Summary of Contents for Acer Z530S
- Page 1 User’s Manual...
- Page 2 This revision: November 2015 Sign up for an Acer ID and enjoy great benefits Open the Acer Portal app from the Home screen to sign up for an Acer ID or sign in if you already have an Acer ID.
-
Page 3: Table Of Contents
Table of contents - 3 A B L E O F C O N T E N T S Setting up Messaging Unpacking your smartphone....5 Creating a new message ....... 30 Getting to know your smartphone.... 5 Replying to a message ......31 Multimedia messages ...... - Page 4 4 - Table of contents Managing your SIM cards Taking care of your smartphone..... 68 Specifications ......... 70 SIM Management........59 Performance ..........70 Appendix Display ............70 FAQ and troubleshooting ....... 62 Multimedia ..........70 Other sources of help......64 USB connector..........
-
Page 5: Setting Up
Your new smartphone comes packed in a protective box. Carefully unpack the box and remove the contents. If any of the following items is missing or damaged, contact your dealer immediately: • Your new Acer smartphone • USB cable • AC adapter •... -
Page 6: Charging The Battery
6 - Setting up Item Description 3.5 mm headphone jack Connects to stereo headphones. LED indicator Indicates the phone’s charge status and if there are any messages needing your attention. Power button Press to turn the screen on/off or enter sleep mode;... -
Page 7: Installing A Sim Card
Setting up - 7 Connect the AC adapter cord to the micro USB connector on your smartphone. Installing a SIM card To take full advantage of your smartphone’s telephony capabilities, you must install a SIM card. Your new smartphone has multiple SIM card holders; install any combination of SIM cards. - Page 8 8 - Setting up 2. Carefully unclip and remove the cover as illustrated. 3. Insert the SIM cards as shown. Nano SIM 2 (optional) Nano SIM 1 Note: Your smartphone may be equipped with one or two SIM slots depending on model.
-
Page 9: Sim Card Lock
Setting up - 9 4. Align the gold-colored connectors on the battery with the connectors at the top of the battery compartment and insert the battery. 5. Replace the cover by aligning the tabs on the cover into the slots on the phone. -
Page 10: Using Your Smartphone
10 - Using your smartphone S I N G Y O U R S M A R T P H O N E Turning on for the first time To turn on your smartphone for the first time, press and hold the power button until the screen turns on. -
Page 11: Locking Your Smartphone
Using your smartphone - 11 Locking your smartphone If you will not use your smartphone for a while, briefly press the power button to lock access. This saves battery power and ensures your smartphone does not unintentionally use any services. Your smartphone will lock automatically if it is not used for one minute (depending on your settings). -
Page 12: Using The Touchscreen
12 - Using your smartphone Back Tap this button to go to the previous page, or to go up one level in a menu. Home Tap this button to go directly to the Home screen. Tap and hold this button, then drag your finger to the Google balloon that appears to open Google Now (if available) or Search. -
Page 13: Onscreen Keyboards
Using your smartphone - 13 Onscreen keyboards Note The keyboard layout varies slightly, depending on the application and information that is required. Google keyboard This is a standard onscreen QWERTY keyboard that allows you to enter text. Tap and hold a key with numbers at the top to select alternative characters, such as letters with accents. -
Page 14: Predictive Text
14 - Using your smartphone Changing the text input method To change the input method, in the Application menu tap Settings > Language & input > Current keyboard and then select your preferred input method. Predictive text Android keyboard provides predictive text input for the browser. As you tap the letters of a word, a selection of words are displayed above the keyboard that continue the sequence of letters tapped, or are a close match allowing for errors. -
Page 15: Search
Using your smartphone - 15 At the bottom of the screen is the application dock which displays default apps. Tap an icon to open the app. Tap the Application menu icon in the middle of the application dock to view your apps. To change apps, see Changing application dock icons on page Search... -
Page 16: Personalizing The Home Screen
16 - Using your smartphone To add a new page to the extended Home screen, tap and drag an icon or widget to the right edge of the last page on the right, and drop it onto the new page that is automatically created. Personalizing the Home screen You may personalize your Home screen by adding or removing app shortcuts or widgets, and by changing the wallpaper. - Page 17 Using your smartphone - 17 Widgets are small apps that display constantly-updated information or quick shortcuts to apps or special functions. To move an app or widget to the Home screen, tap and hold an item until it is selected. The Home screen will open. Drag the item to any free area on the screen.
