Power Trackbarrow
Operator's Manual
MODEL NUMBER
YD8103
SERIAL NUMBER
PURCHASE DATE
Both model number and serial
number may be found on the
main label.
(See Page 2, Figure 1)
You should record both of them
in a safe place for future use.
FOR YOUR SAFETY
READ AND UNDERSTAND THE ENTIRE MANUAL BEFORE OPERATING MACHINE
Tame the Great Outdoors
®
Advertisement
Table of Contents
Related Manuals for YARDMAX YD8103
Summary of Contents for YARDMAX YD8103
- Page 1 Save This Manual for Future Reference Power Trackbarrow Operator’s Manual MODEL NUMBER YD8103 SERIAL NUMBER PURCHASE DATE Both model number and serial number may be found on the main label. (See Page 2, Figure 1) You should record both of them in a safe place for future use.
-
Page 2: Table Of Contents
Up for the job? YARDMAX is. When looking for outdoor power equipment (OPE) to get the job done right, at the right price, YARDMAX delivers the perfect combination of performance and practicality. YARDMAX has a solution that’s right for you. - Page 3 California to cause cancer and birth defects or other reproductive harm. For more information, go to DISCLAIMER www.P65Warnings.ca.gov. YARDMAX reserves the right to discontinue, change, and improve its products at any time without notice or obligation to the purchaser. The descriptions and ENVIRONMENTAL specifications contained in this manual were in effect at printing.
-
Page 4: Specifications
SUPPORT Have questions about your YARDMAX equipment? Call us at 844-YARDMAX, email us at support@yardmax.com, or contact us via your favorite social media site. SPECIFICATIONS Model number YD8103 Engine briggs & Stratton Displacement 208 cc Start Type Recoil load Capacity... -
Page 5: Symbols
Power Trackbarrow Operator’s Manual » SYMBOLS The rating plate on your machine may show symbols. These represent important information about the product or instructions on its use. Keep your hands clear from all rotating Read these instructions carefully. parts. Wear eye protection. Never start or run the engine inside a closed area. -
Page 6: Safety
SAFETY GENERAL SAFETY RULES Stay alert, watch what you are doing, and use common sense UNDERSTAND YOUR MACHINE when operating the machine. Read this manual and labels affixed to the machine to understand its limitations and potential hazards. Do not overreach. Do not operate the machine while barefoot or when wearing sandals or similar lightweight footwear. - Page 7 Power Trackbarrow Operator’s Manual » Do not tamper with the engine in an effort to get it to run at loosen the fuel tank cap slowly to relieve any pressure in the tank. higher speeds. The maximum engine speed is preset by the Never overfill the fuel tank.
-
Page 8: Unpacking The Container
UnPACKInG THE COnTAInER Use the screwdriver and hammer to open all the side locks. (See Figure 1a) Figure 1a Remove all the plywood plates (Figure 1b), and remove all the loose parts on the bottom pallets. Figure 1b Unpacking the Container YD8103PM03 - 1802... -
Page 9: Contents Supplied
Power Trackbarrow Operator’s Manual » COnTEnTS SUPPlIED Your YARDMAX power trackbarrow comes partially assembled, and the package contains the following: Premium 4-Cycle NET CONTENTS 35 OZ (1.05 L) 1. Machine 3. Operator’s Manual & Engine Manual 2. Engine Oil 4. Tools for Spark Plug Assembly... -
Page 10: Assembly
ASSEMblY This trackbarrow was partially assembled at the factory. To assemble your machine and the optional plow blade follow the below instructions. PLOW BLADE (OPTIONAL) 3. Insert the shorter control lever into the longer lever. Align holes and fasten with M8×40 hex bolt, washers and nut. 1. - Page 11 Power Trackbarrow Operator’s Manual » 7. Install the already assembled plow blade to the trackbarrow as shown. (See Figure 3e) M10×25 M12×40 (×2) (×2) Figure 3e M10 × 25 × 2 M12 × 40 × 2 Assembly YD8103PM03 - 1802...
-
Page 12: Know Your Machine
KnOW YOUR MACHInE FEATURES AND CONTROLS Engine On/Off Switch Throttle Control Right Steering Lever Clutch Control Lever Left Steering Lever Gear Selection Lever Hopper Gearbox Track Gas Spring Assistance Know Your Machine YD8103PM03 - 1802... - Page 13 Power Trackbarrow Operator’s Manual » Recoil Starter Handle Throttle Control Choke Control Fuel Shut-Off Valve GEAR SELECTION LEVER ENGINE ON/OFF SWITCH The engine switch has two positions. OFF - engine will The gear selection lever has 4 positions: 3 forward not start or run.
