Gorenje GV62010UK Operating Instructions Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
1
Main power switch
1
Programme selector
2
Daily wash
3
Intensive wash
4
Eco wash
5
Quick wash
6
Rinse
7
Safety instructions ................................................... 2
Before washing for the first time ............................ 3
Loading the dishwasher .......................................... 4
Using the dishwasher ............................................. 5
Settings..................................................................... 8
Care and cleaning ................................................. 9
Troubleshooting ..................................................... 11
Installation .............................................................. 14
Service .................................................................... 15
Information for test institute .................................. 16
Technical information ............................................ 18
2
3
4
5
EN
Operating Instructions
Dishwasher
GV62010UK
6
7
Half load
8
9
Salt indicator
Rinse aid indicator
10
8
9
10

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GV62010UK and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Gorenje GV62010UK

Summary of Contents for Gorenje GV62010UK

  • Page 1: Table Of Contents

    Operating Instructions Dishwasher GV62010UK Half load Main power switch Programme selector Salt indicator Rinse aid indicator Daily wash Intensive wash Eco wash Quick wash Rinse Safety instructions ........... 2 Before washing for the first time ......3 Loading the dishwasher .......... 4 Using the dishwasher ..........

  • Page 2: Safety Instructions

    Safety instructions Winter storage/transport General • • Store the dishwasher where the temperature remains Read the operating instructions and keep them above freezing. in a safe place! • Avoid long transport distances in very cold weather. • Never use the dishwasher for any purpose other •...

  • Page 3: Before Washing For The First Time

    Before washing for the first time The water softener Refill salt indicator In order to achieve good dishwashing results, the When the salt needs topping up, the above symbol lights dishwasher needs soft water (water with low mineral on the display. content).

  • Page 4: Loading The Dishwasher

    Loading the dishwasher Economic dishwashing • Do not start the dishwasher until it is fully loaded to save energy. • Do not rinse under running water. Simply scrape off large food particles before loading the dishwasher. • Choose an environmentally-friendly detergent. Read the environmental declaration on the packaging! Lower basket •...

  • Page 5: Using The Dishwasher

    Using the dishwasher Add detergent The main power switch Add the detergent to the detergent compartment. Close Press and hold the main power switch until the display lights the lid and press until it locks in place. Contact the detergent manufacturer if you have questions about the detergent.
  • Page 6 Start the dishwasher Close the door to start the dishwasher. If the main power switch is on the dishwasher will start automatically when the door is closed. Stopping or changing a programme If you want to change programme after starting the dishwasher, open the door then press and hold the main power switch until the display turns off.

  • Page 8: Settings

    Settings Adjusting salt consumption he dishwasher is designed to allow for adjustment in the amount of salt consumed based on the hardness of the water used. This is intended to optimise and customise the level of salt consumption. Please follow the steps below for adjustment in salt consumption. 1.

  • Page 9: Care And Cleaning

    Care and cleaning Filter System The filter prevents larger remnants of food or other objects from getting inside the pump. The residues may block the filter, in this case they must be removed. Coarse filter Coarse filter Main filter Main filter Fine filter The filter system consists of a coarse filter, a flat (Main filter) And a microfilter (Fine filter).
  • Page 10 Spray arms Holes and bearings can sometimes become blocked. Remove any debris using a pin or the like. The spray arms also have holes underneath. To facilitate cleaning you can remove the spray arms. Remember to fit them firmly back into place afterwards. Lower spray arm •...

  • Page 11: Troubleshooting

    Troubleshooting Type of fault on the display Action The Rinse light Water Inlet Fault Check that the water tap is on. Check that the outer filter on the inlet hose is not flicker fleetly blocked. If the problem persists, call the service department. The Rinse and Not reaching required Call the service department.
  • Page 12 Problem Possible causes Action The dishes are not clean. The spray arms do not rotate. Remove the arms and clean them. Check that the dishes are not blocking the spray arms. Old detergent. Detergent is a perishable Avoid large packages. product.
  • Page 13 Problem Possible causes Action Rattling sound when dishwashing. The dishes are not correctly placed or Check that the dishes are placed the spray arms are not rotating. securely. Spin the spray arms to make sure they can rotate. Water remains in the dishwasher. Blocked drainage hose.

  • Page 14: Installation

    Installation [mm] Setup It is important that you read through and follow the instructions and directions below. Conduct installation and • The recess and connection dimensions are included in connection in accordance with the separate installation the separate installation instructions. Check that all instructions.

  • Page 15: Service

    Service Read the chapter Troubleshooting before contacting the service department. Provide the details on the serial number When the drainage hose is routed to a connection plate in all contact. Include the article number (1) and the nipple on the sink unit's water trap (see illustration 1), serial number (2).

  • Page 16: Information For Test Institute

    Information for test institute LOADING THE BASKETS ACCORDING TO EN50242: 1.Upper basket: Number Item Cups Saucers Glasses Small serving bowl Medium serving bowl Serving spoons Large serving bowl 1 1 1 1 Number Item Dessert dishes Dinner plates 1 1 0 0 Soup plates Oval platter Cutlery basker...
  • Page 17 Information for test institute 3.Cutlery basket: Item Number Soupspoons Forks Knives 4 4 4 Teaspoons Dessert spoons Information for comparability Serving forks tests in accordance with EN 50242 Capacity: 12 place settings Gravy ladles Position of the upper basket: lower position Gravy ladles Program: ECO Rinse aid setting: 6...

  • Page 18: Technical Information

    Information for test institute Information on energy labelling Information sheet, in compliance with Commission Delegated Regulation (EU) No. 1059/2010 Gorenje Model designation: GV62010UK Number of standard place settings: Energy efficiency class: 258 kWh per year Annual energy consumption(AE Energy consumption of the standard cleaning cycle(E ):0.9 kWh...
