COLOR MONITOR
SERVICE MANUAL
CHASSIS NO. : CA-129
MODEL:
**
(
)
CAUTION
BEFORE SERVICING THE UNIT,
READ THE SAFETY PRECAUTIONS IN THIS MANUAL.
MENU
SELECT
E-mail:http://www.LGEservice.com/techsup.html
T910B
Same model for Service
Website:http://biz.LGservice.com
(T910BJ-AL**E)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FLATRON T910BJ and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for LG FLATRON T910BJ

Summary of Contents for LG FLATRON T910BJ

  • Page 1 Website:http://biz.LGservice.com E-mail:http://www.LGEservice.com/techsup.html COLOR MONITOR SERVICE MANUAL CHASSIS NO. : CA-129 MODEL: T910B (T910BJ-AL**E) Same model for Service CAUTION BEFORE SERVICING THE UNIT, READ THE SAFETY PRECAUTIONS IN THIS MANUAL. MENU SELECT...

  • Page 2: Table Of Contents

    CONTENTS SPECIFICATIONS ........... 2 DESCRIPTION OF BLOCK DIAGRAM....10 SAFETY PRECAUTIONS ........3 ADJUSTMENT ............12 TIMING CHART ............4 TROUBLESHOOTING GUIDE ......14 OPERATING INSTRUCTIONS ........ 5 EXPLODED VIEW..........21 CONTROL LOCATIONS ......... 6 REPLACEMENT PARTS LIST ......23 WIRING DIAGRAM ..........

  • Page 3: Safety Precautions

    SAFETY PRECAUTIONS SAFETY-RELATED COMPONENT WARNING! X-RADIATION There are special components used in this color monitor The only potential source of X-radiation is the picture tube. which are important for safety. These parts are marked However, when the high voltage circuitry is operating on the schematic diagram and the replacement properly there is no possibility of an X-radiation problem.

  • Page 4: Timing Chart

    TIMING CHART VIDEO SYNC FACTORY PRESET MODE MODE MARK MODE 1 MODE 2 MODE 3 MODE 4 MODE 5 VESA Sync Polarity – Frequency 43.269 53.674 68.677 91.146 93.750 µs Total Period 23.112 18.631 14.561 10.971 10.666 µs Video Active Time 17.778 14.222 10.836...

  • Page 5: Operating Instructions

    OPERATING INSTRUCTIONS FRONT VIEW REAR VIEW ID Label MENU SELECT AC Power Socket See Front Control Panel Power ON/OFF Button Signal Connector Front Control Panel MENU Button SELECT Button Power (DPMS) Indicator MENU SELECT Buttons Power Button 1. Power ON/OFF Button <Shortcut Keys>...

  • Page 6: Control Locations

    CONTROL LOCATIONS VR801 : High Voltage Adjustment (27kV) VR901: B Adjustment (190V Line) - 6 -...

  • Page 7: Wiring Diagram

    WIRING DIAGRAM Anode Cap DY-Pin DY Assembly Screw P701 P901 P201- P702 (Control PCB) P402 P401 P451 - 7 -...

  • Page 8: Disassembly

    DISASSEMBLY 1. TILT/SWIVEL & BACK COVER REMOVAL 1) Set the monitor face downward. 2) Pull the latch (a), carefully remove the Tilt/Swivel by pulling it upward. 3) Remove two screws (b) . 4) Release the latch (c). 5) Slide the Back Cover away from the Front Cabinet of the monitor. Tip Spec.

  • Page 9: Block Diagram

    BLOCK DIAGRAM - 9 -...

  • Page 10: Description Of Block Diagram

    DESCRIPTION OF BLOCK DIAGRAM 1. Line Filter & Associated Circuit. 5. X-ray Protection. This is used for suppressing noise of power input line This circuit detects the rectified DC voltage comes flowing into the monitor and/or some noise generated from the FBT pin 4. If the high voltage of the FBT in this monitor flowing out through the power input reaches up to about 30kV (abnormal state), H.V control (IC802) detects.
  • Page 11 11. D/D Drive & Convert Circuit. 19. Image Rotation (Tilt) Circuit. This circuit is used for supplying B + voltage to This circuit corrects the tilt of the screen by supplying horizontal deflection output transistor (Q801). This the image rotation signal to the tilt coil which is circuit makes to add side-pincushion correcting signal attached to the CDT near the deflection.

