- Page 1 OPERATION GUIDE LIL’ SQUIRT 1.3-Gallon 3.6V Battery Powered Sprayer Model #: SMSAAC...
- Page 2 Please make sure to remove the harmful and could cause serious personal injury if inhaled or parts before attempting to assemble or use the sprayer for brought into contact with the user the first time. Copyright © WESSOL, LLC...
- Page 3 The sprayer is susceptible to water damage if left in wet conditions. Always store it in a cool, dry place. Always use SprayMate™ original replacement parts. Do not leave the sprayer in reach of children or persons not qualified to handle it in a proper fashion. Copyright © WESSOL, LLC...
- Page 4 Please read and follow this manual carefully to ensure that you get the most out of your new sprayer. If you need assistance with the assembly or operation of your sprayer, please don’t hesitate to contact WESSOL via the support methods below: www.buyspraymate.com...
- Page 5 TABLE OF CONTENTS page 6-7 ABOUT specifications....................page 6 what’s in the box..................page 7 page 8-10 SET UP sprayer assembly..................page 8 spraying.......................page 9 aftercare......................page 10 page 11-15 TROUBLESHOOT common solutions..................page 11 replacement parts..................page 12 warranty.....................page 14 Copyright © WESSOL, LLC...
- Page 6 3.6V Pressure 45 psi Battery Capacity 2.6Ah Spray Distance 15 feet Battery Charging Time 2 hours Tank Capacity 1.3 gallons Battery Cycle Life 500 cycles Flow Rate 0.17 gal/min Battery Charger 3.6V/1Ah Pump Life 500 hours Copyright © WESSOL, LLC...
- Page 7 1. 1.3-Gallon Tank 2. 3.6V Spray Gun & Short Nozzle 3. Tank Cap & Hose WHAT’S IN 4. Holster 5. Battery Charger 6. Coiled Hose 7. Carrying Strap THE BOX? 8. 18-inch Extension Wand Copyright © WESSOL, LLC...
- Page 8 The spray gun and extension wand can be placed in Slide the holster (4) over the opening on the sprayer the holster when not in use. tank. Then, lower the tank cap (3) in place and twist to tighten. Copyright © WESSOL, LLC...
- Page 9 Insert the nozzle or attachment then push the fitting back into its original position. a) Short nozzle = adjustable conical ranging from jet stream to mist b) 18-Inch Extension wand = adjustable, ranging from jet stream to mist Copyright © WESSOL, LLC...
- Page 10 Proper sprayer maintenance is crucial to ensure the life and performance of your sprayer. Many spray materials can harden if left in the sprayer causing clogs in the nozzle or hose. Gasoline should never be used to clean out your sprayer. Copyright © WESSOL, LLC...
- Page 11 Visit buyspraymate.com to purchase a replacement. Dead battery. Damaged lithium cells Purchase a replacement spray gun at buyspraymate.com. Leaking from sprayer Loose hose connection Detach and re-attach the hose to the spray gun and tank cap. Copyright © WESSOL, LLC...
- Page 12 2. FZRABE 1. SMRACY 6-Foot Coiled Hose 3.6V/2.6A Spray Gun 6. FZRABS 5. FZRABU 4. FZRABJ 3. FZRADS 18-Inch Stainless Steel Tank Cap & Hose 3.6V/1A Charger Intake Filter Extension Wand Copyright © WESSOL, LLC...
- Page 13 Copyright © WESSOL, LLC...
- Page 14 The warranty period is not extended if we opt to repair or replace the product in question. WARRANTY CLAIMS WESSOL, LLC reserves the right to require the return of the defective product, proof of purchase, and established product registration to file a claim under this warranty.
- Page 15 DAMAGE. In no event shall WESSOL, LLC be liable for any incidental, special, consequential or punitive damages, or for any costs, attorney fees, expenses, losses or delays alleged to be as a consequence of any damage to, failure of, or defect in any product including, but not limited to, any claims for loss of profits.
- Page 16 +1 (803) 339-2500 support@wessol.com...
