AG SPRAY LA5000 Operation & Maintenance Manual

Liquid applicator 1050 gallon tank w/ 27', 30', 35' or 40' toolbar
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
operation & maintenance manual
LA5000
1050 GALLON tank w/ 27', 30', 35' or 40' toolbar
BAKERSFIELD, CA
COLUMBUS, NE
661.391.9081
402.564.4544
HOPKINSVILLE, KY
MANKATO, MN
270.886.0296
507.388.6295
DOTHAN, AL
FARGO, ND
334.673.0580
701.280.2862
NEWTON, KS
OTHELLO, WA
316.283.4444
509.488.6631
MANUFACTURING
QUALITY PRODUCTS
FOR 30 YEARS
LIQUID
APPLICATOR
GREENWOOD, MS
662.453.4524
WWW.AGSPRAY.COM
TEMPE, AZ
480.705.8047
SHOP ONLINE @

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LA5000 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for AG SPRAY LA5000

Summary of Contents for AG SPRAY LA5000

  • Page 1 MANUFACTURING QUALITY PRODUCTS FOR 30 YEARS operation & maintenance manual LIQUID LA5000 APPLICATOR 1050 GALLON tank w/ 27’, 30’, 35’ or 40’ toolbar BAKERSFIELD, CA COLUMBUS, NE DOTHAN, AL FARGO, ND GREENWOOD, MS SHOP ONLINE @ 661.391.9081 402.564.4544 334.673.0580 701.280.2862 662.453.4524...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS INTRODUCTION PRE-OPERATION CHECKLIST PLACING IN STORAGE REMOVING FROM STORAGE LIMITED WARRANTY OPERATING INSTRUCTIONS BREAK-IN SERVICE AND MAINTENANCE GREASING 12-31 PART BREAKDOWNS L A 5 0 0 0 L I Q U I D A P P L I C A T O R O P E R A T I O N & M A I N T E N A N C E M A N U A L...

  • Page 3: Introduction

    INTRODUCTION 1. Read and understand the Operators Manual and all 7. Stay away from wing pinch points when folding or safety signs before using. extending wings. Keep others away. 2. Place all controls in neutral, stop tractor engine, turn 8. Stay away from power lines when extending or monitor off, set park brake, remove ignition key, wait folding wings.

  • Page 4: Placing In Storage

    PLACING IN STORAGE At the end of the spray season, the machine should be g. Remove nozzles from boom Disassemble and thoroughly inspected and prepared for storage. Repair or wash nozzle, Spring, diaphragm and housing. replace any worn or damaged components to prevent any Store inside.

  • Page 5: Limited Warranty

    Ag Spray Equipment delivery to the buyer, other than by Ag Spray Equipment or has authorized such expenses in advance. its authorize dealers or employees, and does not apply to...

  • Page 6: Operating Instructions

    OPERATING INSTRUCTIONS 6. Remove locking collars as needed to maintain a depth 1. Ensure applicator is connected securely to tractor draw bar of 4 to 5 inches. Constant down pressure on main lift is with clevis pin and safety chain (Figure 1). not recommended (weight of toolbar will keep unit in FIG.
  • Page 7 OPERATING INSTRUCTIONS c. Close and lock down the bypass adjusting screw in the hydraulic motor (if applicable). Switch rate controller to manual and press the “+” button on TeeJet or “Increase” button on Raven, hold for 8 seconds. Then press the “-” button on TeeJet or “Decrease” button on Raven for 4 seconds.
  • Page 8 440/450 Raven Controller With PWM Setup 1. Install Raven 440 or 450 control console and hook up to sprayer (see instructions inside controller box). 2. Turn on control console. When making selections/entering numbers, always be sure to press enter to save your settings. 3.
  • Page 9 2630 JD Rate Controller With PWM Setup 1. After hooking up all wiring between tractor and sprayer, turn the system on. 2. Make sure all nozzles are open with desired tips installed. 3. From the Menu, select Rate Controller 4. Setup your Implement type - Select Pull Behind Sprayer, enter a name and tank size.