  • Page 12: Adjustment

    ADJUSTMENT GENERAL INFORMATION 3) EEPROM → ALL CLEAR → Y(Yes) command. <Caution> Do not run this procedure unless the All adjustment are thoroughly checked and corrected EEPROM is changed. All data in EEPROM (mode when the monitor leaves the factory, but sometimes data and color data) will be erased.
  • Page 13 ± 0.05FL of 5. Input EDID Data. 11) Adjust SUB-Brightness command to 0.4 1) Display color 15,0 cross hatch pattern at Mode 4. the raster luminance. 2) EEPROM → Write EDID command and confirm 12) Display color 15,0 Full White pattern(70x70mm) at mode 4.

  • Page 14: Troubleshooting Guide

    TROUBLESHOOTING GUIDE 1. NO POWER NO POWER (POWER INDICATOR OFF) CHECK TROUBLE IN FUSE OK? FUSE (F901) (F901) CHECK TROUBLE IN D901 BRIDGE DIODE BRIDGE DIODE? (D901) CHECK C905(+) VOLTAGE 145VDC at 110V input TROUBLE IN 310VDC at 220V input IC901 CHECK TROUBLE IN...
  • Page 15 2. NO CHARACTER NO CHARACTER TROUBLE IN CHECK P301, SIGNAL CABLE, IC302 PIN 5, 6, 7 ? PC SIGNAL CHECK TROUBLE IN IC302 PIN 19, 20, 21 IC302, P302 PIN 10 (5V) ? CHECK IC303 PIN 1, 3, 5 TROUBLE IN PIN10 (12V), IC303 PIN 6 (80V) ?
  • Page 16 3. NO RASTER NO VIDEO (POWER INDICATOR GREEN or AMBER) CHECK AMBER POWER INDICATOR TROUBLE IN GREEN or AMBER ? P302 SIGNAL CABLE GREEN CHECK ROTATE SCREEN SCREEN CONTROL CONTROL KNOB TO KNOB OF FBT CLOCKWISE or COUNTER CLOCKWIES CHECK VOLTAGE AT D924/D926 CATHODE (190V) TROUBLE IN PRIMARY...
  • Page 17 4. NO VERTICAL DEFLECTION NO V-DEFLECTION (ONE HORIZONTAL LINE) CHECK TROUBLE IN IC601 Pin 3 T901 15V LINE (15V) ? CHECK TROUBLE IN IC601 PIN 7 T701 -47V LINE (47V)? CHECK TROUBLE IN IC801 PIN 12 IC801 (SAWTOOTH WAVE)? TROUBLE IN IC601, V-CIRCUIT - 17 -...
  • Page 18 5. TROUBLE IN DPM STAND-BY/SUSPEND/ DPMS OFF MODE FAILURE CHECK CHECK PC, IC401 (MICOM) INPUT H/V SYNC SIGNAL (PC IS NOT GOING INTO PIN 40, 41 (H/V INPUT) DPM MODE) SIGNAL? NO H/V SYNC SIGNAL CHECK TROUBLE IN IC401 PIN 9, 8 X401, IC401 WAVEFORM? CHECK...
  • Page 19 6. NO DEGAUSSING NO DEGAUSSING CHECK TROUBLE IN IC401 PIN 6 IC401 (MICOM) (5V)? CHECK TROUBLE IN Q920 COLLECTOR D925 VOLTAGE (0.5V)? CHECK TROUBLE IN P901? P901 CHECK TROUBLE IN RL901? RL901 TROUBLE IN TH901, DEGAUSSING COIL - 19 -...
  • Page 20 7. TROUBLE IN OSD NO OSD CHECK TROUBLE IN IC302 PIN 4 P302 (5V) ? CHECK IC301 PIN 5 TROUBLE IN (NEGATIVE H-PULSE P302 COMES IN ?) CHECK IC301 PIN 18 TROUBLE IN (V-PULSE COMES IN?) P302 CHECK IC301 PIN 13, 14, 15 TROUBLE IN (IS THERE ANY SIGNAL IC301, IC401...
  • Page 21 - 21 -...

  • Page 22: Exploded View

    CABINET ASSEMBLY, T910BG BRAND TKC080 ACORE NO SPRAY - For Europe 3091TKC088G CABINET ASSEMBLY, T910BG/J BRAND C080 ACORE NO SPRAY - For Australia 6318L19007A CDT(CIRC), M46QEF903X 13NPLD LG-PHILIPS 95KHZ 29.1MM FCDT TCO - For Northern Hemisphere 6318L19007B CDT(CIRC), M46QEF903X15SPLD LG-PHILIPS 95KHZ 29.1MM FCDT TCO V2 - For Southern Hemisphere 3809TKC054A BACK COVER ASSEMBLY, T910BG C047 BRAND LGC.

