- Page 1 OWNER'S MANUAL IPS LED MONITOR (LED MONITOR * LG LED Monitors are LCD Monitors with LED Backlighting. Please read the safety information carefully before using the product. 34UC87 34UC87M 34UC87C www.lg.com...
-
Page 2: Table Of Contents
Table of ConTenTs Table of ConTenTs lICense UseR seTTInGs Activating the Main Menu - Main Menu Features asseMblInG anD PRePaRInG User Settings Product Composition - Menu Settings Product and Button Description - Ratio - How to Use the Joystick Button - Function - Input Connector - PBP... -
Page 3: License
Each model has different licenses. Visit www.lg.com for more information on the license. The terms HDMI and HDMI High-Definition Multimedia Interface, and the HDMI logo are trademarks or registered trademarks of HDMI Licensing LLC in the United States and other countries. -
Page 4: Assembling And Preparing
The product warranty will not cover damage or injury caused by the use of unauthorized components. Use the supplied components. If you use generic cables not certified by LG, the screen may not display or there may be image noise. noTe The components may look different from those illustrated here. -
Page 5: Product And Button Description
asseMblInG anD PRePaRInG Product and button Description Joystick button / Power leD on Power on off Power off How to Use the Joystick button You can easily control the functions of the monitor by pressing the joystick button or moving it left or right with your finger. -
Page 6: Input Connector
HDMI IN 1 HDMI IN 2 DP-IN USB UP USB IN 1 USB IN 2 1.1 A 1.1 A (19 V 34UC87M DC-IN HDMI IN 1 HDMI IN 2 DP-IN USB UP USB IN 1 USB IN 2 IR IN IR OUT 1.1 A... -
Page 7: Moving And Lifting The Monitor
asseMblInG anD PRePaRInG Moving and lifting the CaUTIon Monitor Avoid touching the monitor screen as much as possible. When moving or lifting the monitor, follow these - This may result in damage to the screen or instructions to prevent the monitor from being some of the pixels used to create images. -
Page 8: Installing The Monitor
asseMblInG anD PRePaRInG Installing the Monitor assembling the stand stand base CaUTIon Illustrations in this document represent typical CaUTIon procedures, so they may look different from the To protect the screen, place the screen face down actual product. on the screen pad which is inside the box. Applying excessive force when tightening screws may cause damage to the monitor. -
Page 9: Installing On A Table
asseMblInG anD PRePaRInG Installing on a Table Cautions When Connecting Power Cord Lift the monitor and place it on the table in an upright position. Place the monitor at least 10 cm (4 inches) away from the wall to ensure suf- ficient ventilation. -
Page 10: Adjusting The Angle
asseMblInG anD PRePaRInG adjusting the angle Handle the monitor with both hands for safety. Place the monitor mounted on the stand base in an upright position. Adjust the angle of the screen. The angle of the screen can be adjusted forward or backward from -5°... -
Page 11: Tidying Up Cables
asseMblInG anD PRePaRInG Tidying Up Cables Using the Kensington lock Arrange the cables using the cable holder as shown in The connector for the Kensington security system is the illustration. located at the bottom of the monitor. For more information on installation and usage, refer to the Kensington lock owner's manual or visit the website at http://www.kensington.com. -
Page 12: Installing On The Wall
If you use screws longer than the standard length, it may damage the inside of the product. A non-VESA standard screw may damage the product and cause the monitor to fall. LG Elec- tronics is not liable for any accidents relating to the use of non-standard screws. - Page 13 Installing the monitor on the ceiling or on a slanted wall may result in the monitor falling off, which could lead to injury. Use an authorized LG wall mount and contact the local dealer or qualified personnel.
-
Page 14: Using The Monitor
UsInG THe MonIToR UsInG THe MonIToR Connecting to a PC This monitor supports the *Plug and Play feature. The following instructions are based on the * Plug and Play: A feature that allows you to add a de- 34UC87 model. Illustrations in this manual may vice to your computer without having to reconfigure differ from the actual product. -
Page 15: Displayport Connection
Thunderbolt port. Connect your external device to below: the monitor using the Thunderbolt cable as illustrated below. 34UC87 34UC87M DP-IN (sold separately) DP OUT noTe There may be no video or audio output depend- ing upon the DP (DisplayPort) version of the PC. -
Page 16: Connecting Av Devices
UsInG THe MonIToR Connecting aV Devices Connecting Peripherals HDMI Connection Usb Cable connection - PC HDMI transmits digital video and audio signals from The USB port on the product functions as a USB hub. your AV device to the monitor. Connect your AV de- noTe vice to the monitor using the HDMI cable as shown in the illustration below. -
Page 17: Connecting Headphones
USB port may not work properly. Depending on the audio settings of the PC and external device, headphones and speaker func- 34UC87 34UC87M tions may be limited. HDMI IN 1 HDMI IN 2 USB UP USB IN 1 USB IN 2 1.1 A... -
Page 18: Ir Connection
UsInG THe MonIToR IR Connection Connect the IR sensor and stereo cable to the monitor (34UC87M) via the IR Port. Connect as illustrated. 34UC87M IR IN IR OUT (sold separately) (sold separately) IR IN 34UC87M noTe Make sure the power cable is disconnected. -
Page 19: User Settings
UseR seTTInGs UseR seTTInGs activating the Main Menu Press the joystick button on the bottom of the monitor. Move the joystick up or down (▲/▼) and left or right(◄/►) to set the options. Press the joystick button once more to exit the main menu. Joystick button button Menu status... -
