PB TEEN Harry Potter Deathly Hallow Speaker User Manual

Harry Potter™ Deathly Hallow Bluetooth
User Manual
Please read this manual carefully before operating the device and save it for further reference.
Thank you for purchasing the Harry Potter™ Deathly Hallows Bluetooth Speaker. This manual will help you operate the
speaker. Please familiarize yourself first with the Bluetooth functionality of the device you wish to connect.

Package Content

Charging


This speaker contains a built-in rechargeable battery. Before the first use, please fully charge the speaker to
ensure optimal performance and battery life.

Connect the charging cable to any powered USB port (output 5V 500mA). Make sure it is fully plugged in.

Charging time: at least 4 hours. The indicator light will automatically turn red while charging and turn off when
fully charged.
Note: Operating the speaker while charging may affect the battery life.

Pairing


The speaker must be paired with a Bluetooth output device before it can operate.

Manual pairing is only necessary once per device. After the first time, the device will connect automatically.
1. Turn on the Bluetooth function on the device that you wish to pair (i.e. smartphone or other compatible
devices may require selecting "Search for Devices" or "Add New Device" in order to create a Bluetooth pairing. If so,
initiate a manual search.
Select "HP Deathly Hallows Speaker" once it appears on your device screen.
2.
the pairing is complete, the indicator light will turn blue and you will hear an ascending tone.
3. The speaker is now ready to play music. Press the
* It is advised to turn the volume on your device all the way down before connecting, then gradually increase the
volume until a comfortable listening level is reached.
* If the speaker does not pair with any device after 3 minutes, it will turn off automatically to save power.
Status
Device has been
turned on and is
searching
Connection
Success
Low voltage
Charge Mode
Light
Quick blue light flashes
Slow blue light flashes
Red light flashes
Red light turns on while charging, and
off when charging is completed
Manufacture :Shen Zhen Hao Jie Xin Plastic Hardware Co Ltd
®
Speaker

General Functions

"OFF/ON": Switch the button to turn the power on and off.
"DC IN" (charging port): Insert the micro USB end of the charging
cable into this port and connect the USB end to power supply to
charge the battery.
"AUX" (audio cable output port): Insert the audio cable into this port
to play music through a non-Bluetooth device.
Indicator light: Blue or red light indicates operation status. (See
"SPECIFICATIONS" below for more details.)
Play/pause: answer call/hang up call button. Press to play or pause
music. If there is an incoming call on the connected device, press to
answer and press again to hang up.
Microphone: This is the sound receiver when answering a call.
button to play or pause music.

SPECIFICATIONS:

Bluetooth Version
Bluetooth Profiles Supported
Driver
Frequency Response
Operation Range
Product Name:HP Deathly Hallow Speaker
Model Name:4334362,5488310
Brand Name:Pottery Barn Teen
Once a connection is established and
4.1
A2DP, AVRCP
32mm dynamic driver
20Hz to 20kHz
10M (30ft)
device). Some