  • Page 10: Break-In

    BREAK-IN B. After 5 hours and 10 hours of operation Although there are no operational restrictions on the applicator when used for the first time, it is recommended that the 1. Retorque all wheel bolts, fasteners and hardware. following mechanical items be checked: 2.
  • Page 11 GREASING 1. Wipe grease fitting with a clean cloth before greasing L/R GREASE LOCATIONS to prevent injecting dirt and grit into joint. 2. Replace and repair broken fittings immediately. Apply adequate grease to the following: 3. If a fitting will not take grease, remove and clean thoroughly.
  • Page 12 L A 5 0 0 0 L I Q U I D A P P L I C A T O R O P E R A T I O N & M A I N T E N A N C E M A N U A L...
  • Page 13 S H O P O N L I N E @ W W W . A G S P R A Y . C O M...
  • Page 14 27' SINGLE TUBE APPLICATOR - 5280890 EXPLODED STATE 24 20 11 1 DETAIL C SCALE 1 : 20 DETAIL A SCALE 1 : 20 DETAIL B SCALE 1 : 12 NOTE: THIS TOOLBAR IS COMPATIBLE WITH THE FOLLOWING APPLICATOR FRAMES: 5280827 5280879 L A 5 0 0 0 L I Q U I D A P P L I C A T O R O P E R A T I O N &...
  • Page 15 27' SINGLE TUBE APPLICATOR - 5280890 Item No Part Number Qty. Descrip on 5006365 12 1/2-13nc Hex Flanged Toplock Nut Gr. 8 5006366 8 3/8-16nc Hex Flanged Toplock Nut Gr. 8 5006367 8 5/16-18nc Hex Flanged Toplock Nut Gr. 8 5006386 20 Flng Head Lock Nut 1/4-20 5012015...
  • Page 16 30' SINGLE TUBE APPLICATOR - 5280891 EXPLODED STATE Item No Part Number Qty. Descrip on 5280887 1 ASSY, 20.5 IN EXTENSION FOR 7x7 TOOLBAR 5280887 1 ASSY, 20.5 IN EXTENSION FOR 7x7 TOOLBAR 5280890 1 27' SINGLE BAR, SINGLE FOLD TOOLBAR Item No Part Number Qty.
  • Page 17 40' SINGLE TUBE APPLICATOR - 5279129 EXPLODED STATE Item No Part Number Qty. Descrip on 5280801 1 37' SINGLE BAR, DOUBLE FOLD TOOLBAR 5280887 1 ASSY, 20.5 IN EXTENSION FOR 7x7 TOOLBAR 5280887 1 ASSY, 20.5 IN EXTENSION FOR 7x7 TOOLBAR Item No Part Number Qty.

