AG SPRAY LA9000 Operation & Maintenance Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
operation & maintenance manual
LA9000
1650 OR 1950 GALLON tank w/ 27', 30', 35', 40' or 55' toolbar
BAKERSFIELD, CA
COLUMBUS, NE
661.391.9081
402.564.4544
HOPKINSVILLE, KY
MANKATO, MN
270.886.0296
507.388.6295
DOTHAN, AL
FARGO, ND
334.673.0580
701.280.2862
NEWTON, KS
OTHELLO, WA
316.283.4444
509.488.6631
MANUFACTURING
QUALITY PRODUCTS
FOR 30 YEARS
LIQUID
APPLICATOR
GREENWOOD, MS
SHOP ONLINE @
662.453.4524
WWW.AGSPRAY.COM
TEMPE, AZ
480.705.8047

Advertisement

loading
Need help?

Need help?

Do you have a question about the LA9000 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for AG SPRAY LA9000

Summary of Contents for AG SPRAY LA9000

  • Page 1 MANUFACTURING QUALITY PRODUCTS FOR 30 YEARS operation & maintenance manual LIQUID LA9000 APPLICATOR 1650 OR 1950 GALLON tank w/ 27’, 30’, 35’, 40’ or 55’ toolbar BAKERSFIELD, CA COLUMBUS, NE DOTHAN, AL FARGO, ND GREENWOOD, MS SHOP ONLINE @ 661.391.9081 402.564.4544...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS INTRODUCTION PRE-OPERATION CHECKLIST PLACING IN STORAGE REMOVING FROM STORAGE LIMITED WARRANTY OPERATING INSTRUCTIONS BREAK-IN SERVICE AND MAINTENANCE GREASING 12-39 BREAKDOWNS L A 9 0 0 0 L I Q U I D A P P L I C A T O R O P E R A T I O N & M A I N T E N A N C E M A N U A L...

  • Page 3: Introduction

    INTRODUCTION 1. Read and understand the Operators Manual and all 7. Stay away from wing pinch points when folding or safety signs before using. extending wings. Keep others away. 2. Place all controls in neutral, stop tractor engine, turn 8. Stay away from power lines when extending or monitor off, set park brake, remove ignition key, wait folding wings.

  • Page 4: Placing In Storage

    PLACING IN STORAGE At the end of the spray season, the machine should be g. Remove nozzles from boom Disassemble and thoroughly inspected and prepared for storage. Repair or wash nozzle, Spring, diaphragm and housing. replace any worn or damaged components to prevent any Store inside.

  • Page 5: Limited Warranty

    Ag Spray Equipment delivery to the buyer, other than by Ag Spray Equipment or has authorized such expenses in advance. its authorize dealers or employees, and does not apply to...

  • Page 6: Operating Instructions

    OPERATING INSTRUCTIONS 6. Remove locking collars as needed to maintain a depth 1. Ensure applicator is connected securely to tractor draw bar of 4 to 5 inches. Constant down pressure on main lift is with clevis pin and safety chain. (See Figure 1). not recommended (weight of toolbar will keep unit in FIG.
  • Page 7 OPERATING INSTRUCTIONS c. Close and lock down the bypass adjusting screw in the hydraulic motor (if applicable). Switch rate controller to manual and press the “+” button on TeeJet or “Increase” button on Raven, hold for 8 seconds. Then press the “-” button on TeeJet or “Decrease” button on Raven for 4 seconds.
  • Page 8 440/450 Raven Controller With PWM Setup 1. Install Raven 440 or 450 control console and hook up to sprayer (see instructions inside controller box). 2. Turn on control console. When making selections/entering numbers, always be sure to press enter to save your settings. 3.
  • Page 9 2630 JD Rate Controller With PWM Setup 1. After hooking up all wiring between tractor and sprayer, turn the system on. 2. Make sure all nozzles are open with desired tips installed. 3. From the Menu, select Rate Controller 4. Setup your Implement type - Select Pull Behind Sprayer, enter a name and tank size.

