Summary of Contents for LG 34UC89G
- Page 1 OWNER’S MANUAL IPS LED Monitor (LED Monitor*) * LG LED Monitor applies LCD screen with LED backlights. Please read this manual carefully before operating your set and retain it for future reference. 34UC89G www.lg.com...
-
Page 2: Table Of Contents
TABLE OF CONTENTS LICENSE ........3 USING THE MONITOR ....20 TROUBLESHOOTING ....37 - Connecting to a PC...........20 ASSEMBLING AND PREPARING 4 PRODUCT SPECIFICATION ..40 HDMI Connection - Product Composition ..........4 - Factory Support Mode..........42 DisplayPort Connection - Supported Drivers and Software ......5 - G-SYNC Monitor ............42 - Connecting AV Devices ...........22 - Product and Button Description......6... -
Page 3: License
LICENSE Each model has different licenses. Visit www.lg.com for more information on the license. The terms HDMI and HDMI High-Definition Multimedia Interface, and the HDMI logo are trademarks or registered trademarks of HDMI Licensing LLC in the United States and other countries. -
Page 4: Assembling And Preparing
ASSEMBLING AND PREPARING Product Composition Please check whether all the components are included in the box before using the product. If there are any missing components, contact the retailer where you purchased the product. Note that the product and related components may look different from those shown here. CD (Owner’s Manual / Software / Power cord AC/DC Adapter... -
Page 5: Supported Drivers And Software
34UC89G • It is recommend that use the supplied components. Monitor Driver Recommended • If you use generic cables not certified by LG, the screen may not display or there ASM Driver Required may be image noises. Recommended NOTE Optional •... -
Page 6: Product And Button Description
Product and Button Description How to Use the Joystick Button You can easily control the functions of the monitor by pressing the joystick button or moving it left/right with your finger. Basic Functions Press the joystick button once with Power on your finger to turn on the monitor. -
Page 7: Input Connector
Input Connector... -
Page 8: Moving And Lifting The Monitor
Moving and Lifting the Monitor When moving or lifting the monitor, follow these instructions to prevent the monitor from being scratched or damaged and to ensure safe transportation, regardless of its shape or size. • Place the monitor in the original box or packing material before attempting to move it. - Page 9 • If you use the monitor panel without the stand base, its joystick button may cause the monitor to become unstable and fall, resulting in damage to the monitor or human injury. In addition, this may cause the joystick button to malfunction.
-
Page 10: Installing The Monitor
Installing the Monitor Assembling the Stand CAUTION • To protect the screen, place the screen face down on the screen pad which is inside the box. - Page 11 Cable Holder * Assemble the Cable Holder. Stand Body Stand Base...
-
Page 12: Installing On A Table
Installing on a Table NOTE Lift the monitor and place it on the table in an upright position. Place the • Press the stand until the button reaches the top. monitor at least 100 mm away from the wall to ensure sufficient ventilation. 100 mm 100 mm 100 mm... - Page 13 Connect the power adapter to the monitor and then plug the power cord into CAUTION the wall outlet. • Unplug the power cord before moving or installing the monitor. There is risk of electric shock. Cautions When Connecting Power Cord 100-240 V ~ Press the joystick button on the bottom of the monitor to turn on the monitor.
-
Page 14: Adjusting The Stand Height
Adjusting the Stand Height Adjusting the Angle Place the monitor mounted on the stand base in an upright position. Place the monitor mounted on the stand base in an upright position. Handle the monitor with both hands for safety. Adjust the angle of the screen. The angle of the screen can be adjusted forward or backward from -5°... - Page 15 NOTE WARNING • The left or right side of the monitor head can be slightly rotated up or down (up to • To avoid injury to the fingers when adjusting the screen, do not hold the lower part 3°). Adjust the horizontal level of the monitor head. of the monitor’s frame as illustrated below.