  • Page 18: Detail Ascale 1

    37' SINGLE TUBE APPLICATOR - 5280801 EXPLODED STATE DETAIL E SCALE 1 : 25 DETAIL F SCALE 1 : 25 DETAIL D SCALE 1 : 18 DETAIL C SCALE 1 : 20 DETAIL B SCALE 1 : 18 DETAIL A SCALE 1 : 16 NOTE: THIS TOOLBAR IS COMPATIBLE WITH THE FOLLOWING APPLICATOR FRAMES:...
  • Page 19 37' SINGLE TUBE APPLICATOR - 5280801 Item No Part Number Qty. Descrip on 5006260 2 3/4"-10 Hex Jam Nut 5006365 12 1/2-13nc Hex Flanged Toplock Nut Gr. 8 5006366 14 3/8-16nc Hex Flanged Toplock Nut Gr. 8 5006367 12 5/16-18nc Hex Flanged Toplock Nut Gr. 8 5006386 28 Flng Head Lock Nut 1/4-20 5012015...
  • Page 20 5279145 - Small frame narrow single axle assembly Item Part Qty. Descrip on Number 5006359 3/4-10nc Hex Flanged Toplock Nut Gr. 8 5006363 1"-8nc Hex Flanged Toplock Nut Gr. 8 5034742 Flng HH Bolt 3/4-10 X 8" 5034750 Flng HH Bolt 1-8 X 3" 5085016 Hub Assembly (758) (8-Bolt) 5279368...
  • Page 21 5085016 - HUB ASSEMBLY RFM 60 P FLOWMETER REPLACEMENT PARTS 063-0171-793 S H O P O N L I N E @ W W W . A G S P R A Y . C O M...
  • Page 22 L A 5 0 0 0 L I Q U I D A P P L I C A T O R O P E R A T I O N & M A I N T E N A N C E M A N U A L...
  • Page 23 AA(B)126ML-3-*, AA(B)126ML-4-*, AA(B)126ML-F50-* LINE STRAINERS S H O P O N L I N E @ W W W . A G S P R A Y . C O M...
  • Page 24 damage prevention from abuse conditions. Technical Details Operating Pressure (max): Inlet: 3000 PSI (207 bar) Outlet: 3000 PSI (207 bar) Regulated Flow (max): 14 GPM (53 LPM) – Bypass Port Plugged (0 gpm Bypass) 15 GPM (57 LPM) - Bypass Port Open (15 gpm Max Bypass) Electrical: Voltage: 12 VDC Frequency: 110 Hz...
  • Page 25 Operation Instructions The hydraulic control assembly is designed to work with a digital controller with PWM signal output. As the signal current increases, the hydraulic flow control valve opens. To ensure proper hydraulic oil flow metering, follow the calibration procedure described by the manufacturer of the controller that is being used as each controller’s procedure is different.
  • Page 26 Service Instructions The three valves used in the hydraulic control assembly are screw-in cartridge type valves and are replaceable. Each valve must be installed with the correct tightening torque to ensure proper operation. If the valve is tightened above the specified torque value, the valve internals may be damaged causing the valve to stick. Before installing a new valve, inspect the valve to ensure all O-rings are seated in their appropriate grooves and have no damage, such as nicks or cuts.
  • Page 27 Limited Warranty on Hypro/Shurflo Agricultural Pumps & Accessories Hypro/Shurflo (hereafter, “Hypro”) agricultural products are warranted to be free of defects in material and workmanship under normal use for the time periods listed below, with proof of purchase. - Pumps: one (1) year from the date of manufacture, or one (1) year of use. This limited warranty will not exceed two (2) years, in any event.
  • Page 28 COULTER ASSEMBLY Item Part # DESCRIPTION KSC-466360-RP716 Spring Pin, 7/16 X 3 KSC-466315 (20" & 24") COULTER SHAFT KSC-466320 COULTER PIVOT ASSEMBLY KSC-466360-MB10 Machine Bushing 10 ga MF6H Washer, Flat, 3/4" High Strength 106-N1 HHCS,3/4" X 14" BOLT GR.5 KSC-466360-MB14 Machine Bushing, 14 ga KSC-466360-CP Cotter Pin, 1/4 X 2...
  • Page 29 COULTER HUB S H O P O N L I N E @ W W W . A G S P R A Y . C O M...
  • Page 30 7 X 7 STANDARD COULTER MOUNT ITEM# QTY. PART# DESCRIPTION KSC-466670C Casting 3/4 - 10 Jam Nut 106-B1 3/4 - 10 x 2 Square Head Set Screw KSC-466571-4R 4” Right Hand Off-set Mount KSC-466571-4L 4” Left Hand Off-set Mount L A 5 0 0 0 L I Q U I D A P P L I C A T O R O P E R A T I O N & M A I N T E N A N C E M A N U A L...
  • Page 31 7 X 7 OFFSET COULTER MOUNT ITEM NO. PART NUMBER DESCRIPTION QTY. KSC-466571-4MP COULTER MOUNT PLATE, 7", 4" OFFSET KSC-466340-BMT BAR MTG TUBE KSC-466571-4GL KSC-466571-4G FORMED OFFSET GUSSET KSC-466571-4G1L KSC-466571-4G1 FORMED OFFSET GUSSET KSC-466340-4G2 OFFSET COULTER MOUNT GUSSET NUT, HEX 3/4-10 GR 2 NUT, HEX JAM 106-B1 SET SCREW 3/4-10 X 2 SQ HEAD CUP PT...
  • Page 32 LA5000 LIQUID APPLICATOR 1050 GALLON tank w/ 27’, 30’, 35’ or 40’ toolbar operation & maintenance manual BAKERSFIELD, CA COLUMBUS, NE DOTHAN, AL FARGO, ND GREENWOOD, MS 4618 SACO RD, 93308 5834 E 23RD ST, 68601 2401 FORRESTER RD, 36301...