-
Page 14: Operation
OPERATION ADD OIL TO ENGINE IMPORTANT: DO NOT OVERFILL! This equipment and/or its engine may include No oil in the engine originally, but a bottle of engine evaporative emissions control system components, oil is in scope of delivery. Don’t start the engine before required to meet EPA and/or CARB regulations, that adding oil. - Page 15 Power Trackbarrow Operator’s Manual » Avoid sharp turns and frequent changes of direction while driving on rough, hard terrains full of sharp, uneven points with a high degree of friction. FAST SLOW 4. Move the throttle lever slightly Even though the unit has rubber tracks, remember to be careful to the FAST speed.
-
Page 16: Maintenance
MAInTEnAnCE Maintaining your YARDMAX power trackbarrow will ensure long 1. loosen the jam nut by turning it counter clockwise life to the machine and its components. with 10mm wrench. (see Figure 4, Illustration 1) 2. Tighten or loosen the cable by turning the cable... - Page 17 Power Trackbarrow Operator’s Manual » REPLACING DRIVE BELT Adjustment Nut Remove the belt covers as show. (See Figure 6a) Belt Cover M8×20 (×4) Jam Nut Jam Nut Lock Nut Lock Nut Adjustment Nut Jam Nut M6×20 Lock Nut Belt Cover for Gearbox Pulley Figure 5a Figure 6a If the above adjustment does not create enough cable...
- Page 18 LUBRICATION 3. Measure the track midline vs. the horizontal line. The reading must not be more than 0,4”~0,6”. The gearbox is pre-lubricated and sealed at the factory. no need to lubricate until 50 hours use. After first 50 hours use, change all the transmission oil.
- Page 19 Power Trackbarrow Operator’s Manual » 3. loosen the adjusting bolts and pull the steering wheel axle Steering Wheel toward the engine, then track will be loosen. (See Figure 9b) Steering Wheel Steering Wheel Axle Steering Wheel Axle Adjusting Bolt Figure 8b Figure 9b Do not over-tighten your track.
-
Page 20: Storage
STORAGE If the power trackbarrow will not be used for a period longer than Do not use strong detergents or petroleum based 30 days, follow the steps below to prepare your unit for storage. cleaners when cleaning plastic parts. Chemicals can 1. -
Page 21: Troubleshooting
Power Trackbarrow Operator’s Manual » TROUblESHOOTInG Problem Cause Remedy 1. Attach spark plug wire securely to spark plug 1. Spark plug wire is disconnected 2. Fill with clean, fresh gasoline 2. Out of fuel or stale fuel 3. Engine and Fuel valve must be in On 3. -
Page 22: Parts Diagram
PARTS DIAGRAM Parts Diagram YD8103PM03 - 1802... - Page 23 Power Trackbarrow Operator’s Manual » Gearbox Parts Diagram YD8103PM03 - 1802...
-
Page 24: Parts List
PARTS LIST Description Description Description Tensioner Pulley Cable Tensioner Pulley bracket Track 180×60 Safety Control Handle Engine Axle Head Cover(42) Screw M6×16 Key 4.7×33 Circlip 42 Screw M5×20 belt Protect Frame bear 61905-2RS nut M5 bolt 5/16-24×30 Guiding Wheel Handle Sleeve Fixed bracket Sealing Ring30×42×7 Throttle Cable... - Page 25 Power Trackbarrow Operator’s Manual » Description Description Description 110 Gear 139 Gear II-5 168 Circlip 58 111 bearing 6302 140 Gear II-4 169 Output Gear 112 Gearshift Fork Guide Pin 141 Gear II-3 170 Intermediate Joint bush 113 Spring 142 Gear II-2 Intermediate Joint bush Composite bushing 114 Steel ball 6...
- Page 26 Plow Blade (Optional) OPTIONAL PLOW BLADE Description Description Description bolt M8×35 14* bolt M12×40 27* bolt M8×40 Shave Plate 15* Washer12 28* Adjusting Rod Weldment A Rubber Plate 16* Washer12 29* Handle Sleeve 28 blade Weldment 17* Washer10 30* limiter Rod Wedment Washer8 18* Washer10 31* bolt M24×110...
- Page 27 Power Trackbarrow Operator’s Manual » YD8103PM03 - 1802...
