ASSEMBLY INSTRUCTIONS
1
2
1
MODEL# 9336GBP
3
4
STEP 3:
Parts:
Part 6 (x2) - Adjustable Knob
Screw the adjustable knob on to the top
of the main frame on each side facing
outwards like diagram shown. Turn
clockwise to tighten.
STEP 4:
Parts:
Part 2 (x2) - Base Tube
Grab both base tubes and attach to the
bottom of the main frame by sliding push
pin until it clicks. Install in the following
order 1-2-3-4 on diagram shown.
2
6
