Go-Video DDV2120 Specifications page 2

DDV2120
DDV2120TechnicalSpecifications
Unit Weight/Dimensions: 11.1 lbs. (5 kg)
21"x 4"x12-3/4" (534x102x324 mm.)
Boxed with accessories: 14.25 lbs. (6.5 kg)
25-1/4"w x 8"h x 17-1/2"d (641x203x445mm.)
Units can be stacked 10 high.
Container quantity 900 units.
Video System: VHS system
Television System: NTSC-type color signal EIA
standard (525 lines, 60 fields)
Audio Track: Normal: 1 track; Hi-Fi: 2 track
Tape Width: 12.7mm, 1/2 inch
Tape Speed: SP: 33.35mm/s SLP: 11.12mm/s
Play/Record Time: T-120 tape: SP 2 hrs,
SLP 6 hrs
FF/Rew Time: T-120 tape: <110 seconds
Power Requirement: 120V AC, 60Hz,
32 watts max.
Agency Approvals: UL, FCC, CSA
RF Modulation: Channel 3 or 4
Clock Backup Time: 1 Minute
Environment: 41-104°F (5-40°C);
10-75% humidity
Frequency Response:
20 Hz-20kHz (Hi-Fi);
S/N Ratio: 70dB (Hi-Fi)
Wow & Flutter:<0.005% (Hi-Fi)
Heads:
Video: DA 4 rotary heads, both decks
Audio: 2 rotary heads (Hi-Fi);
1 stationary head (Linear)
Control: 1 stationary head
Erase: 1 full track, 1 audio track
Video: Input: RCA type 75 ohms unbalanced,
1 V P-P
Output: RCA type 75 ohms unbalanced, 1 V P-P
Horiz Res: Monochrome, more than 230 lines (SP)
Signal to noise ratio: Better than 43 db
Audio: Input: AUDIO IN (RCA) -8dbu,
47K ohms; Output: AUDIO OUT (RCA) -8dbu,1.5K
ohm unbalanced
TV Tuner: 181 channel frequency synthesized.
VHF input Ch 2-13. UHF input Ch 14-69. Cable
Channel 1-125.
7835 East McClain Drive
Scottsdale, Arizona USA 85260-1732
TEL 480.998.3400 FAX 480.998.8312
www.sensoryscience.com
DDV2120Features
4-Head Hi-Fi VCR x 4 Head Hi-Fi VCR
One Touch Commercial Free Copy For
Ad-Free Tapes
Commercial Advance® /
Movie Advance® Lets You Skip Ads
and Trailers (Deck 1)
Flying Erase Heads (Deck 2)
For Seamless Edits Like the Pros
VCR Plus+ C 3 (Cable Box Control) For
Easy Timer Recordings from TV,
Cable or Satellite
Multi-Media Go-Port® For
PC Interface and Control
8-Scene-At-a-Time Automatic Assembly
Editor, Titler, Audio and Video Dubbing
(with Microphone Input) For
Custom Home Movies
S-VHS Quasi Playback
S-Video Input
Front and Rear A/V Inputs For Ultimate
Flexibility in Hooking Up Other
Components
Multi-Brand Jog Shuttle Remote
With Glow Keys
Second Zone A/V Output
More Features
EZ Copy™ (One Touch Copying)
Just-Fit (Complete Program Record™)
Automatically Adjusts Tape Speed
During Recording So You Don't Miss
the End of a TV Show
One-Touch Recording
Sequential Recording (12-hour) from
Deck to Deck
Speed Matching
Copy Audio Insert
Skip Edit During Copy
User Assignable Line Input Labels
Auto Channel Search / Auto Clock Set
For Easy Setup
©2001 Sensory Science Corporation. Dual-Deck, EZ Copy
trademark of Macrovision Corporation. Commercial Advance and Movie Advance are registered trademarks of SRT, Inc. VCR Plus+, C
Gemstar Development Corporation. All other brand and product names are trademarks or registered trademarks of their respective companies. All rights reserved. Copyright
Warning: Sensory Science's Dual-Deck VCR is not made or sold for unauthorized recording of copyrighted works, including, without limitation, unauthorized recordings from pre-
recorded copyrighted movies, and it will not copy Macrovision-encrypted VHS tapes. All specifications subject to change.
Convenient front panel connections allow easy hookup of any
camcorder. On the back, RF in and out connections allow the
simplest hookup (mono sound) to any television, while the line in
and line out composite connections allow stereo hookup (left and
right channels) to other components in your entertainment
center. Cable box control allows you to connect the mouse
(included), S-Video input allows higher resolution connection,
Multi-Media Go-Port™ allows connection to your PC.
Remote Eject
Child Lock of Front Panel for
Toddler-Proofing
High Speed Rewind
Mute & Volume Control
TV View (One-Button A/V Switching)
Auto Daylight Savings Time
On-Screen Menus in English and French
On-Screen 99-Year Calendar /12 Hr. Clock
Real-Time Tape Counter
Tape Remaining Counter
Brightness Control for Front Panel Display
Record Speeds - SP, SLP/EP
Playback Speeds - SP, LP, SLP/EP
181 Channel Cable Ready Tuner with
One Year/16 Event Timer
Timer Conflict Advisory
Date/Time Stamp
Playback Modes - Still, Cue 1, Cue 2,
Review 1, Review 2, 6-Step Slow
Motion, Play x2
Sequential/Loop Playback
Auto Play / Auto Rewind
Repeat (30-Second Review)
Freeze Frame
Frame Advance
Digital Tracking (Auto & Manual)
Sync Editing
Syncro-Start with Pre-Roll
VISS Index Scan
Auto Index
Auto Power On/Off, Auto Eject
Blank Search
Direct Time Search
Return to 0:00:00
Skip Search (1-5 minutes)
Accessories Included
Jog/Shuttle TV Remote with Glow Keys
Cable Box Control Mouse
36" RF Cable
Batteries
