: Introduction
If the message disappears before you respond and you still wish to enter Setup, restart the system to try again by turning it OFF then ON or pressing the "RESET" button on the system case. You may also restart by simultaneously pressing <Ctrl>, <Alt>, and <Delete> keys. ARC-1232/1532 Quick Reference Guide 45... -
Page 46: Using Setup
Note: Some of the navigation keys differ from one screen to another. To Display a Sub Menu Use the arrow keys to move the cursor to the sub menu you want. Then press <Enter>. A “” pointer marks all sub menus. 46 ARC-1232/1532 Quick Reference Guide... -
Page 47: Getting Help
BIOS Vendor and your systems manufacturer to provide the absolute maximum performance and reliability. Even a seemingly small change to the chipset setup has the potential for causing you to use the override. ARC-1232/1532 Quick Reference Guide 47... -
Page 48: Bios Setup
<Enter> to accept and enter the sub-menu. 3.6.1 Main Menu This section allows you to record some basic hardware configurations in your computer and set the system clock. 48 ARC-1232/1532 Quick Reference Guide... -
Page 49: System Language
Note: The BIOS setup screens shown in this chapter are for reference purposes only, and may not exactly match what you see on your screen. 3.6.2 Advanced Menu This section allows you to configure your CPU and other system devices for basic operation through the following sub-menus. ARC-1232/1532 Quick Reference Guide 49... -
Page 50: Trusted Computing
Item Options Description Enables or Disables BIOS support for Disable, security device. O.S. will not show Security Device Support Enable[Default] Security Device. TCG EFI protocol and INT1A interface will not be available. 3.6.2.2 APCI Settings 50 ARC-1232/1532 Quick Reference Guide... - Page 51 AC loss resume. Last state Disabled[Default], 30 sec 40 sec 50 sec Watch Dog Select WatchDog. 1 min 2 min 10 min 30 min Disabled Enabled/Disabled USB Standby Power USB Standby Power Setting Enabled[Default], during S3/S4/S5. ARC-1232/1532 Quick Reference Guide 51...
-
Page 52: Amt Configuration
Disabled Intel AMT always enabled. This option just controls the BIOS Enabled[Default], extension execution. If enabled, this requires additional firmware in the SPI device. Disabled[Default] Un-Configure ME OEMFlag Bit 15: Un-Configure ME without password. Enabled, 52 ARC-1232/1532 Quick Reference Guide... -
Page 53: Pch-Fw Configuration
You can use this item to set up or change the IT8528 Super IO configuration for serial ports. Please refer to 3.6.2.5.1~ 3.6.2.5.5 for more information. Item Options Description DB-A/C/E/J DB board A-K. DA-A/B/C/E/J w/o UART DB-G w/t DB board DB-B 3UART DB-D/H/K w/t 2UART DB-F w/t 1UART. DB-F 1COM ARC-1232/1532 Quick Reference Guide 53... -
Page 54: Serial Port 1 Configuration
Set Parameters of Serial Port 5 (COME). 3.6.2.5.1 Serial Port 1 Configuration Item Option Description Enabled[Default], Serial Port Enable or Disable Serial Port (COM). Disabled UART 232[Default] UART 232 422 485 UART 422 Change the Serial Port UART 485 54 ARC-1232/1532 Quick Reference Guide... -
Page 55: Serial Port 2 Configuration
Quick Reference Guide 3.6.2.5.2 Serial Port 2 Configuration Item Option Description Enabled[Default], Serial Port Enable or Disable Serial Port (COM). Disabled 3.6.2.5.3 Serial Port 3 Configuration ARC-1232/1532 Quick Reference Guide 55... -
Page 56: Serial Port 4 Configuration
Option Description Enabled[Default], Serial Port Enable or Disable Serial Port (COM). Disabled 3.6.2.5.4 Serial Port 4 Configuration Item Option Description Enabled[Default], Serial Port Enable or Disable Serial Port (COM). Disabled 3.6.2.5.5 Serial Port 5 Configuration 56 ARC-1232/1532 Quick Reference Guide... -
Page 57: H/W Monitor
Quick Reference Guide Item Option Description Enabled[Default], Serial Port Enable or Disable Serial Port (COM). Disabled 3.6.2.6 H/W Monitor 3.6.2.7 S5 RTC Wake Settings ARC-1232/1532 Quick Reference Guide 57... -
Page 58: Serial Port Console Redirection
Select Dynamic Time, System will wake on Dynamic Time the current time + Increase minute(s). 3.6.2.8 Serial Port Console Redirection Item Options Description Disabled[Default], Console Redirection Console Redirection Enable or Disable. Enabled 3.6.2.8.1 Legacy Console Redirection Settings 58 ARC-1232/1532 Quick Reference Guide... -
Page 59: Cpu Configuration
Select a COM port to display redirection of Legacy Serial Redirection Port COM1[Default], Legacy OS and Legacy OPROM Messages. 3.6.2.9 CPU Configuration Use the CPU configuration menu to view detailed CPU specification and configure the CPU. 3.6.2.10 Intel TXT Configuration ARC-1232/1532 Quick Reference Guide 59... -
Page 60: Sata Configuration