- Page 18 18 - Using your smartphone This will create an Unnamed Folder. Tap the folder icon and then tap the name of the folder to rename it. To delete an app shortcut from a folder, tap on the folder icon to display the apps inside and then tap and hold the app icon that you want to remove.
-
Page 19: The Application (Apps) Menu
Using your smartphone - 19 The Application (Apps) menu To access the Application menu, on the Home screen tap in the center of the dock. Apps are displayed in alphabetical order. Swipe the page to the left or right to see more apps. Notification and status area Notification and status icons are shown at the top of the screen. -
Page 20: Multitasking
20 - Using your smartphone Drag the Notification area down the screen to view more information about new events and the Quick Settings. You can drag the Notification area upwards to hide the Quick Settings. Multitasking You can have multiple apps open at the same time. -
Page 21: Managing Contacts
Managing contacts - 21 A N A G I N G C O N T A C T S Managing your contacts Your smartphone features an address book that allows you to save contacts to either the internal memory or onto your SIM card. Tap the Contacts app from the Application menu or tap CONTACTS from the Dialer to view your contacts. - Page 22 22 - Managing contacts To create a contact, first choose where you want to store the contact’s information. You will then be asked to enter the contact’s information, such as name, address, and phone number. You may scroll down the page and tap ADD ANOTHER FIELD to add things such as: •...
-
Page 23: Making Calls
Making calls - 23 A K I N G C A L L S This chapter shows you how to make phone calls, and the various options available to you during your call. Before making a call Check that the smartphone is connected to the network before you make a call. -
Page 24: Making A Call
24 - Making calls Making a call Note If you have multiple SIMs inserted in the smartphone, you will be asked which SIM to use before the call is connected. To select a SIM, just tap the name of the carrier. 1. -
Page 25: Making A Call To One Of Your Contacts
Making calls - 25 3. On your smartphone’s lock screen. Tap the notification and slide to the left or right to display the missed call details. Making a call to one of your contacts Calling a contact from the Contacts tab 1. -
Page 26: Answering Or Declining A Call
26 - Making calls screen. Once placed, you will be able to select a contact to associate with that particular widget on your Home screen. Answering or declining a call When you have an incoming call and the screen is locked, the number will be shown on the screen. - Page 27 Making calls - 27 Ending a call To end a call, tap from the voice call screen. Voice call options Icon Description Speakerphone. Mute a call. Access the keypad while a call is in progress. Place the call on hold. Add a second call.
-
Page 28: Internet Calling
28 - Internet calling N T E R N E T C A L L I N G You can place and receive internet calls over a wireless network. Adding an internet calling account From the Home screen, tap Phone. If open, tap the Back button to close the onscreen number pad. -
Page 29: Calling A Contact's Internet Calling Address
Internet calling - 29 Calling a contact’s internet calling address You must add an internet calling address to a contact to be able to place an internet call to them. To make an internet call, from the Application menu tap Contacts. Tap on the contact to open their profile, and then tap on their internet calling address to place the call. -
Page 30: Messaging
30 - Messaging E S S A G I N G This chapter shows you how to set up and use the Messaging functions of your smartphone. All SMS and MMS messages are accessed via Messaging. Messaging automatically arranges received and sent messages into threads. -
Page 31: Replying To A Message
Messaging - 31 3. Enter your message in the text box labeled Type message. Note Text messages may be up to 160 characters long. If your message is longer than 160 characters, it will be sent as multiple linked messages. Most phones will automatically join the linked messages to present the recipient with a single long message, however, some older phones do not have this ability. -
Page 32: Multimedia Messages
32 - Messaging Multimedia messages Multimedia messages are similar to text messages but also allow you to attach files such as pictures, audio or video clips. Each message can be up to 300 KB in size. Note You need to set up an MMS profile before you can send MMS messages. Normally, your smartphone will set up the profile for you based on information retrieved from your provider. - Page 33 Messaging - 33 4. To reply to the message, enter your text in the text box labeled Type message and tap the Send icon. Simple text replies will be sent as SMS messages. If you wish to attach a file, .
