- Page 1 GigaFast 24-Port 10/100Mbps Switch User Manual EE2400-SS...
- Page 2 GigaFast opyright The contents of this publication may not be reproduced in any part or as a whole, stored, transcribed in an information retrieval system, translated into any language, or transmitted in any form or by any means, mechanical, magnetic, electronic, optical, photocopying, manual, or otherwise, without prior written permission.
- Page 3 GigaFast : Introduction : System Requirements : Hardware Requirements Section : Software Requirements : Starting Management Application : Management Software Overview : Select an Adapter : Show Switch Status : Configuration : Security : Diagnostic : System Menu : Save and Load Configuration...
-
Page 4: System Requirements
Layer 2 switches by software. The EE2400-SS Management Application is a Window-based software package that implements RRCP functions at the management host side. The EE2400-SS Management Application gives network administrators the ability to configure and monitor dumb layer 2 switches like intelligent switches. -
Page 5: Management Software Overview
You can select one network adapter. The adapters are displayed in the combo box. Show Switch Status The Management Application shows one switch’s information at one time. So, you must select a switch using the combo-box witch displayed switches discovered in the network. Section 2... - Page 6 Network topology link vector: Show the link status of the switches. Update button If you want to know the newest switch’s information of the network, press the Update button. Switch database button You can view the switch database. The database dialog box displays the switch’s name, MAC address and authentication Key.
- Page 7 Port Status You can view the port status of the switch that you select. The list box will show the status of port1, port2…, and port26. The port status includes port type, enabled status, link status, speed duplex, flow control, TX bandwidth control, Rx bandwidth control, and trunk setting status.
- Page 8 None : No flow control Asymmetric to Link Partner : A relationship between linked network devices in which only the device that is connected to the switch can send pause frames. Symmetric: A relationship between linked network devices in which both devices can send and receive pause frames.
- Page 9 Rx Bandwidth Control: Controls on speed of packets being received. Trunking: Trunk ports together to allow increased bandwidth through the switch, or to connect multiple switches together to increase VLAN capabilities. Global Configuration Global Configuration is used to configure the global port control registers. Press the ‘Refresh’...
- Page 10 TOS/DiffServ (DS) priority field. These 3 types of QoS can be configured by hardware pins, EEPROM or Registers 0x0400, 0x0401. EE2400-SS support 2 level priority queues. The queue service rate is based on the packet based Weighted Round Robin algorithm. The packet based service weight ratio of high-priority and low-priority queuing can be set as 4:1, 8:1, 16:1 or "Always...
- Page 11 Port based priority 802.1p based priority When 802.1p tag priority is applied, the EE2400-SS can recognize the 802.1Q VLAN tag frames and extract the 3-bit User_Priority information from the VLAN tag. The RTL8326 set the threshold of User_Priority as 3.
-
Page 12: Vlan Configuration
Note: IPv6 refer to rcf2460; Flow control auto turn off scheme The EE2400-SS can automatically turn off 802.3x flow control and Back pressure flow control for 1~2 seconds whenever the port receives a high priority frames. The flow control is re-enabled when no priority frames are received for 1~2 seconds. - Page 13 GigaFast Refresh Button Read the VLAN table registers. Configuration button Setting up a VLAN Select one VLAN in the list box or double-click the VLAN you want to configure. It will pop up a dialog like follows: Port Tagging Control button Press this button you will see a dialog like follows.
- Page 14 VLAN control registers to the selection. EE2400-SS support VLAN function to broken the switch up into 32 VLAN, each VLAN is a broadcast domain .Each VLAN member can be flexible configured from 0 to 26 port members.
- Page 15 VLAN Table configurations are not different to Tag-based VLAN function. The VLAN classification of any incoming packet on a port for Port-based VLAN is defined by the port PVID. EE2400-SS use the PVID to search VLAN table to get the VLAN member. Support 802.1Q Tag-based VLAN By setting the register 0x030B to enable the En8021Qaware control bit, the 802.1Q...
- Page 16 Ingress Filtering control: to enable filter the frame received from a port which port is not included in the classified VLAN group member. Support leaky VLAN feature EE2400-SS support the leaky VLAN feature to enable the ability for some specific frame to be forward between different VLAN. For example, the VLAN table entry is VLAN 1 = port # 1, 2, 3.
-
Page 17: Device Features
Press the ‘Update’ button to set the registers, and it will set the register to the selection. EE2400-SS Support the ASIC based IGMP snooping function which can be enable via register 0x0308 and no other external CPU handling is required. It support the ability to parser the IGMP control protocol packets and IP multicast data packets to learn the multicast router port and group address member ports into the multicast address table. - Page 18 Management security scheme Two RRCP security scheme of EE2400-SS are implemented: (1) RRCP management authorized port control (2) Protocol Authentication Key control. (1) RRCP management authorized port control: The authorized port can be configured via register 0x0201~0x0202.
-
Page 19: Fault Information
GigaFast Fault Information This part shows some of the information like: Trunk Port Fault, Network Loop Fault Test, and Gigabit PHY existence report for Gigabit Port G1G0. Device Reset The software reset will reset the system to the initial state. The MAC table and VLAN table data will be kept. -
Page 20: System Menu
In the Browser, click System | Load Configuration. 1. In the Open File dialog box, select an “.rrcp” file and click Load. 2. In the Setting Active Switch dialog box, select a switch you want to set, and click OK. -
Page 21: Console Configuration
GigaFast Console Configuration Logging into Console Serial Connection To connect using Console : 1. Connect Your Computer To Serial Port. 2. Open Hyper Terminal Accessories -> Communications 3. Use the COM Port you connected to Click OK 4. Settings are... -
Page 22: Appendix A: Specifications
GigaFast Appendix A: Specifications Standards Ports Cables Bandwidth Forwarding/Filtering Rate Latency MAC Address Buffer Memory Duplex Modes Crossover LED Indicators Power Supply Power Consumption Environment Certifications Dimensions Warranty Appendix A IEEE802.3; IEEE802.3u and IEEE802.3x Flow-Control for Full-Duplex operation Twenty-four (24) 100Base-TX (Copper) 10Base-T : Cat. -
Page 23: Appendix B: Technical Support
Limited Warranty Limited Warranty Statement: GigaFast Ethernet Solutions Inc. ("GFE") warrants its products to be free from defects in workmanship and materials, under normal use and service, for the applicable warranty term. All GFE products carry a standard limited warranty from the date of purchase from GFE or its Authorized Reseller. GFE may, at its own discretion, repair or replace any product not operating as warranted with a similar or functionally equivalent product, during the applicable warranty term. - Page 24 GigaFast THE RANGE OF THE INTENDED USE, OR BY ACCIDENT, FIRE, LIGHTNING, OR OTHER HAZARD. LIMITATION OF LIABILITY: IN NO EVENT, WHETHER BASED IN CONTRACT OR TORT (INCLUDING NEGLIGENCE), SHALL GFE BE LIABLE FOR INCIDENTAL, CONSEQUENTIAL, INDIRECT, SPECIAL, OR PUNITIVE DAMAGES OF ANY...