Disabled state. Enabled[Default] Port 1/2 Enable or Disable SATA Port. Disabled, Hard Disk Drive [Default] Identify the SATA port is connected to Solid SATA Device Type Solid State Drive State Drive or Hard Disk Drive. 60 ARC-1232/1532 Quick Reference Guide... -
Page 61: Network Stack Configuration
Quick Reference Guide 3.6.2.12 Network Stack Configuration Item Options Description Enabled Network Stack Enable/Disable UEFI Network Stack. Disabled[Default] 3.6.2.13 CSM Configuration ARC-1232/1532 Quick Reference Guide 61... -
Page 62: Usb Configuration
Interrupt transfers. 20 sec[Default] 10 sec 20 sec[Default] USB mass storage device Start Unit command Device reset time-out 30 sec time-out. 40 sec Device power-up delay Auto[Default] Maximum time the device will take before it 62 ARC-1232/1532 Quick Reference Guide... -
Page 63: Chipset
1100 Forced FDD format. Optical drives are emulated as ‘CDROM’, drives with no media will be Hard Disk CD-ROM emulated according to a drive type. 3.6.3 Chipset 3.6.3.1 System Agent (SA) Configuration ARC-1232/1532 Quick Reference Guide 63... -
Page 64: Graphics Configuration
Active Internal LVDS (eDP->Ch7511- Active LVDS (CH7511) Disabled to-LVDS). BIOS[Default] LVDS Brightness Control Method. BR Button Brightness Control Method 1.BIOS 2.Brightness Button 3.Variable Resistor 4.OS Driver. OS Driver LVDS Back Light PWM Select LVDS back light PWM duty. 64 ARC-1232/1532 Quick Reference Guide... -
Page 65: Memory Configuration
Onboard Touch Setting Enable/Disable USB Touch. Disabled 3.6.3.1.2 Memory Configuration Item Option Description Maximum Value of TOLUD. Dynamic Dynamic[Default] assignment would adjust TOLUD Max TOLUD 1GB/1.25GB/1.5GB/1.75GB automatically based on largest MMIO length /2GB/2.25GB/2.5GB/2.75GB of installed graphic controller. ARC-1232/1532 Quick Reference Guide 65... -
Page 66: Pch-Io Configuration
ARC-1232/1532 3.6.3.2 PCH-IO Configuration Item Option Description Disabled PCH LAN Controller Enable or disable onboard NIC. Enabled[Default] 3.6.3.2.1 PCI Express Configuration 66 ARC-1232/1532 Quick Reference Guide... -
Page 67: Pci Express Root Port5 (I210/211)
L0s State AUTO – BIOS auto ASPM Support configure DISABLE – Disables ASPM. L0sL1 Auto Disabled L1.1 L1 Substates PCI Express L1 Substates settings. L1.2 L1.1 & L1.2[Default], Auto[Default] Gen1 PCIe Speed Select PCI Express port speed. Gen2 Gen3 ARC-1232/1532 Quick Reference Guide 67... -
Page 68: Pci Express Root Port8 (B2B Mpcie)
L0s State AUTO – BIOS auto ASPM Support configure DISABLE – Disables ASPM. L0sL1 Auto Disabled L1.1 L1 Substates PCI Express L1 Substates settings. L1.2 L1.1 & L1.2[Default], Auto[Default] Gen1 PCIe Speed Select PCI Express port speed. Gen2 Gen3 68 ARC-1232/1532 Quick Reference Guide... -
Page 69: Pci Express Root Port12 (Mpcie)
L0s State AUTO – BIOS auto ASPM Support configure DISABLE – Disables ASPM. L0sL1 Auto Disabled L1.1 L1 Substates PCI Express L1 Substates settings. L1.2 L1.1 & L1.2[Default], Auto[Default] Gen1 PCIe Speed Select PCI Express port speed. Gen2 Gen3 ARC-1232/1532 Quick Reference Guide 69... -
Page 70: Usb Configuration
Option to disable Compliance Mode. Default FALSE[Default], XHCI Disable Compliance Mode is FALSE to not disable Compliance Mode. TRUE Set TRUE to disable Compliance Mode. 3.6.3.2.3 HD Audio Configuration 70 ARC-1232/1532 Quick Reference Guide... -
Page 71: Security
Auto = HDA will be enabled if present, disabled otherwise. 20db[Default], 26db Amplifier Gain Amplifier Gain. 32db 36db 3.6.4 Security Administrator Password Set setup Administrator Password User Password Set User Password ARC-1232/1532 Quick Reference Guide 71... -
Page 72: Secure Boot Menu
Secure Boot User mode with enrolled Platform Key(PK) 2.CSM Enabled function is disabled. Secure Boot mode selector. ‘Custom’ Mode enables Standard Secure Boot Mode users to change Image Execution policy and manage Custom[Default] Secure Boot Keys. 72 ARC-1232/1532 Quick Reference Guide... -
Page 73: Key Management
Quick Reference Guide 3.6.4.1.1 Key Management Item Option Description Enabled, Install Factory default Secure Boot Keys Provision Factory Default keys Disabled[Default] when System is in Setup Mode. 3.6.5 Boot ARC-1232/1532 Quick Reference Guide 73... -
Page 74: Save And Exit
Fast Boot Enabled required to launch active boot option. Has no effect for BBS boot options. Boot Option #1 Set the system boot order. 3.6.6 Save and exit 74 ARC-1232/1532 Quick Reference Guide... -
Page 75: Save Changes And Reset
This option restores all BIOS settings to the factory default. This option is useful if the controller exhibits unpredictable behavior due to an incorrect or inappropriate BIOS setting. 3.6.6.4 Launch EFI Shell from filesystem device Attempts to Launch EFI Shell application (Shellx64.efi) from one of the available filesystem devices. ARC-1232/1532 Quick Reference Guide 75...
