Owner's Manual
USB-C
Docking Station
Dual HDMI Ports, GbE, USB-A
and PD 3.0 Charging
Model: U442-DOCK20-B
USB Type-C and USB-C are trademarks of USB Implementers Forum
Este manual esta disponible en español en la página deTripp Lite :
Ce manuel est disponible en français sur le site Web deTripp Lite :
WARRANTY REGISTRATION
Register your product today and be automatically entered to
win an ISOBAR
1111 W. 35th Street, Chicago, IL 60609 USA • tripplite.com/support
Copyright © 2020 Tripp Lite. All rights reserved.
Dual Display
™
tripplite.com/support
tripplite.com/support
surge protector in our monthly drawing!
®
tripplite.com/warranty
1
Advertisement
Table of Contents
Related Manuals for Tripp Lite U442-DOCK20-B
Summary of Contents for Tripp Lite U442-DOCK20-B
- Page 1 WARRANTY REGISTRATION Register your product today and be automatically entered to win an ISOBAR surge protector in our monthly drawing! ® tripplite.com/warranty 1111 W. 35th Street, Chicago, IL 60609 USA • tripplite.com/support Copyright © 2020 Tripp Lite. All rights reserved.
-
Page 2: Product Features
Product Features • Dual-display capability let you extend across up to three screens (including the host computer) at resolutions up to 1920 x 1080p @ 60 Hz when connecting up to two HDMI displays • Single-monitor installations support resolutions up to 2560 x 1440 @ 50 Hz •... -
Page 3: Package Includes
Package Includes • U442-DOCK20-B • USB 3.1 Gen2 C-to-C Cable with C-to-A Adapter – 1 m • Power Supply with C5 to NEMA 5-15P Power Cord (Input: 100-240V) • Owner’s Manual Optional Accessories • P569-Series High Speed HDMI Cables • N201-Series Cat6 Gigabit Snagless Patch Cables •... -
Page 4: Product Overview
Product Overview Front: Back: Sides:... - Page 5 Product Overview Bottom: Item Description Audio In/Out Jack USB 3.1 Gen1 Type-A Port, BC 1.2-Compliant USB Type-C Port with PD 3.0 Charging LED Indicator - Illuminates blue when powered, green when active Power On/Off Button DC Power In Jack RJ45 Ethernet Port USB 3.1 Gen1 Type-A Ports HDMI Ports Mounting Screw Holes...
-
Page 6: Installation
Once the drivers are successfully installed, restart the host computer. Notes: • The U442-DOCK20-B is able to recognize USB peripherals such as a mouse, keyboard or flash drive, without DisplayLink drivers installed on the host PC or laptop running Windows. - Page 7 Installation 1. Connect the host computer or laptop to the U442-DOCK20-B using the included USB-C to C cable. Use the USB-A to C adapter if necessary. Note: Your source device will only charge when using a USB-C to C cable.
-
Page 8: Specifications
Specifications Input USB-C Output (x2) HDMI RJ45 (x3) USB 3.1 Gen 1 Type-A 3.5 mm Video (HDMI) Single: 2560 x 1440 @ 50 Hz Dual: 1920 x 1080 @ 60 Hz Audio (3.5 mm) 2.1 Channel Surround Sound Ethernet (RJ45) 10/100/1000 Mbps Power Supply Input: 100-240V @ 50/60 Hz, 2A... -
Page 9: Warranty And Product Registration
Tripp Lite warrants its products to be free from defects in materials and workmanship for a period of three (3) years from the date of initial purchase. Tripp Lite’s obligation under this warranty is limited to repairing or replacing (at its sole option) any such defective products. - Page 10 • Consult the dealer or an experienced radio/TV technician for help. Any changes or modifications to this equipment not expressly approved by Tripp Lite could void the user’s authority to operate this equipment. WEEE Compliance Information for Tripp Lite Customers and Recyclers...
- Page 11 Tripp Lite has a policy of continuous improvement. Specifications are subject to change without notice. Photos and illustrations may differ slightly from actual...
- Page 12 1111 W. 35th Street, Chicago, IL 60609 USA • tripplite.com/support 20-06-033 93-3BAC_RevC...