-
Page 34: Going Online
34 - Going online O I N G O N L I N E Browsing the internet In order to browse the internet with your smartphone, you must be connected to a data or wireless network. Using the browser To start browsing tap Browser from the application dock. To open a new website, tap the address box at the top of the page. -
Page 35: Setting Up Email
Going online - 35 Setting up Email Your smartphone enables you to access your email. Most popular ISPs can be set up in two steps. From the Application menu tap Email to start setting up your email account. If necessary, enter your email address and tap MANUAL SETUP to enter the parameters manually. -
Page 36: Voice Search
36 - Going online Composing an email 1. Make sure your smartphone is connected to a data or Wi-Fi connection. 2. From the Application menu tap Gmail. 3. Tap 4. Enter the recipient's email address, the subject and message. 5. When you are finished composing your message, tap Voice search With voice... -
Page 37: Play Store
Going online - 37 Play Store Important see FAQ and troubleshooting For connection issues with Play Store, on page 62 Tap Play Store from the Application menu to open Google Play. Here you can obtain a variety of add-on programs and apps to enhance the functionality of your smartphone. - Page 38 38 - Going online You may keep track of the download progress from both the app’s page and the notification area. Important Some apps may require payment before you can download them. You will need to have a Google Wallet account in order to pay for these apps, or a credit card number associated with your Google account.
-
Page 39: Google Hangouts
Going online - 39 Google Hangouts Tap Hangouts from the Application menu to open Google Hangouts. Here you can see a list of your contacts connected to Google Hangouts services. Tap on a contact to open a chat session. After you have connected, you can open a video chat session. -
Page 40: Using The Camera
40 - Using the Camera S I N G T H E A M E R A Your smartphone features a digital camera mounted on the front and rear. This section will take you through all the steps in taking photos and videos with your smartphone. - Page 41 Using the Camera - 41 Tap the Camcorder button and the camcorder immediately begins filming. While filming, you are unable to access camera/camcorder settings; however, you can still take pictures with the Shutter button. Flash Time elapsed Zoom Last picture / video taken Stop recording Pause...
-
Page 42: Mode Selector
42 - Using the Camera Mode Selector Tap the Mode selector icon to open the list of modes you can choose from. Tap the icons along the top to select different items. Camera Capture mode: Select a capture mode. Normal Panorama Beautification Bright Magic... - Page 43 Using the Camera - 43 Camcorder The camcorder’s scene mode changes depending on the record mode setting (see table below). Record mode: Normal Time lapse Scene mode: Night Effect: None Mono Sepia Negative Aqua White balance Compensate for different lighting environments. Auto Day light Cloudy...
-
Page 44: Settings Menus
44 - Using the Camera Settings menus Note Some of the following settings are not available for the front camera. Tap the Settings icon to open the Settings menu. Photo You may adjust the following: • Set the Resolution and aspect ratio. •... -
Page 45: Taking A Photo
Using the Camera - 45 Other You may adjust the following: • Turn GPS Location info on or off: Stores GPS information in the image information. • Turn Voice Control on or off. • Choose to Reset to default camera settings. Taking a photo 1. -
Page 46: Geotagging
46 - Using the Camera Geotagging Geotagging allows you to store the location where a photo or video was taken right in the photo or video itself. For the geotag to display, pictures must be taken with GPS Location info turned on. -
Page 47: Advanced Settings
Advanced settings - 47 D V A N C E D S E T T I N G S Putting your smartphone in Airplane mode You can enable Airplane mode (also known as flight mode) to turn off cellular, Wi-Fi and Bluetooth functions and use your smartphone as a handheld device during a flight. -
Page 48: Adjusting Settings
48 - Advanced settings Adjusting settings Activating or deactivating connections Open the Application menu and tap Settings to manage your connection settings. Item Description Wi-Fi Turn the Wi-Fi function on or off. Bluetooth Turn the Bluetooth function on or off. Set a default SIM for particular functions (such as voice calling or messaging), turn the data connection on or off, set roaming... - Page 49 Advanced settings - 49 If your smartphone is in Airplane mode, the option to turn Bluetooth on will be disabled. Please refer to Putting your smartphone in Airplane mode on page 47 for instructions on turning Airplane mode on or off. Adjusting Bluetooth settings You can use Bluetooth to exchange information between your smartphone and other mobile devices.
