- Page 1 ® OPERATION GUIDE 2.5-Gallon Battery Powered Electrostatic Backpack Sprayer...
- Page 2 WARNINGS ......................SAFETY ......................REGISTER YOUR SPRAYER ......................SPRAYER CAPABILITIES ......................WHAT’S IN THE BOX ......................Copyright ©WESSOL, LLC...
- Page 3 ASSEMBLY & SPRAYING ......................BATTERY CHARGING ......................PARTS & ACCESSORIES ......................TROUBLESHOOTING ......................WARRANTY POLICY ......................Copyright ©WESSOL, LLC...
- Page 4 This product contains chemicals, including lead, known to the state of California to cause birth defects and other reproductive harm. This product is designed to apply chemicals that may be harmful and could cause serious personal injury if inhaled or brought into contact with the user. Copyright ©WESSOL, LLC...
- Page 5 Always use common sense and be cautious when using the sprayer. It is not possible to anticipate every situation that could result in a dangerous outcome. Do not use this sprayer if you do not understand these operating instructions or if you feel the work is beyond your capability. Copyright ©WESSOL, LLC...
- Page 6 Do not dispose of Lithium-ion batteries with household waste; including respiratory masks, gloves, eye protection, etc. recycle where proper facilities exist. DO NOT RETURN SPRAYER TO STORE, if you experience problems or have questions contact our Customer Support Center, M-F 9am-5pm. Email: info@germsafe24.com or Call:800.581.5088 Copyright ©WESSOL, LLC...
- Page 7 Do not let familiarity gained from frequent use of the sprayer allow you to become complacent and ignore tool safety principles. A careless action can cause severe injury within a fraction of a second. PLEASE NOTE • To reduce static electricity buildup, consider wearing our Electrostatic Discharge (ESD) Grounded Foot Strap - XCAAKJ. See page 23. Copyright ©WESSOL, LLC...
- Page 8 Please read and follow this manual carefully to ensure that you get the most out of your new sprayer. If you need assistance with the assembly or operation of your sprayer, please don’t hesitate to contact us via the support methods below: germsafe24.com SPRAYING! info@GermSafe24.com 800.581.5088 Copyright ©WESSOL, LLC...
- Page 9 Coverage per Tank Up to 42,300 ft Tank Capacity 2.5 gallons Battery Cycle Life 1000 cycles Seals Viton™ Up to 6 hours Spray Time Pump Life 1000 hours * (Up to 4 hours on Turbo Boost™ Mode) Copyright ©WESSOL, LLC...
- Page 10 WHAT’S IN THE BOX Copyright ©WESSOL, LLC...
- Page 11 PART NUMBER: FZRABW 80-MICRON STAINLESS-STEEL MISTING NOZZLE PART NUMBER: XCAAKG COMFORTSTRAPS ™ PART NUMBER: XCAAKK 120-MICRON STAINLESS-STEEL MISTING NOZZLE PART NUMBER: XCAAKH ELECTROSTATIC CHARGE LINE & HOSE ASSEMBLY PART NUMBER: XCRAJH GUN HOLSTER KIT PART NUMBER: XCRALP Copyright ©WESSOL, LLC...
-
Page 12: Assembling Your Sprayer
Repeat on other side. Next, slide the adjustable strap through the top tank loop. Continue by sliding the strap over and under the buckle fitting. Lightly tug at the strap to make sure it’s secure. Repeat on other side. Copyright ©WESSOL, LLC... - Page 13 Place the gun holster (13) on the molded holster bracket on the tank. While holding the holster, place nut on one side of the hexagonal slots and screw the bolt through the other side until it fastens into the nut. Copyright ©WESSOL, LLC...
-
Page 14: Preparing To Spray
11) 40-Micron nozzle ~ 4min Dwell Time 12) 80-Micron nozzle ~ 5min Dwell Time 13) 120-Micron nozzle ~ 8min Dwell Time Place any unused nozzles and nozzle washer into the small accessory pouch until ready to spray. Copyright ©WESSOL, LLC... - Page 15 There are 3 spray distance capabilities. Close Spray - Turbo-Boost Mode Off ™ Medium Spray - Low Turbo-Boost Mode ™ Far Spray - High Turbo-Boost Mode ™ Begin spraying by squeezing the black spray trigger on the handle of the spray gun. Copyright ©WESSOL, LLC...
- Page 16 Disconnect the hose from the spray gun and let the hose hang down towards the ground in order to drain the hose of any liquid. Dry the sprayer tank and clear the nozzle of any buildup. Copyright ©WESSOL, LLC...
- Page 17 Proper sprayer maintenance is crucial to ensure the extended life and performance of your sprayer. Many spray materials can harden if left in the sprayer, causing clogs in the nozzle or hose. Gasoline should never be used to clean out your sprayer. Copyright ©WESSOL, LLC...
- Page 18 For long-term storage, regular charging of the battery is required to maximize battery life. Check the battery level using the indicator lights every 4 weeks. Recharge the battery if it falls below 3 bars. Do not allow the battery to fully discharge. Copyright ©WESSOL, LLC...
- Page 19 If after 2 hours during the charging process, none of the LEDs are lit, remove the battery pack from the charger to avoid damaging the product. DO NOT insert another battery. Contact Customer Support for instruction on replacing the battery. Email: info@germsafe24.com or Call:800.581.5088 M-F 9am-5pm. Copyright ©WESSOL, LLC...
-
Page 20: Replacement Parts
XCRALP Tank Strainer Gun Holster Kit XC RAGV XC R A J L Tank Lid 2.5-Gallon/10-Liter F ZA AEL F ZRAGL 21V/2.5Ah Battery Charger Pump Inlet Filter FZ A AEM XC AAKK 18V/5.2Ah Battery 2.5G ComfortStraps ™ Copyright ©WESSOL, LLC... - Page 21 XC RA J H XC RAJK Electrostatic Charge Line DC-to-DC XCR A J F XC AAKJ Pump ESD Grounded Foot Strap XC A A J G XC AAKG Nozzle Wrench 80-Micron Stainless-Steel XCA AKF XC AAKH 40-Micron Stainless-Steel 120-Micron Stainless-Steel Copyright ©WESSOL, LLC...
-
Page 22: Troubleshoot
Defective circuit board Purchase replacement part or contact Support for help. Loose connection Ensure spray gun is fully tightened onto threaded end of the hose. Leaks from gun/nozzle area Missing or worn gasket Contact Support to purchase replacement gaskets. Copyright ©WESSOL, LLC... - Page 23 Open the pump and clean. Contact Support for assistance. Loose hose-pump connection Open cover plate and identify the hose clamps. Use a flathead screwdriver to tighten. Leak from sprayer Damage on pump Replace the pump. tank Damage on tank Replace the sprayer tank. Copyright ©WESSOL, LLC...
-
Page 24: Warranty
® exclusions detailed below. At the discretion of WESSOL, LLC, we will repair or replace any parts found to be defective in material or workmanship without charge, apart from shipping and handling costs, during the covered warranty period. - Page 25 LIABILITY UNDER THIS WARRANTY FOR ANY AND ALL INCIDENTAL AND CONSEQUENTIAL LOSS OR DAMAGE. In no event shall WESSOL, LLC be liable for any incidental, special, consequential or punitive damages, or for any costs, attorney fees, expenses, losses or delays alleged to be as a consequence of any damage to, failure of, or defect in any product including, but not limited to, any claims for loss of profits.
- Page 26 ® germsafe24.com 800.581.5088 info@GermSafe24.com © WESSOL, LLC...
