EN6T4722AF
EN
Washing Machine
User Manual

Advertisement

Table of Contents
loading

Related Manuals for Electrolux EN6T4722AF

Summary of Contents for Electrolux EN6T4722AF

  • Page 1 EN6T4722AF Washing Machine User Manual...

  • Page 2: Table Of Contents

    16. QUICK GUIDE....................33 WE’RE THINKING OF YOU Thank you for purchasing an Electrolux appliance. You’ve chosen a product that brings with it decades of professional experience and innovation. Ingenious and stylish, it has been designed with you in mind. So whenever you use it, you can be safe in the knowledge that you’ll get great results every time.

  • Page 3: Safety Information

    ENGLISH SAFETY INFORMATION Before the installation and use of the appliance, carefully read the supplied instructions. The manufacturer is not responsible for any injuries or damage that are the result of incorrect installation or usage. Always keep the instructions in a safe and accessible location for future reference.

  • Page 4: Safety Instructions

    This appliance is intended to be used in household • and similar applications such as: staff kitchen areas in shops, offices and other – working environments; by clients in hotels, motels, bed & breakfast and – other residential type environments;...
  • Page 5 ENGLISH the drum to prevent an internal • Connect the mains plug to the mains damage. socket only at the end of the • Always take care when moving the installation. Make sure that there is appliance as it is heavy. Always use access to the mains plug after the safety gloves and enclosed footwear.

  • Page 6: Product Description

    Prewash such fabrics by hand before are only available to professional loading them into the washing repairers, and that not all spare parts machine. are relevant for all models.
  • Page 7 ENGLISH 3.2 Appliance overview 9 10 Control panel Drain hose Mains cable Lid handle Transit bolts Drain pump filter Hose support Feet for levelling the appliance Rating plate Inlet hose Information for register product. The rating plate reports the model name The info label reports the model name (A), (A) , product number (B), electrical product number (B ) and serial number (C).

  • Page 8: Technical Data

    4. TECHNICAL DATA Dimension Width/ Height/ Total depth 39,7 cm /90,8 cm /59,9 cm Electrical connection Voltage 230 V Overall power 2200 W Fuse 10 A Frequency 50 Hz Level of protection against ingress of solid particles IPX4 and moisture ensured by the protective cover, except...
  • Page 9 ENGLISH We recommend that you keep the packaging and the transit bolts for any transport of the appliance. Adjust the appliance correctly to prevent vibration, noise and movement of the appliance when it operates. WARNING! Do not put cardboard, wood or equivalent materials below the appliance feet to adjust the level.
  • Page 10 5.3 Water drainage min.600 mm max.1000 mm The drain hose should stay at a height of no less than 600 mm and not more than 1000 mm. You can extend the drain hose to maximum 4000 mm. Contact the authorised service centre for the other drain hose and the extension.

  • Page 11: Control Panel

    ENGLISH 6. CONTROL PANEL 6.1 Control panel description Programme dial Centrif. reduction options touch button Display • No Spin option Inicio Diferido touch button • Rinse Hold option Time Manager touch button • Silencio option Inicio/Pausa touch button On/Off push button Soft Plus touch button Temp.

  • Page 12: Dial And Buttons

    Delay start indicator. The digital indicator can show: • Programme duration (e. g. • Delay time (e. g. • Cycle end ( • Warning code (e.g. Time Manager bars level indicator. Drum clean indicator. Child safety lock indicator. Add garments indicator. Illuminates at the beginning of the Wash phase, while the user can still pause the appli‐...
  • Page 13 ENGLISH creasing. The washing programme Use this option for people with allergies ends with water in the drum. to detergent residues and with sensitive The lid stays locked and the drum skin. turns regularly to reduce creasing. This option increases the You must drain the water to unlock programme duration.

  • Page 14: Programmes

    (max. half load ■ ■ ■ recommended). ■ ■...
  • Page 15 ENGLISH Programme Reference Maxi‐ Programme description Default tem‐ spin (Type of load and level of soiling) perature speed load Temperature Spin range speed range [rpm ] Rápido 800 rpm 2 kg Synthetic and mixed fabric items. Lightly 30 °C (800 - 400) soiled items and items to freshen up.
  • Page 16 Programme Reference Maxi‐ Programme description Default tem‐ spin (Type of load and level of soiling) perature speed load Temperature Spin range speed range [rpm ] 1200 rpm Outdoor Do not use fabric softener and (1200 - 30 °C make sure that there is no soften‐...
  • Page 17 ENGLISH Programme Reference Maxi‐ Programme description Default tem‐ spin (Type of load and level of soiling) perature speed load Temperature Spin range speed range [rpm ] Denim 800 rpm 3 kg Special programme for Denim clothing 30 °C (1200 - with delicate washing phase to minimize 40 °C - Cold 400)
  • Page 18 Programme ■ ■ ■ Seda ■ ■ ■ ■ Lana/Lãs Sport ■ ■ ■ ■ ■ ■ ■ ■ ■ ■ ■ Outdoor Denim ■ ■ ■ ■ ■ ■ ■ Suitable detergents for washing programmes Universal Liquid Liquid for...