Page 20: User Settings
Adjusts the Sharpness, Black Level, and Response Time of the screen. Color Adjusts Gamma, Color Temperature, Red, Green, Blue, and Six Color. settings Adjusts Language, Power LED, Automatic Standby, DisplayPort 1.2, OSD Lock, and Set ID (34UC87M model only). Reset Restores the default settings. ◄ exit Exits the OSD menu. -
Page 21: Ratio
UseR seTTInGs Ratio easy control > brightness To view the osD menu, press the joystick button at the bottom easy control > Contrast of the monitor and then enter the Menu. > Volume Go to easy control > Ratio by moving the joystick. function >... -
Page 22: Function
UseR seTTInGs function function > Maxxaudio To view the osD menu, press the joystick button at the bottom easy control > Reader Mode of the monitor and then enter the Menu. > Picture Mode Custom Go to function by moving the joystick. function >... - Page 23 SAVING is High or Low, monitor luminance becomes higher or lower depending upon the source. If option of SMART ENERGY SAVING is High or Low, Picture Mode will automatically be Custom, and Reader Mode will automatically be Reader Off. In the IR function, MaxxAudio is disabled when using the headphones. (34UC87M model only)
-
Page 24: Pbp
Description Displays the screens of two input modes on one monitor. sub screen (Right) Thunderbolt ( ) PbP Connection HDMI 1 HDMI 2 DisplayPort (34UC87, 34UC87M model only) HDMI 1 HDMI 2 Main screen DisplayPort (left) Thunderbolt ( ) (34UC87, 34UC87M... - Page 25 UseR seTTInGs Menu > PbP Description Ratio Adjusts the aspect ratio of the main screen or sub screen. Main Wide Displays the video to fit the PBP screen, regardless of the video signal input. original Displays the video in the aspect ratio of the video signal input on the PBP screen.
-
Page 26: Picture
UseR seTTInGs Picture Picture > sharpness To view the osD menu, press the joystick button at the bottom easy control > black level High of the monitor and then enter the Menu. > Response Time Middle Go to screen > Picture by moving the joystick. function Configure the options following the instructions that appear in the bottom right corner. -
Page 27: Color
UseR seTTInGs Color Color > Gamma Gamma 1 To view the osD menu, press the joystick button at the bottom easy control > Color Temp Custom of the monitor and then enter the Menu. > Go to screen > Color by moving the joystick. function >... -
Page 28: Settings
ID You can assign a unique Set ID No. (name assignment) to each product when several products are (34UC87M model connected for display. Specify the number (1 to 6) using the button and exit. Use the assigned Set ID to only) individually control each product using the Product Control Program. -
Page 29: Reset
UseR seTTInGs Reset Reset Do you want to reset your settings? To view the osD menu, press the joystick button at the easy control Reset bottom of the monitor and then enter the Menu. Cancel Go to Reset by moving the joystick. function Configure the options following the instructions that appear in the bottom right corner. -
Page 30: Troubleshooting
TRoUblesHooTInG TRoUblesHooTInG nothing is displayed on the screen. Is the monitor's power cord Check if the power cord is correctly plugged into the power outlet. plugged in? Is the power LED on? Check the power cable connection and press the power button. Is the power on and the power Check that the connected input is enabled (Menu - Input). - Page 31 TRoUblesHooTInG noTe Check if the video card's resolution or frequency is within the range allowed by the monitor and set it to the recommended (optimal) resolution in Control Panel > Display > settings. Not setting the video card to the recommended (optimal) resolution may result in blurred text, a dimmed screen, a truncated display area, or misalignment of the display.
-
Page 32: Product Specification
PRoDUCT sPeCIfICaTIon PRoDUCT sPeCIfICaTIon 34UC87 34UC87M LCD Screen Type TFT (Thin Film Transistor) LCD (Liquid Crystal Display) Screen Color Depth HDMI 8-bit color is supported. DP (DisplayPort) 10-bit color is supported. 8-bit color is supported. Thunderbolt ( ) Pixel Pitch 0.2325 mm x 0.2325 mm... - Page 33 PRoDUCT sPeCIfICaTIon 34UC87C LCD Screen Type TFT (Thin Film Transistor) LCD (Liquid Crystal Display) Screen Color Depth HDMI 8-bit color is supported. DP (DisplayPort) 10-bit color is supported. Pixel Pitch 0.2325 mm x 0.2325 mm Resolution HDMI Max Resolution 3440 x 1440 @ 50 Hz Recommended Resolution 3440 x 1440 @ 50 Hz DP (DisplayPort)
-
Page 34: Hdmi Timing (Video)
PRoDUCT sPeCIfICaTIon factory support Mode 34UC87 34UC87M (Preset Mode, HDMI/ DisplayPort/ Thunderbolt PC) 34UC87C (Preset Mode, HDMI/ DisplayPort PC) Horizontal frequency Preset Mode Vertical frequency (Hz) Polarity (H/V) Remarks (kHz) 640 x 480 31.469 59.94 800 x 600 37.879 60.317 1024 x 768 48.363... -
Page 35: Proper Posture
PRoPeR PosTURe PRoPeR PosTURe Proper Posture for Using the Monitor Adjust the screen so that you can comfortably look at it at a slight downward angle from your natural eye level. Take a break for approximately 10 minutes every hour to reduce any fatigue caused by prolonged usage. - Page 36 Declaration of Conformity Trade Name: LG Model: 34UC87, 34UC87M, 34UC87C Responsible Party: LG Electronics Inc. Address: 1000 Sylvan Ave. Englewood Cliffs NJ 07632 U.S.A TEL: 201-266-2534 This device meets the EMC requirements for ENERGY STAR is a set of power-saving home appliances (Class B) and is intended for guidelines issued by the U.S.Environmental...