-
Page 16: Tidying Up Cables
Tidying up Cables Using the Kensington Lock Arrange the cables using the cable holder as shown in the illustration. The connector for the Kensington security system is located at the bottom of the monitor. For more information on installation and usage, refer to the Kensington lock owner’s Mouse Holder manual or visit the website at http://www.kensington.com. -
Page 17: Detaching The Stand Body
Detaching the Stand Body Installing the Wall Mount Plate This monitor meets the specifications for the wall mount plate or other compatible Place the monitor’s screen face down. To protect the screen from scratches, devices. cover the surface with a soft cloth. Remove the stand from the monitor by pressing the button on the bottom Place the screen face down. -
Page 18: Installing On The Wall
If you use screws longer than the standard length, it may damage the inside of bracket. the product. A non-VESA standard screw may damage the product and cause the monitor to fall. LG Electronics is not liable for any accidents relating to the use of non- standard screws. 100 mm Wall Mount (mm) - Page 19 • Installing the monitor on the ceiling or on a slanted wall may result in the monitor Monitor falling off, which could lead to injury. Use an authorized LG wall mount and contact the local dealer or qualified personnel. Screw •...
-
Page 20: Using The Monitor
This monitor supports the *Plug and Play feature. • The following instructions are based on the 34UC89G model. Illustrations in this * Plug and Play: A feature that allows you to add a device to your computer without manual may differ from the actual product. -
Page 21: Displayport Connection
DisplayPort Connection CAUTION Transmits digital video and audio signals from your PC to the monitor. Connect the • In HDMI input, only the RGB 4:4:4 Color Format is supported. YCbCr is not monitor to your PC using the DisplayPort cable as shown in the illustration below. supported. -
Page 22: Connecting Av Devices
Connecting AV Devices Connecting Peripherals HDMI Connection USB Cable connection HDMI transmits digital video and audio signals from your AV device to the monitor. The USB port on the product functions as a USB hub. Connect your AV device to the monitor using the HDMI cable as shown in the To use USB 3.0, connect the A-B type USB 3.0 cable of the product to the PC. -
Page 23: Connecting Headphones
Connecting Headphones NOTE Connect peripherals to the monitor via the headphones port. Connect as illustrated. • Make sure to install the most recent Windows OS service pack before using the product. • Peripheral devices are sold separately. (sold separately) • A keyboard, mouse, or USB device can be connected to the USB port. -
Page 24: Service Only Port
Service only port This port is used only for "Service"... -
Page 25: User Settings
USER SETTINGS Button Menu Status Description Main menu disabled Enables the main menu. Exits the main menu. Activating the Main Menu (Holding down the button to turn off the monitor. You can Main menu enabled turn off the monitor this way at any time, including when the Press the joystick button on the bottom of the OSD is on.) monitor. -
Page 26: Main Menu Features
Main Menu Features Main Menu Description Input Sets input mode. Power Off Power Off Turns off the monitor. Menu Configures the screen settings. Close Input Menu Game Mode Sets the game mode for gaming. Close Closes the main menu. Game Mode... -
Page 27: User Settings
User Settings Menu Settings To view the OSD menu, press the joystick button at the bottom of the monitor and then enter the Menu. Configure the options by moving the joystick up/down/left/right. To return to the upper menu or set other menu items, move the joystick to or pressing ( ) it. -
Page 28: Game Mode
Menu Description Game Mode Changes the game mode to the one optimized for a given feature. Game Adjust Adjusts the Overclock, Black Stabilizer, Response Time, Cross Hair and Game Reset. Picture Adjust Adjusts the Brightness/Contrast, Gamma, Color Temp, R/G/B and Picture Reset. Input Input List Selects the input mode. -
Page 29: Game Mode
Game Mode To view the OSD menu, press the joystick button at the bottom of the monitor and then enter the Menu. G-SYNC Overclock Black Stabilizer Response Time Go to Game Mode by moving the joystick. To return to the upper menu or set other menu items, move the joystick to Gamer 1 pressing ( ) it. -
Page 30: Game Adjust
Game Adjust To view the OSD menu, press the joystick button at the bottom of the monitor and then enter the Menu. G-SYNC Overclock Black Stabilizer Response Time Go to Game Adjust by moving the joystick. To return to the upper menu or set other menu items, move the joystick to Overclock pressing ( ) it. - Page 31 Menu > Game Adjust Description Sets Overclock to a higher refresh rate than specified by the panel specification. Disables the Overclock improvement feature. NOTE Overclock • After the monitor reboots, change the maximum refresh rate setting in the NVIDIA control panel. If the screen display appears abnormal, turn off the Overclock setting.
