- Page 1 GL G110B Beam USER MANUAL CP2018100PD.1 WWW.GLEELITE.COM...
-
Page 2: Table Of Contents
GL 110B Beam Table of contents Safety instructions..................Operating determination................Fixture exterior view ................. Installation ....................Connection to the mains............... Replacing gobos ................Rigging the fixture................. DMX-512 connection..............Control menu map..................6. Technical Specifications................7. Maintenance and cleaning................8. Photometric diagram..................9. -
Page 3: Safety Instructions
CAUTION! Keep this device away from rain and moisture! Unplug mains lead before opening the housing! FOR YOUR OWN SAFETY, PLEASE READ THIS USER MANUAL CAREFULLY BEFORE YOU INITIAL START - UP! 1. Safety instructions Every person involved with installation and maintenance of this device have to: - be qualified - follow the instructions of this manual CAUTION! -
Page 4: Operating Determination
Do not view the light output with optical instruments or any device that may concentrate the beam. 2. Operating determination This device is a moving head for creating decorative effects and was designed for indoor use only. This device is for professional use only. It is not for household use. If the device has been exposed to drastic temperature fluctuation (e.g. -
Page 5: Fixture Exterior View
3. Fixture exterior view 1 - Head 2 - Front lens 3 - Handles 4 - Display screen 5 - Control buttons 6 - Yoke 9 - Power (PowerCon) 10 - Fuse holder 11 - DMX OUT (3-pin) 12 - DMX IN (3-pin) -
Page 6: Installation
4. Installation Fixtures must be installed by a Qualified electrician in accordance with all national and local electrical and construction codes and regulations. 4.1 Connection to the mains For protection from electric shock, the fixture must be earthed! For protection from electric shock, the fixture must be earthed! The GL G110A is equipped with auto-switching power supply that automatically adjusts to any 50-60Hz AC power source from 100-240 Volts. -
Page 7: Rigging The Fixture
4.2 Rigging the fixture The installation of the fixture has to be built and constructed in a way that it can hold 10 times the weight for 1 hour without any harming deformation. The installation must always be secured with a secondary safety attachment, e.g. an appropriate catch net. - Page 8 The fixture can be placed directly on the stage floor or rigged in any orientation on a truss without altering its operation characteristics . For securing a fixture to the truss, install a safety wire that can hold at least 10 times the weight of the fixture.
- Page 9 Alternativelly, fixtures handels can be used for safety attachment 1-Clamps 2-Safety wire 3-Omega holder 4-Quick-lock fastener 5-truss When installing fixtures side-by-side, avoid illuminating one fixture with another! DANGER TO LIFE! Before taking into operation for the first time,the installation has to be approved by an expert!
-
Page 10: Dmx-512 Connection
4.3 DMX-512 connection The fixture is equipped with both 3-pin and 5-pin XLR sockets for DMX input and output.The sockets are wired in parallel. Only use a shielded twisted-pair cable designed for RS-485 and 3-pin or 5-pin XLR-plugs and connectors in order to connect the controller with the fixture or one fixture with another. -
Page 11: Control Menu Map
5. Control menu map 1、 Button Instruction S1：Return S2：Down S3：UP S4：UPEnter Menu Page: 1.Address 2.Fixture Setting 3.Manual Setting Auto Test 5.System Test 6.Information 2、 Menu Function When in Start Page,press any button,then reach the Selection Page Main Menu Selection Using Noted Selection a) Press S4 enter to Selection Page;... - Page 12 Rot-Gobo Rot Prism Prism Rot. Focus Zoom Stop Select “Auto Test” Test program 1 a) Press S4 enter to test program Page; Auto Test Test program 2 b) Press S2 or S3 to select test program options; c) Press S4 to save and run selected test program; Test program 3 d) Press S1 to exit without save .
- Page 13 Curve 4 c) Press S3 to save and exit at selection Page; d) Press S1 to exit directly-without save the selection. Curve 5 Select “Reset” Head Reset a) Press S3 enter to option selection Page; Reset Pan/Tilt Reset b) Press S2 or S4 to select Reset options; c) Press S3 to save and exit at selection Page;...
-
Page 14: Technical Specifications
6. Technical Specifications Electrical Power supply:......electronic auto-ranging Input voltage range:....100-240V, 50/60Hz Max. power consumption:..152 W@230V Fuse:........T 5 A Light source 100W white engine Colour temperature: 8500K CRI=70 Colour wheel 13 dichroic filters + open Static gobo wheel 19metal gobos, image diameter =5mm, aluminium, thickness=0.5 mm Gobo wheel continuous rotation... - Page 15 Prism Rotating 8-facet 11° prism with continuous rotation in both directions Iris Motorized iris for different beam diameters Strobe Strobe effect with variable speed (max.15 flashes/sec.) Dimmer Smooth dimmer from 0 - 100 % Control Readout fixture and llight source usage, receiving DMX values, temperatures, etc Built-in analyzer for easy fault finding, error messages Built-in demo sequences Black-out while head moving, colour changing...
-
Page 16: Maintenance And Cleaning
7. Maintenance and cleaning It is absolutely essential that the fixture is kept clean and that dust, dirt and smoke-fluid residues must not build up on or within the fixture. Otherwise, the fixture‘s light-output will be significantly reduced. Regular cleaning will not only ensure the maximum light-output, but will also allow the fixture to function reliably throughout its life. -
Page 17: Photometric Diagram
Clean the air filters placed in the fixture bases. Use a vacuum cleaner, compressed air or you can wash them and put back dry. After replacing the air filters, reset the elapsed time counter in the menu "Information" (Information--->Air Filters---> Elapsed Time). Replacing the fuse. -
Page 18: Dmx Protocol
9. DMX protocol LED100 Beam DMX Channel Mode/Channel Value Function 0-255 0-100% Pan fine 0-255 0-100% Tilt 0-255 0-100% Tilt fine 0-255 0-100% Pan/Fine Speed 0-255 Fast -> Slow Dimmer 0-255 0 -> 100% Dimmer Fine 0 -> 100% Strobe/Shutter 252-255 Open 213-251... - Page 19 Static Gobo 223-255 Rotation(CCW): Slow -> Fast 190-222 Rotation(CW): Slow -> Fast 182-189 Gobo17 Shake: Slow -> Fast 174-181 Gobo16 Shake: Slow -> Fast 166-173 Gobo15 Shake: Slow -> Fast 158-165 Gobo14 Shake: Slow -> Fast 150-157 Gobo13 Shake: Slow -> Fast 142-149 Gobo12 Shake: Slow ->...
- Page 20 System Control 224-255 Curve 4 192-223 Curve 3 160-191 Curve 2 128-159 Curve 1 96-127 All reset 64-95 Head reset 32-63 Pan and tilt reset 0-31 Unused If you have any questions, please contact your local dealer CP2018100PD.2...
