- Page 1 GL G110A Beam Spot USER MANUAL CP2018100PD.1 WWW.GLEELITE.COM...
-
Page 2: Table Of Contents
GL 110A Beam Spot Table of contents Safety instructions..................Operating determination................Fixture exterior view ................. Installation ....................Connection to the mains............... Replacing gobos ................Rigging the fixture................. DMX-512 connection..............Control menu map..................6. Technical Specifications................7. Maintenance and cleaning................8. Photometric diagram..................9. -
Page 3: Safety Instructions
CAUTION! Keep this device away from rain and moisture! Unplug mains lead before opening the housing! FOR YOUR OWN SAFETY, PLEASE READ THIS USER MANUAL CAREFULLY BEFORE YOU INITIAL START - UP! 1. Safety instructions Every person involved with installation and maintenance of this device have to: - be qualified - follow the instructions of this manual CAUTION! -
Page 4: Operating Determination
Do not view the light output with optical instruments or any device that may concentrate the beam. 2. Operating determination This device is a moving head for creating decorative effects and was designed for indoor use only. This device is for professional use only. It is not for household use. If the device has been exposed to drastic temperature fluctuation (e.g. -
Page 5: Fixture Exterior View
3. Fixture exterior view 1 - Head 2 - Front lens 3 - Handles 4 - Display screen 5 - Control buttons 6 - Yoke 9 - Power (PowerCon) 10 - Fuse holder 11 - DMX OUT (3-pin) 12 - DMX IN (3-pin) -
Page 6: Installation
For protection from electric shock, the fixture must be earthed! For protection from electric shock, the fixture must be earthed! The GL G110A is equipped with auto-switching power supply that automatically adjusts to any 50-60Hz AC power source from 100-240 Volts. Power cord is enclosed to the fixture. -
Page 7: Replacing Gobos
5. Remove the original gobo (2) and insert the new one (glazy side towards the light source). The Gleelite gobo has a small position point (8) at its edge which has to aimed at the position point (4) on the gobo holder (4). Insert the spring lock to secure correct gobo position in the gobo holder. -
Page 8: Rigging The Fixture
4.3 Rigging the fixture The installation of the fixture has to be built and constructed in a way that it can hold 10 times the weight for 1 hour without any harming deformation. The installation must always be secured with a secondary safety attachment, e.g. an appropriate catch net. - Page 9 The fixture can be placed directly on the stage floor or rigged in any orientation on a truss without altering its operation characteristics . For securing a fixture to the truss, install a safety wire that can hold at least 10 times the weight of the fixture.
- Page 10 Alternativelly, fixtures handels can be used for safety attachment 1-Clamps 2-Safety wire 3-Omega holder 4-Quick-lock fastener 5-truss When installing fixtures side-by-side, avoid illuminating one fixture with another! DANGER TO LIFE! Before taking into operation for the first time,the installation has to be approved by an expert!
-
Page 11: Dmx-512 Connection
4.4 DMX-512 connection The fixture is equipped with both 3-pin and 5-pin XLR sockets for DMX input and output.The sockets are wired in parallel. Only use a shielded twisted-pair cable designed for RS-485 and 3-pin or 5-pin XLR-plugs and connectors in order to connect the controller with the fixture or one fixture with another. -
Page 12: Control Menu Map
5. Control menu map 1、 Button Instruction S1：Return S2：Down S3：UP S4：UPEnter Menu Page: 1.Address 2.Fixture Setting 3.Manual Setting Auto Test 5.System Test 6.Information 2、 Menu Function When in Start Page,press any button,then reach the Selection Page Main Menu Selection Using Noted Selection a) Press S4 enter to Selection Page;... - Page 13 Rot-Gobo Rot Prism Prism Rot. Focus Zoom Stop Select “Auto Test” Test program 1 a) Press S4 enter to test program Page; Auto Test Test program 2 b) Press S2 or S3 to select test program options; c) Press S4 to save and run selected test program; Test program 3 d) Press S1 to exit without save .
- Page 14 Curve 4 c) Press S3 to save and exit at selection Page; d) Press S1 to exit directly-without save the selection. Curve 5 Select “Reset” Head Reset a) Press S3 enter to option selection Page; Reset Pan/Tilt Reset b) Press S2 or S4 to select Reset options; c) Press S3 to save and exit at selection Page;...
-
Page 15: Technical Specifications
6. Technical Specifications Electrical Power supply:......electronic auto-ranging Input voltage range:....100-240V, 50/60Hz Max. power consumption:..152 W@230V Fuse:........T 5 A Light source 100W white engine Colour temperature: 8500K CRI=70 Colour wheel 13 dichroic filters + open Static gobo wheel 19metal gobos, image diameter =5mm, aluminium, thickness=0.5 mm Gobo wheel continuous rotation... - Page 16 Rotating gobo wheel 8 glass gobos can be indexed and rotated in both directions different speeds Gobo wheel continuous rotation Glass gobos: outside diameter=12 mm, max. thickness=3 mm, high temperature borofloat or better glass "Slot&lock" system for easy replacement of gobos Warning!!! All glass Gobos which needed change,must be supply f rom the original factory.These glass gobos are professi...
-
Page 17: Maintenance And Cleaning
Optional Wireless DMX/RDM module Compliance with USITT DMX-512 (1986 & 1990) and 512-A Full DMX fidelity and frame integrity Auto sensing of DMX frame rate and frame size <5ms DMX latency Operational frequency range of 2402-2480 MHz Pan/Tilt Pan movement range 540° Tilt movement range 270°... -
Page 18: Photometric Diagram
It is absolutely essential that the fixture is kept clean and that dust, dirt and smoke-fluid residues must not build up on or within the fixture. Otherwise, the fixture‘s light-output will be significantly reduced. Regular cleaning will not only ensure the maximum light-output, but will also allow the fixture to function reliably throughout its life. -
Page 20: Dmx Protocol
9. DMX protocol GLG80 DMX Channel Mode/Channel Value Function 0-255 0-100% Pan fine 0-255 0-100% Tilt 0-255 0-100% Tilt fine 0-255 0-100% Pan/Fine Speed 0-255 Fast -> Slow Dimmer 0-255 0 -> 100% Dimmer Fine 0 -> 100% Strobe/Shutter 252-255 Open 213-251 Random Strobe... - Page 21 Static Gobo 234-255 Rotation(CCW): Slow -> Fast 212-233 Rotation(CW): Slow -> Fast 204-211 Gobo19 Shake: Slow -> Fast 196-203 Gobo18 Shake: Slow -> Fast 188-195 Gobo17 Shake: Slow -> Fast 180-187 Gobo16 Shake: Slow -> Fast 172-179 Gobo15 Shake: Slow -> Fast 164-171 Gobo14 Shake: Slow ->...
- Page 22 Rotating Gobo 194-255 Rotation(CCW): Slow -> Fast 132-193 Rotation(CW): Slow -> Fast 120-131 Gobo7 Shake: Slow -> Fast 108-119 Gobo6 Shake: Slow -> Fast 96-107 Gobo5 Shake: Slow -> Fast 84-95 Gobo4 Shake: Slow -> Fast 72-83 Gobo3 Shake: Slow -> Fast 60-71 Gobo2 Shake: Slow ->...
