Wen 418CV Instruction Manual

PARTS
No. Part No. Description
1 416CV-001 Base
2 416CV-002 Nut
3 416CV-003 Saddle
4 418CV-004 Gib
5 416CV-005 Hex Nut, M6
6 416CV-006 Set Screw, M6x20
7 413CV-007 Flat Washer, M6
Longitudinal
8 418CV-008
Feed Screw
Cross Feed
9 416CV-009
Screw
10 416CV-010 Retaining Plate
Socket Head Bolt,
11 416CV-011
M8x20
Crank Handle
12 416CV-012
Assembly
No. Part No. Description
Qty. 13 413CV-013 Locking Nut, M6
Leadscrew With
1
14 418CV-014
Handle
1
15 418CV-015 Guide Rod
1
16 418CV-016 Body
2
Socket Head Bolt,
17 416CV-017
6
M8x20
4
18 418CV-018 Movable Jaw
2
Dog Point Set
19 416CV-019
Screw, M8x10
1
20 418CV-020 Jaw Plate
Grooved Jaw
1
21 418CV-021
Plate
1
22 416CV-022 Retaining Plate
23 416CV-023 Set Screw, M6x25
4
24 416CV-024 Lock Washer, M6
2
25 414CV-025 Ball Bearing
INSTRUCTION MANUAL
ASSEMBLY
1. Remove all components and parts from the box. Your cross vise includes the following
hardware:
• (3) Hex Wrenches
• (2) Locking Nuts
2. If necessary, adjust the longitudinal (top) feed screw until the handle-mounting portion of
the feed screw protrudes beyond the vise body, as shown in Fig. 1 below. Turning the feed
screw clockwise retracts it; turning it counterclockwise advances it. Turn the feed screw fully
clockwise until it can no longer retract.
3. Mount one of the crank handles on the leadscrew, as shown in Fig. 2 below.
4. Secure the crank handle to the feed screw using the included flat washer and locking nut (Fig.
2). Tighten the nut (turning clockwise) against the handle using a 10 mm socket (not included),
then back it off a quarter turn (turning counterclockwise). Turn the handle a couple of times. If
it is difficult to turn, loosen the nut. Adjust the nut as necessary to ensure that the handle turns
Qty.
smoothly and advances the slide properly.
2
5. Repeat the same procedure to mount the remaining crank handle on the cross feed screw.
1
Top View
1
1
4
1
1
1
1
1
2
4
1
8 - 3/8 - INCH
CROSS VISE
• (2) Flat Washers
• (2) Crank Handles
Clockwise Brings
Feed Screw Out
Counterclockwise
Sends Feed Screw
In
Fig. 1
MODEL 418CV
ÉTAU POUR PERCEUSE
Top View
Feed Screw
Flat Washer
Locking Nut
Crank Handle
Fig. 2
