- Page 1 Operation Manual GT-24, GT-30 lasswashers GT-24-CW GT-30-CCW Glastender, Inc. · North Michigan Road · Saginaw, MI · 48604-9780 800.748.0423 · 989.752.4275 · Fax 989.752.4444 · www.glastender.com Rev. 11-13-07 © 2007 Glastender, Inc.
-
Page 3: Table Of Contents
Cleaning Instructions ... 17-18 Troubleshooting Guide ... 19-21 LABOR: Glastender, Inc. warrants all products to be free of defects in material and workmanship. In established areas, a start-up and a 90- day labor warranty are included with glasswasher models GT-24 and GT-30. -
Page 4: What Is A Glasswasher
This manual describes the operational features of the GT-24 and GT-30 model glasswashers with digital tempera- ture gauges. Please review this information before attempting installation and operation. Long term, trouble-free operation will follow if good housekeeping and maintenance procedures are followed. -
Page 5: Uncrating Instructions And Equipment Checklist
Make plumbing and electrical connections (see page 8). : Figure 1 shows a clockwise model with front switch panel. Glastender, Inc. • 5400 North Michigan Road • Saginaw, MI • 48604-9780 800.748.0423 • 989.752.4275 • Fax 989.752.4444 • www.glastender.com quIpment... -
Page 6: Main Section - Top View
Figure 2 shows a model GT-24 with clockwise conveyor movement. Counterclockwise conveyor movement models have identical parts in reverse positions. Please familiarize yourself with the following parts: umber escrIptIon Glass Stop Arm Drain Plug (2 required) Pump Inlet Screen (2 required) - One pump inlet screen is in the rinse tank hidden from view below the rinse tank guide. -
Page 7: Wiring Diagrams Manufactured Before Jan. 2003
. 2003 IrInG IaGram nIts eFore Glastender, Inc. • 5400 North Michigan Road • Saginaw, MI • 48604-9780 800.748.0423 • 989.752.4275 • Fax 989.752.4444 • www.glastender.com... -
Page 8: Manufactured After Jan. 2003
. 2003 IrInG IaGram nIts Fter Glastender, Inc. • 5400 North Michigan Road • Saginaw, MI • 48604-9780 800.748.0423 • 989.752.4275 • Fax 989.752.4444 • www.glastender.com... -
Page 9: Utility Requirements And Connections
: ... A. In all cases, consult local plumbing, electrical, and health codes for regu- otes Glastender, Inc. • 5400 North Michigan Road • Saginaw, MI • 48604-9780 800.748.0423 • 989.752.4275 • Fax 989.752.4444 • www.glastender.com b. Minimum water pressure - 25 psi. -
Page 10: Start-Up Instructions
Note: The prime button overrides the pre-set adjustment and dispenses at full speed. Turn Fill Switch to “off” position. Glastender, Inc. • 5400 North Michigan Road • Saginaw, MI • 48604-9780 800.748.0423 • 989.752.4275 • Fax 989.752.4444 • www.glastender.com equIrements and 12-1/16"... -
Page 11: Peristaltic Pump Adjustments
Install front panel of Main Section (see Figure 1 on page 3). Your glasswasher is now ready for operation. erIstaltIc nIts anuFactured Glastender, Inc. • 5400 North Michigan Road • Saginaw, MI • 48604-9780 800.748.0423 • 989.752.4275 • Fax 989.752.4444 • www.glastender.com tart nstructIons 2003 - d... - Page 12 Glastender, Inc. • 5400 North Michigan Road • Saginaw, MI • 48604-9780 800.748.0423 • 989.752.4275 • Fax 989.752.4444 • www.glastender.com 2003 - c eFore anuary 2003 - p Fter anuary dJustment elay Imer 1. Locate Peristaltic Pump in Glasswasher.
-
Page 13: Useful Information About Water, Detergent And Sanitizer
: Glasswashers are NOT water conditioners. Consult local water conditioning experts to mportant note determine your specific water condition. Glastender, Inc. • 5400 North Michigan Road • Saginaw, MI • 48604-9780 800.748.0423 • 989.752.4275 • Fax 989.752.4444 • www.glastender.com bout... -
Page 14: How To Operate The Glasswasher
17 & 18 of this manual. ow the An important part of owning a GT-24 or GT-30 glasswasher is becoming familiar with the machine’s components and operation. This section of the Operation Manual covers machine operation and identifies some of the machine compo- nents. - Page 15 The GT-24 and GT-30 also have three curtains and a rinse tank guide. The front curtain is to prevent water from splashing out the front of the machine. The wash and rinse curtains run perpendicular to the front curtain and are intended to prevent the wash and rinse water from mixing.
-
Page 16: Tips For Trouble-Free Operation
8. Only Glastender, Inc. replacement parts should be used. Components from other suppliers may result in machine malfunctions. Please consult your Glastender, Inc. service agent if service or technical assistance is required. The factory is also available to answer any operational questions. -
Page 17: Important Information About Chemicals
6. A GT-24 or GT-30 glasswasher can use either Iodine or Chlorine for sanitizer. Iodine is often used in hard water conditions, because it has a sheeting action the helps to prevent water spots. You cannot switch between these two dif- ferent chemicals for sanitizing without re-adjusting the chemical pumps, because they require different concentration levels. -
Page 18: Diagnosing Poor Wash Results
The best way to understand why you are getting poor results is to know what components belong in your machine and how it is supposed to operate. If you are getting poor results from your GT-24 or GT-30 glasswasher, follow these simple steps to help diagnose your problem. - Page 19 Wash Tank and components, especially the Heater. Excessive debris in the tanks (straws, garnishes, broken glass, etc.). Plugged spray nozzles. Glastender, Inc. • 5400 North Michigan Road • Saginaw, MI • 48604-9780 800.748.0423 • 989.752.4275 • Fax 989.752.4444 • www.glastender.com leanInG nstructIons omment This unit is receiving proper user maintenance.
-
Page 20: Cleaning Instructions
15. Replace Conveyor, Front Curtain(s), and Front Shield. 16. Allow the unit to reach operating temperature. 17. Your glasswasher is now ready for operation. Glastender, Inc. • 5400 North Michigan Road • Saginaw, MI • 48604-9780 800.748.0423 • 989.752.4275 • Fax 989.752.4444 • www.glastender.com leanInG... -
Page 21: Troubleshooting Guide
E. Water recirculating, conveyor not moving F. Hot glasses at end of cycle Glastender, Inc. • 5400 North Michigan Road • Saginaw, MI • 48604-9780 800.748.0423 • 989.752.4275 • Fax 989.752.4444 • www.glastender.com roubleshootInG ause 1. No power (Power light “off.”) 2. - Page 22 N. Hot water runs contin- uously, but detergent pump turns on and off Glastender, Inc. • 5400 North Michigan Road • Saginaw, MI • 48604-9780 800.748.0423 • 989.752.4275 • Fax 989.752.4444 • www.glastender.com roubleshootInG ause 1. Completely plugged pump inlet screen.
