- Page 1 MLU270-F Series Intelligent Processing Card User Manual V0.9 Cambricon Technologies, MLU270-F Series Intelligent Processing Card User Manual...
- Page 2 Revision History Document Name MLU270-F Series Intelligent Processing Card User Manual Revision V0.9 Created Date 2019.07.03 Revision History Date Version Notes 2019.07.03 V0.9 First Release : service@cambricon.com Technical supports contact www.cambricon.com Cambricon Technologies, MLU270-F Series Intelligent Processing Card User Manual...
-
Page 3: Table Of Contents
2.4 Mechanical Specifications ....................7 2.5 Package Size and Weight ....................8 2.6 Thermal Specifications ......................8 2.7 Power Supplies Specifications .................... 9 3. Cambricon NeuWare Development Environment ..............11 4. Compliance ..........................12 Cambricon Technologies, MLU270-F Series Intelligent Processing Card User Manual... -
Page 4: Product Brief
AI PC/server so as to provide a huge extension of calculation power of AI inferences. MLU270-F series has a moderate TDP of 150W and it can provide a calculation power as high as 4 times of the previous generation. It can be widely used in applications such as... -
Page 5: Product Specifications
MLU270-F series will decrease the load of CPU and the occupation for PCIe bandwidth, so as to increase the performances even more. Calculating flexibility and programmability SIYUAN 270 ASIC can provide supports to many kinds of Neural Networks. Cambricon NeuWare software stack can easily deploy inference environment.BANG Lang.CHENG... - Page 6 0x04,and restore to pre-frequency when write 0x01 PCIE Vendor 0xA0 [15:0] Vendor ID：0xCABC and Device ID [31:16] Device ID：0x0270 PCIE Sub-Vendor 0xA1 [15:0] Sub-Vendor ID：0xCABC ID and Sub-System [31:16] Sub-System ID：for example 0x0018 Cambricon Technologies, MLU270-F Series Intelligent Processing Card User Manual...
-
Page 7: Operating Environment
2018.11 0xF5 Display Device ID ， e.g 0x20023 means device id is Device ID 20023 Operating Environment Table 5 MLU270-F Series Intelligent Processing Card Working Environment 0℃～45°C Operating Temperature Storage Temperature -40℃～75℃ 5%—95% Relative Humidity Operating Humidity S torage Humidity 5%—95% Relative Humidity... -
Page 8: Package Size And Weight
0-85℃ Recommended Operating Slowdown Tj 87℃ Slowdown Rate Shutdown Tj 95℃ 2.6.2 MLU270-F Series Airflow Directions Requirement MLU270-F Series use a blower to cool the card，the airflow direction is shown below： Cambricon Technologies, MLU270-F Series Intelligent Processing Card User Manual... -
Page 9: Power Supplies Specifications
Figure.3 MLU270-F Series Airflow direction Power Supplies Specifications ： MLU270-F Series Intelligent Processing Card provides a 8-Pin Power Connector as below Figure.4 8-Pin Power supply Connector Cambricon Technologies, MLU270-F Series Intelligent Processing Card User Manual... - Page 10 PCIe 8-Pin Socket 2 Colour connector Yellow Yellow Yellow Yellow Black Black Black Black Figure.5 Adapter Cable Note: The first pin (Pin No.1) of every connector/socket should have obviously distinguishable mark at the side. Cambricon Technologies, MLU270-F Series Intelligent Processing Card User Manual...
-
Page 11: Cambricon Neuware Development Environment
TensorFlow, Caffe, PyTorch, MXNet and so on.With above mentioned Programming Frameworks, users can easily and conveniently develop and deploy their Deep Learning Applications on Cambricon MLU270-F Series Intelligent Processing Cards.At the same time, NeuWare provides complete runtime system and driver software to speed up the system integration procedure. -
Page 12: Compliance
Address: 11/F, Block D, Zhizhen Tower, No.7 Zhichun Road, Haidian District, Beijing, China Compliance The MLU270-F Series is compliant with the regulations listed in this section. Compliance marks, including the FCC ID numbers, can be found on the labels of each devices. - Page 13 Connect the equipment into an outlet on a circuit different from that to which the receiver is connected Consult the dealer or an experienced radio/TV technician for help Underwriters Laboratories (UL) UL Listed Product Logo for MLU270-F Series Intelligent Processing Cards，model name MLU270-F. Cambricon Technologies, MLU270-F Series Intelligent Processing Card User Manual...
