REMOTE CONTROL SWITCH
Before using this equipment, read, understand and follow all instructions
in the Operator's Manuals provided with this equipment. If the user and/
or assistants cannot read or understand the warnings and instructions,
the employer of the user and/or assistants must provide adequate and necessary training to
ensure proper operation and compliance with all safety procedures pertaining to this equipment. If
Operator's Manuals have been lost, please visit www.marco.us, or contact Marco at 563.324.2519
for replacements. Failure to comply with the above warning could result in death or serious injury.
OPERATOR'S MANUAL
BLASTMASTER
156E
®
Advertisement
Table of Contents
Related Manuals for Marco BLASTMASTER 156E
Summary of Contents for Marco BLASTMASTER 156E
- Page 1 If Operator’s Manuals have been lost, please visit www.marco.us, or contact Marco at 563.324.2519 for replacements. Failure to comply with the above warning could result in death or serious injury.
-
Page 2: Company Profile
The Marco Difference • Industry Experience – With Marco on your team, you have access to expertise which can only come from decades of industry leadership. We have organized our engineering department, production specialists, customer operations, and safety support into a “Center of Competence.”... -
Page 3: Table Of Contents
TABLE OF CONTENTS Company Profile ......1 Troubleshooting ......14 Operating Instructions . - Page 4 HAZARD IDENTIFICATIONS Failure to comply with ANY WARNING listed below could result in death or serious injury. OSHA sets exposure limits to protect workers from exposure to respirable crystalline silica, 29 CFR 1910.1053. Airborne dust could increase the exposure levels beyond permissible limits. Breathing dust containing silica could cause silicosis, a fatal lung disease.
- Page 5 Use of Marco remote control switches with other manufacturer’s remote control systems could cause unintended activation of remote control systems resulting in the release of high speed abrasive and compressed air. Only Marco remote control switches should be used with Marco remote control systems.
- Page 6 HAZARD IDENTIFICATIONS Failure to comply with ANY CAUTION listed below may result in minor or moderate injury. Static electricity can be generated by abrasive moving through the abrasive blasting hose causing a shock hazard. Prior to use, ground the abrasive blasting pot and abrasive blasting nozzle to dissipate static electricity. High decibel noise levels are generated during the abrasive blasting process which may cause loss of hearing.
- Page 7 AIR & ABRASIVE CONSUMPTION CHART Failure to comply with ANY NOTICE listed below could pose a hazard to personnel or property. See Air & Abrasive Consumption Chart for estimated abrasive consumption rates and required air flow (cubic feet per minute). Your system must meet these minimum requirements to ensure proper function and performance.
- Page 8 “THE BIG PICTURE” Blastmaster 156E Remote Control Switch ®...
- Page 9 * Optional or alternative device. Abrasive Blasting Pot Exhaust Muffler – Inspect Abrasive Blasting Pot Ask your Marco Representative Exhaust Muffler (24) at start and end of daily use. Replace element of Abrasive Blasting Pot Exhaust Muffler (24) per Operator's Manual instructions.
-
Page 10: Operating Instructions
A remote control switch gives an operator the ability to remotely activate and deactivate the remote control system at the abrasive blasting nozzle. An electric remote control switch Use of Marco remote reduces the cycle time required to activate and deactivate the remote control system control switches with other manufacturer’s... -
Page 11: Installation
INSTALLATION Blastmaster 156E Remote Control Switch ® Pulling and dragging abrasive blasting hose may cause control line and power cord connections to separate. Connect the control line and power cord to the abrasive blasting hose every 4 to 6 feet and on each side of the control line connections. -
Page 12: Maintenance
MAINTENANCE Disassemble and Assemble Blastmaster 156E Remote Control Switch ® Maintenance of the Blastmaster 156E Remote Control Switch is limited to the daily ® cleaning and the immediate replacement of damaged or worn parts. Always depressurize the Note: Anytime a switch is being replaced, the cord supplied with switch should be replaced entire blasting system, disconnect all power and discarded. - Page 13 MAINTENANCE Disassemble and Assemble Blastmaster 156E Remote Control ® Switch (cont.) Blastmaster 156E Remote Control Switch ®...
-
Page 14: Disassemble And Assemble Blastmaster ® 156E Remote Control Switch - Kwikchange
MAINTENANCE Disassemble and Assemble Blastmaster 156E Remote Control ® Switch - Kwikchange Maintenance of the Blastmaster 156E Remote Control Switch is limited to the daily ® cleaning and the immediate replacement of damaged or worn parts. Always depressurize the entire blasting system, Disassemble: disconnect all power sources and lockout/... -
Page 15: Troubleshooting
TROUBLESHOOTING If the Blastmaster 156E Remote Control Switch does not function properly, check the ® following: Always depressurize the entire blasting system, SYMPTOM (Cause) ACTION disconnect all power sources and lockout/ tagout all components Control Switch operates in only Clean around Toggle boot. Remove any before any maintenance debris. -
Page 16: Assembly Part Numbers And Schematic 15 Blastmaster ® 156E Remote Control Switch
MAINTENANCE NOTES DATE TYPE OF SERVICE PART NUMBER Blastmaster 156E Remote Control Switch ®... - Page 17 MAINTENANCE NOTES DATE TYPE OF SERVICE PART NUMBER Blastmaster 156E Remote Control Switch ®...
- Page 18 MAINTENANCE NOTES DATE TYPE OF SERVICE PART NUMBER Blastmaster 156E Remote Control Switch ®...
-
Page 19: Limited Warranty
LIMITED WARRANTY ADDITIONAL TECHNICAL DATA Seller warrants to the original purchaser that the Product covered by this Limited Warranty will remain free from defects in workmanship or material under normal commercial use and service for a period of one year from the The associations listed date of shipment to the original Purchaser. - Page 20 SERVICE & REPAIR WWW.MARCO.US VACUUMS SALES@MARCO.US Marco and Blastmaster are registered trademarks of Marco Group International Opco. LLC. Part #1090139_6/20/2019 ® ® All other brand names or marks are used for identification purposes and are trademarks of their respective owners.