-
Page 50: Mobile Network Settings
50 - Advanced settings Wi-Fi hotspot You can turn your smartphone into a portable Wi-Fi hotspot to share your mobile internet connection with up to 8 clients. 1. In the Application menu tap Settings > More > Tethering & portable hotspot. Turn Wi-Fi hotspot ON.Tap Wi-Fi hotspot > Set up Wi-Fi hotspot. -
Page 51: Smartphone Settings
Advanced settings - 51 Tap Auto to connect to the available network with the strongest signal. This may lead to your smartphone jumping between networks when you move around. Note Contact your service provider should you have any problems obtaining voice mail and the text message service center numbers. -
Page 52: Display
52 - Advanced settings Item Description Default notification Set your smartphone’s default notification ringtone ringtone. Enable or disable Dial pad tones, Screen Other sounds locking sounds, Touch sounds and Vibrate on touch. Adjusting the volume Adjust the volume of your smartphone using the volume button on the side of the smartphone. -
Page 53: Setting Alarms
Advanced settings - 53 Setting alarms There are two predefined alarms on your smartphone by default. Tap Clock in the Application menu, and then tap to edit alarm settings. You may: • Turn the alarm on or off. • Set the alarm time. •... -
Page 54: Synchronization
54 - Advanced settings Synchronization You can sync your calendar, email and contacts on your smartphone and never worry about losing them again. Sync in real time or adjust it as you please. In the Application menu, tap Settings. Under ACCOUNTS, appropriate account... -
Page 55: Fm Radio
Advanced settings - 55 FM radio The FM radio allows you to listen to your favorite stations while on the move. Headphones must be inserted to the 3.5 mm jack as the cable functions as an antenna. You can access the radio by tapping FM Radio from the Application menu. -
Page 56: Restoring To Factory Settings
56 - Advanced settings Restoring to factory settings You may perform a clean boot to restore your smartphone to the factory settings. Before performing a clean boot, ensure that your smartphone is not locked. Press any key or tap the screen to see if the smartphone responds. -
Page 57: Accessories And Tips
Accessories and tips - 57 C C E S S O R I E S A N D T I P S This chapter shows you how to use accessories with your smartphone, as well as provide useful tips for when you are using your smartphone. - Page 58 58 - Accessories and tips Important Some providers and countries do not allow the use of a smartphone as a modem over HSDPA. Please check with your provider before attempting to do so.
-
Page 59: Managing Your Sim Cards
Managing your SIM cards - 59 S I M A N A G I N G Y O U R C A R D S Note This chapter is for models with more than one SIM card. SIM Management Open the Application menu and tap Settings > SIM cards. - Page 60 60 - Managing your SIM cards Selecting which SIM to use when making a call If you have set Calls to Always ask, you will be asked which SIM to use each time you make call. Enter the number, then tap .
- Page 61 Managing your SIM cards - 61 Identifying calls Whenever you receive a call, the caller’s number will be shown. You will also be shown the name of the SIM receiving the call. In the call log, the name of the SIM will be shown beneath the number of the call -- whether the call was missed, answered or was an outgoing call.
