- Page 1 User Manual WMP-ND03B 無線網路卡 Mini-PCI Card Version: 1.1 2008/6/12...
- Page 2 This document contains confidential proprietary information and is the property of Alpha Networks Corporation. The contents of this document may not be disclosed to unauthorized persons without the written consent of Alpha Networks Corporation.
-
Page 3: Revision History
Revision History Rev. Date Author Reason for Changes • New release 2008/3/14 Alfred Chin • Add band 4 (5725~5850MHz) in item 2.2.1.3 2008/6/12 Alfred Chin and 2.2.4.3... -
Page 4: Table Of Contents
Contents TEST OPERATION MANUAL ......................... 5 Test Utility Installation:......................... 5 Configuration: ............................6 1.0 SCOPE..............................7 1.1 D ............................7 OCUMENT 1.2 P ..........................7 RODUCT EATURES 2.0 REQUIREMENTS ..........................8 2.1 G ........................8 ENERAL EQUIREMENTS 2.2.1 IEEE 802.11a Section........................8 2.2.2 IEEE 802.11b Section........................ -
Page 5: Test Operation Manual
Test Operation Manual Test Utility Installation: 1. Unzip “ART_V0_5_b25ALL.zip” to “C:\”. 2. The utility must run on Win2000 or WinXP. Hardware Installation: Before insert the card, please execute the below instruction at first !! 1. Win2000 OS : Enter in the directory : C:\ v0_5_b25ALL\art_driver\bin\2000 Execute the uninst_new_drv_2k.bat: Execute the... -
Page 6: Configuration
Configuration: 1. Enter the DOS command mode , then change the directory to : C:\ v0_5_b25ALL\art_driver\bin\xp 2. Input the instruction: art \id=2082 Then press enter . ART TEST MODE: 1. Once utility is executed, a menu with test options will appear. To run a test, press the character key that is assigned to the test option. -
Page 7: Scope
3. Continuous Receive Options Continuous receive options will put the radio into receive mode to allow for radio measurements. Press ESC to return to the main Test Options menu when finished. 1.0 Scope 1.1 Document This document is to specify the product requirements for 802.11 a/b/g/n Mini-PCI Card. -
Page 8: Requirements
data rate Ÿ Compatible with IEEE 802.11 draft n standard to provide wireless 300Mbps data rate Ÿ Maximum reliability, throughput and connectivity with automatic data rate switching Ÿ Supports infrastructure networks via Access Point and ad-hoc network via peer-to-peer communication 2.0 Requirements The following sections identify the detailed requirements of the 802.11n/ a or g/b Mini-PCI Card. -
Page 9: Ieee 802.11B Section
2.2.2 IEEE 802.11b Section Feature Detailed Description Ÿ 2.2.2.1 Standard IEEE 802.11b Ÿ 2.2.2.2 Radio and DQPSK, DBPSK, DSSS, and CCK Modulation Schemes Ÿ 2.2.2.3 Operating 2400 ~ 2483.5MHz ISM band Frequency Ÿ 2.2.2.4 Channel 11 channels for United States/ Canada/ Taiwan Numbers 13 channels for Europe Countries/ Japan Ÿ... -
Page 10: Ieee 802.11 Draft N Section
2.2.4 IEEE 802.11 Draft n Section Feature Detailed Description Ÿ 2.2.4.1 Standard Draft n Ÿ 2.2.4.2 Radio and BPSK, QPSK, 16QAM, 64QAM with OFDM Modulation Type 2.2.4.3 Operating CE: 240 ~2483.5MHz , 5150~5350MHz, Frequency 5470MHz ~5725MHz C-Tick: 2400~2483.5MHz , 5150~5350MHz, 5470MHz ~5725MHz, 5725MHz ~5850MHz FCC: 2400~2483.5MHz , 5150~5250MHz, 5725MHz ~5850MHz... -
Page 11: General Section
Feature Detailed Description Connector 5GHz Band/HT-20 5GHz Band/HT-40 Ÿ –84dBm at Ÿ –81dBm at MCS0/8 –81dBm at MCS1/9 Ÿ MCS0/8 Ÿ –84dBm at Ÿ –79dBm at MCS2/10 Ÿ –76dBm at MCS3/11 MCS1/9 Ÿ Ÿ –82dBm at –74dBm at MCS4/12 Ÿ –70dBm at MCS5/13 MCS2/10 –79dBm at... -
Page 12: Compatibility Requirements
Meet Wi-Fi certification for IEEE 802.11a/b/g/draft n product Ÿ WHQL 2.3.2 Meet applicable WHQL certification requirements Ÿ Physical Layer and 2.3.3 Meet Alpha Networks Engineering Test Plan and Test Functionality Report 2.4 Regulatory Requirements Feature Detailed Description 2.4.1 United States IEEE 802.11a/n: EMI: FCC Part 15.407(b) -
Page 13: Quality
Mean Time Between Failure > 30,000 hours Ÿ Maintainability 2.5.2 There is no scheduled preventive maintenance required Ÿ Quality 2.5.3 The product quality is followed-up by Alpha Networks factory quality control system 2.6 Environmental Requirements Feature Detailed Description Ÿ 2.6.1 Operating The product is capable of continuous reliable operation when operating in ambient temperature of 0 ℃... - Page 14 Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
-
Page 15: End Product Labeling
band by supplied firmware programming tool. OEM shall not supply any tool or info to the end-user regarding to Regulatory Domain change. As long as 3 conditions above are met, further transmitter test will not be required. However, the OEM integrator is still responsible for testing their end-product for any additional compliance requirements required with this module installed (for example, digital device emissions, PC peripheral requirements, etc.). - Page 16 Caution: The device for the band 5150-5250 MHz is only for indoor usage to reduce potential for harmful interference to co-channel mobile satellite systems. Because high power radars are allocated as primary users (meaning they have priority) in 5250-5350 MHz and 5650-5850 MHz, these radars could cause interference and/or damage to license exempt LAN devices.
- Page 17 integrator will be responsible for re-evaluating the end product (including the transmitter) and obtaining a separate IC authorization. End Product Labeling The final end product must be labeled in a visible area with the following: “Contains TX IC : 4833A-WMPND03B”. Manual Information That Must be Included: The OEM integrator has to be aware not to provide information to the end user regarding how to install or remove.