  • Page 10: Break-In

    BREAK-IN B. After 5 hours and 10 hours of operation Although there are no operational restrictions on the applicator when used for the first time, it is recommended that the 1. Retorque all wheel bolts, fasteners and hardware. following mechanical items be checked: 2.
  • Page 11 GREASING Wipe grease fitting with a clean cloth before greasing L/R GREASE LOCATIONS to prevent injecting dirt and grit into joint. Replace and repair broken fittings immediately. Apply adequate grease to the following: If a fitting will not take grease, remove and clean thoroughly.
  • Page 12 L A 9 0 0 0 L I Q U I D A P P L I C A T O R O P E R A T I O N & M A I N T E N A N C E M A N U A L...
  • Page 13 S H O P O N L I N E @ W W W . A G S P R A Y . C O M...
  • Page 14 27' DOUBLE TUBE APPLICATOR - 5280873 EXPLODED STATE DETAIL B SCALE 1 : 12 DETAIL D DETAIL E SCALE 1 : 24 SCALE 1 : 24 30 20 DETAIL A SCALE 1 : 24 NOTE: THIS TOOLBAR IS COMPATABLE WITH THE FOLLOWING APPLICATOR FRAMES: 5280878 DETAIL C...
  • Page 15 27' DOUBLE TUBE APPLICATOR - 5280873 Item No Part Number Qty. Description 5006344 18 1/4-20nc Hex Flanged Toplock Nut Gr. 5 5006345 4 3/8-16nc Hex Flanged Toplock Nut Gr. 5 5006359 4 3/4-10nc Hex Flanged Toplock Nut Gr. 8 5006365 8 1/2-13nc Hex Flanged Toplock Nut Gr.
  • Page 16 30' DOUBLE TUBE APPLICATOR - 5280906 EXPLODED STATE Item No Part Number Qty. Description 5280873 1 ASSY, 27' DOUBLE TUBE, VERT. FOLD TOOLBAR 5280904 1 ASSY, 15" EXTENSION FOR DOUBLE TUBE TOOLBAR 5280904 1 ASSY, 15" EXTENSION FOR DOUBLE TUBE TOOLBAR Item No Part Number QTY.
  • Page 17 40' DOUBLE TUBE APPLICATOR - 5280907 EXPLODED STATE Item No Part Number Qty. Description 5280874 1 ASSY, 35' DOUBLE TUBE, VERT. FOLD TOOLBAR 5280905 1 ASSY, 30" DOUBLE TUBE TOOLBAR EXTENSION 5280905 1 ASSY, 30" DOUBLE TUBE TOOLBAR EXTENSION NOTE: THIS TOOLBAR IS COMPATABLE WITH THE FOLLOWING APPLICATOR FRAMES: 5280878 5280877...
  • Page 18 35' DOUBLE TUBE APPLICATOR - 5280874 EXPLODED STATE DETAIL D SCALE 1 : 28 38 32 8 29 DETAIL C SCALE 1 : 28 DETAIL A SCALE 1 : 28 DETAIL B SCALE 1 : 28 NOTE: THIS TOOLBAR IS COMPATABLE WITH THE FOLLOWING APPLICATOR FRAMES: 5280878 5280877...
  • Page 19 35' DOUBLE TUBE APPLICATOR - 5280874 Item No Part Number Qty. Description 5006260 8 3/4"-10 Hex Jam Nut 5006344 26 1/4-20nc Hex Flanged Toplock Nut Gr. 5 5006345 6 3/8-16nc Hex Flanged Toplock Nut Gr. 5 5006359 12 3/4-10nc Hex Flanged Toplock Nut Gr. 8 5006365 8 1/2-13nc Hex Flanged Toplock Nut Gr.
  • Page 20 55' DOUBLE TUBE APPLICATOR - 5280871 EXPLODED STATE DETAIL D SCALE 1 : 20 6 16 DETAIL E SCALE 1 : 20 29 31 DETAIL C SCALE 1 : 30 DETAIL A DETAIL B SCALE 1 : 30 SCALE 1 : 30 NOTE: THIS TOOLBAR IS COMPATABLE WITH THE FOLLOWING APPLICATOR FRAMES: 5280877...