  • Page 19: Settings

    ENGLISH 8.2 Woolmark Apparel Care - Blue The wool wash cycle of this machine has been approved by The Woolmark Compa‐ ny for the washing of wool garments label‐ led as «hand wash» provided that the gar‐ ments are washed according to the instruc‐ tions issued by the manufacturer of this washing machine.

  • Page 20: Daily Use

    11. DAILY USE The drum opens automatically. WARNING! 3. Put the laundry in the drum, one item Refer to Safety chapters. at a time. 4. Shake the items before you put them 11.1 Activating the appliance in the appliance.
  • Page 21 ENGLISH Detergent compartment for prewash phase. The marks MAX are the maxi‐ mum levels of the quantity of detergent (powder or liquid). Detergent compartment for washing phase. The marks MAX are the maxi‐ mum levels of the quantity of detergent (powder or liquid). Compartment for liquid addi‐...
  • Page 22 3. If desired, set one or more options by 3. Touch the Inicio/Pausa button touching the related buttons. The again to start the programme related indicators illuminate on the immediately. display and the given information changes accordingly. Changing the delay start after...
  • Page 23 ENGLISH 2. Change the options. The given the Inicio/Pausa button. The information in the display changes programme or the delay start accordingly. continues. 3. Touch the button Inicio/Pausa 11.12 End of the programme again. The washing programme continues. When the programme has finished, the appliance stops automatically.

  • Page 24: Hints And Tips

    Press the button On/Off to activate 2. Press the Inicio/Pausa button: the appliance again. • If you have set Rinse Hold • 5 minutes after the end of the washing appliance drains the water and programme spins. Press the On/Off button to activate •...
  • Page 25 ENGLISH • Use less detergent if: – you are washing a small load, – the laundry is lightly soiled, – there is large amounts of foam during washing. • When using detergent tabs or pods, always put them inside the drum, not in the detergent dispenser.

  • Page 26: Care And Cleaning

    To know the water hardness in your Use the correct quantity of the water area, contact your local water authority. softener. Obey the instructions that you find on the packaging of the product. 13. CARE AND CLEANING to 'Cleaning the drum', 'Cleaning the...
  • Page 27 ENGLISH clean the inner part of the appliance, run 1. Remove all laundry from the drum. a maintenance wash regularly (at least 2. Run a Algod. programme with the once a month). highest temperature. 3. Add a small quantity of powder Refer to "Cleaning the drum"...
  • Page 28 13.9 Cleaning the inlet hose and the valve filter 13.10 Cleaning the drain filter WARNING! • Disconnect the mains Regularly check the drain pump filter and plug from the mains make sure that it is clean. socket. Clean the drain pump if: •...

  • Page 29: Troubleshooting

    ENGLISH 13.11 Emergency drain 1. Disconnect the mains plug from the mains socket. If the appliance cannot drain the water, 2. Close the water tap. carry out the same procedure, described 3. Put the two ends of the inlet hose in in 'Cleaning the drain pump' paragraph.
  • Page 30 • Make sure that the sink spigot is not clogged. • Make sure that the drain hose has no kinks or bends. The appliance does • Make sure that the drain filter is not clogged. Clean the fil‐ not drain the water.
  • Page 31 ENGLISH Problem Possible solution • Set the spin programme. The spin phase does • Make sure that the drain filter is not clogged. Clean the fil‐ not operate or the ter, if necessary. Refer to "Care and cleaning". washing cycle lasts •...

  • Page 32: Consumption Values

    15. CONSUMPTION VALUES 15.1 Introduction See the web link www.theenergylabel.eu for detailed information about Energy Label. The QR code on the energy label supplied with the appliance provides a web link to the information related to the performance of the appliance in the EU EPREL database.

  • Page 33: Quick Guide

    ENGLISH Power consumption in different modes Off (W) Stand-by (W) Delay start (W) 0.48 0.48 4.00 Time to Off/Standby mode is 15 minutes maximum. 15.4 Common programmes These values are indicative only. Programme Litres h:mm °C Algod. 2.60 3:25 1200 90°C Algod.
  • Page 34 Connect the mains plug to the mains 2. Set the desired options (1) by means socket. of the corresponding touch buttons. To start the programme, touch the Open the water tap. Inicio/Pausa (2) button. Load the laundry. 3. The appliance starts.
  • Page 35 ENGLISH Programmes Load Product description Single synthetic blanket, padded clothes, Anorak/Anoraque 3 kg duvets, down jackets. Special programme for silk and mixed syn‐ 1 kg thetic items. Seda Machine washable wool, hand washable 1 kg wool and delicates. Lana/Lãs Sport 3 kg Sportswear.
  • Page 36 www.electrolux.com/shop...