  • Page 23: Replacement Parts List

    REPLACEMENT PARTS LIST CAUTION: BEFORE REPLACING ANY OF THESE COMPONENTS, READ CAREFULLY THE SAFETY PRECAUTIONS IN THIS MANUAL. * NOTE SAFETY Mark AL ALTERNATIVE PARTS DATE: 2003. 5. 24. DATE: 2003. 5. 24. *S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION *S *AL LOC.
  • Page 24 DATE: 2003. 5. 24. DATE: 2003. 5. 24. *S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION *S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION C841 0CE476CR630 47UF SHL,SD 250V M FM5 BULK D303 0DS141489AB 1N4148 TP GRANDE DO-34 500MW C842 0CBZTTA002A 2000PF D 2.5KV J M/PP NI TP7...
  • Page 25 Q726 0TR555109AB 2N5551 TP SAMSUNG TO92 AMP COILs & COREs Q771 0TR920009AB KSP92 TP SAMSUNG TO92 HIGH V Q801 0TR558900BA 2SC5589(LG,W/M) BK TOSHIBA T FB201 125-155J BFS2550A0FG SAMWHA 2.5*5.0MM Q802 0TR471009AA KSD471AC-Y TP SAMSUNG TO92 FB301 125-022J FERRITE KQ-1 JS 3.5*5.0MM AX...
  • Page 26 DATE: 2003. 5. 24. DATE: 2003. 5. 24. *S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION *S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION Q811 0TF630000CA IRFS630A BK SAMSUNG 200V 6.5 R346 0RD0332Q609 33 1/4W(3 5% TA52 Q812 0TR114009AB DTC114ES TP ROHM-K SPT NPN R347...
  • Page 27 DATE: 2003. 5. 24. DATE: 2003. 5. 24. *S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION *S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION R710 0RD0222Q609 22 1/4W(3 5% TA52 R825 0RN1002F409 10K 1/6W 1 TA52 R711 0RN1502F409 15K 1/6W 1% TA52 R826 0RN1502F409...
  • Page 28 DATE: 2003. 5. 24. *S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION R927 0RD1001Q609 1K 1/4W(3 5% TA52 R929 0RN0220H609 0.22 1/2W 5% TA52 R930 0RN0220H609 0.22 1/2W 5% TA52 R931 0RC4703A609 470K OHM 1/2 W(7.0) 5% TA52 R932 0RC4703A609 470K OHM 1/2 W(7.0) 5% TA52 R933...

  • Page 29: Pin Configuration

    PIN CONFIGURATION M24C08 Serial I C BUS EEPROM SYMBOL PSDIP8 (BN) DESCRIPTION 0.25mm Frame Chip Enable Input E0-E2 Serial Data Address Input/Output Serial Clock Write Control SO8 (MN) 150mil Width Supply Voltage Logic Dirgram TSSOP8 (DW) Ground 169mil Width M62501P /FP Teerminal Number and The facillty PIN CONFIGURATION(TOP VIEW) PIN NO.
  • Page 30 TDA4867J PHILIPS 32P, SDIP SYMBOL DESCRIPTION non-inverted input inverted input supply voltage OUTB output B OUTB ground TDA4867J OUTA output A OUTA flyback supply voltage V FB GUARD guard output GUARD FEEDB feedback inprt FEEDB Pin Configuration GUARO output/ power save mode GUARD FLYBACK CIRCUIT...
  • Page 31 TDA4841PS PHLIPS 32P HFLB FOCUS XRAY HSMOD HPLL2 BSENS HCAP HREF BDRV HBUF PGND HPLL1 HDRV SGND TDA4841PS XSEL VCAP VREF EWDRV VAGC VOUT2 VSMOD VOUT1 ASCOR VSYNC HSYBC CLBL HUNLOCK Pin Configuration EHT compensaton Block Diagram via vertical size EHT compensation via horizontal size 1.2V...

  • Page 32: Schematic Diagram

    SCHEMATIC DIAGRAM NOTICE Since this is a basic schematic diagram. The value of components and some partial connection are sucject to be changed for improvement without notice. - 32 - - 33 -...

  • Page 33: Printed Circuit Board

    PRINTED CIRCUIT BOARD 1. CONTROL BOARD (Component Side) 2. CONTROL BOARD (Solder Side) 3. MAIN BOARD (Component Side) 4. MAIN BOARD (Solder Side) - 34 - - 35 -...
  • Page 34 May. 2003 P/NO : 3828TSL076J Printed in Korea...
