Sharp NTT docomo SH-06E Instruction Manual page 13

While charging, the handset may not turn on even when the
charging lamp is illuminated in red. Charge longer and try turning
power on again.
Frequently recharging the battery when its power is still
remaining enough may shorten the usable life of the internal
battery. It is recommended to use the battery to a certain level
(e.g. after the battery level decreases) before recharging.
When the temperature of the handset is too high or too low,
charging may automatically stop even if the battery has not been
fully charged.
You may have difficulty in watching Mobacas, receiving its
contents, etc. while charging with the wireless charger. To watch
Mobacas, receive its contents, etc. while charging, use the AC
adapter. Also move the handset as far away as possible from the
power plug of the AC adapter.
Estimated battery life when fully charged
Continuous FOMA/3G
talk time Approx. 750 min
GSM
Approx. 810 min
Continuous FOMA/3G
stand-by time At rest: Approx. 530 hr (Network Mode: LTE/
3G/GSM (Auto))
GSM
At rest: Approx. 460 hr (Network Mode: LTE/
3G/GSM (Auto))
LTE
At rest: Approx. 460 hr (Network Mode: LTE/
3G/GSM (Auto))
Mobacas Approx. 340 min
watching time
1Seg watching Approx. 480 min
time
For details on the battery life nP. 87
Internal battery usable life
Internal battery is a consumable product. Service time per
charge is gradually reduced every time the battery is charged.
When service time per charge is reduced to about half of the
default time, this means that the internal battery is approaching
the end of its usable life. In this case, it is recommended to
replace the battery as soon as possible. For details on replacing
the internal battery, contact the number listed in "Repairs" (in
Japanese only) on the last page or a repair counter that
DOCOMO specifies.
If you watch 1Seg etc. while charging for a long time, the usable
life of the internal battery may become shorter than estimated.
AC adapter and DC adapter
Refer to user's guide of AC Adapter 03/04 (sold separately) or
DC Adapter 03 (sold separately).
AC Adapter 03/04 covers from 100 to 240V AC.
The shape of the plug for the AC adapter is for 100V AC (for
domestic use). To use the AC adapter of 100 to 240V AC
overseas, a conversion plug adapter applicable to your country
of stay is required. Do not use a voltage converter for overseas
travel to charge the battery.
Charging with AC adapter/DC adapter
[Read the user's guides of AC Adapter 03/04 (sold
separately) and DC Adapter 03 (sold separately)]
Following operations describe how to charge with AC Adapter 04
or DC Adapter 03.
1
Insert the microUSB plug of the AC adapter/DC
adapter horizontally into the external connector
terminal on the handset with the side marked
with "B" turned up
: Check the direction (front or rear) of the microUSB plug and
insert it horizontally.
microUSB plug
2
When you erect the AC adapter power plug and
insert it into an outlet or insert the DC adapter
power plug into a car cigarette lighter socket,
the charging lamp illuminates and charging
starts
Power plug
AC adapter
3
When charging is complete, the charging lamp
turns off
4
Remove the AC adapter power plug from the
outlet, or remove the DC adapter power plug
from the car cigarette lighter socket
5
Remove the microUSB plug of the AC adapter/
DC adapter horizontally from the external
connector terminal
14
Charging lamp
External connector
terminal
Keep side marked with "B" up
100V AC
outlet
Power plug
Cigarette
lighter socket
DC adapter
Before Using the Handset
