User Manual
For
Wireless Mini PCI Adapter
(Atheros AR9223)
Model Number : WMP-N09H
Revision: 1.3
This document contains confidential proprietary information and is the property of Alpha Networks Inc.. The contents of
this document may not be disclosed to unauthorized persons without the written consent of Alpha Networks Inc..
Alpha Networks Proprietary and Confidential Information

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Atheros AR9223 and is the answer not in the manual?

Questions and answers

Related Manuals for Alpha Atheros AR9223

Summary of Contents for Alpha Atheros AR9223

  • Page 1 Model Number : WMP-N09H Revision: 1.3 This document contains confidential proprietary information and is the property of Alpha Networks Inc.. The contents of this document may not be disclosed to unauthorized persons without the written consent of Alpha Networks Inc..

  • Page 3: Test Utility Installation

    1. Once utility is executed, a menu with test options will appear. To run a test, press the character key that is assigned to the test option. For example, press “c” to run the continuous transmit test, or press “r ” to run the continuous receive test. Alpha Networks Proprietary and Confidential Information...
  • Page 4 For example: press “h” to choice single chain or both chains in test mode. Alpha Networks Proprietary and Confidential Information...
  • Page 5 Power is 17dBm, press ESC to return to the main Test Options menu when finished. 3. Continuous Receive Options Continuous receiver option will put the radio into receive mode to allow for radio measurement. Press ESC to return to the main Test Option menu when finished. Alpha Networks Proprietary and Confidential Information...

  • Page 6: Product Features

    Friendly user configuration and diagnostic utilities Support Linux driver. Supports Mini-PCI Type IIIA form factor 2.0 Requirements The following sections identify the detailed requirements of the 802.11n Draft 2.0 mPCI. 2.1 Functional Block Diagram Alpha Networks Proprietary and Confidential Information...

  • Page 7: General Requirements

    –70dBm at 54Mbps 2.2.3 IEEE 802.11n Section Feature Detailed Description 2.2.3.1 Standard IEEE 802.11n Draft 2.0 2.2.3.2 Radio and BPSK, QPSK, 16QAM, 64QAM with OFDM Modulation Type 2.2.3.3 Operating Frequency 2400 ~ 2483.5MHz ISM band Alpha Networks Proprietary and Confidential Information...
  • Page 8 650mA at continuous transmit mode (2 Tx chains on ) Consumption 250mA at continuous receive mode (2 Rx chains on ) 2.2.4.4 Form Factor and Mini-PCI Type IIIA form factor Interface 2.2.4.5 LEDs External LED function supported Alpha Networks Proprietary and Confidential Information...
  • Page 9 Wi-Fi Meet Wi-Fi certification for IEEE 802.11b/g/n product 2.5.2 WHQL Meet applicable WHQL certification requirements 2.5.3 Physical Layer and Meet ALPHA Engineering Test Plan and Test Report Functionality 2.6 Requirements of Reliability, Maintainability and Quality Feature Detailed Description 2.6.1 MTBF Mean Time Between Failure >...
  • Page 10 10% conditions and 90% non-condensing. 2.7.4 Non-Operating The product is not damaged nor the performance is Humidity degraded after exposure to relative humidity ranging Conditions from 5% to 95% non-condensing Alpha Networks Proprietary and Confidential Information...
  • Page 11 ■ Rate: Rate in Mbps ■ NES: Number of FEC encoders used ■ NSD: Number of Data Subcarriers ■ NCBPS: Number of Code Bits Per Symbol (total of all spatial streams) ■ NSS: Number of Spatial Streams Alpha Networks Proprietary and Confidential Information...

  • Page 12: Federal Communication Commission Interference Statement

    FCC ID can not be used on the final product. In these circumstances, the OEM integrator will be responsible for re-evaluating the end product (including the transmitter) and obtaining a separate FCC authorization. Alpha Networks Proprietary and Confidential Information...

  • Page 13: Industry Canada Statement

    IC ID can not be used on the final product. In these circumstances, the OEM integrator will be responsible for re-evaluating the end product (including the transmitter) and obtaining a separate IC authorization. End Product Labeling Alpha Networks Proprietary and Confidential Information...
  • Page 14 The user’s manual for OEM Integrators must include the following information in a prominent location “IMPORTANT NOTE: To comply with FCC RF exposure compliance requirements. The antenna must not be co-located or operating in conjunction with any other antenna or transmitter”. Alpha Networks Proprietary and Confidential Information...
  • Page 15 以下警語適用台灣地區： 經型式認證合格之低功率射頻電機，非經許可，公司、商號或使用者均不得擅自變更頻 率、加大功率或變更原設計之特性及功能。 低功率射頻電機之使用不得影響飛航安全及干擾合法通信；經發現有干擾現象時，應立即 停用，並改善至無干擾時方得繼續使用。前項合法通信，指依電信法規定作業之無線電通 信。低功率射頻電機須忍受合法通信或工業、科學及醫療用電波輻射性電機設備之干擾。 本模組於取得認證後將依規定於模組本體標示審合格籤，並要求平台上標示「本產品內含 射頻模組：ID 編號」 Alpha Networks Proprietary and Confidential Information...
