- Page 1 OPERATING MANUAL CORECUT30i YEAR Warranty (POWERSOURCE) OPERATING MANUAL PLEASE READ AND UNDERSTAND THIS MANUAL CAREFULLY BEFORE THE INSTALLATION AND OPERATION OF THIS EQUIPMENT...
- Page 2 PAGE CONTENTS Warranty Safety - Cautions Air Plasma Cutting Technology Technical Data, Product Information Machine Layout and Descriptions 9-10 Set Up and Operating Procedure Plasma Cutting 11-13 Procedure & Techniques Torch spare parts Machine Warranty+ Notes 15-18...
-
Page 3: California Proposition
Thank you for your purchase of your Corecut 30i Plasma Cutting Machine. We are proud of our range of welding and Cutting equipment that has a proven track record of innovation, performance and reliability. Our product range represents the latest developments in Inverter technology put together by our professional team of highly skilled engineers. - Page 5 Arc rays: harmful to people's eyes and skin. Arc rays from the plasma cutting process produce in tense visible and invisible ultraviolet and infrared rays that can burn eyes and skin. Protect your eyes with welding masks or goggles fitted with filtered lenses, and protect your body with appropriate safety garments.
-
Page 7: Air Plasma Cutting Technology
AIR PLASMA CUTTING TECHNOLOGY Plasma cutters work by passing an electric arc through a gas that is passing through a constricted opening. The gas can be air, nitrogen, argon, oxygen. etc. The electric arc elevates the temperature of the gas to the point that it enters a 4th state of matter. We all are familiar with the first three: i.e., Solid, liquid, and gas. - Page 8 : Steels, Stainless, Cast Iron, Bronze, Aluminum 110/230V Single Phase 30 Amp Plasma utter Lightweight and Portable Small, Features This model’s main functional features are Double plastic panel Delay Panel gauge display Built-in air filter o connector for Torch Low frequency arc fully CSA/CAN Compliant •...
- Page 9 connection Air hose P.C.B Regulator drain chamber Air solonoid...
-
Page 10: Operating Procedure
Operating Procedure: Connect the Plasma Torch to the machine. Insert the torch connection into the torch connection receptacle at the front of the machine and screw up hand tight. If direct connect torch, the torch is already matched to the machine. Caution: Be careful not to bend the pins located inside the torch connector. - Page 11 Operating procedure using the Stand Off Guide mounted to the Plasma torch. The feet of the standoff guide are placed on the cutting surface. This maintains an optimal 5/64" standoff distance between the plasma cutting tip and the work, this is especially suitable if your hands are unsteady, or if you wish to use a straight edge guide or pattern guide.
- Page 12 Operating Procedure and Techniques • Amperage Standard rule of thumb is the thicker the material the more amperage required. On thick material, set the machine to full output and vary your travel speed. On thinner material, you need to turn down the amperage and change to a lower-amperage tip to maintain a narrow kerf.
- Page 13 Operating Procedure & Techniques for PLASMA Cutting continued... • Air pressure and volume Air pressure, flow rate and air quality are critical to quality plasma cutting and consumable life span. The required air pressure and volume can vary from model to model and the manufacturer will provide the specs. The Viper cut 30 air pressure is adjustable but requires a minimum of 6CFM and 65-75psi.
- Page 14 • Piercing Hold the torch at an angle to the work piece, When sparks are exiting from the bottom of When the pierce is complete, proceed with pull the trigger to start the arc and slowly the work piece, the arc has pierced through the cutting.
-
Page 15: Warranty Period
WARRANTY PERIOD We offer the following 'Warranty Periods' from 'date of purchase': 1 Year (Clause 3) CORECUT30i Inverter PLASMA (Power Source Only) 3 Months (Clause 1) TORCHES -GMAW, GTAW, MMAW, PLASMA, EARTH LEADS, (Clause 3) This only Covers Manufacturers faults on all Machines for the first 12 months after date of purchase. -
Page 16: Making A Claim
WARRANTY/ RETURNS/ EXCHANGES We understand that sometimes a product may need to be returned. If you have purchased from Core One or from an Authorised Dealer Network, to assist you in following the correct procedure enclosed is the returns policy. Our Returns Policy includes the rights you have under the American consumer Law and other relevant laws . -
Page 17: Warranty Exclusions
WARRANTY EXCLUSIONS This Warranty covers Material and Faulty Workmanship defects only. This Warranty does not cover damage caused by: Normal wear and tear due to usage Misuse or abusive use of the JASIC instructions supplied with the product. Failure to clean or improper cleaning of the product Failure to maintain the equipment such as regular services etc Incorrect voltage or non-authorised electrical connections Improper installation... - Page 19 COREONE Welding Engineered Welding Solutions Cel: + 1 330-546-5917 e-mail: info@coreonewelding.com Cc:::,r-c:zCut30i...