  • Page 21 55' DOUBLE TUBE APPLICATOR - 5280871 Item No Part Number Qty. Description 5006260 4 3/4"-10 Hex Jam Nut 5006344 36 1/4-20nc Hex Flanged Toplock Nut Gr. 5 5006345 6 3/8-16nc Hex Flanged Toplock Nut Gr. 5 5006359 4 3/4-10nc Hex Flanged Toplock Nut Gr. 8 5006365 8 1/2-13nc Hex Flanged Toplock Nut Gr.
  • Page 22 L A 9 0 0 0 L I Q U I D A P P L I C A T O R O P E R A T I O N & M A I N T E N A N C E M A N U A L...
  • Page 23 5280832 - SHORT ADJUSTABLE 20K AXLE with IF380/90R54 TIRES Item Part Qty. Descrip on Number 5006359 3/4-10nc Hex Flanged Toplock Nut Gr. 8 5034785 Flng HH Bolt 3/4-10 X 2 1/2" 5279102 TIRE AND RIM IF380/90R54 RH 5279106 TIRE AND RIM IF380/90R54- LH 5279111 ASSY, ADJUSTABLE AXLE- SINGLE WHEEL- SHORT 5279529...
  • Page 24 5280833 - SHORT ADJUSTABLE 20K AXLE with IF480/80R42 TIRES Item Part Qty. Descrip on Number 5006359 3/4-10nc Hex Flanged Toplock Nut Gr. 8 5034785 Flng HH Bolt 3/4-10 X 2 1/2" 5279104 TIRE AND RIM 480/80R42 5279108 TIRE AND RIM 480/80R42- LH 5279111 ASSY, ADJUSTABLE AXLE- SINGLE WHEEL- SHORT 5279529...
  • Page 25 5280834 - DUAL AXLE, 60”-120”, IF320/90R54 TIRES Item Part Qty. Descrip on Number 5006359 3/4-10nc Hex Flanged Toplock Nut Gr. 8 5006363 1"-8nc Hex Flanged Toplock Nut Gr. 8 5034750 Flng HH Bolt 1-8 X 3" 5034785 Flng HH Bolt 3/4-10 X 2 1/2" 5279105 TIRE AND RIM IF320/90R54 RH 5279109...
  • Page 26 5280835 - DUAL AXLE, 88”-132”, IF320/90R54 TIRES Item Part Qty. Descrip on Number 5006359 3/4-10nc Hex Flanged Toplock Nut Gr. 8 5034785 Flng HH Bolt 3/4-10 X 2 1/2" 5279105 TIRE AND RIM IF320/90R54 RH 5279109 TIRE AND RIM IF320/90R54- LH 5279112 ASSY, DUAL AXLE 5279264...
  • Page 27 5280839 - DUAL AXLE, 80”-160”, IF320/90R54 TIRES Item Part Qty. Descrip on Number 5006359 3/4-10nc Hex Flanged Toplock Nut Gr. 8 5034785 Flng HH Bolt 3/4-10 X 2 1/2" 5279105 TIRE AND RIM IF320/90R54 RH 5279109 TIRE AND RIM IF320/90R54- LH 5279112 ASSY, DUAL AXLE 5280840...
  • Page 28 5280838 - DUAL AXLE, 76”-152”, IF320/90R54 TIRES Item Part Qty. Descrip on Number 5006359 3/4-10nc Hex Flanged Toplock Nut Gr. 8 5034785 Flng HH Bolt 3/4-10 X 2 1/2" 5279105 TIRE AND RIM IF320/90R54 RH 5279109 TIRE AND RIM IF320/90R54- LH 5279112 ASSY, DUAL AXLE 5279206...
  • Page 29 S H O P O N L I N E @ W W W . A G S P R A Y . C O M...
  • Page 30 L A 9 0 0 0 L I Q U I D A P P L I C A T O R O P E R A T I O N & M A I N T E N A N C E M A N U A L...
  • Page 31 AA(B)126ML-3-*, AA(B)126ML-4-*, AA(B)126ML-F50-* LINE STRAINERS S H O P O N L I N E @ W W W . A G S P R A Y . C O M...
  • Page 32 RFM 60 P FLOWMETER REPLACEMENT PARTS 063-0171-793 L A 9 0 0 0 L I Q U I D A P P L I C A T O R O P E R A T I O N & M A I N T E N A N C E M A N U A L...