-
Page 62: 62 - Appendix
62 - Appendix P P E N D I X FAQ and troubleshooting This section lists frequently asked questions that may arise during the use of your smartphone, and gives easy answers and solutions to these questions. Aspect Question Suggestions If the headset is plugged into the device, the speaker is automatically shut off. - Page 63 Appendix - 63 Aspect Question Suggestions 1. First check that you have a Wi-Fi or data connection and then try again. Some Wi-Fi "hotspots" require you to log in before accessing the internet. 2. If you still cannot connect, try Why can’t I Google Play adjusting your date/time settings.
-
Page 64: Other Sources Of Help
Other sources of help For information on Refer to ... Up-to-date information regarding www.acer.com your smartphone mobile.acer.com Service enquiries www.acer.com/support... -
Page 65: Warnings And Precautions
Warnings and precautions - 65 A R N I N G S A N D P R E C A U T I O N S • Do not use this product near water. • Do not place this product on an unstable cart, stand or table. If the product falls, it could be seriously damaged. -
Page 66: Medical Devices
66 - Warnings and precautions Operating environment Important For safety reasons, turn off all wireless or radio transmitting devices when using your smartphone device under the following conditions. These devices may include, but are not limited to: wireless LAN (WLAN), Bluetooth and/or cellular devices. Remember to follow any special regulations in force in any area, and always switch off your device when its use is prohibited or when it may cause interference or danger. -
Page 67: Vehicles
Warnings and precautions - 67 • Not carry the device near your pacemaker when the device is switched on. If you suspect interference, switch off your device, and move it. Hearing aids. Some digital wireless devices may interfere with some hearing aids. -
Page 68: Emergency Calls
68 - Warnings and precautions storage, and distribution areas; chemical plants; or where blasting operations are in progress. Areas with a potentially explosive atmospheres are often, but not always, clearly marked. They include below deck on boats, chemical transfer or storage facilities, vehicles using liquefied petroleum gas (such as propane or butane), and areas where the air contains chemicals or particles such as grain, dust or metal powders. - Page 69 Warnings and precautions - 69 3. DO be careful not to drop your smartphone or subject it to any strong impact. Do not place your smartphone in your back pocket. 4. DO NOT expose your smartphone to extreme temperatures. For example, do not leave your smartphone on the dashboard of a car on a hot day or when temperatures are below freezing point.
-
Page 70: Specifications
70 - Specifications Note Specifications may vary depending on region and configuration. Performance • 1.3 GHz octa-core processor • System memory: • ROM 32 GB + RAM 3 GB • Android operating system Display • 5.0" TFT LCD, capacitive touchscreen •... -
Page 71: Connectivity
- 71 Connectivity • Bluetooth 4.0 + EDR • IEEE 802.11b/g/n • HSPA / WCDMA 850 (B5) / 900 (B8) / 1900 (B2) / 2100 (B1) MHz • LTE 800 (B20) / 1800 (B3) / 2100 (B1) / 2600 (B7) MHz •... -
Page 72: End User License Agreement
6. Sublicense or otherwise make the Software available to third parties, except that you may, after prior written notification to Acer, transfer the Software as a whole to a third party so long as you do not retain any copies of the Software and such third party accepts the terms of this Agreement. - Page 73 Title, ownership rights and intellectual property rights in and to the Software and all copies thereof shall remain with Acer or Acer's licensors or suppliers (as applicable). You do not have or shall not gain any proprietary interest in the Software (including any modifications or copies made by or for you) or any related intellectual property rights.
- Page 74 In such event, you must: 1. Cease all use of the Software; 2. Destroy or return to Acer the original and all copies of the Software; and 3. Delete the Software from all phones on which it was resident. All disclaimers of warranties and limitation of liability set forth in this Agreement shall survive termination of this Agreement.
- Page 75 End User License Agreement - 75 Privacy policy During registration you will be asked to submit some information to Acer. Please refer to Acer’s privacy policy at www.acer.com or your local Acer website. RADEMARK INFORMATION DTS Studio Sound For DTS patents, see http://patents.dts.com. Manufactured under license from DTS Licensing Limited.
