Charging A Hot Or Cold Battery Pack - SNOWJOE SUNJOE SPX6000C-RM Operator's Manual

3. Place the battery pack into the charger by sliding the
pack as shown to lock it into position. When you insert
the battery into the charger, the bottom red light will
illuminate to indicate that the battery is charging (Fig. 13).
4. When the bottom light turns green, the battery is fully
charged (Fig. 14).
Fig. 14
green
red
Charging
NOTE: If the top light remains green while the bottom light
alternately flashes red and green, this indicates a temperature
abnormality (i.e. that the battery pack is either too hot or too cold).
If there is only a red blinking light, this indicates that something is
wrong with the battery. Contact Snow Joe
service center at 1-866-SNOW-JOE (1-866-766-9563) for
assistance.
Green
Flashing red/green
Temperature abnormal
5. A fully discharged pack with an internal temperature
in the normal range will fully charge in 2.5 to 3 hours
(between 32ºF/0ºC and 113ºF/45ºC). Heavily cycled
battery packs may take longer to charge completely.
6. If the charging light indicator alternately blinks red and
green or the light indicator does not come on at all, check
that the battery pack is fully seated into the bay. Remove
the pack and reinsert. If the problem persists, contact the
Snow Joe + Sun Joe
®
1-866-SNOWJOE (1-866-766-9563) for assistance.
green
green
Fully charged
+ Sun Joe
® ®
Flashing red only
Something is wrong
customer service center at
®
7. When charging is complete, remove the battery from the
charger by pulling the push lock button and sliding the
battery backward to unlock it from the charger (Fig. 15).
Fig. 15
Push lock button
8. Timely recharging of the battery will help prolong the
battery's life. You must recharge the battery pack when
you notice a drop in the equipment's power.
IMPORTANT! Never allow the battery pack to become fully
discharged as this will cause irreversible damage to the
battery.

Charging a Hot or Cold Battery Pack

A red and green flashing indicator light on the charger
indicates that the battery pack temperature is outside the
charging range. Once the pack is within the acceptable
range, normal charging will take place and the red light will
be continuous. Hot or cold battery packs may take longer to
charge.
customer
Battery Pack
Temperature
Too hot
Normal range
Too cold
Operation
m
IMPORTANT!
a micro-switch sensitive to water flow. This Total Stop System
(TSS) senses water flow in the pump. When the trigger is
released, water stops flowing through the pump. The TSS then
automatically turns the motor off to protect the pump from
overheating, thus saving energy and prolonging pump life.
12
Lithium-Ion Charging Status
Red Charger
Indicator Light
Flashing
Continuous
Flashing
This pressure washer is equipped with
Charging
Status
Not charging
Normal charging
Not charging