  • Page 33 damage prevention from abuse conditions. Technical Details Operating Pressure (max): Inlet: 3000 PSI (207 bar) Outlet: 3000 PSI (207 bar) Regulated Flow (max): 14 GPM (53 LPM) – Bypass Port Plugged (0 gpm Bypass) 15 GPM (57 LPM) - Bypass Port Open (15 gpm Max Bypass) Electrical: Voltage: 12 VDC Frequency: 110 Hz...
  • Page 34 Operation Instructions The hydraulic control assembly is designed to work with a digital controller with PWM signal output. As the signal current increases, the hydraulic flow control valve opens. To ensure proper hydraulic oil flow metering, follow the calibration procedure described by the manufacturer of the controller that is being used as each controller’s procedure is different.
  • Page 35 Service Instructions The three valves used in the hydraulic control assembly are screw-in cartridge type valves and are replaceable. Each valve must be installed with the correct tightening torque to ensure proper operation. If the valve is tightened above the specified torque value, the valve internals may be damaged causing the valve to stick. Before installing a new valve, inspect the valve to ensure all O-rings are seated in their appropriate grooves and have no damage, such as nicks or cuts.
  • Page 36 Limited Warranty on Hypro/Shurflo Agricultural Pumps & Accessories Hypro/Shurflo (hereafter, “Hypro”) agricultural products are warranted to be free of defects in material and workmanship under normal use for the time periods listed below, with proof of purchase. - Pumps: one (1) year from the date of manufacture, or one (1) year of use. This limited warranty will not exceed two (2) years, in any event.
  • Page 37 6 X 4 STANDARD COULTER MOUNT Fixture Item over Item To Hold 90° With Step FORWARD CENTER OVER HOLE IN ITEM 1/4" FILLET WELD Weld Areas Shown 1/4 x 2" Fillets & All Around Base of Tube RIGHT SIDE VIEW LOOKING UP FROM BOTTOM QUAN.
  • Page 38 6 X 4 OFFSET COULTER MOUNT ITEM NO. PART NUMBER DESCRIPTION QTY. KSC-466340-4M COULTER MOUNT PLATE, 4", 4" OFFSET KSC-466340-BMT BAR MTG TUBE KSC-466340-4GL KSC-466340-4G FORMED OFFSET GUSSET KSC-466340-4G1L KSC-466340-4G1 FORMED OFFSET GUSSET 2 " KSC-466340-4G2 OFFSET COULTER MOUNT GUSSET HEAVY NUT, 3/4-10 GR2 NUT, HEX JAM 106-B1...
  • Page 39 COULTER ASSEMBLY Item DESCRIPTION Part # KSC-466360-RP716 Spring Pin, 7/16 X 3 COULTER SHAFT KSC-466315 (20" & 24") KSC-466320 COULTER PIVOT ASSEMBLY KSC-466360-MB10 Machine Bushing 10 ga MF6H Washer, Flat, 3/4" High Strength 106-N1 HHCS,3/4" X 14" BOLT GR.5 KSC-466360-MB14 Machine Bushing, 14 ga KSC-466360-CP Cotter Pin, 1/4 X 2...
  • Page 40 LIQUID LA9000 APPLICATOR 1650 OR 1950 GALLON tank w/ 27’, 30’, 35’, 40’ or 55’ toolbar operation & maintenance manual BAKERSFIELD, CA COLUMBUS, NE DOTHAN, AL FARGO, ND GREENWOOD, MS 4618 SACO RD, 93308 5834 E 23RD ST, 68601 2401 FORRESTER RD, 36301...