- Page 32 Sets a response time for displayed pictures based on the speed of the screen. For a normal environment, it is recommended that you use Normal. For a fast-moving picture, it is recommended that you use Fast. Setting to Fast may cause image sticking. Fast Sets the response time to fast.
-
Page 33: Picture Adjust
Picture Adjust To view the OSD menu, press the joystick button at the bottom of the monitor and then enter the Menu. G-SYNC Overclock Black Stabilizer Response Time Go to Picture Adjust by moving the joystick. To return to the upper menu or set other menu items, move the joystick to Brightness/Contrast pressing ( ) it. -
Page 34: Input
Input To view the OSD menu, press the joystick button at the bottom of the monitor and then enter the Menu. G-SYNC Overclock Black Stabilizer Response Time Go to Input by moving the joystick. To return to the upper menu or set other menu items, move the joystick to Input List pressing ( ) it. -
Page 35: General
General To view the OSD menu, press the joystick button at the bottom of the monitor and then enter the Menu. G-SYNC Overclock Black Stabilizer Response Time Go to General by moving the joystick. To return to the upper menu or set other menu items, move the joystick to Language pressing ( ) it. - Page 36 Menu > General Description Language Sets the menu screen to the desired language. Turns the power LED on the bottom of the monitor on or off. Power LED The power LED turns on automatically. The power LED turns off. Automatic Feature that automatically turns off the monitor when there is no movement on the screen for a period of time.
-
Page 37: Troubleshooting
• Be sure to install the display driver from the display driver CD (or diskette) that comes with your display. Or, you can also download the driver from our web site: http://www.lg.com. • Make sure to check if the graphics card supports Plug and Play function. - Page 38 The screen retains an image. Does image sticking occur even when the • Displaying a still image for a prolonged time may cause damage to the screen, resulting in the retention of the image. monitor is turned off? • To extend the lifetime of the monitor, use a screensaver. Screen display is unstable and shaky.
- Page 39 The display color is abnormal. Does the display appear discolored • Set the color to 24 bit (true color) or higher. In Windows, go to Control Panel > Display > Settings > Color Quality. (The (16 colors)? settings may differ depending on the operating system (OS) you use.) Does the display color appear unstable or •...
-
Page 40: Product Specification
PRODUCT SPECIFICATION LCD Screen Type TFT (Thin Film Transistor) LCD (Liquid Crystal Display) Screen Color Depth HDMI 8-bit color is supported. DP (DisplayPort) 8-bit color is supported. Pixel Pitch 0.312 mm x 0.310 mm Resolution Max Resolution 2560 x 1080 @ 60 Hz (HDMI) 2560 x 1080 @ 144 Hz (DP) 2560 x 1080 @ 166 Hz (DP Overclock function: On)** Recommended Resolution... - Page 41 AC/DC Adapter ADS-110CL-19-3 190110G, manufactured by Honor Output: 19 V 5.79 A Environmental Conditions Operating Conditions Temperature 0 °C to 40 °C Humidity Less than 80 % Storing Conditions Temperature -20 °C to 60 °C Humidity Less than 85 % Dimensions Monitor Size (Width x Height x Depth) With Stand...
-
Page 42: Factory Support Mode
Factory Support Mode (Preset Mode, HDMI/ DisplayPort PC) Preset Mode Horizontal Frequency (kHz) Vertical Frequency (Hz) Polarity (H/V) Remarks 640 x 480 31.469 59.94 HDMI/ DisplayPort 800 x 600 37.879 60.317 HDMI/ DisplayPort 1024 x 768 48.363 60.0 HDMI/ DisplayPort 2560 x 1080 66.64 59.98... -
Page 43: Power Led
Power LED Mode LED Color On Mode White (For a few seconds) Sleep Mode Off Mode... - Page 44 This device can be used in all regions. Read the owner's manual (CD) carefully and keep it at hand. Please note that the label attached to the product provides information for technical support. Model Serial No.
